Lexus ES300h 2013 Maintenance and care / Owner's Manual (OM33A01U)

ES350 300h_OM_OM33A01U_(U)
6015-4. Using the audio system
5
Interior features
Select the desired preset button and register the data into speed dial by
either of the following methods:
a. Press the desired preset button and select “Confirm” by using a voice
command or .
b. Press and hold the desired preset button.
Select “Delete Entry” using a voice command or .
Pattern A
Select the data to be deleted by either of the following methods and
select “Confirm” using a voice command or :
a. Press the talk switch and say the name of the desired phone number.
b. Press the talk switch and say “L ist Names”. When the name of the
desired phone number is read aloud, press the talk switch.
Pattern B
Select the desired data to be deleted using .
Deleting the registered data
3
1
2
2

602
ES350 300h_OM_OM33A01U_(U)
5-4. Using the audio system
Select “Delete Speed Dial (Del Spd Dial)” using a voice command or
.
Press the preset button to which the desired speed dial is registered
and select “Confirm” using a voice command or .
■Limitation of number of digits
A phone number that exceeds 24 digits cannot be registered.
Deleting speed dials
1
2

603
ES350 300h_OM_OM33A01U_(U)
5-5. Using the interior lights
5
Interior features
Interior lights list
When the instrument panel light control switch is turned to minimum and the tail
lights are on, the ornament lights and the footwell lights will turn off. (P. 9 4 )
Outer foot lights
Shift lever light
Interior light ( P. 6 0 4 )
Front personal lights (P. 6 0 4 ) Rear personal lights (
P. 604)
Door courtesy lights
Ornament lights (if equipped)
Footwell lights1
2
3
4
5
6
7
8

604
ES350 300h_OM_OM33A01U_(U)
5-5. Using the interior lights
Turns the light on/off
The rear personal lights are also
turned on/off by the interior light
operation. However, if the interior light
is turned off after being turned on
while the rear personal lights are
turned on, the rear personal lights will
not turn off simultaneously.
Turns the door position on
■Front
Turns the light on/off
■Rear
Turns the light on/off
If the lights are turned on by interior
light operation, the lights cannot
turn off by pressing the switch.
Interior light
1
2
Pe r s o n a l l i g h t s

ES350 300h_OM_OM33A01U_(U)
6055-5. Using the interior lights
5
Interior features
■Illuminated entry system
The lights automatically turn on/off according to “START STOP ENGINE”
<“POWER”> switch mode, the presence of the electronic key, whether the doors are
locked/unlocked, and whether the doors are opened/closed.
■To prevent 12-volt battery discharge
If the following lights remain on when the door is not fully closed and the personal/
interior light main switch is in the door position, the lights will go off automatically
after 20 minutes:
●Outer foot lights
●Personal/interior light
●Door courtesy lights
●Ornament lights (if equipped)
●Footwell lights
■Customization
Setting (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features: P. 8 5 2 )

606
ES350 300h_OM_OM33A01U_(U)
5-6. Using the storage features
List of storage features
Cup holders (P. 610)
Glove box ( P. 6 0 8 )Console box (
P. 609)
Auxiliary box ( P. 6 1 1 )1
2
3
4

ES350 300h_OM_OM33A01U_(U)
6075-6. Using the storage features
5
Interior features
CAUTION
■Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause
the following when cabin temperature becomes high:
●Glasses may be deformed by heat or cracked if they come into contact with
other stored items.
●Lighters or spray cans may explode. If they come into contact with other stored
items, the lighter may catch fire or the spray can may release gas, causing a fire
hazard.
■When driving or when the storage compartments are not in use
Keep the lids closed.
In the event of sudden braking or sudden swerving, an accident may occur due to
an occupant being struck by an open lid or the items stored inside.

608
ES350 300h_OM_OM33A01U_(U)
5-6. Using the storage features
Open (press the button)
Unlock with the mechanical key
Lock with the mechanical key
■Glove box light
The glove box light turns on when the tail lights are on.
■Trunk opener main switch
The trunk opener main switch is located in the glove box. ( P. 1 4 5 )
■Removing the insert
The insert inside the glove box can be removed. ( P. 7 0 8 )
Glove box
1
2
3

ES350 300h_OM_OM33A01U_(U)
6095-6. Using the storage features
5
Interior features
Push the knob to release the lock,
and lift the armrest to open fully.
■Tray in the console box
■Console box light
The console box light turns on when the tail lights are on.
Console box
The tray slides forward/backward and can be
removed.
CAUTION
When using the console box with half-open, do not apply too much load on the
armrest. Doing so may damage the armrest and may cause you to injure yourself.

610
ES350 300h_OM_OM33A01U_(U)
5-6. Using the storage features
■Driver’s sideTo open, move the cup holder
lid until it locks.
To close, press and release the
cup holder lid.
■Front passenger’s side
To open, press down and release
the cup holder lid.
■Rear
To open, pull down the armrest
and press in and release the rear
cup holder on the armrest.
Cup holders
1
2
