steering wheel Lexus GS F 2015 Owner's Manuals

3
1
8 7
6
5
4
3
2
GS350_200t_GS F_OM_OM30E87E_(EE)
3-1. Key informationKeys................................................... 154
3-2. Opening, closing and locking the doors and trunk
Doors ............................................... 159
Trunk ................................................. 166
Smart entry & start system .......173
3-3. Adjusting the seats Front seats ...................................... 195
Driving position memory ......... 198
Head restraints............................203
3-4. Adjusting the steering wheel and mirrors
Steering wheel ............................206
Inside rear view mirror ............ 208
Outside rear view mirrors ....... 210
3-5. Opening, closing the windows and moon roof
Power windows ............................ 213
Moon roof ...................................... 216 4-1. Before driving
Driving the vehicle ..................... 222
Cargo and luggage ...................230
Trailer towing (vehicles without towing package) ...... 231
Trailer towing (vehicles with towing package) ...................... 232
4-2. Driving procedures Engine (ignition) switch ...........239
Automatic transmission........... 245
Turn signal lever ..........................253
Parking brake............................... 254
Brake Hold (GS350/GS200t) ................ 257
ASC (Active Sound Control) (GS F) ....................... 259
4-3. Operating the lights and wipers
Headlight switch .........................260
AHS (Adaptive High-beam System) ........................................ 263
Automatic High Beam .............268
Fog light switch............................ 273
Windshield wipers and washer.................................. 274
4-4. Refueling Opening the fuel tank cap..... 280
3Operation of
each component4Driving

TABLE OF CONTENTS4
GS350_200t_GS F_OM_OM30E87E_(EE)
4-5. Using the driving support systems
Lexus Safety System+...............284
PCS (Pre-Crash Safety system)......................................... 293
LKA (Lane-Keeping Assist).......................................... 305
LDA (Lane Departure Alert with steering control).............. 315
RSA (Road Sign Assist) ........... 324
Dynamic radar cruise control with full-speed range .............329
Dynamic radar cruise control........................................... 341
Cruise control..............................353
Driving mode select switch ...........................................356
BSM (Blind Spot Monitor) ...... 361 • The Blind Spot Monitor function..................................... 367
• The Rear Crossing Traffic Alert function .........................369
TVD (Torque Vectoring Differential)................................ 372
Driving assist systems ................374
4-6. Driving tips Winter driving tips .....................382 5-1. Remote Touch screen
Remote Touch/12.3-inch display ......................................... 388
5-2. Using the air conditioning system and defogger
Front automatic air conditioning system ......... 394
Rear air conditioning system .........406
Heated steering wheel/ seat heaters/
seat ventilators .........................409
5-3. Using the interior lights Interior lights list........................... 414• Interior lights ........................... 415
• Personal lights......................... 415
5-4. Using the storage features List of storage features...............417• Glove box................................. 418
• Console box ............................ 418
• Cup holders ............................ 419
• Auxiliary boxes....................... 421
Trunk features .............................. 4225Interior features

21Pictorial index
GS350_200t_GS F_OM_OM30E87E_(EE)
VSC OFF switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 376
Heated steering wheel switch
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 410
Automatic High Beam switch
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 269
Adaptive High-beam System switch
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 263
Instrument panel light control switches. . . . . . . . . . . . . . . . . . . . . . . . . . P. 111, 118
Odometer/trip meter and trip meter reset button . . . . . . . . . . . . . . P. 110, 117
HUD (Head-up display) switches
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 141
Brake hold switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 257
ASC switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 2 5 9
*: If equipped
1
2
3
4
5
6
7
8

34Pictorial index
GS350_200t_GS F_OM_OM30E87E_(EE)
■Switches (Right-hand drive vehicles)
Odometer/trip meter and trip meter reset button . . . . . . . . . . . . . . . . . . .P. 117
Instrument panel light control switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 118
HUD (Head-up display) switches
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 141
VSC OFF switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 376
Automatic High Beam switch
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 269
Adaptive High-beam System switch
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 263
Heated steering wheel switch
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 410
ASC switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 2 5 9
1
2
3
4
5
6
7

441-1. For safe use
GS350_200t_GS F_OM_OM30E87E_(EE)
For safety drive
Adjust the angle of the seatback so
that you are sitting straight up and so
that you do not have to lean forward
to steer. (→P. 1 9 5 )
Adjust the seat so that you can
depress the pedals fully and so that
your arms bend slightly at the elbow
when gripping the steering wheel.
( → P. 1 9 5 )
GS350/GS200t: Lock the head restraint in place with the center of the head
restraint closest to the top of your ears. ( →P. 2 0 3 )
Wear the seat belt correctly. ( →P. 4 6 )
Make sure that all occupants are wearing their seat belts before driving the vehi-
cle. ( →P. 4 6 )
Use a child restraint system appropriat e for the child until the child becomes
large enough to properly wear the vehicle’s seat belt. ( →P. 6 4 )
Make sure that you can see backward clearly by adjusting the inside and outside
rear view mirrors properly. ( →P. 208, 210)
For safe driving, adjust the seat and mi rror to an appropriate position before
driving.
Correct driving posture
1
2
Correct use of the seat belts
Adjusting the mirrors
3
4

531-1. For safe use
1
For safety and security
GS350_200t_GS F_OM_OM30E87E_(EE)
The main SRS airbag system components are shown above. The SRS airbag sys-
tem is controlled by the airbag sensor assembly. As the airbags deploy, a chemi-
cal reaction in the inflators quickly fills the airbags with non-toxic gas to help
restrain the motion of the occupants.
WA R N I N G
■SRS airbag precautions
Observe the following precautions regarding the SRS airbags.
Failure to do so may cause death or serious injury.
●The driver and all passengers in the vehicle must wear their seat belts properly.
The SRS airbags are supplemental devices to be used with the seat belts.
●The SRS driver airbag deploys with considerable force, and can cause death or seri-
ous injury especially if the driver is very close to the airbag.
Since the risk zone for the driver’s airbag is the first 50 - 75 mm (2 - 3 in.) of inflation,
placing yourself 250 mm (10 in.) from your driver airbag provides you with a clear
margin of safety. This distance is measured from the center of the steering wheel to
your breastbone. If you sit less than 250 mm (10 in.) away now, you can change your
driving position in several ways:
• Move your seat to the rear as far as you can while still reaching the pedals com-
fortably.
• Slightly recline the back of the seat. Although vehicle designs vary, many drivers can achieve the 250 mm (10 in.) dis-
tance, even with the driver seat all the wa y forward, simply by reclining the back of
the seat somewhat. If reclining the back of your seat makes it hard to see the road,
raise yourself by using a firm, non-slippery cushion, or raise the seat if your vehicle
has that feature.
• If your steering wheel is adjustable, tilt it downward. This points the airbag toward
your chest instead of your head and neck.
The seat should be adjusted as recommend ed above, while still maintaining control
of the foot pedals, steering wheel, and yo ur view of the instrument panel controls.

551-1. For safe use
1
For safety and security
GS350_200t_GS F_OM_OM30E87E_(EE)
WA R N I N G
■SRS airbag precautions
●Do not hang coat hangers or other hard objects on the coat hooks. All of these items
could become projectiles and may cause death or serious injury, should the SRS cur-
tain shield airbags deploy.
●If a vinyl cover is put on the area where the SRS knee airbag will deploy, be sure to
remove it.
●Do not use seat accessories which cover the parts where the SRS side airbags inflate
as they may interfere with inflation of the airbags. Such accessories may prevent the
side airbags from activating correctly, disable the system or cause the side airbags to
inflate accidentally, resulting in death or serious injury.
●Do not allow anyone to kneel on the passen-
ger seat toward the door or put their head or
hands outside the vehicle.
●Do not attach anything to or lean anything
against areas such as the dashboard, steering
wheel pad, lower portion of the instrument
panel and door of the glove box.
These items can become projectiles when the
SRS driver, front passenger and knee airbags
deploy.
●Do not attach anything to areas such as a door,
windshield glass, side door glass, front or rear
pillar, roof side rail and assist grip. (Except for
the speed limit sticker →P. 5 7 5 )

561-1. For safe use
GS350_200t_GS F_OM_OM30E87E_(EE)
WA R N I N G
■SRS airbag precautions
●Do not strike or apply significant levels of force to the area of the SRS airbag compo-
nents.
Doing so can cause the SRS airbags to malfunction.
●Do not touch any of the component parts immediately after the SRS airbags have
deployed (inflated) as they may be hot.
●If breathing becomes difficult after the SRS airbags have deployed, open a door or
window to allow fresh air in, or leave the vehicle if it is safe to do so. Wash off any resi-
due as soon as possible to prevent skin irritation.
●If the areas where the SRS airbags are stored, such as the steering wheel pad, door of
the glove box and front and rear pillar garnishes are damaged or cracked, have them
replaced by any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
■Modification and disposal of SRS airbag system components
Do not dispose of your vehicle or perform any of the following modifications without
consulting any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional. The SRS airbags may malfunction or deploy (inflate) acciden-
tally, causing death or serious injury.
●Installation, removal, disassembly and repair of the SRS airbags
●Repairs, modifications, removal or replace ment of the steering wheel, instrument
panel, dashboard, glove box, seats or seat upholstery, front, side and rear pillars or
roof side rails
●Repairs or modifications of the front fend er, front bumper, or side of the occupant
compartment
●Installation of a grille guard (bull bars, kangaroo bar, etc.), snow plows or winches
●Modifications to the vehicle’s suspension system
●Installation of electronic devices such as mobile two-way radios (RF-transmitter) and
CD players
●Modifications to your vehicle for a person with a physical disability

571-1. For safe use
1
For safety and security
GS350_200t_GS F_OM_OM30E87E_(EE)
■If the SRS airbags deploy (inflate)
●Slight abrasions, burns, bruising etc., may be sustained from SRS airbags, due to the
extremely high speed deployment (inflation) by hot gases.
●A loud noise and white powder will be emitted.
●Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the
seats, the glove box, parts of the front and rear pillars, and roof side rails may be hot for
several minutes. The airbag itself may also be hot.
●The windshield may crack.
■SRS airbag deployment conditions (SRS front airbags)
●The SRS front airbags will deploy in the event of an impact that exceeds the set thresh-
old level (the level of force corresponding to an approximately 20 - 30 km/h [12 - 18
mph] frontal collision with a fixed wall that does not move or deform).
However, this threshold velocity will be considerably higher in the following situations:
• If the vehicle strikes an object, such as a parked vehicle or sign pole, which can move or deform on impact
• If the vehicle is involved in an underride collision, such as a collision in which the
front of the vehicle “underrides”, or goes under, the bed of a truck
●Depending on the type of collision, it is possi ble that only the seat belt pretensioners will
activate.
■SRS airbag deployment conditions (SRS side and curtain shield airbags)
●The SRS side and curtain shield airbags w ill deploy in the event of an impact that
exceeds the set threshold level (the level of force corresponding to the impact force
produced by an approximately 1500 kg [ 3300 lb.] vehicle colliding with the vehicle
cabin from a direction perpendicular to the vehicle orientation at an approximate
speed of 20 - 30 km/h [12 - 18 mph]).
●The SRS side and curtain shield airbags may also deploy in the event of a severe frontal
collision.
■Conditions under which the SRS airbags may deploy (inflate), other than a collision
The SRS front airbags, SRS side and curtain shield airbags may also deploy if a serious
impact occurs to the underside of your vehicle. Some examples are shown in the illustra-
tion.
●Hitting a curb, edge of pavement or hard sur-
face
●Falling into or jumping over a deep hole
●Landing hard or falling

591-1. For safe use
1
For safety and security
GS350_200t_GS F_OM_OM30E87E_(EE)
■When to contact any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional
In the following cases, the vehicle will require inspection and/or repair. Contact any
authorized Lexus dealer or repairer, or another duly qualified and equipped professional
as soon as possible.
●Any of the SRS airbags have been inflated.
●The front of the vehicle is damaged or
deformed, or was involv ed in an accident that
was not severe enough to cause the SRS front
airbags to inflate.
●A portion of a door or it’s surrounding area is
damaged or deformed, or the vehicle was
involved in an accident that was not severe
enough to cause the SRS side and curtain
shield airbags to inflate.
●The pad section of the steering wheel, dash-
board near the front passenger airbag, lower
portion of the instrument panel or door of the
glove box is scratched, cracked, or otherwise
damaged.
