TABLE OF CONTENTS4
ES350_OM_OM33B64U_(U)
5-1. Basic OperationsLexus Display Audio System ......................................... 266
Steering wheel audio switches .......................................273
USB/AUX ports .......................... 274
5-2. Setup Setup menu ................................... 276
General settings.......................... 277
Voice settings ................................281
Display settings ........................... 282
5-3. Using the audio system Selecting the audio source .......................................... 284
Optimal use of the audio system .......................................... 285
Audio settings ............................. 286
Audio menu screen operation .................................... 289
5-4. Using the radio Radio operation.......................... 292
5-5. Playing an audio CD and MP3/WMA/AAC discs
CD player operation ................ 299
5-6. Using an external device Listening to an iPod ................... 306
Using USB memory device ........................................... 310
Using the AUX port ...................314 5-7. Connecting Bluetooth
®
Steps for using Bluetooth®
devices ..........................................315
Registering a Bluetooth
®
device ............................................ 317
Selecting a Bluetooth
®
device ........................................... 318
Connecting a Bluetooth
®
audio player ................................319
Connecting a Bluetooth
®
phone ........................................... 320
Displaying a Bluetooth
®
device details ..............................321
Detailed Bluetooth
®
settings ........................................ 322
5-8. Bluetooth
® Audio
Listening to Bluetooth
®
Audio ........................................... 323
5-9. Bluetooth
® Phone
Using a Bluetooth
®
Phone........................................... 325
Making a call.................................327
Receiving a call ........................... 330
Speaking on the phone .............331
Using a Bluetooth
®
phone message ....................... 334
Using the steering wheel switches ...................................... 336
Bluetooth
® phone
settings .........................................337
5Lexus Display Audio system

5
ES350_OM_OM33B64U_(U)
1
9 8
7 4 3
2
10
5
6
5-10. PhonebookContact settings ......................... 339
Messaging setting ..................... 342
5-11. Bluetooth
®
What to do if... (Troubleshooting) ................... 343
Bluetooth
®................................... 346
5-12. Other function “Information” screen...................351
USB photo .................................... 353
Weather information ................ 355
Voice command system .......... 356
Mobile Assistant......................... 360
LEXUS Enform Remote ......... 362
6-1. Using the air conditioning system and defogger
Automatic air conditioning system .......................................... 364
Heated steering wheel/ seat heaters/seat
ventilators....................................373
6-2. Using the interior lights Interior lights list ..........................375• Interior lights ........................... 376
• Personal lights ........................ 376 6-3. Using the storage features
List of storage features .............378• Glove box ................................379
• Console box ...........................379
• Cup holders ...........................380
• Auxiliary box........................... 381
Trunk features .............................. 382
6-4. Using the other interior features
Other interior features ............ 384 • Sun visors ................................ 384
• Vanity mirrors ........................ 384
• Clock ........................................385
• Power outlets .........................385
• Armrest.................................... 386
•Rear sunshade/rear door sunshades ............................... 387
•Trunk storage extension ................................. 389
• Coat hooks............................. 390
• Assist grips ............................. 390
Garage door opener ................ 391
Compass ....................................... 398
LEXUS Enform Safety Connect...................................... 402
6Interior features

264
ES350_OM_OM33B64U_(U)
5-1. Basic OperationsLexus Display Audio System ......................................... 266
Steering wheel audio switches........................................273
USB/AUX ports .......................... 274
5-2. Setup Setup menu ................................... 276
General settings ..........................277
Voice settings ............................... 281
Display settings ........................... 282
Lexus Display Audio system
5

265
ES350_OM_OM33B64U_(U)
Lexus Display Audiosystem
5
5-3. Using the audio system
Selecting the audio source ..........................................284
Optimal use of the audio system ......................................... 285
Audio settings ..............................286
Audio menu screen operation ....................................289
5-4. Using the radio Radio operation .......................... 292
5-5. Playing an audio CD and MP3/WMA/AAC discs
CD player operation.................299
5-6. Using an external device Listening to an iPod .................. 306
Using USB memory device ............................................ 310
Using the AUX port................... 314
5-7. Connecting Bluetooth
®
Steps for using Bluetooth®
devices .......................................... 315
Registering a Bluetooth
®
device ............................................ 317
Selecting a Bluetooth
®
device ............................................ 318
Connecting a Bluetooth
®
audio player ................................ 319
Connecting a Bluetooth
®
phone .......................................... 320
Displaying a Bluetooth
®
device details ............................. 321
Detailed Bluetooth
®
settings.........................................322 5-8. Bluetooth
® Audio
Listening to Bluetooth
®
Audio ........................................... 323
5-9. Bluetooth
® Phone
Using a Bluetooth
®
Phone ........................................... 325
Making a call ................................ 327
Receiving a call ...........................330
Speaking on the phone............. 331
Using a Bluetooth
®
phone message........................ 334
Using the steering wheel switches....................................... 336
Bluetooth
® phone
settings ........................................ 337
5-10. Phonebook Contact settings ......................... 339
Messaging setting...................... 342
5-11. Bluetooth
®
What to do if... (Troubleshooting)....................343
Bluetooth
®................................... 346
5-12. Other function “Information” screen .................. 351
USB photo .................................... 353
Weather information ................ 355
Voice command system .......... 356
Mobile Assistant.........................360
LEXUS Enform Remote ......... 362

273
ES350_OM_OM33B64U_(U)5-1. Basic Operations
5
Lexus Display Audio system
Steering wheel audio switches
Volume switch
• Press: Increases/decreases vol- ume
• Press and hold: Continuously increases/decreases volume
Radio mode: • Press: Selects a radio station
• Press and hold: Seeks up/down
CD, MP3/WMA/AAC disc, Bluetooth
®, iPod or USB mode:
• Press: Selects a track/file/video
• Press and hold: Scrolls up/down tracks/files/videos (MP3/WMA/AAC disc, iPod or USB)
“MODE” switch • Press: Turns the power on, selects audio source
• Press and hold this switch to mute or pause the current operation. To can- cel the mute or pause, press and hold.
Some audio features can be controlled using the switches on the steering
wheel.
Operation may differ depending on th e type of audio system or navigation
system. For details, refer to the manual provided with the audio system or nav-
igation system.
Operating the audio system us ing the steering wheel switches
1
2
WA R N I N G
■To reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.
3

274
ES350_OM_OM33B64U_(U)5-1. Basic Operations
USB/AUX ports
Push the knob to release the lock,
and lift the armrest to open fully.
Open the cover.
■iPod
Open the cover and connect an
iPod using an iPod cable.
Turn on the power of the iPod if it is not turned on.
■USB memory
Open the cover and connect the USB memory device.
Turn on the power of the USB memory device if it is not turned on.
■Portable audio player
Open the cover and connect the portable audio player.
Turn on the power of the portable audio player if it is not turned on.
Connect an iPod, USB memory device or portable audio player to the USB/
AUX port as indicated below. Select “iPod”, “USB”, “AUX” or “A/V” on the
audio source selection screen and the device can be operated via Lexus Display
Audio system.
Connecting using the USB/AUX port
1
2

ES350_OM_OM33B64U_(U)
2755-1. Basic Operations
5
Lexus Display Audio system
To view a video on an iPod video or VTR, it is necessary to use a 4-pole AUX
cable to connect the portable audio device.
When connecting a portable audio device to the AUX port, use a 4-pole AUX
cable with a plug that matches the exact layout shown in the illustration.Connected device (portable
audio device, etc.)
Left audio
Right audio
Ground
Video
When using an iPod video, a cable
that has a 4-pole AUX plug and a
USB connector is necessary. Con-
nect the plug and connector to the
AUX and USB ports.
■When using a 4-pole AUX cable
If a 4-pole AUX cable with a different layout is used, audio and/or video may not be out-
put properly.
Using a 4-pole AUX cable
1
2
3
4
5
WA R N I N G
■While driving
Do not connect a device or operate the device controls.
NOTICE
■If the armrest cannot be fully closed
Depending on the size and shape of the USB memory that is connected to the system,
the armrest may not close fully. In this case, do not forcibly close the armrest as this may
damage the USB memory or the terminal, etc.

2785-2. Setup
ES350_OM_OM33B64U_(U)
Go to “Customize Images”: “MENU” button  “Setup”  “General” 
“Customize Images”
Select “Set Images” and then select the desired image.
Set as startup image.
Set as screen off image.
Set as startup image and screen
off image.
■Adding an imageConnect a USB memory device. ( P. 2 74 )
Select “Copy from USB” on the “Customize Images” screen and then
select the desired image.
Move the controller to the left and then select “Copy”.
Up to 10 images can be downloaded.
■Deleting images
Select “Delete Images” on the “Customize Images” screen and then select the
desired images.
Customizing images
1
2
1
2
3
1
2
3

ES350_OM_OM33B64U_(U)
2795-2. Setup
5
Lexus Display Audio system
■USB memory
When saving the images to a USB memory device, name the folder that the images are
saved to “Image”.
●Compatible device formats
The following device format can be used: • USB communication format: USB2.0 FS (480 Mbps)
• File system format: FAT16/32 (Windows)
• Correspondence class: Mass storage class
The following types of files can be used:
• The image’s file format must be JPEG.
• The file name may only contain ASCII characters.
●JPEG file compatibility
Compatible image size: Maximum 5MB
NOTICE
■To prevent damage to the USB memory device or its terminals
 P. 3 1 3

286
ES350_OM_OM33B64U_(U)5-3. Using the audio system
Audio settings
Go to “Audio Settings”: “MENU” button
 “Setup”  “Audio”
Change radio settings ( P. 2 8 6 )
Change iPod settings ( P. 2 8 7 )
Change A/V settings ( P. 2 8 7 )
Change the cover art settings
( P. 288)
Change USB settings ( P. 288)
To change radio settings, select “Radio Settings” on the “Audio Settings” screen
or radio menu screen. ( P. 2 8 9 )
Set the displaying RBDS text mes-
sage on/off
Change the number of radio presets
Screen for audio settings
1
2
3
4
5
Changing radio settings
1
2
