400FX-04
40-2
- AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY
2517 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
AUTOMATIC TRANSAXLE ASSY
PRECAUTION
1. The automatic transaxle is composed of highly precision-finished parts, if nequine careful in-
spection before reassembly therefore even a small nick may cause fluid leakage or may de-
grade the performance. The instructions here are organized so that you work on only one com-
ponent group at a time. This will help you to avoid confusion about similar-looking parts of
different sub-assemblies being on your workbench at the same time. The component groups
are inspected and repaired from the converter housing side. Inspectio, repair and reassembly
As much as possible, before proceeding to the next component group. If a defect is found in
a certain component group during reassembly, inspect and repair this group immediately. If a
component group cannot be assembled because parts are being ordered, be sure to keep all
parts of the group in a separate container while proceeding with disassembly, inspection, re-
pair and reassembly of other component groups.
Recommended ATF: T-IV
2. All disassembled parts should be washed clean and any fluid passages and holes should be
blown with compressed air.
3. Dry all parts with compressed airnever use shop rags.
4. When using compressed air, do not aim at yourself to prevent accidentally spraying ATF or ker-
osene on your face.
5. The recommended automatic transaxle fluid or kerosene should be used for cleaning.
6. After cleaning, the parts should be arranged in the correct order for efficient inspection, repairs,
and reassembly.
7. When disassembling a valve body, be sure to match each valve together with the correspond-
ing spring.
8. New discs for the brakes and clutches that are to be used for replacement must be soaked in
ATF for at least 15 minutes before reassembly.
9. All oil seal rings, clutch discs, clutch plates, rotating parts, and sliding surfaces should be
coated with ATF prior to reassembly.
10. All gaskets and rubber O-rings should be replaced.
11. Do not apply adhesive cements to gaskets and similar parts.
12. Make sure that the ends of a snap ring are not aligned with one of the cutouts and are installed
in the groove correctly.
13. If a worn bushing is to be replaced, the sub-assembly containing the bushing must also be re-
placed.
14. Check thrust bearings and races for wear or damage. Replace if necessary.
15. Use petroleum jelly to keep parts in place.
16. When working with FIPG material, you must perform the following.
Using a razor blade and a gasket scraper, remove all the old packing (FIPG) material from the
gasket surface.
Thoroughly clean all components to remove all the loose material.
Clean both sealing surfaces with a non-residue solvent.
Parts must be reassembled within 10 minutes of application. Otherwise, the packing (FIPG) ma-
terial must be removed and reapplied.
Page 202 of 969
4010O-05
D30614
D25415
C99458
- AUTOMATIC TRANSMISSION / TRANSPARK/NEUTRAL POSITION SWITCH ASSY (U151E)
40-3
2518 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
PARK/NEUTRAL POSITION SWITCH ASSY (U151E)
REPLACEMENT
1. REMOVE BATTERY
2. REMOVE AIR CLEANER ASSY
3. REMOVE AIR CLEANER HOSE NO.1
4. REMOVE AIR CLEANER BRACKET
5. REMOVE AIR CLEANER INLET NO.1
6. REMOVE INTAKE AIR RESONATOR SUB-ASSY
7. REMOVE ENGINE UNDER COVER NO.1
8. DISCONNECT TRANSMISSION CONTROL CABLE
ASSY
(a) Remove the nut from the control shaft lever.
(b) Disconnect the control cable from the control shaft lever.
(c) Remove the clip and disconnect the control cable from
the control cable bracket.
9. REMOVE PARK/NEUTRAL POSITION SWITCH ASSY
(a) Disconnect the park/neutral position switch connector.
(b) Remove the nut, washer and control shaft lever.
Page 203 of 969
C99457
C87814
C99454
C99454Manual Valve Shaft
C99455
40-4
- AUTOMATIC TRANSMISSION / TRANSPARK/NEUTRAL POSITION SWITCH ASSY (U151E)
2519 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(c) Pry out the lock plate.
(d) Remove the lock nut and lock plate.
(e) Remove the 2 bolts and pull out the park/neutral position
switch.
10. INSTALL PARK/NEUTRAL POSITION SWITCH ASSY
(a) Install the park/neutral position switch to the manual valve
shaft.
(b) Temporarily install the 2 bolts.
(c) Place the lock plate and tighten the nut.
Torque: 6.9 NVm (70 kgfVcm, 61 in.Vlbf)
(d) Temporarily install the control shaft lever.
(e) Turn the lever counterclockwise until it stops, then turn it
clockwise 2 notches.
(f) Remove the control shaft lever.
Page 204 of 969
C99456
Neutral
Basic
Line
Groove
C99457
C99458
D30614
D25415
- AUTOMATIC TRANSMISSION / TRANSPARK/NEUTRAL POSITION SWITCH ASSY (U151E)
40-5
2520 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(g) Align the groove with neutral basic line.
(h) Hold the switch in position and tighten the 2 bolts.
Torque: 5.4 NVm (55 kgfVcm, 48 in.Vlbf)
(i) Using a screwdriver, stake the nut with the lock plate.
(j) Install the control shaft lever, washer and nut.
Torque: 13 NVm (130 kgfVcm, 9 ftVlbf)
(k) Connect the park/neutral position switch connector.
11. CONNECT TRANSMISSION CONTROL CABLE ASSY
(a) Temporarily install the control cable to the control shaft le-
ver with the nut.
(b) Install the control cable and a new clip to the bracket.
Page 205 of 969
40-6
- AUTOMATIC TRANSMISSION / TRANSPARK/NEUTRAL POSITION SWITCH ASSY (U151E)
2521 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
12. ADJUST SHIFT LEVER POSITION (SEE PAGE 40-40)
13. INSPECT SHIFT LEVER POSITION (SEE PAGE 40-40)
14. INSPECT PARK/NEUTRAL POSITION SWITCH ASSY (SEE PAGE 40-7)
15. INSTALL ENGINE UNDER COVER NO.1
16. INSTALL INTAKE AIR RESONATOR SUB-ASSY
17. INSTALL AIR CLEANER INLET NO.1
18. INSTALL AIR CLEANER BRACKET
19. INSTALL AIR CLEANER HOSE NO.1
20. INSTALL AIR CLEANER ASSY
21. INSTALL BATTERY
Page 206 of 969
4010P-03
C99453
Groove
Neutral
Basic Line
- AUTOMATIC TRANSMISSION / TRANSPARK/NEUTRAL POSITION SWITCH ASSY (U151E)
40-7
2522 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
ADJUSTMENT
1. INSPECT PARK/NEUTRAL POSITION SWITCH ASSY
(a) Apply the parking brake and turn the ignition switch to ON.
(b) Depress the brake pedal and check that the engine starts only when the shift lever is set in N or P posi-
tion.
(c) Check that the back-up light is lit and the reverse warning buzzer sounds only when the shift lever is
set in R position.
If a failure is found, check the continuity of the park/neutral position switch.
2. ADJUST PARK/NEUTRAL POSITION SWITCH ASSY
(a) Loosen the 2 bolts of park/neutral position switch and set
the shift lever to the N position.
(b) Align the groove with neutral basic line.
(c) Hold the switch in position and tighten the 2 bolts.
Torque: 5.4 NVm (55 kgfVcm, 48 in.Vlbf)
(d) After adjustment, perform the inspection described in
step 1.
Page 207 of 969
4010Q-02
D31337
Bearing Bracket Hole Snap Ring
32 (326, 24)
12 (122, 9)
64 (653, 47)
46 (470, 34)
Front Drive Shaft Assy RH
Transmission Control
Cable Bracket No.2
41 (418, 30)
12 (122, 9)
37 (377, 27)
5.5 (56, 49 in.Vlbf)
9.8 (100, 87 in.Vlbf)
Wire Harness
Automatic
Transmission Case
Cover
Front Drive
ShaftLH Hole
Snap Ring
Front Drive Shaft
Assy LH
Starter Assy
O-ring
Transimission Oil
Filler Tube Sub-assy
ATF Level
Gauge Oil Cooler
Outlet Tube No.1 Oil Cooler Inlet
Tube No.1Oil Cooler Tube ClampTransmission Control
Cable Bracket No.1 Flywheel Housing
Under CoverTorque Converter ClutchEngine
Mounting
Bracket FR
X6
N´m (kgf´cm, ft´lbf): Specified torque
Non-reusable partWire Harness Clamp
12 (122, 9)
12 (122, 9)
34 (350, 25)
8.4 (86, 74 in.Vlbf)
64 (653, 47)
5.4 (55, 48 in.Vlbf)
7.8 (80, 69 in.Vlbf)
13 (130, 9)
Exhaust Pipe Support Bracket
37 (377, 27)
34 (350, 25)
x 5 40-8
- AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY (U151E)
2523 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
AUTOMATIC TRANSAXLE ASSY (U151E)
COMPONENTS
Page 208 of 969
4010R-03
C91731
D31338
D30466
D30464
- AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY (U151E)
40-9
2524 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
REPLACEMENT
1. REMOVE ENGINE ASSEMBLY WITH TRANSAXLE (SEE PAGE 14-29)
2. REMOVE FRONT DRIVE SHAFT ASSY RH
(SEE PAGE 30-8)
3. REMOVE FRONT DRIVE SHAFT ASSY LH (SEE PAGE 30-8)
4. REMOVE TRANSMISSION CONTROL CABLE
BRACKET NO.2
(a) Remove the bolt and transmission control cable bracket
No.2.
5. REMOVE WIRE HARNESS CLAMP
(a) Disconnect the wire harnesses from the clamps.
(b) Remove the 2 bolts and 2 clamps.
6. DISCONNECT WIRE HARNESS
(a) Remove the bolt and wire harness.
7. REMOVE STARTER ASSY
(a) Disconnect the connector.
(b) Remove the nut and disconnect the starter wire.
(c) Remove the 2 bolts and starter assy.
Page 209 of 969
D30864
Transmission
Wire Connector
Park/neutral Position Switch Connector
Transmission Revolution
Sensor Connectors
C91736
C91737
C88047
SST
40-10
- AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY (U151E)
2525 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
8. DISCONNECT CONNECTORS
(a) Disconnect the transmission wire connector.
(b) Disconnect the park/neutral position switch connector.
(c) Disconnect the 2 transmission revolution sensor connec-
tors.
9. REMOVE TRANSMISSION CONTROL CABLE
BRACKET NO.1
(a) Remove the bolt and oil cooler tube clamp.
(b) Remove the 2 bolts and transmission control cable brack-
et.
10. REMOVE TRANSMISSION OIL FILLER TUBE
SUB-ASSY
(a) Remove the ATF level gauge.
(b) Remove the bolt and oil filler tube.
(c) Remove the O-ring from the oil filler tube.
11. REMOVE OIL COOLER INLET TUBE NO.1
(a) Using SST and spanner, disconnect the oil cooler inlet
tube No.1.
SST 09023-12701
Page 210 of 969
D31339
D25420
D31340
D30472
- AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY (U151E)
40-1 1
2526 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(b) Disconnect the breather hose from the wire harness
bracket.
12. REMOVE OIL COOLER OUTLET TUBE NO.1
(a) Using SST and spanner, disconnect the oil cooler outlet tube No.1.
SST 09023-12701
13. REMOVE ENGINE MOUNTING BRACKET FR
(a) Remove the 3 bolts and engine mounting bracket FR.
14. REMOVE AUTOMATIC TRANSAXLE ASSY
(a) Remove the 2 bolts and fryweel housing under cover.
(b) Turn the crankshaft to gain access and remove the 6 bolts
while holding the crankshaft pulley bolt with a wrench.
