IN CASE OF AN EMERGENCY
326
5. Position the jack at the jack points as shown.
Rotate the load rest 90 from storage position to
lifting position.
Make sure the jack is positioned on a level and solid
surface.6. After making sure no one is in the vehicle, raise
it high enough so that the spare tire can be
installed.
Allow for the fact that you need more ground
clearance when putting on the spare tire than when
removing the flat tire.
To raise the vehicle, insert the jack handle into the
jack (it is a loose fit) and turn it clockwise. As the
jack touches the vehicle and begins to lift,
double-check that it is properly positioned.
CAUTION
Never get under the vehicle when the vehicle
is supported by the jack alone.
