audio Lexus ES350 2020 Owner's Manual / LEXUS 2020 ES350 THROUGH SEPT. 2019 PROD. OWNER'S MANUAL QUICK GUIDE (OM06176U)

1
ES350_QG_OM06176U_(U)
Air Conditioning System*
Control panel .................................................................................................................................. 62
Main control screen............................................................................................................ ..........63
Option control screen .......................................................................................................... ....... 64
Side display................................................................................................................... ....................65
Using automatic mode ........................................................................................................... .....65
Audio System
*
Audio control screen ........................................................................................................... ........54
Selecting an audio source ...................................................................................................... ....54
Steering switch operation ...................................................................................................... ....55
Radio ................................................................................................................................................... 57
CD....................................................................................................................................................... 58
DVD ....................................................................................................................................................59
iPod/iPhone .....................................................................................................................................60
Automatic High Beam........................................................................................................... 3 3
Automatic Transmission ......................................................................................................... 19
Brake Hold ..................................................................................................................... ............25
Door Locks ..................................................................................................................... .......... 84
Engine (Ignition) Switch ....................................................................................................... ... 16
Floor Mat Installation ......................................................................................................... ...... 11
Front Seats .................................................................................................................... ..............15
Fuel Consumption Screen ...................................................................................................44
Garage Door Opener............................................................................................................ 75
Hands-free System For Cellular Phone
*
Registering/connecting Bluetooth® device ..................................................................... 50
Contacts transfer .............................................................................................................. .............. 51
Registering the contacts in the favorites list .... ...................................................................52
Calling by favorites list ...................................................................................................... ...........52
Calling the message sender..................................................................................................... .52
Receiving a call ............................................................................................................... ................53
Steering switches .............................................................................................................. .............53
Contents
The Quick Guide is not intended as a substitute for yourOWNER’S MANUAL. We strongly encourage you to review
the OWNER’S MANUAL and supplementary manuals so you
will have a better understanding of your vehicle’s capabilities
and limitations.

4
ES350_QG_OM06176U_(U)
Parking brake switch ............................................................................................... P.23
Applying/releasing..............................................................................................................P.23
Precautions against winter season
*1
Warning buzzer/message*1
Turn signal lever ........................................................................................................ P.22
Headlight switch ....................................................................................................... P.32
Headlights/parking lights/tai l lights/daytime running lights .............................P.32
Automatic High Beam .......................................................................................................P.33
Windshield wiper and washer switch ................................................................. P.35
Usage .......................................................................................................................... ..............P.35
Adding washer fluid
*1
Warning messages*1
Emergency flasher switch*1
Hood lock release lever*1
Tilt and telescopic steering control switch/tilt and telescopic steering lock
release lever
*1
Adjustment*1
Driving position memory*1, 2
Air conditioning system .......................................................................................... P.62
Usage .......................................................................................................................... ..............P.63
Rear window defogger ...................................................................................................... P.62
Audio system.............................................................................................................. P.54
Trunk opener main switch
*1
*1: Refer to the “OWNER’S MANUAL”.
*2: If equipped
E
F
G
H
I
J
K
L
M

7
ES350_QG_OM06176U_(U)
Meter control switches .......................................................................................... P.28
Paddle shift switches ........................................................................................ P.20, 21
TEL switch ................................................................................................................... P.53
LTA (Lane Tracing Assist) switch
*
Vehicle-to-vehicle distance switch*
Cruise control switches*
Dynamic radar cruise control with full-speed range*
Audio remote control switches ............................................................................ P.55
Talk switch .................................................................................................................. P.53
*: Refer to the “OWNER’S MANUAL”.
A
B
C
D
E
F
G
H

17
ES350_QG_OM06176U_(U)
1Stop the vehicle completely.
2Set the parking brake (P.23), and shift the shift lever to P. ( P.19)
3Press the engine switch.
4Release the brake pedal and check that “ACCESSORY” or “IGNITION ON” is not
shown on the meter.
Modes can be changed by pressing the engine switch with the brake pedal released. (The
mode changes each time the switch is pressed.)
1Off*
The emergency flashers can be used.
2ACCESSORY mode
Some electrical components such as
the audio system can be used.
“ACCESSORY” will be displayed on
the meter.
3IGNITION ON mode
All electrical components can be used.
“IGNITION ON” will be displayed on
the meter.
*: If the shift lever is in a position other than
P when turning off the engine, the
engine switch will be turned to ACCES-
SORY mode, not to off.
Stopping the engine
Changing engine switch modes

27
ES350_QG_OM06176U_(U)
■Menu icons
The menu icons will be displayed by pressing or of the meter control switches.
F SPORT models: The menu icons can be displayed when the main meter is moved to the
right.
Driving information display
Select to display various drive data.
Navigation system-linked display (if equipped)
Select to display the following navigation system-linked information.
• Route guidance to destination
• Compass display (heading-up display)
Audio system-linked display
Select to enable selection of an audio source or track on the meter using the
meter control switches.
Driving support system information display
Select to display the operational status of the following systems:
• LTA (Lane Tracing Assist)
• Dynamic radar cruise cont rol with full-speed range
• RSA (Road Sign Assist) (if equipped)
Warning message display
Select to display warning messages and me asures to be taken if a malfunction is
detected.
Settings display
Select to change the meter display settings

30
ES350_QG_OM06176U_(U)
■Enabling/Disabling the head-up display
Press the head-up display switch.
■Changing settings of the head-up display
The following settings can be changed on of the multi-information display. For details,
refer to the “OWNER’S MANUAL”.
● Brightness and vertical position of the head-up display
Select to adjust the brightness or ve rtical position of the head-up display.
● Tachometer/Eco Driving Indicator
Select to display the tachometer, Ec o Driving Indicator or no content.
● Display content
Select to enable/disab le the following items:
• Route guidance to destination/street name
• Driving support system display
*
• Compass (heading-up display)
• Audio system operation status
*: Make sure to enable this display wh en using the driving support systems
● Display angle
Select to adjust the angle of the head-up display.
Using the head-up display

39
ES350_QG_OM06176U_(U)
Press the “MENU” button on the Remote Touch to display the menu screen.
12.3-inch display model
Select to display the destination screen. ( P.46)
Select to display the audio control screen. ( P.54)
Select to display the ha nds-free control screen.
*1, 2 ( P.50)
Select to display the “Apps” screen.
*1, 2
When an Apple CarPlay connection is established and this button displays “Apple Car-
Play”, select to di splay the home screen of Apple CarPlay.
*1, 3
Select to display the fuel consumption screen. ( P.44)
Select to display the general settings screen.
*3, 4
Select to display the air conditioning control screen. (  P.63)
*1: This function is not made availa ble in some countries or areas.
*2:The Lexus Enform App Suite 2.0 screen may not be displayed when an Apple CarPlay
connection is established.
*3: Refer to the “NAVIGATION AND MU LTIMEDIA SYSTEM OWNER’S MANUAL”.
*4: Refer to the “OWNER’S MANUAL”.
Menu screen
A
B
C
D
E
F
G
H

41
ES350_QG_OM06176U_(U)
8-inch display model (Type B)
Select to display the audio control screen. ( P.54)
Select to display the hands-free control sc reen. When an Apple CarPlay connection is
established, select to display the Phone app screen.
*1 (  P.50)
Select to display the “Apps” screen.
*1, 2, 3
When an Apple CarPlay co nnection is established and this button displays
“Apple CarPlay”, select to display the home screen of Apple CarPlay.
*1, 2
Select to display the fuel consumption screen. ( P.44)
Select to display the general settings screen.
*1, 4
Select to display the air conditioning control screen. ( P.63)
Select to adjust the contrast and brightness of the screens, turn the screen off, etc.
*1
*1: Refer to the “NAVIGATION AND MU LTIMEDIA SYSTEM OWNER’S MANUAL”.
*2: This function is not made available in some countries or areas.
*3:The Lexus Enform App Suite 2.0 screen may not be displayed when an Apple CarPlay
connection is established.
*4: Refer to the “OWNER’S MANUAL”
A
B
C
D
E
F
G
H

42
ES350_QG_OM06176U_(U)
Different information can be displayed on the left and right of the screen. For example, air
conditioning system screen can be displayed and operated while the fuel consumption
information screen is being displayed. The large screen on the left of the display is called the
main display, and the small screen to the right is called the side display.
The following function s can be displayed
and operated on the side display.
Navigation system ( P.46)
Audio ( P.57, 58, 59, 60)
Vehicle information ( P.45)
Air conditioning system ( P.65)
Show/hide the side display
Split-screen display (12.3-inch display model)
Side display (12.3-inch display model)
A
B
C
D
E

54
ES350_QG_OM06176U_(U)
The audio control screen can be reached by the following methods:
Using the audio control switch
Press the “RADIO” or “MEDIA” button.
 Using the Remote Touch (1 2.3-inch display model)
Press the “MENU” button on the Re mote Touch, then select “Audio”.
 Using the Remote Touch (8-inch display model)
Press the “MENU” button on the Remote Touch, then select “Radio”, “Media” or “Audio”.
 Using the audio control switch
1Press the “RADIO” or “MEDIA” button.
2Each time the “RADIO” or “MEDIA”
button is pressed, the audio source
changes.
“RADIO” button: To change radio
modes.
“MEDIA” button: To change media
modes.
 From the audio source selection screen
1Display the audio control screen.
2Select “Source” on the sub menu.
3Select the desired source.
Audio System
Audio control screen
Selecting an audio source
