Lexus ES350 2020 / LEXUS 2020 ES350 THROUGH SEPT. 2019 PROD. QUICK GUIDE (OM06176U) Owner's Guide
Manufacturer: LEXUS, Model Year: 2020, Model line: ES350, Model: Lexus ES350 2020Pages: 94, PDF Size: 1.92 MB
Page 31 of 94
31
ES350_QG_OM06176U_(U)
■Tachometer
Displays the engine speed in revolutions per minute.
■Eco Driving Indicator
Eco Driving Indicator Zone Display
Eco driving ratio based on accelera-
tion
Zone of Eco driving
Displayed content is the same as that
displayed on the multi-information dis-
play (Eco Driving Indicator).
Tachometer/Eco Driving Indicator display area
A
B
C
The head-up display may seem dark or hard to see when viewed through sunglasses,
especially polarized sunglasses. Adjust the brightness of the head-up display or remove
your sunglasses.
Page 32 of 94
32
ES350_QG_OM06176U_(U)
U.S.A.
Canada
1 The side marker, parking, tail,
license plate and instrument panel
lights, and daytime running lights turn
on.
2 The headlights an d all the lights
listed above (except daytime running
lights) turn on.
3 The headlights, daytime running
lights and all the lig hts listed above turn
on and off automatically.
4 (U.S.A.) Off
(Canada) The daytime running
lights turn on.
1With the headlights on, push the lever
away from you to turn on the high
beams.
Pull the lever toward you to the center
position to turn the high beams off.
2Pull the lever toward you and release it
to flash the high beams once.
You can flash the high beams with the
headlights on or off.
Headlights
A
B
Turning on the high beam headlights
Page 33 of 94
33
ES350_QG_OM06176U_(U)
1Press the Automatic High Beam
switch.
2Push the lever away from you with the
headlight switch in the or
position.
The Automatic High Beam indicator
will come on when the headlights are
turned on automatically to indicate that
the system is active.
Automatic High Beam
The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of
streetlights, the lights of vehicle ahead, etc., and automatically turns the high beam on or
off as necessary.
Activating the Automatic High Beam system
Page 34 of 94
34
ES350_QG_OM06176U_(U)
■Switching to low beam
Pull the lever to the original position.
The Automatic High Beam indicator will
turn off.
Push the lever away from you to activate the
Automatic High Beam system again.
■Switching to high beam
Press the Automatic High Beam switch.
The Automatic High Beam indicator will
turn off and the high beam indicator will
turn on.
Press the switch to activate the Automatic
High Beam system again.
Turning the high beam on/off manually
Page 35 of 94
35
ES350_QG_OM06176U_(U)
Intermittent windshield wipe rs with interval adjuster
1*1 or *2 Off
2
*1 or *2 Intermittent
operation
The intermittent windshield wiper
operates more frequently as vehicle
speed becomes higher.
3*1 or *2 Low speed oper-
ation
4*1 or *2 High speed
operation
5*1 or *2 Temporary oper-
ation
*1: For U.S.A.
*2:For Canada
Wiper intervals can be adjusted when inter-
mittent operation is selected.
6Increases the interm ittent windshield
wiper frequency
7Decreases the intermittent windshield
wiper frequency
8 Washer/wiper dual operation
Pulling the lever op erates the wipers
and washer.
The wipers will automatically operate a
couple of times after the washer
squirts. (After oper ating several times,
the wipers operate once more time
after a short delay to prevent dripping.
However, the dripping prevention does
not operate while the vehicle is mov-
ing.)
Windshield Wipers and Washer
Page 36 of 94
36
ES350_QG_OM06176U_(U)
Rain-sensing windshield wipers
1*1 or *2 Off
2AUTO Rain-sensing operation
3*1 or *2 Low speed opera-
tion
4*1 or *2 High speed opera-
tion
5*1 or *2 Temporary opera-
tion
*1: For U.S.A.
*2:For Canada
When “AUTO” is selected, the sensor sensi-
tivity can be adjusted by turning the switch
ring.
6Increases the sensitivity
7Decreases the sensitivity
8 Washer/wiper dual operation
Pulling the lever operates the wipers
and washer.
The wipers will automatically operate a
couple of times after the washer
squirts.
(After operating seve ral times, the wip-
ers operate once more time after a
short delay to prevent dripping. How-
ever, the dripping prevention does not
operate while the vehicle is moving.)
Page 37 of 94
37
ES350_QG_OM06176U_(U)
“MAP” button*1
Press this button to display the current location.
“HOME” button
*2
Press this button to display the home screen.
“MENU” button
Press this button to display the menu screen.
Back button
Press this button to display the previous screen.
Remote Touch
The Remote Touch can be used to operate the Center Display.
Remote Touch is the name for the device that includes the “MAP” (“HOME”) button,
“MENU” button, back button, touchpad and sub function button.
Names and operations of each part
A
B
C
D
Page 38 of 94
38
ES350_QG_OM06176U_(U)
Touchpad
Slide your finger on the touchpad and move the pointer to select a function, letter and
screen button.
Press the touchpad to enter the selected function, letter or screen button. Certain fin-
ger movements on the touchpad can perform functions, such as changing map scalings
and scrolling list screens.
Sub function button
When is displayed on the screen, a function screen assigned to the screen can be
displayed.
*1: 12.3-inch display model
*2:8-inch display model
E
F
Page 39 of 94
39
ES350_QG_OM06176U_(U)
Press the “MENU” button on the Remote Touch to display the menu screen.
12.3-inch display model
Select to display the destination screen. ( P.46)
Select to display the audio control screen. ( P.54)
Select to display the ha nds-free control screen.
*1, 2 ( P.50)
Select to display the “Apps” screen.
*1, 2
When an Apple CarPlay connection is established and this button displays “Apple Car-
Play”, select to di splay the home screen of Apple CarPlay.
*1, 3
Select to display the fuel consumption screen. ( P.44)
Select to display the general settings screen.
*3, 4
Select to display the air conditioning control screen. ( P.63)
*1: This function is not made availa ble in some countries or areas.
*2:The Lexus Enform App Suite 2.0 screen may not be displayed when an Apple CarPlay
connection is established.
*3: Refer to the “NAVIGATION AND MU LTIMEDIA SYSTEM OWNER’S MANUAL”.
*4: Refer to the “OWNER’S MANUAL”.
Menu screen
A
B
C
D
E
F
G
H
Page 40 of 94
40
ES350_QG_OM06176U_(U)
8-inch display model (Type A)
Select to display the radio control screen. ( P.54)
Select to display the media control screen. ( P.54)
Select to display the hands-free control screen. ( P.50)
Select to display the “Apps” screen.
*1
Select to display the fuel consumption screen. ( P.44)
Select to display the ge neral settings screen.
*2, 3
Select to display the air co nditioning control screen. ( P.63)
Select to adjust the contrast and brightness of the screens, turn the screen off, etc.
*2
*1: This function is not made availa ble in some countries or areas.
*2: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
*3: Refer to the “OWNER’S MANUAL”.
A
B
C
D
E
F
G
H
