3607-2. Steps to take in an emergency
Vehicle pulls heavily to one side
when driving on a level road
 Loss of brake effectiveness, spongy
feeling, pedal almost touches the
floor
Follow the procedure below to restart
the engine after the system is activated.
1Turn the engine switch to ACCES-
SORY mode or turn it off.
2 Restart the engine.Fuel pump shut off system
To minimize the risk of fuel leakage
when the engine stalls or when an
airbag inflates upon collision, the
fuel pump shut off system stops the
supply of fuel to the engine.
Restarting the engine
NOTICE
■Before starting the engine
Inspect the ground under the vehicle.
If you find that fuel has leaked onto the
ground, the fuel system has been dam-
aged and is in need of repair. Do not
restart the engine.

3707-2. Steps to take in an emergency
WARNING
As an added safety feature, your vehicle
has been equipped with a tire pressure
monitoring system (TPMS-tire pressure
warning system) that illuminates a low
tire pressure telltale (tire pressure warn-
ing light) when one or more of your tires
is significantly under-inflated. Accord-
ingly, when the low tire pressure telltale
(tire pressure warnin g light) illuminates,
you should stop and check your tires as
soon as possible, and inflate them to the
proper pressure. Driving on a signifi-
cantly under-inflated tire causes the tire
to overheat and can lead to tire failure.
Under-inflation also reduces fuel effi-
ciency and tire tread life, and may affect
the vehicle’s handling and stopping abil-
ity.
Please note that the TPMS (tire pressure
warning system) is not a substitute for
proper tire maintenance, and it is the
driver’s responsibility to maintain correct
tire pressure, even if under-inflation has
not reached the level to trigger illumina-
tion of the TPMS low tire pressure telltale
(tire pressure warning light).
Your vehicle has also been equipped
with a TPMS (tire pressure warning sys-
tem) malfunction indicator to indicate
when the system is not operating prop-
erly. The TPMS (tire pressure warning
system) malfunction indicator is com-
bined with the low tire pressure telltale
(tire pressure warnin g light). When the
system detects a malfunction, the telltale
will flash for approximately one minute
and then remain continuously illumi-
nated. This sequence will continue upon
subsequent vehicle start-ups as long as
the malfunction exists. When the mal-
function indicator is illuminated, the sys-
tem may not be able to detect or signal
low tire pressure as intended.
TPMS (tire pressure warning system)
malfunctions may occur for a variety of
reasons, including the installation of
replacement or alternate tires or wheels
on the vehicle that prevent the TPMS
(tire pressure warning system) from
functioning properly. Always check the
TPMS (tire pressure warning system)
malfunction telltale after replacing one
or more tires or wheels on your vehicle
to ensure that the replacement or alter-
nate tires and wheels allow the TPMS
(tire pressure warning system) to con-
tinue to function properly.
NOTICE
■To ensure the tire pressure warning
system operates properly
Do not install tires with different specifi-
cations or makers, as the tire pressure
warning system may not operate prop-
erly.

3737-2. Steps to take in an emergency
7
When trouble arises
*: A buzzer sounds the first time a message is shown on the multi-information display.
In some situations, the master warning light and warning buzzer may not oper-
ate as specified. In this case, follow the instructions displayed in the warning
message.
 If a warning light comes on or flashes at the same time that a warning message is
displayed, take corrective actio n according to the warning light. ( P.361)
■Warning messages
The warning messages explained below
may differ from the actual messages
according to operation conditions and vehi-
cle specifications.
■Warning buzzer
In some cases, the bu zzer may not be heard
due to being in a noisy location or audio
sound.
■If “Engine Oil Level Low Add or
Replace” is displayed
The engine oil level is low. Check the level
of the engine oil, and add if necessary.
This message may appear if the vehicle is
stopped on a slope. Move the vehicle to a
level surface and check to see if the mes-
sage disappears.
■If “Engine Stoppe d Steering Power
Low” is displayed
This message is displa yed if the engine is
stopped while driving.
When steering wheel operations are
heavier than usual, grip the steering wheel
firmly and operate it using more force than
usual.
■If “Auto Power Off to Conserve Bat-
tery” is displayed
Power was turned off due to the automatic
power off function. Next time when starting
the engine, increase the engine speed
slightly and maintain that level for approxi-
mately 5 minutes to recharge the battery.
■If “High Power Cons umption Power to
Climate Temporarily Limited” is dis-
played
Turn off unnecessary electronic equipment
to reduce power consumption.
Please wait until the power supply returns
to normal.
■If “Headlight System Malfunction Visit
Your Dealer” is displayed
The following systems may be malfunction-
ing. Have the vehicle inspected by your
Lexus dealer immediately.
●The LED headlight system
●AFS (Adaptive Front-lighting System)
●The automatic headlight leveling system
(if equipped)
●Automatic High Beam
■If “Radar Cruise Control Unavailable
See Owner’s Manual” is shown
The dynamic radar cruise control with full-
Comes onDoes not sound
Indicates a condition, such as malfunction of electri-
cal components, their condition, or indicates the
need for maintenance
FlashesDoes not sound
Indicates a situation, such as when an operation has
been performed incorrectly, or indicates how to
perform an operation correctly
Warning buzzer*Warning

3897-2. Steps to take in an emergency
7
When trouble arises
4Press the engine switch shortly and
firmly.
In the event that the engine still cannot
be started, contact your Lexus dealer.
■Stopping the engine
Set the parking brake, shift the shift lever to
P and press the engine switch as you nor-
mally do when stopping the engine.
■Electronic key battery
As the above procedure is a temporary
measure, it is recomme nded that the elec-
tronic key battery be replaced immediately
when the battery is depleted. ( P.341)
■Changing engine switch modes
Release the brake pedal and press the
engine switch in step 3 above.
The engine does not start and modes will be
changed each time the switch is pressed.
(  P.147)
If you have a set of jumper (or booster)
cables and a second vehicle with a 12-
volt battery, you can jump start your
vehicle using the following procedure.
1 Confirm that the electronic key is
being carried.
When connecting the jumper (or booster)
cables, depending on the situation, the
alarm may activate and doors locked.
( P.64)
2 Open the hood. ( P.316)
3 Connect a positive jumper cable clamp to on your vehicle and connect the
clamp on the other end of the positive cable to on the second vehicle.
Then, connect a negative cable clamp to on the second vehicle and con-
nect the clamp at the other end of the negative cable to .
If the battery is discharged
The following procedures may be
used to start the engine if the bat-
tery is discharged.
You can also call your Lexus dealer
or a qualified repair shop.
Restarting the engine
A
B
C
D

3917-2. Steps to take in an emergency
7
When trouble arises
ing parts as shown in the illustration
4 Start the engine of the second vehi-
cle. Increase the engine speed
slightly and maintain at that level for
approximately 5 minutes to
recharge the battery of your vehi-
cle.
5 Open and close any of the doors of
your vehicle with the engine switch
off.
6 Maintain the engine speed of the
second vehicle and start the engine
of your vehicle by turning the
engine switch to IGNITION ON
mode.
7 Once the vehicle’s engine has
started, remove the jumper cables
in the exact reverse order from
which they were connected.
Once the engine starts, have the vehicle
inspected at your Lexus dealer as soon as
possible.
■Starting the engine when the battery is
discharged
The engine cannot be started by push-start-
ing.
■To prevent battery discharge
●Turn off the headlights and the audio sys-
tem while the engine is stopped.
●Turn off any unnecessary electrical com-
ponents when the vehicle is running at a
low speed for an extended period, such
as in heavy traffic.
■When the battery is removed or dis-
charged
●Information stored in the ECU is cleared.
When the battery is depleted, have the
vehicle inspected at your Lexus dealer.
●Some systems may require initialization.
(  P.430)
■When removing the battery terminals
When the battery terminals are removed,
the information stored in the ECU is
cleared. Before removi ng the battery termi-
nals, contact your Lexus dealer.
■Charging the battery
The electricity stored in the battery will dis-
charge gradually even when the vehicle is
not in use, due to natural discharge and the
draining effects of certain electrical appli-
ances. If the vehicle is left for a long time,
the battery may discharge, and the engine
may be unable to start. (The battery
recharges automatically during driving.)
■When recharging or replacing the bat-
tery
●In some cases, it may not be possible to
unlock the doors using the smart access
system with push-button start when the
battery is discharged. Use the wireless
remote control or the mechanical key to
lock or unlock the doors.
●The engine may not start on the first
attempt after the battery has recharged
but will start normally after the second
attempt. This is not a malfunction.
●The engine switch mode is memorized by
the vehicle. When the battery is recon-
nected, the system will return to the
mode it was in before the battery was dis-
charged. Before disconnecting the bat-
tery, turn the engine switch off.
If you are unsure wh at mode the engine
switch was in before the battery dis-
charged, be especially careful when
reconnecting the battery.
■When replacing the battery
●Use a battery that conforms to European
regulations.
●Use a battery that the case size is same as
the previous one (LN3), 20 hour rate
capacity (20HR) is equivalent (70Ah) or
greater, and performance rating (CCA)
is equivalent (592A) or greater.
• If the sizes differ, the battery cannot be properly secured.
• Battery performance may decrease and
the engine may not be able to start.

3947-2. Steps to take in an emergency
A25A-FKS engineReservoir
“F” line
“L” line
Coolant inlet cap
5 Add coolant if necessary.
2GR-FKS engine
Water can be used in an emergency if
coolant is unavailable.
A25A-FKS engine
Water can be used in an emergency if
coolant is unavailable.
6Start the engine and turn the air
conditioning system on to check
that the radiator cooling fan oper-
ates and to check for coolant leaks
from the radiator or hoses.
The fan operates when the air conditioning
system is turned on immediately after a
cold start. Confirm that the fan is operating
by checking the fan sound and air flow. If it
is difficult to check these, turn the air con-
ditioning system on and off repeatedly.
(The fan may not oper ate in freezing tem-
peratures.)
7 If the fan is not operating:
Stop the engine immediately and
contact your Lexus dealer.
If the fan is operating:
Have the vehicle inspected at the
nearest Lexus dealer.
A
B
C
D
WARNING
■When inspecting under the hood of
your vehicle
Observe the following precautions.
Failure to do so may result in serious
injury such as burns.
●If steam is seen coming from under the
hood, do not open the hood until the
steam has subsided. The engine com-
partment may be very hot.
●Keep hands and clothing (especially a
tie, a scarf or a muffler) away from the
fan and belts. Failure to do so may
cause the hands or clothing to be
caught, resulting in serious injury.
●While the engine and radiator are hot,
do not loosen or remove the coolant
inlet cap or coolant reservoir cap.
High temperature steam or coolant
could spray out.

3957-2. Steps to take in an emergency
7
When trouble arises
1Stop the engine. Set the parking
brake and shift the shift lever to P.
2 Remove the mud, snow or sand
from around the front wheels.
3 Place wood, stones or some other
material under the front wheels to
help provide traction.
4 Restart the engine.
5 Shift the shift lever to D or R and
release the parking brake. Then,
while exercising caution, depress
the accelerator pedal.
■When it is difficult to free the vehicle
Press the switch to turn off TRAC.
NOTICE
■When adding engine coolant
Add coolant slowly after the engine has
cooled down sufficiently. Adding cool
coolant to a hot engine too quickly can
cause damage to the engine.
■To prevent damage to the cooling
system
Observe the following precautions:
●Avoid contaminating the coolant with
foreign matter (such as sand or dust
etc.).
●Do not use any coolant additive.
If the vehicle becomes stuck
Carry out the following procedures
if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
Recovering procedure

447What to do if... (Troubleshooting)
In this case, the engine can be started in a
temporary way. ( P.388)
Is the battery discharged?
( P.389)
 Is the engine switch in IGNITION
ON mode?
If you cannot release the shift lever
by depressing the brake pedal with
the engine switch in IGNITION ON
mode ( P.150)
 It is locked automatically to prevent
theft of the vehicle. ( P.145)
 Is the window lock switch pressed?
The power window at the except for the
one at the driver’s seat cannot be operated
if the window lock switch is pressed.
( P.125)
 The auto power off function will be
operated if the vehicle is left in
ACCESSORY or IGNITION ON
mode (the engine is not running) for
a period of time. ( P.147) 
The seat belt reminder light is flash-
ing
Are the driver and the passengers wearing
the seat belts? ( P.364)
 The parking brake indicator is on
Is the parking brake released? ( P.154)
Depending on the situation, other
types of warning buzzer may also
sound. ( P.361, 371)
 Did anyone inside the vehicle open
a door during setting the alarm?
The sensor detects it and the alarm sounds.
( P.63)
To stop the alarm, turn the engine
switch to IGNITION ON mode, or
start the engine.
 Is the message displayed on the
multi-information display?
Check the message on the multi-informa-
tion display. ( P.371)
 When a warning light turns on or a
warning message is displayed, refer
to P.361, 371.
The shift lever cannot be shifted
from P even if you depress the
brake pedal
The steering wheel cannot be
turned after the engine is
stopped
The windows do not open or
close by operating the power
window switches
The engine switch is turned off
automatically
A warning buzzer sounds during
driving
An alarm is activated and the
horn sounds
A warning buzzer sounds when
leaving the vehicle
A warning light turns on or a
warning message is displayed

Alphabetical index451
change ....................................................... 71, 76
Do-it-yourself maintenance ..................... 310
Door courtesy lights ....................................274
Door lock Doors.................................................................. 95
Smart access system with push-button start ................................................................. 106
Wireless remote control........................... 93
Doors ................................................................... 95 Automatic door lock ing and unlocking
system ............................................................. 98
Door glasses .................................................. 124
Door lock.......................................................... 95
Open door warning buzzer .......... 96, 98
Outside rear view mirrors ........................121
Rear door child-protectors ..................... 98
Drive distance ...................................................79
Drive info 1/Drive info 2 ...............................79
Driver’s seat position memory .................. 114 Driving position memory...........................114
Memory recall function ............................. 116
Drive-start control ........................................135
Driving................................................................134 Break-in tips ...................................................135
Correct driving posture .............................23
Driving Mode Select switch...................210
Procedures ..................................................... 134
Winter drive tips...........................................251
Driving information display .........................79
Driving Mode Select switch......................210
Driving range ....................................................79
Driving support system information display ............................................................................. 82
Dynamic radar cruise control with full- speed range..................................................195Warning message..................................... 203
Dynamic Torque Control AWD system .......................................................................... 246
E
Eco drive mode ..............................................210
Eco Driving Indicator.................... 80, 81, 87 Eco Driving Indicator Light ........................ 80
EDR (Event data recorder) ............................7
Elapsed time ......................................................79
Electric Power Steering (EPS)
Function .......................................................... 246
Warning light ...............................................363
Electronic key .................................................. 92 Battery-saving function............................ 107
If the electronic key does not operate properly .......................................................387
Replacing the battery .................................341
Electronic roof sunshade Jam protection function ........................... 130
Operation ........................................................129
Emergency, in case of If a warning buzzer sounds.................... 361
If a warning light turns on........................ 361
If a warning message is displayed .......371
If the battery is discharged ................... 389
If the electronic key does not operate properly .......................................................387
If the engine will not start....................... 384
If the fuel filler do or cannot be opened
......................................................................... 386
If the vehicle is trapped in rising water ..........................................................................353
If you have a flat tire ..................................375
If you lose your keys ................................ 386
If you think something is wrong......... 359
If your vehicle becomes stuck ............ 395
If your vehicle has to be stopped in an emergency .................................................352
If your vehicle needs to be towed .... 355
If your vehicle overheats ........................393
Emergency flashers .................................... 352
Engine ................................................................144 ACCESSORY mode................................147
Compartment............................................... 318
Engine switch .................................................144
Fuel pump shut off system.................... 360
Hood ................................................................. 316
How to start the engine ............................144

452Alphabetical index
Identification number ...............................399
If the engine will not start .......................384
If your vehicle has to be stopped in an
emergency ................................................ 352
Ignition switch (engine switch) ............. 144
Overheating................................................. 393
Tachometer .............................................70, 73
Engine coolant.............................................. 322 Capacity ......................................................... 402
Checking ....................................................... 322
Preparing and checking before winter...........................................................................251
Engine coolant temperature gauge 70, 73
Engine immobilizer system .......................... 61
Engine oil ..........................................................319 Capacity ........................................................ 400
Checking .........................................................319
Preparing and checking before winter...........................................................................251
Warning light ............................................... 362
Engine oil maintenance data ....................321
Engine switch ..................................................144 Auto power off function ........................... 147
Changing the engine switch modes.. 147
If your vehicle has to be stopped in an
emergency ................................................ 352
Starting the engine ...................................... 144
Enhanced Vehicle Stability Control (Enhanced VSC) ...................................... 246
Enhanced VSC (Enhanced Vehicle Stabil- ity Control) .................................................. 246
EPS (Electric Power Steering) .............. 246 Function .......................................................... 246
Warning light ............................................... 363
Event data recorder (EDR) ............................7
F
Flat tire ............................................................. 375 Tire pressure warning system ............. 328
Floor mats ...........................................................22
Fluid Automatic transmission ..........................403 Brake ............................................................... 404
Washer ...........................................................325
Footwell light ..................................................274
Front passenger occupant classification system ...............................................................37
Front seats ......................................................... 113 Adjustment ....................................................... 113
Cleaning .........................................................307
Correct driving posture ............................ 23
Driving position memory .......................... 114
Head restraints............................................... 117
Memory recall function.............................. 116
Power easy access system ...................... 114
Seat heaters ..................................................270
Seat position memory ................................ 114
Seat ventilators ............................................270
Front side marker light ............................... 158 Light switch .................................................... 158
Front side marker lights Replacing light bulbs ................................346
Front turn signal lights .................................153 Replacing light bulbs ................................346
Turn signal lever .......................................... 153
Fuel ......................................................................169 Capacity ........................................................ 400
Fuel gauge ............................................... 70, 73
Fuel pump shut off system.................... 360
Information ................................................... 408
Refueling.......................................................... 169
Type ................................................................. 400
Warning light ...............................................364
Fuel consumption Average fuel economy .............................. 79
Current fuel consumption ........................ 79
Fuel filler door .................................................169 If the fuel filler do or cannot be opened
......................................................................... 386
Refueling.......................................................... 169
Fuel gauge ................................................. 70, 73
Fuel pump shut off system........................ 360
Fuses ................................................................. 342
