Lexus ES300h 2018 Owner's Manual (OM33D45U)

ES300h_OM_OM33D45U_(U)
4016-3. Using the storage features
6
Interior features
■Driver’s sideTo open, move the cup holder lid
until it locks.
To close, press and release the
cup holder lid.
■Front passenger’s side
To open, press down and release the
cup holder lid.
■Rear
To open, pull down the armrest and
open the lid.
Cup holders
1
2

402
ES300h_OM_OM33D45U_(U)6-3. Using the storage features
Press in the button.
WARNING
●Do not place anything other than cups or beverage cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or sudden
braking, causing injury. If possible, cover hot drinks to prevent burns.
●Front passenger’s side cup holder only: Do no
t place anything larger than a 32 oz cup
in the cup holder.
Doing so may prevent the switches from being operated properly or block the
driver’s view of the switches, which may cause an accident.
NOTICE
To prevent damage to the rear cup holder, stow the cup holder before stowing the arm-
rest.
Auxiliary box

403
ES300h_OM_OM33D45U_(U)6-3. Using the storage features
6
Interior features
Trunk features
Raise the hooks when needed.
The cargo hooks are provided for
securing loose items.
Cargo hooks
WARNING
To avoid injury, always return
the cargo hooks to their stow ed positions when not in use.
Grocery bag hooks

404
ES300h_OM_OM33D45U_(U)6-3. Using the storage features
Pull the lever upwards when lifting
the luggage mat up.
The lever can be hooked on the
edge of the trunk.
Luggage mat
1
2
NOTICE
When closing the trunk door, do not leave
the luggage mat lever hooked on the edge
of the trunk. The luggage mat may get damaged.

405
ES300h_OM_OM33D45U_(U)6-4. Using the other interior features
6
Interior features
Other interior features
To set the visor in the forward posi-
tion, flip it down.
To set the visor in the side position,
flip down, unhook, and swing it to the
side.
To use the side extender, place the
visor in the side position, then slide it
backward.
Slide the cover to open.
The light turns on when the cover is
opened.
Sun visors
1
2
3
Vanity mirrors
NOTICE
To prevent 12-volt battery discharge, do not leave the vanity lights on for extended peri-
ods while the hybrid system is not operating.

406
ES300h_OM_OM33D45U_(U)6-4. Using the other interior features
The clock can be adjusted.
Pressing and holding will move the
clock hands backward.
Pressing and holding will move the
clock hands forward.
The power outlets can be used for 12V accessories that run on less than 10A.
■Front
Open the lid.
■Rear
Open the lid.
The power outlets can be used when the power switch is in ACCESSORY or ON mode.
Clock
1
2
Power outlets

ES300h_OM_OM33D45U_(U)
4076-4. Using the other interior features
6
Interior features
Fold down the armrest for use.
NOTICE
●To avoid damaging the power outlets, close the power outlet lids when the power out-
lets are not in use.
Foreign objects or liquids that enter the power outlets may cause a short circuit.
●To prevent blown fuse, do not use an ac cessory that uses more than 12V 10A.
●To prevent 12-volt battery discharge, do not use the power outlets longer than neces-
sary when the hybrid system is not operating.
Armrest
NOTICE
To prevent damage to the armrest, do not apply too much load on the armrest.

408
ES300h_OM_OM33D45U_(U)6-4. Using the other interior features
■Rear sunshade
The rear sunshade can be raised and lowered by operating the button shown
below.
Raise/lower
■Rear door sunshades
Pull the tab of the rear door sun-
shade and hook the sunshade on the
anchors.
To retract the rear door sunshade,
unhook the sunshade and retract it
slowly.
Rear sunshade (if equipped)/rear door sunshades (if equipped)

ES300h_OM_OM33D45U_(U)
4096-4. Using the other interior features
6
Interior features
●The rear sunshade can be used when the power switch is in ON mode.
●The rear sunshade can be operated for approximately 1 minute even after the power
switch is turned to ACCESSORY mode or turned off.
●Reverse operation feature: To ensure adequate rear visibility, the rear sunshade auto-
matically lowers when the sh ift lever is shifted to R.
However, the rear sunshade is raised again if any of the following occurs:
• The button is pressed again.
*
• Shift the shift lever to P.
• The shift lever is shifted out of R, and the vehicle reaches a speed of 9 mph (15 km/h).
If the hybrid system is off when the rear sunshade has been lowered due to the
reverse operation feature, it will not be raised even when the hybrid system is turned
on again and the vehicle reaches a speed of 9 mph (15 km/h). To raise the sunshade
again, press the button.
*: Occasionally, the reverse function may not be carried out after the switch has been
pressed. Repeat the above oper ation to operate the function.
●Time elapsed before the reverse operation feature activates can be changed.
(Customizable features: →P. 560)
WARNING
When the rear sunshade is being operated no t place fingers or other objects in the fas-
tener section or in the opening. They may get caught, causing injury.
NOTICE
●To prevent 12-volt battery discharge, do not operate the rear sunshade when the
hybrid system is not operating.
●To ensure normal operation of the rear su nshade and rear door sunshades, observe
the following precautions:
• Do not place excessive load on the moto r or other components of the rear sun-
shade.
• Do not attach items to the rear sunshade and rear door sunshades.
• Keep the opening clean and clear of obstructions.
• Do not operate the rear sunshade cont inuously for long periods of time.
●Do not operate the rear sunshade when any
objects are on top of its opening/closing part.
The rear sunshade may not operate properly.

410
ES300h_OM_OM33D45U_(U)6-4. Using the other interior features
The coat hooks are provided with the
rear assist grips.
An assist grip installed on the ceiling
can be used to support your body while
sitting on the seat.
Coat hooks
WARNING
Do not hang coat hangers or other hard or
sharp objects on the hook. If the SRS cur-
tain shield airbags deploy, these items may become projectiles, causing death or seri-
ous injury.
Assist grips
WARNING
Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
NOTICE
To prevent damage to the assist grip, do not hang any heavy object or put a heavy load
on the assist grip.
