fuel tank capacity Lexus ES300 2002 Owner's Manuals (in English)

GAUGES, METERS AND SERVICE REMINDER INDICATORS
46
FUEL GAUGE
Low fuel level warning light
The gauge is displayed when the ignition switch is on and
indicates the approximate quantity of fuel remaining in the
tank.
It is a good idea to keep the tank over 1/4 full.
If the fuel level approaches “E” or the low fuel level warning light\
comes on, fill the fuel tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the fuel gauge needle may fluctuate or the low fuel level
warning light may come on earlier than usual.
If the fuel tank is completely empty, the malfunction indicator
lamp comes on. Fill the fuel tank immediately.
The indicator lamp goes off after driving several times. If the
indicator lamp does not go off, contact your Lexus dealer as
soon as possible. See the inner back cover for fuel capacity and recommended
fuel selection.
ENGINE COOLANT
TEMPERATURE GAUGE
Normal range
The gauge indicates the engine coolant temperature when
the ignition switch is on. The engine operating
temperature will vary with changes in weather and engine
load.
If the needle points to the red zone or higher, stop your vehicle
and allow the engine to cool.

ENGINE
301
Cleaner burning gasoline
Cleaner burning gasoline, including reformulated
gasoline that contains oxygenates such as ethanol or
MTBE is available in many areas.
Lexus recommends the use of cleaner burning gasoline and
appropriately blended reformulated gasoline. These types of
gasoline provide excellent vehicle performance, reduce
vehicle emissions, and improve air quality.
Oxygenates in gasoline
Lexus allows the use of oxygenate blended gasoline
where the oxygenate content is up to 10% ethanol or 15%
MTBE. If you use gasohol in your Lexus, be sure that it has
an octane rating no lower than 87.
Lexus does not recommend the use of gasoline containing
methanol.
Gasoline containing MMT
Some gasoline contain an octane enhancing additive
called MMT (Methylcyclopentadienyl Manganese
Tricarbonyl).
Lexus does not recommend the use of gasoline that contains
MMT. If fuel containing MMT is used, your emission control
system may be adversely affected. The Malfunction Indicator
Lamp on the instrument cluster may come on. If this happens,
contact your Lexus dealer for service.
Gasoline quality
In a very few cases, you may experience driveability problems
caused by the particular gasoline that you are using. If you
continue to have unacceptable driveability, try changing
gasoline brands. If this does not rectify your problem, then
consult your Lexus dealer.
NOTICE
 Do not use gasohol other than stated above. It will
cause fuel system damage or vehicle performance
problems.
 If drivability problems are encountered (poor hot
starting, vaporizing, engine knock, etc.), discontinue
its use.
 Take care not to spill gasohol during refueling.
Gasohol may cause paint damage.
Fuel tank capacity
70 L (18.5 gal., 15.4 lmp. gal.)

BODY
342
SPECIFICATIONS
DIMENSIONS AND WEIGHTOverall length
Overall width
Overall height
Wheelbase
Tread Front Rear
Vehicle capacity weight (occupants + luggage)
4855 mm (191.1 in.)
1810 mm (71.3 in.)
1455 mm (57.3 in.)*
2720 mm (107.1 in.)
1545 mm (60.8 in.)
1535 mm (60.4 in.)
410 kg (900 lb.)
*: Unladen vehicle
FUEL TANK
Capacity
70 L (18.5 gal., 15.4 lmp. gal.)

GAS STATION INFORMATION
Fuel selection:
Select premium unleaded gasoline with an Octane Rating
of 91 (Research Octane Number 96) or higher for optimum
engine performance. However, if such premium type
cannot be obtained, you may temporarily use unleaded
gasoline with an Octane Rating as low as 87 (Research
Octane Number 91).
 Fuel tank capacity:
70 L (18.5 gal., 15.4 lmp. gal.)
 Engine oil:
API grade SJ “EnergyConserving”, SL
“EnergyConserving” or ILSAC multigrade engine oil
Recommended oil viscosity SAE 5W30 if normal
temperatures are below 38 C (100 F)
Oil capacity: L (qt., lmp. qt.)
Drain and refill With filter 4.7 (5.0, 4.1)
Without filter 4.5 (4.8, 4.0)
See page 304 for detailed information.
Engine coolant:
Capacity: 9.2 L (9.7 qt., 8.2 lmp. qt.)
Coolant type “Toyota Long Life Coolant” or equivalent
With ethyleneglycol type coolant for a proper corrosion
protection of aluminum components
Do not use alcohol type antifreeze or plain water alone.
For checking the engine coolant, see page 306 .
 Automatic transaxle:
Fluid type Automatic transmission fluid Type TIV
See page 310 for detailed information.
 Tire information:
See pages 315 through 321 for detailed information.
 Tire pressure:
Tire size: P215/60R16 94V
Tire pressure:
Front 200 kPa (2.0 kgf/cm
2 or bar, 29 psi)
Rear 200 kPa (2.0 kgf/cm2 or bar, 29 psi)
For sustained high speeds above 160 km/h (99 mph), in
countries where such speeds are permitted by law, add 40
kPa (0.4 kgf/cm
2 or bar, 6 psi) to the front tires and rear tires,
but never exceed the maximum cold tire pressure molded
on the tire sidewall.
