Lexus ES300h 2019 Quick Guide (OM06179U) Workshop Manual

51
ES300h_QG_OM06179U_(U)
Search by city ( )
4Select “City”.
5Enter a city name and select “Search”.
“Last 5 Cities”: Select the desired city name from the list of the last 5 cities.
6Select the desired city name.
7Enter a street name and select “Search”.
8Select the desired street name.
9Enter a house number and select “Search”.
Search by street address ( )
4Select “Street Address”.
5Enter a house number and select “Search”.
6Enter a street name and select “Search”.
7Select the desired street name.
8Enter a city name and select “Search”.
9Select the desired city name.
B
C

52
ES300h_QG_OM06179U_(U)
■Search by point of interest
There are 3 methods to search for a destination by Point of Interest.
1Display the destination search screen by either operation:
●“MAP” button 
●“MENU” button  “Destination”
2Select “Point of Interest”.
3Select the desired search method.
Select to change the search area.
Select to search by name.
Select to search by category.
Select to search by phone number.
Search by name ( )
4Select “Name”.
5Enter a POI name and select “Search”.
6Select the desired POI.
A
B
C
D
B

53
ES300h_QG_OM06179U_(U)
Search by category ( )
4Select “Category”.
5Select the desired search point.
Select to search for POIs near your
current position.
Select to search for POIs along the set
route.
Select to search for POIs near a spe-
cific city center.
Select to search for POIs near a desti-
nation. When more than 1 destination
has been set, a list will be displayed on
the screen. Select the desired destina-
tion.
6Select the desired POI category.
7Select the desired POI.
Search by phone number ( )
4Select “Phone #”.
5Enter a phone number and select “OK”.
C
A
B
C
D
D

54
ES300h_QG_OM06179U_(U)
To use the hands-free system, it is necessary to register a Bluetooth® phone with the system.
Refer to http://www.lexus.com/MobileLink
to find approved Bluetooth® phones for this
system.
1Turn the Bluetooth® connection setting of your cellular phone on.
2Press the “MENU” button on the Remote Touch.
3Select “Phone”.
4Select “Yes” to register a phone.
5Select the desired Bluetooth® device.
6Register the Bluetooth® device using your Bluetooth® device.
7Check that the following screen is dis-
played, indicating pairing was success-
ful.
●The system is connecting to the regis-
tered device.
●At this stage, the Bluetooth
® functions
are not yet available.
8Check that “Connected” is displayed
and registration is complete.
Hands-free System For Cellular Phone
Registering/connecting Bluetooth® device

55
ES300h_QG_OM06179U_(U)
1Display the phone settings screen:
●“MENU” button  “Setup”  “Phone” on the sub menu
2Select “Contacts/Call History”.
3Select “Transfer Contacts from
Device”.
4Select “From Phone (Bluetooth)”.
5Transfer the contact data to the system
using a Bluetooth
® phone.
6Check that a confirmation screen is
displayed when the operation is com-
plete.
Contacts transfer
Depending on the type of Bluetooth® phone, certain functions may not be available.

56
ES300h_QG_OM06179U_(U)
1Display the phone settings screen:
●“MENU” button  “Setup”  “Phone” on the sub menu
2Select “Contacts/Call History”.
3Select “Add Favorite”.
4Select the desired contact to add to the
favorites list.
5Check that a confirmation screen is
displayed when the operation is com-
plete.
1Press the “MENU” button on the Remote Touch.
2Select “Phone”.
3Select “Favorites” on the sub menu and select the desired contact.
4Select the desired number.
5Check that the dialing screen is displayed.
1Display the message screen:
●“MENU” button  “Phone”  “Message” on the sub menu
2Select a desired account name that is displayed on the left side of screen.
3Select the desired message from the list.
4Select , or press the switch on the steering wheel.
5Check that the dialing screen is displayed.
Registering the contacts in the favorites list
Calling by favorites list
Calling the message sender

57
ES300h_QG_OM06179U_(U)
Select “Answer” or press the switch on the steering wheel to talk on the phone.
“Decline”: Select to refuse to receive the call.
TEL switch
• Start talking
• End talking
•End dialing
• If the switch is pressed when an
Apple CarPlay connection is estab-
lished, the Apple CarPlay phone
application will be displayed on the
system screen.*
Volume control switch
• Press the “+” side to increase the volume.
• Press the “-” side to decrease the volume.
Talk switch
• Press the talk switch to start the voice command system.
• To cancel voice recognition, press and hold the talk switch.
*:If equipped
Receiving a call
Main displaySide display (12.3-inch display model)
Steering switches
A
B
C

58
ES300h_QG_OM06179U_(U)
The audio control screen can be reached by the following methods:
Using the audio control switch
Press the “RADIO” or “MEDIA” button.
Using the Remote Touch (12.3- inch display model)
Press the “MENU” button on the Remote Touch, then select “Audio”.
Using the Remote Touch (8-inch display model)
Press the “MENU” button on the Remote Touch, then select “Radio”, “Media” or “Audio”.
Using the audio control switch
1Press the “RADIO” or “MEDIA” button.
2Each time the “RADIO” or “MEDIA”
button is pressed, the audio source
changes.
“RADIO” button: To change radio
modes.
“MEDIA” button: To change media
modes.
From the audio source selection screen
1Display the audio control screen.
2Select “Source” on the sub menu.
3Select the desired source.
Audio System
Audio control screen
Selecting an audio source

59
ES300h_QG_OM06179U_(U)
Some parts of the audio/visual system can be adjusted using the switches on the steering
wheel.
Volume control switch
“MODE” switch
switch
■Volume control switch
●Press: Volume up/down
●Press and hold (0.8 sec. or more): Volume up/down continuously
■“MODE” switch
AM, FM, SXM
●Press: Change audio modes
●Press and hold (0.8 sec. or more): Mute
*1 (Press and hold again to resume the sound.)
AUX
●Press: Change audio modes
●Press and hold (0.8 sec. or more): Mute
CD, MP3/WMA/AAC disc, DVD
*2, USB*3, iPod, Bluetooth® audio*3, APPS*3
●Press: Change audio modes
●Press and hold (0.8 sec. or more): Pause
*1: If cached radio is enabled, pressing and holding the “MODE” switch pauses the broad-
cast. (Press and hold again to play back the cached radio program.)
*2: 12.3-inch display model
*3: When an Apple CarPlay connection is established, this function will be unavailable.
Steering switch operation
A
B
C

60
ES300h_QG_OM06179U_(U)
■ switch
AM, FM, HD
●Press: Preset station up/down
●Press and hold (0.8 sec. or more): Seek up/down
●Press and hold (1.5 sec. or more): Seek up/down continuously while the switch is being
pressed
SXM
●Press: Preset channel up/down
●Press and hold (0.8 sec. or more): Seek for stations in the relevant program type/channel
category
●Press and hold (1.5 sec. or more): Seek for the channel while the switch is being pressed
CD
●Press: Track up/down
●Press and hold (0.8 sec. or more): Fast forward/rewind
MP3/WMA/AAC disc
●Press: File up/down
●Press and hold (0.8 sec. or more): Fast forward/rewind
DVD
*1
●Press: Chapter up/down
●Press and hold (0.8 sec. or more): Fast forward/rewind
USB
*2
●Press: File/Track up/down
●Press and hold (0.8 sec. or more): Fast forward/rewind
iPod
●Press: Track up/down
●Press and hold (0.8 sec. or more): Fast forward/rewind
Bluetooth
® audio*2
●Press: Track up/down
●Press and hold (0.8 sec. or more): Fast forward/rewind
*1: 12.3-inch display model
*2: When an Apple CarPlay connection is established, this function will be unavailable.
