1
ES300h_QG_OM33A73U_(U)
The Quick Guide is not intended as a substitute for your Owner’s
Manual. We strongly encourage you to review the Owner’s
Manual and supplementary manuals so you will have a better
understanding of your vehicle’s capabilities and limitations.
Air Conditioning System (with Lexus Display Audio) ..........................................................84
Air Conditioning System (with navigation system) ................................................................ 70
Air Conditioning System (without navigation system or Lexus Display Audio)......... 91
Audio System (with Lexus Display Audio)
Audio control screen.................................................................................................................... 79
Basic operation ............................................................................................................................... 79
Radio ................................................................................................................................................... 79
Using the CD player...................................................................................................................... 81
Operating an iPod .........................................................................................................................82
Remote control (steering wheel switches)..........................................................................83
Audio System (with navigation system)
Audio control screen.................................................................................................................... 66
Basic operation ............................................................................................................................... 66
Radio ................................................................................................................................................... 67
DVD player/CD player ...............................................................................................................68
Operating an iPod ......................................................................................................................... 69
Remote control (steering wheel switches).......................................................................... 69
Audio System (without navigation system or Lexus Display Audio)
Basic operation ............................................................................................................................... 87
Radio .................................................................................................................................................. 88
CD player......................................................................................................................................... 88
Operating an iPod .........................................................................................................................90
Remote control (steering wheel switches)..........................................................................90
Automatic High Beam .......................................................................................................................38
Contents
Page 2 of 116
2
ES300h_QG_OM33A73U_(U)
BSM (Blind Spot Monitor) ................................................................................................................ 51
Cruise Control ......................................................................................................................................43
Door Locks ........................................................................................................................................... 102
Driving Mode Select Switch ............................................................................................................ 52
Driving Position Memory ..................................................................................................................25
Dynamic Radar Cruise Control ..................................................................................................... 45
Energy Monitor/Consumption Screen........................................................................................ 14
EV Drive Mode ...................................................................................................................................... 31
Floor mat installation..............................................................................................................................11
Front Seats ..............................................................................................................................................23
Fuel Tank Cap ...................................................................................................................................... 106
Garage Door Opener .......................................................................................................................95
Hands-free System For Cellular Phone (with Lexus Display Audio)
Bluetooth
® phone pairing ..........................................................................................................76
Phonebook transfer .......................................................................................................................76
Registering a speed dial .............................................................................................................. 77
Calling by speed dial .................................................................................................................... 78
Receiving a call ............................................................................................................................... 78
Steering switches ........................................................................................................................... 78
Hands-free System For Cellular Phone (with navigation system)
Bluetooth
® phone pairing .......................................................................................................... 61
Phonebook transfer ...................................................................................................................... 62
Registering a speed dial .............................................................................................................. 62
Calling by name..............................................................................................................................63
Calling by speed dial ....................................................................................................................64
Calling using SMS/MMS message........................................................................................64
Receiving a call ...............................................................................................................................65
Steering switches ...........................................................................................................................65
Page 3 of 116
3
ES300h_QG_OM33A73U_(U)
Hands-free System For Cellular Phone
(without navigation system or Lexus Display Audio)
Bluetooth
® phone pairing ........................................................................................................ 85
Dialing by inputting a number ..................................................................................................86
Dialing by inputting a name .......................................................................................................86
Speed dial .........................................................................................................................................86
When receiving a phone call ....................................................................................................87
Headlights ............................................................................................................................................... 37
Head Restraints..................................................................................................................................... 24
Hybrid System ....................................................................................................................................... 12
Hybrid Transmission ........................................................................................................................... 32
Intuitive Parking Assist ...................................................................................................................... 50
Keys............................................................................................................................................................. 18
Lexus Enform with Safety Connect ..............................................................................................99
LDA (Lane Departure Alert) ..........................................................................................................48
Lexus Display Audio controller (with Lexus Display Audio)
Basic operation ................................................................................................................................74
Menu ................................................................................................................................................... 75
Display ................................................................................................................................................ 75
Moon Roof ............................................................................................................................................ 104
Multi-information Display .................................................................................................................35
Navigation System
Register home ................................................................................................................................. 57
Destination input - Search by address ................................................................................. 58
Destination input - Search points of interest by name....................................................59
Destination input - Search points of interest by category.............................................59
Destination input - Search points of interest by telephone number .........................60
Page 5 of 116
5
ES300h_QG_OM33A73U_(U)
OverviewInstrument Panel
Windshield wiper and washer switch P.40
Multi-information display P.35
Headlight switch
Turn signal lever
Fog light switch
*
P.37
P.34
Inside lock button P.102
Trunk opener P.107
Hood lock release lever*
Driving position memory switches P.25
See P.6
See P.5
Window lock switch P.103
Power window switches P.103
Door lock switch P.102
Tire pressure warning reset
switch
P.53
Fuel filler door opener P.106
Page 6 of 116
6
ES300h_QG_OM33A73U_(U)
Remote Touch screen
Navigation system
Lexus Display Audio system
P.54
P.57
P.74
Clock*
Trunk opener main switch
P.107
Audio system P.66, 79, 87
Air conditioning system
P.70, 84, 91
Emergency flasher switch*
See P.7Power (ignition) switch
P.28
Parking brake*
: If equipped
*: Refer to “Owner’s Manual”.
PCS OFF switch *
Tilt and telescopic steering rock release lever*
Page 9 of 116
9
ES300h_QG_OM33A73U_(U)
OverviewInstrument Panel
Remote Touch P.54
Heated steering wheel switch*
Driving mode select switch P.52
VSC OFF switch*
Seat heater and ventilator switches P.92
EV drive mode switch P.31
Shift lever P.32
Rear sunshade switch P.93
Lexus Display Audio controller P.74
Page 12 of 116
12
ES300h_QG_OM33A73U_(U)
Hybrid System
■Hybrid System Indicator
Po w e r a r e a
Shows that an Eco-friendly driving
range is being exceeded (during full
power driving etc.)
Eco area
Shows that the vehicle is being driven
in an Eco-friendly manner.
Hybrid Eco area
Shows that gasoline engine power is
not being used very often.
The gasoline engine will automatically
stop and restart under various condi-
tions.
Charge area
Shows regenerative charging.
●Hybrid System Indicator is displayed when the driving mode is other than the sport
mode.
●By keeping the indicator needle within Eco area, more Eco-friendly driving can be
achieved.
●Charge area indicates regeneration
* status. Regenerated energy will be used to charge
the battery.
*: When used in this manual, “regeneration” refers to the conversion of energy created by
the movement of the vehicle into electrical energy.
Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles.
Be sure you are closely familiar with the characteristics of your vehicle, and operate with
care.
The hybrid system combines the use of a gasoline engine and an electric motor (traction
motor) according to driving conditions, improving fuel efficiency and reducing exhaust
emissions.
For details, refer to the “Owner’s Manual”.
1
2
3
4
Page 14 of 116
14
ES300h_QG_OM33A73U_(U)
Energy Monitor/Consumption Screen
■Energy monitor
●How to display on the navigation system screen or Lexus Display Audio system screen (if
equipped)
Vehicles with a navigation system
Press the “MENU” button on Remote Touch.
Select “Info/Apps” on the “Menu” screen.
Select “Fuel Consumption” on the “Information” screen.
If the “Energy Monitor” screen is not displayed, select “Energy”.
Vehicles with Lexus Display Audio system
Press the “MENU” button on the Lexus Display Audio controller.
Select “Car” on the “Menu” screen.
If the “Energy Monitor” screen is not displayed, select “Energy”.
You can view the status of your vehicle on the multi-information display and the naviga-
tion system screen or Lexus Display Audio system screen.
1
2
3
The flow of energy is displayed on the navigation system screen.
Amber: gasoline energy
Yellow: electrical energy
Light blue: energy recovery
A light blue arrow appears when regenerative braking
occurs.
1
2
The flow of energy is displayed on the Lexus Display Audio sys-
tem screen.
Purple: gasoline energy
Yellow: electrical energy
Light blue: energy recovery
A light blue arrow appears when regenerative braking
occurs.
Page 15 of 116
15
ES300h_QG_OM33A73U_(U)
●How to display on the multi-information display
Press the “DISP” button on the steering wheel several times to select the energy monitor
display.
The flow of energy is indicated by the movement of the arrows
on the multi-information display.
The displayed energy flow, battery level, etc. will change in response to the current driving
conditions.
Page 16 of 116
16
ES300h_QG_OM33A73U_(U)
■Consumption (if equipped)
Vehicles with a navigation system
Press the “MENU” button on Remote Touch, then select “Info/Apps” on the “Menu”
screen.
Select “Fuel Consumption” on the “Information” screen.
If the “Energy Monitor” screen is displayed, select “Fuel Consumption”.
Vehicles with Lexus Display Audio system
Press the “MENU” button on the Lexus Display Audio controller, then select “Car” on the
“Menu” screen.
If the “Energy Monitor” screen is displayed, select “Fuel Consumption”.
●Trip information
If the “Trip Information” screen is not displayed, select “Trip Information”.
Vehicles with a navigation system
Current fuel consumption
Fuel consumption in the past 15 min-
utes
Regenerated energy in the past 15
minutes
Displays the average vehicle speed
since the hybrid system was started.
Displays the elapsed time since the
hybrid system was started.
Cruising range
Reset the consumption data
“Past Record” (Navigation system) or
“History” (Lexus Display Audio sys-
tem) screen appears
“Energy Monitor” screen appears Vehicles with Lexus Display Audio system
1
2
1
2
3
4
5
6
7
8
