FOREWORD
i
Welcome to the growing group of value±conscious people who drive Lexus\
vehicles. We
are proud of the advanced engineering and quality construction of each v\
ehicle we build.
This
Owner's Manual explains the features of your new Lexus. Please read it and follow the
instructions carefully so that you can enjoy many years of safe motoring\
.
When it comes to service, remember that your Lexus dealer knows your veh\
icle best and
is interested in your complete satisfaction. Your Lexus dealer will provide quality
maintenance and any other assistance you may require.
If there is not a Lexus dealer near you, or you need emergency assistance \
for any reason,
please call the following number:
U.S. OWNERS
When traveling in the U.S. mainland or Canada:
Lexus Roadside Assistance 1±800±25±LEXUS (Toll±Free)
(1±800±255±3987)
HAWAII:
Lexus Customer Service Assistance 1±800±25±LEXUS (Toll±Free)
(1±800±255±3987)
CANADIAN OWNERS
Please refer to the ªOwner's Guideº or ªOwner's Manual Supplementº.
Please leave this Owner's Manual in this vehicle at the time of resale. The next owner
will need this information also.
All information and specifications in this manual are current at the tim\
e of printing.
However, because of the Lexus policy of continual product improvement, we reserve\
the right to make changes at any time without notice.
Please note that this manual applies to all models and explains all equipment,
including options. Therefore, you may find some explanations for equipm\
ent not
installed on your vehicle.
Page 2 of 504
INTRODUCTION
ii
New vehicle warranty
Your new vehicle is covered by the following Lexus limited
warranties:
New vehicle warranty
Emission control systems warranty
Others
For further information, please refer to the ªOwner's Guideº,
ªOwner's Manual Supplementº or ªWarranty Bookletº.
Your responsibility for maintenance
It is the owner's responsibility to make sure the specified
maintenance is performed. Section 5 of this Owner's Manual
gives details of these maintenance requirements. Included in
Section 6 is general maintenance. For scheduled
maintenance information, pl ease refer to the ªOwner's Manual
Supplement/Maintenance Scheduleº.
Accessories, spare parts and modification of
your Lexus
A wide variety of non±genuine spare parts and accessories for
Lexus vehicles are currently available in the market. You
should know that Toyota does not warrant these products and
is not responsible for their performance, repair, or
replacement, or for any damage they may cause to, or adverse
effect they may have on, your Lexus vehicle. This vehicle should not be modified with non±genuine Lexus
products. Modification with non±genuine Lexus products
could af
fect its performance, safety or durability, and may even
violate governmental regulations. In addition, damage or
performance problems re sulting from the modification may not
be covered under warranty.
Spark ignition system of your Lexus
The spark ignition system in your Lexus meets all
requirements of the Canadian Interference±Causing
Equipment Standard.
Installation of a mobile two±way radio system
As the installation of a mobile two±way radio system in your
vehicle could affect electronic systems such as the multiport
fuel injection system/sequential multiport fuel injection system,
cruise control system, anti±lock brake system, SRS airbag
system and seat belt pretensioner system, be sure to check
with your Lexus dealer for precautionary measures or special
instructions regarding installation.
Scrapping of your Lexus
The SRS airbag and seat belt pretensioner devices in your
Lexus contain explosive chemicals. If the vehicle is scrapped
with the airbags and seat belt pretensioners left as they are,
this may cause an accident such as fire. Be sure to have the
systems of the SRS airbag and seat belt pretensioner removed
and disposed of by a qualified service shop or by your Lexus
dealer before you scrap your vehicle.
Page 3 of 504
HOW TO USE THIS MANUAL
iii
HOW TO USE THIS MANUAL
The contents of this manual are explained briefly on this
page to help you make the best use of the manual. Please
read this page and the rest of the Owner's Manual
carefully to make sure you fully understand the operation
of your vehicle.
This will help you enjoy safe and comfortable driving.
TABLE OF CONTENTS
The table of contents and the pictorial index provide easy
reference to the appropriate pages.
BASIC OPERATION ± QUICK REFERENCE
Operation of basic equipment is briefly explained in an easily
understandable way for quick reference.
SECTION 1 ± INSTRUMENTS AND CONTROLS
The vehicle's equipment is divided into the 7 groups listed
below. Use of the equipment is explained, including any points
you should pay particular attention to.
1. Keys and doors
2. Switches
3. Gauges, meters and service reminder indicators
4. Interior equipment
5. Exterior equipment
6. Comfort adjustment
7. Theft deterrent
SECTION 2 ± AIR CONDITIONING AND AUDIO
The features of the vehicle's air conditioning and audio are
explained in detail. Be sure to read this section so that you can
make full use of them.
SECTION 3 ± STARTING AND DRIVING
Starting the engine, driving, stopping, operation of features
affecting vehicle handling, hints on vehicle safety and safe
driving techniques are all explained. Please read everything
in this section, and remember ± drive safely!
SECTION 4 ± IN CASE OF AN EMERGENCY
This section explains what to do in the event of an urgent
situation such as the engine not starting or getting a flat tire,
etc. If such a problem occurs, check the contents of this
Owner's Manual and follow the instructions given.
SECTION 5 ± MAINTENANCE
This section explains the importance of regular maintenance.
Regular and periodic inspection and maintenance of your
Lexus will help to keep your vehicle in its best condition.
SECTION 6 ± SERVICE PROCEDURES AND
SPECIFICATIONS
Simple maintenance procedure and service data are provided
here for your reference should you wish to perform inspection
and maintenance yourself.
Page 4 of 504
HOW TO USE THIS MANUAL
iv
INDEX
The page number is listed for each item in the Owner's Manual
so that you can rapidly find the item and page you are
searching for.
GAS STATION INFORMATION
The information you need to know for appropriate servicing at
the gas station is provided here.
QUICK INDEX
This is designed so that you can quickly find the needed
information when an urgent situation arises.
Safety symbol
In this manual, you will also see a circle with a slash through
it. This means ªDo notº, ªDo not do thisº, or ªDo not le\
t this
happenº.
Safety and vehicle damage warnings
In this manual you will see CAUTION and NOTICE warnings.
These are used in the following ways:
CAUTION
This is a warning against something which may cause
injury to people if the warning is ignored. You are
informed what you must or must not do in order to avoid
or reduce the risk to yourself and other people.
NOTICE
This is a warning against something which may cause damage to the vehicle or its equipment if the warning isignored. You are informed what you must or must notdo in order to avoid or reduce the risk of damage to yourLexus and its equipment.
Your Lexus Owner's Manual provides you with a
considerable amount of information. To use this
information most effectively, please take the time to
familiarize yourself with the contents and use of the
manual.
Page 5 of 504
PICTORIAL INDEX
v
INSTRUMENT PANEL
PE038
Page 6 of 504
For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
vi
Page
1 Door lock switch and power windowswitches 28, 42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Power rear view mirror control switches 132 . . . . . .
3 Side vents 232
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Instrument panel light control 69
. . . . . . . . . . . . . . . . .
5 Headlight, turn signal and fog light switch 31 . . . . .
6 Wiper and washer switch 36
. . . . . . . . . . . . . . . . . . . . .
7 Ignition switch 279
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 Emergency flasher switch 48
. . . . . . . . . . . . . . . . . . . .
9 Clock 81
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
10 Car audio 238
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11 Security indicator light 12, 211
. . . . . . . . . . . . . . . . . . .
12 Automatic air conditioning controls 217
. . . . . . . . . .
13 Glove box/CD automatic changer 85/256
. . . . . . . . . . Page
14 Automatic transmission selector lever 284
. . . . . . . .
15 Ashtray 81
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
16 Electronic modulated suspension
control switch 301 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17 Seat heater switches 49
. . . . . . . . . . . . . . . . . . . . . . . . .
18 Vehicle skid control system off switch
or Traction control system off switch 301, 305 . . . . .
19 Cruise control switch 297
. . . . . . . . . . . . . . . . . . . . . . .
20 Trunk lid opener 105
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
21 Fuel filler door opener 108
. . . . . . . . . . . . . . . . . . . . . . .
22 Parking brake 281
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
23 Hood lock release lever 102
. . . . . . . . . . . . . . . . . . . . .
24 Auxiliary box 96
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 7 of 504
PICTORIAL INDEX
vii
INSTRUMENT CLUSTER (Vehicles sold in U. S. A.) (Type A)
PE022
Page 8 of 504
For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
viii
Page
1 Engine coolant temperature gauge56
. . . . . . . . . . . .
2 Tachometer 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Automatic headlight leveling system
warning light 67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Overdrive off indicator light 286
. . . . . . . . . . . . . . . . . .
5 Turn signal indicator light 36
. . . . . . . . . . . . . . . . . . . .
6 Automatic transmission indicator lights 284 . . . . . .
7 Odometer and trip meter 58
. . . . . . . . . . . . . . . . . . . . .
8 ªODO/TRIPº knob 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
9 Fuel gauge 54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10 Low fuel level warning light 67
. . . . . . . . . . . . . . . . . . .
11 Low washer fluid warning light 67
. . . . . . . . . . . . . . . .
12 SRS warning light 63
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
13 Anti±lock brake system warning light 65
. . . . . . . . . . Page
14 Vehicle skid control system off
indicator light 65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
15 Malfunction indicator lamp 64
. . . . . . . . . . . . . . . . . . .
16 Low engine oil level warning light 64
. . . . . . . . . . . . .
17 Open door warning light 65
. . . . . . . . . . . . . . . . . . . . . .
18 Headlight high beam indicator light 35
. . . . . . . . . . .
19 Headlight indicator light 31
. . . . . . . . . . . . . . . . . . . . . .
20 Slip indicator light 301, 304
. . . . . . . . . . . . . . . . . . . . . .
21 Low oil pressure warning light 64
. . . . . . . . . . . . . . . .
22 Discharge warning light 63
. . . . . . . . . . . . . . . . . . . . . .
23 Brake system warning light 62
. . . . . . . . . . . . . . . . . . .
24 Seat belt reminder light 63
. . . . . . . . . . . . . . . . . . . . . . .
25 Rear light failure warning light 65
. . . . . . . . . . . . . . . .
26 Cruise control indicator light 297
. . . . . . . . . . . . . . . .
27 Vehicle skid control system warning light 65 . . . . . .
Page 9 of 504
PICTORIAL INDEX
ix
INSTRUMENT CLUSTER (Vehicles sold in Canada) (Type A)
PE023
Page 10 of 504
For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
x
Page
1 Engine coolant temperature gauge56
. . . . . . . . . . . .
2 Tachometer 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Automatic headlight leveling system
warning light 67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Overdrive off indicator light 286
. . . . . . . . . . . . . . . . . .
5 Turn signal indicator light 36
. . . . . . . . . . . . . . . . . . . .
6 Automatic transmission indicator lights 284 . . . . . .
7 Odometer and trip meter 58
. . . . . . . . . . . . . . . . . . . . .
8 ªODO/TRIPº knob 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
9 Fuel gauge 54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10 Low fuel level warning light 67
. . . . . . . . . . . . . . . . . . .
11 Low washer fluid warning light 67
. . . . . . . . . . . . . . . .
12 SRS warning light 63
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
13 Anti±lock brake system warning light 65
. . . . . . . . . . Page
14 Vehicle skid control system off
indicator light 65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
15 Malfunction indicator lamp 64
. . . . . . . . . . . . . . . . . . .
16 Low engine oil level warning light 64
. . . . . . . . . . . . .
17 Open door warning light 65
. . . . . . . . . . . . . . . . . . . . . .
18 Headlight high beam indicator light 35
. . . . . . . . . . .
19 Tail light indicator light 31
. . . . . . . . . . . . . . . . . . . . . . .
20 Slip indicator light 301, 304
. . . . . . . . . . . . . . . . . . . . . .
21 Low oil pressure warning light 64
. . . . . . . . . . . . . . . .
22 Discharge warning light 63
. . . . . . . . . . . . . . . . . . . . . .
23 Brake system warning light 62
. . . . . . . . . . . . . . . . . . .
24 Seat belt reminder light 63
. . . . . . . . . . . . . . . . . . . . . . .
25 Rear light failure warning light 65
. . . . . . . . . . . . . . . .
26 Cruise control indicator light 297
. . . . . . . . . . . . . . . .
27 Vehicle skid control system warning light 65 . . . . . .
