Page 341 of 969
C90470
Turn
Buckle
- PARKING BRAKEPARKING BRAKE CABLE ASSY NO.4
33-15
2511 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(c) Tighten the turn buckle, connect the parking brake cable
assy No.4 to the parking brake cable assy No.1.
Torque: 5.4 NVm (55 kgfVcm, 48 in.Vlbf)
8. INSTALL YAWRATE SENSOR (W/ VSC)(See page 32-59)
9. INSTALL CONSOLE BOX MOUNTING BRACKET NO.2
(a) Install the console box mounting bracket No.2 with the 2 bolts.
Torque: 12.5 NVm (128 kgfVcm, 9 ftVlbf)
10. INSTALL RR CONSOLE BOX
11. INSTALL CONSOLE BOX CARPET
12. INSTALL CONSOLE PANEL UPPER REAR
13. INSPECT AND ADJUST PARKING BRAKE PEDAL TRAVEL
14. CHECK VSC SENSOR SIGNAL (W/ VSC)(See page 05-471)
Page 342 of 969
3305M-03
C64523
Contract
F06409
F40318
33-16
- PARKING BRAKEPARKING BRAKE ASSY
2512 Author: Date:
PARKING BRAKE ASSY
OVERHAUL
HINT:
COMPONENTS: See page 33-3
Overhaul the RH side by the same procedures with LH side.
1. REMOVE REAR WHEEL
2. REMOVE REAR DISC BRAKE CALIPER ASSY LH
(a) Remove the 2 bolts and separate the rear disc brake caliper assy LH.
HINT:
Do not disconnect the flexible hose from the brake caliper.
3. REMOVE REAR DISC
(a) Release the parking brake, and remove the rear disc.
HINT:
Put matchmarks on the disc and the axle hub.
If the disc cannot be removed easily, turn the shoe adjust-
er until the wheel turns freely.
4. INSPECT BRAKE DISC INSIDE DIAMETER
(a) Using a brake drum gauge or equivalent, measure the in-
side diameter of the disc.
Standard inside diameter: 170 mm (6.69 in.)
Maximum inside diameter: 171 mm (6.73 in.)
5. REMOVE PARKING BRAKE SHOE RETURN TENSION
SPRING
(a) Using a needle-nose pliers, remove the 2 return tension
springs.
6. REMOVE PARKING BRAKE SHOE STRUT COMPRESSION SPRING
(a) Slide out the front shoe and remove the compression spring.
7. REMOVE PARKING BRAKE SHOE STRUT LH
Page 343 of 969
F40319
F40320
BR5332
BR0828
- PARKING BRAKEPARKING BRAKE ASSY
33-17
2513 Author: Date:
8. REMOVE PARKING BRAKE SHOE
(a) Release the cup claw and remove the front and rear park-
ing brake shoe.
(b) Disconnect the parking brake cable from the shoe lever.
(c) Remove the tension spring and shoe adjuster screw set
from the front and rear shoe.
(d) Remove the 2 shoe hold-down springs, 4 cups and 2
pins.
(e) Using a screwdriver, remove the C-washer.
(f) Remove the shim and shoe lever from the parking brake
shoe.
9. INSPECT PARKING BRAKE SHOE LINING
THICKNESS
(a) Using a ruler, measure the thickness of the shoe lining.
Standard thickness: 2.0 mm (0.079 in.)
Minimum thickness: 1.0 mm (0.039 in.)
If the lining thickness is at the minimum thickness or less, or if
there is severe, uneven wear, replace the brake shoe.
10. INSPECT BRAKE DISC AND PARKING BRAKE SHOE
LINING FOR PROPER CONTACT
(a) Apply chalk to the inside surface of the disc, then grind
down the brake shoe lining to fit.
If the contact between the brake disc and the shoe lining is im-
proper, repair it using a brake shoe grinder or replace the brake
shoe assembly.
11. APPLICATION HIGH TEMPERATURE GREASE
(a) Apply the high temperature grease to the shoe attached surface of backing plate.
Page 344 of 969
R00343
C80705
F40318
33-18
- PARKING BRAKEPARKING BRAKE ASSY
2514 Author: Date:
12. INSTALL PARKING BRAKE SHOE
(a) Install the shoe lever and shim to the rear shoe with a new
C-washer .
(b) Using a feeler gauge, measure the clearance.
Standard clearance: Less than 0.35 mm (0.0138 in.)
If the clearance is not within the specification, replace the shim
with one of the correct size.
Shim ThicknessShim Thickness
0.3 mm (0.012 in.)0.9 mm (0.035 in.)
0.6 mm (0.024 in.)-
(c) Apply the high temperature grease to the adjusting bolt.
(d) Install the shoe adjusting screw set and tension spring to
the front and rear shoe.
(e) Install the 2 pins, 4 cups and 2 shoe hold-down springs.
(f) Connect the parking brake cable to the shoe lever.
(g) Install the front and rear parking brake shoe.
13. INSTALL PARKING BRAKE SHOE STRUT LH
14. INSTALL PARKING BRAKE SHOE STRUT COMPRESSION SPRING
15. INSTALL PARKING BRAKE SHOE RETURN TENSION
SPRING
(a) Using a needle nose pliers, install the 2 return tension
springs.
Page 345 of 969
F40322
Front FrontRH
LH
F40026
Expand
Contract
- PARKING BRAKEPARKING BRAKE ASSY
33-19
2515 Author: Date:
16. CHECK PARKING BRAKE INSTALLATION
(a) Check that each part is installed properly.
NOTICE:
There should be no oil or grease adhering to the friction surface of the shoe lining and disc.
17. INSTALL REAR DISC(See page 32-41)
18. ADJUST PARKING BRAKE SHOE CLEARANCE
(a) Temporarily install the hub nuts.
(b) Remove the hole plug, and turn the adjuster and expand
the shoes until the disc locks.
(c) Contract the shoe adjuster until the disc can rotate
smoothly.
Standard : Return 8 notches
(d) Check shoe is no brake drag.
(e) Install the hole plug.
19. INSTALL REAR DISC BRAKE CALIPER ASSY LH
(a) Install the rear disc brake caliper with the 2 bolts.
Torque: 47 NVm (480 kgfVcm, 35 ftVlbf)
20. INSTALL REAR WHEEL
Torque: 103 NVm (1,050 kgfVcm, 76 ftVlbf)
21. INSPECT AND ADJUST PARKING BRAKE PEDAL TRAVEL(See page 33-2)
Page 346 of 969
3001U-13
- DRIVE SHAFT / PROPELLER SHAFTDRIVE SHAFT, PROPELLER SHAFT, AXLE (From July,
2003)30-1
2404 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
DRIVE SHAFT, PROPELLER SHAFT, AXLE (From July, 2003)
PROBLEM SYMPTOMS TABLE
Use the table below to help determine the cause of the problem. The numbers indicate the priority of the
possible cause of the problem. Check each part in order. If necessary, replace these parts.
SymptomSuspected AreaSee page
Wander
1. Wheel alignment
2. Steering linkage (Loosen or worn)
3. Hub bearing (Worn)
4. Stabilizer bar26-5
27-3
-
30-2
26-17
27-18
Front wheel shimmy
1. Wheel balance
2. Shock absorber
3. Ball joint (Worn)
4. Hub bearing (Worn)28-1
26-8
27-4
26-16
30-2
Noise1. Inboard joint or outboard joint (Worn)30-8
Page 347 of 969
3001V-08
F40163
F40164
C98686
30-2- DRIVE SHAFT / PROPELLER SHAFTDRIVE SHAFT, PROPELLER SHAFT, AXLE (From July,
2003)
2405 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
ON-VEHICLE INSPECTION
1. REMOVE FRONT WHEEL
2. DISCONNECT FRONT DISC BRAKE CALIPER ASSY LH (SEE PAGE 30-8)
3. REMOVE FRONT DISC
4. INSPECT FRONT AXLE HUB BEARING BACKLASH
(a) Using a dial indicator, check the backlash near the center
of the axle hub.
Maximum: 0.05 mm (0.0020 in.)
If the backlash exceeds the maximum, replace the bearing.
NOTICE:
Ensure that the dial indicator is set at right angles to the
measurement surface.
5. INSPECT FRONT AXLE HUB DEVIATION
(a) Using a dial indicator, check the deviation at the surface
of the axle hub outside the hub bolt.
Maximum: 0.05 mm (0.0020 in.)
If the deviation exceeds the maximum, replace the axle hub.
NOTICE:
Ensure that the dial indicator is set at right angles to the
measurement surface.
6. INSTALL FRONT DISC
7. INSTALL FRONT DISC BRAKE CALIPER ASSY LH (SEE PAGE 30-8)
8. INSTALL FRONT WHEEL
Torque: 103 NVm (1,050 kgfVcm, 76 ftVlbf)
9. REMOVE REAR WHEEL
10. DISCONNECT REAR DISC BRAKE CALIPER ASSY LH (SEE PAGE 30-26)
11. REMOVE REAR DISC
12. INSPECT REAR AXLE HUB BEARING BACKLASH
(a) Set a dial indicator near the center of the axle hub and
check the backlash in the bearing shaft direction.
Maximum: 0.05 mm (0.0020 in.)
If the backlash exceeds the maximum, replace the axle hub as-
sembly.
NOTICE:
Ensure that the dial indicator is set at right angles to the
measurement surface.
Page 348 of 969
C98687
- DRIVE SHAFT / PROPELLER SHAFTDRIVE SHAFT, PROPELLER SHAFT, AXLE (From July,
2003)30-3
2406 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
13. INSPECT REAR AXLE HUB DEVIATION
(a) Using a dial indicator, check the deviation at the surface
of the axle hub outside the hub bolt.
Maximum: 0.07 mm (0.0027 in.)
If the deviation exceeds the maximum, replace the axle hub as-
sembly.
NOTICE:
Ensure that the dial indicator is set at right angles to the
measurement surface.
14. INSTALL REAR DISC
15. INSTALL REAR DISC BRAKE CALIPER ASSY LH (SEE PAGE 30-26)
16. INSTALL REAR WHEEL
Torque: 103 NVm (1,050 kgfVcm, 76 ftVlbf)
Page 349 of 969
300AX-02
C91613
Front Drive Shaft
Assy LH Drive Shaft Bearing
Bracket Hole Snap Ring
Tie Rod Assy LH
Front Suspension
Arm Sub-assy Lower
No.1 LHFront Axle Assy LH Front Stabilizer Link Assy LH
Speed Sensor Front LH
Cotter Pin Front Drive Shaft
Assy RH
N´m (kgf´cm, ft´lbf): Specified torque
Non-reusable part
32 (330, 24)
8.0 (82, 71 in.Vlbf)
294 (2,998, 217)
49 (500, 36)
75 (765, 55)
74 (755, 55)
Front Flexible Hose
No. 1
19 (192, 14)
30-4
- DRIVE SHAFT / PROPELLER SHAFTDRIVE SHAFT, PROPELLER SHAFT, AXLE (From July,
2003)
2407 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
COMPONENTS
Page 350 of 969
F47192 Non-reusable partSupply Parts:
Front Axle Outboard
Joint Boot RH
No.2 Clamp
Front Drive Outboard
Joint Shaft Assy RHFront Axle Outboard Joint
Boot RH Clamp
Front Drive Shaft
Damper RH Clamp
Front Axle Inboard
Joint Boot RH Clamp
Front Drive Shaft
Dust Cover RH Front Drive Shaft
Dust CoverFront Drive Shaft Hole
Snap Ring RH
Front Drive Inboard
Joint Assy RH
Front Drive Inner Shaft Inner
RH Shaft Snap Ring Front Drive
Shaft Bearing
Front Axle Inboard
Joint Boot
Front Axle Inboard
Joint Boot RH No.2 Clamp
Front Drive Shaft
Dust Cover LH Front Drive Inboard
Joint Assy LH
Front Drive Shaft LH
Hole Snap Ring
Front Drive Shaft
Damper RH
Outboard Joint Boot
LH:
Front Drive Inboard
Joint Assy RH
- DRIVE SHAFT / PROPELLER SHAFTDRIVE SHAFT, PROPELLER SHAFT, AXLE (From July,
2003)30-5
2408 Author: Date:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
