802
ES350 300h_OM_OM33A01U_(U)
7-2. Steps to take in an emergency
If the electronic key does not operate properly
■Doors
Use the mechanical key
(P. 120) in order to perform
the following operations:
Locks all the doors
Closes the windows and moon
roof (turn and hold)
*
Unlocks the door
Turning the key rearward unlocks
the driver’s door. Turning the key
once again within 5 seconds
unlocks the other doors.
Opens the windows and moon
roof (turn and hold)
*
*
: This setting must be customized at your Lexus dealer.
If communication between the ele ctronic key and vehicle is inter-
rupted ( P. 130) or the electronic key cannot be used because the
battery is depleted, the smart access system with push-button start and
wireless remote control cannot be us ed. In such cases, the doors and
trunk can be opened and the engine can be started by
following the procedure below.
Locking and unlocking the doors, unlocking the trunk and key
linked functions
1
2
3
4

8077-2. Steps to take in an emergency
ES350 300h_OM_OM33A01U_(U)
7
When trouble arises
■When recharging or replacing the 12-volt battery
●Make sure the key is not inside the vehicle when recharging or replacing the 12-volt
battery to prevent the doors from being locked with the key left inside the vehicle
when the alarm operates.
●In some cases, it may not be possible to unlock the doors using the smart access
system with push-button start when the 12-volt battery is discharged. Use the wire-
less remote control or the mechanical key to lock or unlock the doors.
●The engine may not start on the first atte mpt after the 12-volt battery has recharged
but will start normally after the second attempt. This is not a malfunction.
●The “START STOP ENGINE” switch mode is memorized by the vehicle. When the
12-volt battery is reconnected, the system will return to the mode it was in before
the 12-volt battery was discharged. Before disconnecting the 12-volt battery, turn
the “START STOP ENGINE” switch off.
If you are unsure what mode the “START STOP ENGINE” switch was in before the
12-volt battery discharged, be especially careful when reconnecting the 12-volt
battery.
CAUTION
■Avoiding 12-volt battery fires or explosions
Observe the following precautions to prev ent accidentally igniting the flammable
gas that may be emitted from the 12-volt battery:
●Make sure each jumper cable is connected to the correct terminal and that it is
not unintentionally in contact with any other than the intended terminal.
●Do not allow the other end of the jumper cable connected to the “+” terminal to
come into contact with any other parts or metal surfaces in the area, such as
brackets or unpainted metal.
●Do not allow the + and - clamps of the jumper cables to come into contact with
each other.
●Do not smoke, use matches, cigarette lighters or allow open flame near the 12-
volt battery.

8117-2. Steps to take in an emergency
ES350 300h_OM_OM33A01U_(U)
7
When trouble arises
■Starting the hybrid system when the 12-volt battery is discharged
The hybrid system cannot be started by push-starting.
■To prevent 12-volt battery discharge
●Turn off the headlights and the audio system while the hybrid system is off.
●Turn off any unnecessary electrical components when the vehicle is running at a
low speed for an extended period, such as in heavy traffic.
■Charging the 12-volt battery
The electricity stored in the 12-volt battery will discharge gradually even when the
vehicle is not in use, due to natural discharge and the draining effects of certain elec-
trical appliances. If the vehicle is left for a long time, the 12-volt battery may dis-
charge, and the hybrid system may be unable to start. (The 12-volt battery recharges
automatically while the hybrid system is operating.)
■When recharging or replacing the 12-volt battery
●Make sure the key is not inside the vehicl e when recharging or replacing the 12-volt
battery to prevent the doors from being locked with the key left inside the vehicle
when the alarm operates.
●In some cases, it may not be possible to unlock the doors using the smart access
system with push-button start when the 12-volt battery is discharged. Use the wire-
less remote control or the mechanical key to lock or unlock the doors.
●The hybrid system may not start on the fir st attempt after the 12-volt battery has
recharged but will start normally after the second attempt. This is not a malfunction.
●The “POWER” switch mode is memorized by the vehicle. When the 12-volt battery
is reconnected, the system will return to the mode it was in before the 12-volt bat-
tery was discharged. Before disconnectin g the 12-volt battery, turn the “POWER”
switch off.
If you are unsure what mode the “POWER” switch was in before the 12-volt battery
discharged, be especially careful when reconnecting the 12-volt battery.

856
ES350 300h_OM_OM33A01U_(U)
8-2. Customization
■Smart access system with push-button start (P. 123) and wireless
remote control ( P. 136)
FunctionDefault
settingCustom-
ized setting
“Lock/Unlock Feedback-
To n e ”
(Adjust the volume of
buzzer sounds)
5
Off
O—O—OO1 to 7
“Lock/Unlock Feedback-
Lights”
(Enable/disable the opera-
tion of the emergency
flashers when the vehicle is
locked or unlocked)
OnOffO—O—OO
“A u t o R e l o c k Ti m e r ”
(Adjust the time elapsed
before the automatic door
lock function is activated if
a door is not opened after
being unlocked)
60 seconds
Off
O—O—OO
30 seconds
120
seconds
Operation buzzer (When
the vehicle is locked or
unlocked)
OnOff—————O
Open door reminder
buzzer (When locking the
vehicle)
OnOff—————O
123456

ES350 300h_OM_OM33A01U_(U)
8578-2. Customization
8
Vehicle specifications
■Smart access system with push-button start (P. 1 2 3 )
■Wireless remote control (P. 136)
FunctionDefault
settingCustom-
ized setting
“Access System with Elec.
Key”
(Smart access system with
push-button start can be
disabled)
OnOff——O—OO
“Select Doors to Unlock”
(The doors that are
unlocked using the smart
access system with push-
button start can be
selected)
Driver’s doorAll the doorsO—O—OO
Number of consecutive
door lock operations2 timesAs many as desired—————O
123456
FunctionDefaultsettingCustom-
ized setting
Wireless remote controlOnOff—————O
“Remote 2-Press Unlock”
(Allows all doors to be
unlocked by pressing on the electronic
key twice)
On
(Driver’s door
unlocked in
one step, all doors
unlocked in two steps)
Off (All doors
unlocked in one step)
O—O—OO
Trunk unlocking operationPress and
hold (short)
One short press
—————OPush twice
Press and
hold (long)
Off
Alarm (panic mode)OnOff—————O
123456

864
ES350 300h_OM_OM33A01U_(U)
8-2. Customization
■Vehicle customization
●When the “Auto Lock by Speed” and “Auto Lock by Shift from P” are both on, the
door lock operates as follows.
• When shifting the shift lever to any position other than P, all the doors will be
locked.
• If the vehicle is started with all the door s locked, the “Auto Lock by Speed” would
not operate.
• If the vehicle is started with any door unlocked, the “Auto Lock by Speed” will operate.
●When the smart access system with push-b utton start is off, the “Select Doors to
Unlock” cannot be customized.
●When the doors remain closed after un locking the doors and the “Auto Relock
Timer” activates, the signals will be generated in accordance with the “Lock/
Unlock Feedback-Tone” and the “Lock/Unlock Feedback-Lights” settings.
■When customizing using the Remote Touch
Stop the vehicle in a safe place, apply the parking brake, and shift the shift lever to P.
Also, to prevent 12-volt battery discharge, leave the engine running
while customizing the features.
CAUTION
■During customization
As the engine needs to be running during customiza-
tion, ensure that the vehicle is parked in a place with adequate ventilation. In a
closed area such as a garage, exhaust gases including harmful carbon monoxide
(CO) may collect and enter the vehicle. This may lead to death or a serious health
hazard.
NOTICE
■During customization
To prevent 12-volt battery discharge, ensure that the engine is run-
ning while customizing features.

895Alphabetical index
ES350 300h_OM_OM33A01U_(U)
I/M test ..................................................... 664
IdentificationEngine ..................................................... 826
Vehicle ................................................... 825
Ignition switch (“POWER” switch) .................................................... 204
Ignition switch (“START STOP ENGINE” switch) ............................... 197
Illuminated entry system .................... 605
Immobilizer system ........................ 80, 82
Indicators ......................................................91
Initialization Maintenance........................................ 658
Tire pressure warning system............................... 695
Initiators (tire pressure warning system)...................................701
Inside rear view mirror .........................164
Instrument panel light control ............ 94
Interior light............................................. 603
Intuitive parking assist Function .................................................... 271
Warning message .................763, 770 Jack
Positioning a floor jack.................... 670
Vehicle-equipped jack ................... 785
Jack handle ................................................. 785
Jam protection function Moon roof ............................................... 175
Power trunk opener and closer ............................................146
Power windows...................................... 171
Keyless entry Smart access system with push-button start.................... 123
Wireless remote control..................136
Keys Battery-saving function .................... 129
Electronic key ........................................120
Engine switch ............................197, 204
If the electronic key does not operate properly ........802
Key number plate ................................120
Keyless entry ............................... 123, 136
Mechanical key.....................................120
“Power” switch .................................... 204
Replacing the battery ........................710
“START STOP ENGINE” switch ..................................................... 197
Warning buzzer................................... 127
Wireless remote control key .........136
Knee airbags ............................................. 38
IJ
K
*: For vehicles with a navigation system, refer to the “Navigation System Owner’s Manual”.

903Alphabetical index
ES350 300h_OM_OM33A01U_(U)
TiresChains..................................................... 328
Checking............................................... 694
If you have a flat tire ..........................784
Inflation pressure ............................... 835
Information ........................................... 840
Replacing ...............................................784
Rotating tires ....................................... 694
Size ........................................................... 835
Snow tires ............................................. 330
Spare tire ................................................784
Tire inflation pressure display function ................................................... 101
Tire pressure warning system .... 695
Warning light .......................................755
Warning message ............................. 775
Tools........................................................... 785
Top tether strap........................................ 66
Total load capacity .................................194
Towing Dinghy towing ...................................... 196
Emergency towing ............................ 743
Towing eyelet.......................................745
Trailer towing ........................................ 195
TRAC (Traction Control) ................. 298
Traction battery (hybrid battery) .......74
Traction motor (electric motor) .........74
Transmission Automatic transmission ....................214
Driving mode select switch ..........296
Hybrid transmission............................ 217
If the shift lever cannot be shifted from P ....................................801
Trip information........................................ 99
Trip meters ................................................. 93 Trunk
Internal trunk release lever ............. 147
Jam protection function....................146
Luggage security system.................145
Open trunk warning message.... 767
Power trunk opener and closer ... 144
Smart access system with push-button start.................... 124
Trunk closer switch.............................145
Trunk easy closer ................................146
Trunk features........................................ 612
Trunk handle ..........................................145
Trunk light................................................146
Trunk opener main switch ..............145
Trunk opener switch .......................... 144
Trunk storage extension ................ 626
Wireless remote control..................136
Trunk light Trunk light................................................146
Wattage .................................................836
Turn signal lights Replacing light bulbs ........... 730, 734
Turn signal lever ................................... 221
Wattage .................................................836
USB memory ............................... 413, 532
U
*: For vehicles with a navigation system, refer to the “Navigation System Owner’s Manual”.
