Lexus ES300 2001 Owner's Manuals (in English)

BODY
484

Dirt or sand adhered to the leather may damage
the treated surface and cause it to wear earlier.Remove dirt or sand using a vacuum cleaner.

If a stain should fail to come out with a neutraldetergent, apply a cleaner that does notcontain an organic solvent.

Never use organic substances such asbenzine, alcohol or gasoline, or alkaline or acid
solutions for cleaning the leather as these could cause discoloring.

Use of a nylon brush or synthetic fiber cloth,etc. may scratch the fine grained surface of the
leather.

Mildew may develop on soiled leather upholstery. Be especially careful to avoid oil
spots. Try to keep your upholstery alwaysclean.

Long exposure to direct sunlight may causethe leather surface to harden and shrink. Keepyour vehicle in a shaded area, especially in thesummer.

The interior of your vehicle is apt to heat up onhot summer days, so avoid placing on theupholstery items made of vinyl or plastic orcontaining wax as these tend to stick to leather
when warm.

Improper cleaning of the leather upholstery could result in discoloration or staining.
Synthetic Leather Areas (Dash)
The synthetic leather areas may be easily cleaned
with a mild soap or detergent and water.
First vacuum over the upholstery to remove loose dirt.
Then, using a sponge or soft cloth, apply the soap
solution to the synthetic leather. After allowing it to soak
in for a few minutes to loosen the dirt, remove the dirt and
wipe off the soap with a clean damp cloth. If all the dirt
does not come off, repeat the procedure. Commercial
foaming±type cleaners are also available which work
well. Follow the manufacturer's instructions.
NOTICE
Do not use solvent, thinner, gasoline or windowcleaner on the interior.
Carpets, Windows and Seat Belts
Begin by vacuuming thoroughly to remove as much dirt
as possible. Several types of foam cleaners are
available; some are in aerosol cans and others are
powders or liquids which you mix with water to produce
a foam. To shampoo the carpets, use a sponge or brush
to apply the foam. Rub in overlapping circles. Do not
apply water ± the best results are obtained by keeping
the carpet as dry as possible. Read the shampoo
instructions and follow them closely.
The seat belts may be cleaned with mild soap and

BODY
485
water or with lukewarm water.
Use a cloth or sponge. As you are cleaning, check the
belts for excessive wear, fraying or cuts.
NOTICE

Use a good foam±type shampoo to clean the
carpets.

Do not use dye or bleach on the belts ± it mayweaken them.

Do not use the belts until they become dry.

The windows may be cleaned with anyhousehold window cleaner.

When cleaning the inside of the rear window, be
careful not to scratch or damage the heater
wires or connectors.
Air Conditioning Control Panel, Car
Audio, Instrument Panel, Console Panel,
and Switches
Use a soft damp cloth for cleaning.
Soak a clean soft cloth in water or lukewarm water then
lightly wipe off any dirt.
NOTICE

Do not use organic substances (solvents,kerosene, alcohol, gasoline, etc.) or alkaline oracidic solutions. These chemicals can causediscoloring, staining or peeling of the surface.

If you use cleaners or polishing agents, makesure their ingredients do not include thesubstances mentioned above.

If you use a liquid car freshener, do not spill theliquid onto the vehicle's interior surfaces. Itmay contain the ingredients mentioned above.Immediately clean any spill using the method
mentioned above.
If you have any questions about the cleaning of your
Lexus, your local Lexus dealer will be pleased to
answer them.

SECTION 7
486
REPORTING SAFETY DEFECTS
FOR U.S. OWNERS
Reporting safety defects for U.S. owners486
. . . . . . . . .
REPORTING SAFETY DEFECTS
FOR U.S. OWNERS
If you believe that your vehicle has a defect
which could cause a crash or could cause
injury or dea th, you should immediately inform
the National Highway Traffic Safety
Administration (NHTSA) in addition to
notifying Toyota Motor Sales, U.S.A., Inc.
(Toll±free: 1±800±25±LEXUS).
If NHTSA receives similar complaints, it may
open an investigation, and if it finds that a
safety defect exists in a group of vehicles, it
may order a recall and remedy campaign.
However, NHTSA cannot become involved in
individual problems between you, your dealer,
or Toyota Motor Sales, U.S.A., Inc.
To contact NHTSA, you may either call the
Auto Safety Hotline toll±free at 1±800±424±9393 (or 366±0123 in
Washington, D.C. area) or write to: NHTSA,
U.S. Department of Transportation,
Washington,
D.C. 20590. You can also obtain
other information about motor vehicle safety
from the Hotline.

GAS STATION INFORMATION

Fuel selection:
Select Octane Rating 87 (Research Octane Number 91) or
higher. For improved vehicle performance, the use of
premium unleaded gasoline with an Octane Rating 91
(Research Octane Number 96) or higher is recommended.

Fuel tank capacity:
70 L (18.5 gal., 15.4 lmp. gal.)

Engine oil:
API SJ, ªEnergy±Conservingº multigrade engine oil or
ILSAC multigrade engine oil.
Recommended oil viscosity ± SAE 5W±30 if normal
temperatures are below 38 C (100F)
Oil capacity: L (qt., lmp. qt.)
Drain and refill with filter 4.7 (5.0, 4.1)
without filter 4.5 (4.8, 4.0)
See page 410 for detailed information.

Engine coolant:
Capacity: 8.8 L (9.3 qt., 7.7 lmp. qt.)
Coolant type ± ªToyota Long Life Coolantº or equivalent
With ethylene±glycol type coolant for a proper corrosion
protection of aluminum components
Do not use alcohol type antifreeze or plain water alone.
For checking the engine coolant, see page 415 .

Automatic transaxle:
Fluid type ± Automatic transmission fluid Type T±IV
See page 421 for detailed information.

Tire information:
See pages 431 through 440 for detailed information.

Tire pressure:
Tire size: P205/65R15 92V or P205/60R16 91V
cold tires
kPa (kgf/cm
2 or bar, psi)
Vehicle loaded up
Vehicle load up to vehicle capacity
to 4 occupants weight
Front tires 180 (1.8, 26) 220 (2.2, 32) . . . . . . . . . . . .
Rear tires 180 (1.8, 26) 220 (2.2, 32) . . . . . . . . . . .
When driving under the above vehicle load conditions at
sustained high speeds above 160 km/h (100 mph), in countries
where such speeds are permitted by law, inflate the front and
rear tires 220 kPa (2.2 kgf/cm
2 or bar, 32 psi), but never exceed
the maximum cold tire pressure molded on the tire sidewall.
