Page 32 of 596

32
1-2. Opening, closing and locking the doors and trunk
GS_G_U
October 23, 2015 1:08 pm
■If the smart access system with push-button start does not operate properly
●Locking and unlocking the doors and trunk: Use the mechanical key.
( P. 5 2 6 )
●Starting the engine: P. 5 2 7
■When the electronic key battery is fully depleted
P. 4 4 0
■Customization that can be configured at Lexus dealer
Settings (e.g. smart access system with push-button start) can be changed.
(Customizable features P. 5 6 9 )
■Certification for the smart access system with push-button start
For vehicles sold in the U.S.A.
NOTE:
This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
FCC WARNING:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
For vehicles sold in Canada
NOTE:
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interfer-
ence that may cause undesired operation of the device.
FCC ID: NI4TMLF-1
Page 35 of 596

35
1-2. Opening, closing and locking the doors and trunk
1
Before driving
GS_G_U
October 23, 2015 1:08 pm
■Door lock buzzer
P. 2 6
■Security feature
P. 3 0
■If the wireless remote control does not operate properly
● Locking and unlocking the doors an d trunk: Use the mechanical key.
( P. 5 2 6 )
●Starting the engine. ( P. 5 2 7 )
■Electronic key battery depletion
P. 2 8
■When the electronic key battery is fully depleted
P. 4 4 0
■Conditions affecting operation
P. 2 6
■Customization that can be configured at Lexus dealer
Settings (e.g. 2-step unlocking function, trunk unlocking function) can be changed.
(Customizable features P. 5 6 9 )
Page 144 of 596

144
2-3. Operating the lights and windshield wipers
GS_G_U
June 5, 2008 10:37 am
■Automatic light off system
The headlights and tail lights turn off 30 seconds after all doors are closed if the
“ENGINE START STOP” switch has been switched to ACCESSORY mode or
turned OFF while the headlights are turned on. (The lights turn off immediately if
the button on the key is pressed after all doors are locked.)
To turn the lights on again, switch to IG NITION ON mode, or turn the light switch
off once and then back to the or position.
■Automatic headlight leveling system
The level of the headlights is automatica lly adjusted according to the number of
passengers and the loading condition of the vehicle to ensure that the headlights do
not interfere with other road users.
■If the indicator flashes...
It may indicate a malfunction in the system. Contact your Lexus dealer.
■Customization that can be configured at Lexus dealer
Settings (e.g. light sensor sensitivity) can be changed.
(Customizable features P. 5 7 2 )
NOTICE
■To prevent 12 volt battery discharge
Do not leave the lights on longer than necessary when the engine is off.
Page 528 of 596

528
5-2. Steps to take in an emergency
GS_G_U
May 13, 2008 5:14 pm
To change the “ENGINE START STOP” switch modes: Within 10
seconds of the buzzer sounding , release the brake pedal and
press the “ENGINE START STOP” switch. Modes can be
changed each time the switch is pressed. (
P. 122)
To start the engine: Press the “ENGINE START STOP” switch
within 10 seconds after the buzz er sounds, keeping the brake
pedal depressed.
If the “ENGINE START STOP” switch still cannot be operated, contact
your Lexus dealer.
■Stopping the engine
Shift the shift lever to “P” and press th e “ENGINE START STOP” switch as you nor-
mally do when stopping the engine.
■Replacing the key battery
As the above procedure is the temporary measure, it is recommended that the
electronic key battery be replaced i mmediately when the battery depletes.
( P. 440)
STEP3
Page 585 of 596

585
Alphabetical index
GS_G_U
May 13, 2008 5:14 pm
BrakeFluid ............................................................ 416
Parking brake ..........................................131
Brake assist ............................................... 184
Care Exterior ...................................................388
Interior....................................................... 391
Seat belts ............................................... 392
Cargo capacity ....................................... 194
Cargo hooks .......................................... 360
CD player/changer .............................242
Chains....................................................... 200
Child-protectors ..................................... 38
Child restraint system Definition................................................... 98
Installation................................................ 102
Installing CRS with lower
anchors .................................................106
Installing CRS with seatbelts .........103
Installing CRS with top straps ....... 107
Child safety Airbag precautions ............................. 87
Battery precautions ................ 419, 532
Child restraint system ........................ 98
Child-protectors................................... 38
How your child should wear
the seatbelt ........................................... 56
Installing child restraints ................... 102
Moon roof precautions ..................... 69
Power window lock switch ..............64
Power window precautions.............64
Removed electronic key battery
precautions ......................................... 441
Seat belt comfort guide..................... 54
Seat belt precautions...........................57 Seat heater precautions................ 355
Trunk precautions................................. 44
Cigarette lighter....................................352
Cleaning Exterior................................................... 388
Interior ...................................................... 391
Seat belts ................................................392
Clock ......................................................... 349
Coin holder .............................................345
Compass ..................................................369
Condenser ............................................... 415
Console box ........................................... 342
Cooling system Engine overheating.......................... 533
Cruise control Cruise control....................................... 150
Dynamic radar cruise control....... 153
Cup holders ............................................345
Curtain shield airbags........................... 80
Customizable features .......................569
Daytime running light system ........... 143
Defogger Rear window ........................................ 225
Side mirror............................................. 225
Dimension................................................540
Dinghy towing ........................................205
Display Multi-information display ................ 139
Touch screen ...................................... 208
Trip information ................................... 140
Warning message ............................. 497
Do-it-yourself maintenance ............ 400
Door courtesy lights ............................ 337
Door pocket............................................ 346
C
D
Page 586 of 596

586
Alphabetical index
GS_G_U
May 13, 2008 5:14 pm
DoorsDoor lock................................. 22, 34, 37
Rear door child protector ................ 38
Driver’s seat belt reminder light .....490
Driver’s seat position memory ........... 47
Driving Correct posture .................................... 78
Procedures ...............................................112
DVD player/changer........................... 251
Electric power steering ....................... 184
Electronic key If the electronic key does
not operate properly .................... 526
Replacing battery .............................. 440
Emergency, in case of If a warning light turns on ............. 488
If a warning message is
displayed ............................................ 497
If the electronic key does
not operate properly .................... 526
If the engine will not
start........................................................ 523
If the shift lever cannot be shifted from “P”................................ 524
If the 12 volt battery is
discharged ....................................... 529
If you have a flat tire ............... 512, 522
If you lose your keys......................... 525
If you think something is
wrong ................................................... 484
If your vehicle becomes stuck.....536
If your vehicle needs to be
towed ................................................... 478
If your vehicle overheats ................ 533 Engine
ACCESSORY mode........................122
Compartment ..................................... 406
Engine (ignition) switch...................... 121
Hood ....................................................... 403
How to start the engine ..................... 121
If the engine will not start ............... 523
Overheating ........................................ 533
Engine compartment cover .............408
Engine coolant temperature
gauge .......................................................132
Engine coolant Capacity ................................................ 546
Checking................................................. 414
Preparing and checking
before winter...................................... 199
Engine oil Capacity ................................................ 544
Checking............................................... 409
Preparing and checking
before winter...................................... 199
Engine oil maintenance data .............412
Engine (ignition) switch......................... 121
Event data recorder ............................ 486
First-aid kit storage belt ..................... 360
Floor mats ................................................ 359
Fluid Brake ......................................................... 416
Washer................................................... 420
Fog lights Switch ........................................................ 145
Wattage ................................................. 552
Foot light .................................................. 337
E
F
