Lexus GS350 2010 Using The Audio System / LEXUS 2010 GS460/350 QUICK GUIDE (OM30B76U) Owner's Manual

21
Quick_GS_G_U
Intuitive Parking Assist
■Turning the system on and off
The system can be turned on and off using the
intuitive parking assist switch.
■Screen display
Multi-information display
Sensors are used to detect obstacles near the
vehicle. The distance to a detected obstacle is
shown by the number of indicator bars.
Indicates obstacles detected by the dual sen-
sors
Indicates the steering maneuvers required to
avoid an obstacle
Indicates obstacles detected by the rear cor-
ner sensors
Indicates obstacles detected by the back sen-
sors To u c h s c r e e n
: If equipped
The system uses a screen display and buzzer to inform the driver of obstacles near the
vehicle when parking or driving at low speed.
1
2
3
4

Quick_GS_G_U
22
Cruise Control
Indicator
Cruise control switch
■Setting the speed
Press the “ON-OFF” button.
The system will turn on.
Accelerate or decelerate to the desired
speed, and then push the lever down.
This sets the speed in the cruise control
memory.
■Adjusting the speed setting
To i n c r e a s e s p e e d: push the lever up.
To decrease speed: push the lever down.
Release the lever when the desired speed is
reached.
■Canceling
To temporarily cancel the cruise control, pull
the lever toward you. To resume the cruise
control, push the lever up.
To turn the system off, press the “ON-OFF”
button.
: If equipped
Cruise control allows the driver to maintain a constant speed without having to operate the
accelerator pedal.
Use for highway driving or when traveling at a constant speed for long periods of time.
1
2
1
2

23
Quick_GS_G_U
Dynamic Radar Cruise Control
Indicator
Display
Cruise control switch
Vehicle-to-vehicle distance control switch
■Cruise control display
Cruise control settings are shown on the multi-
information display.
Vehicle ahead indicator
Vehicle-to-vehicle distance
Preset speed
■Vehicle-to-vehicle distance control mode
Press the “ON-OFF” button.
Accelerate or decelerate to the desired
speed, and then push the lever down.
Following distance can be adjusted using the
vehicle-to-vehicle distance control switch.
: If equipped
Dynamic radar cruise control supplements conventional cruise control with a vehicle-to-
vehicle distance control mode.
1
2
3
4
1
2
3

Quick_GS_G_U
24
■Conventional (constant speed) cruise control mode
Press the “ON-OFF” button.
Push the lever forward and hold for at least
one second.
Accelerate or decelerate to the desired
speed, and then push the lever down.
■Adjusting the speed setting
To i n c r e a s e s p e e d: push the lever up.
To decrease speed: push the lever down.
Release the lever when the desired speed is
reached.
■Canceling
To temporarily cancel the dynamic radar
cruise control, pull the lever toward you. To
resume the cruise control, push the lever up.
To turn the system off, press the “ON-OFF”
button.1
2
The vehicle-to-vehicle distance control mode maintains the preset cruising speed as long
as no vehicle is detected ahead.

25
Quick_GS_G_U
AVS (Adaptive Variable Suspension System)
Sports mode
Suitable for meandering mountainous driv-
ing or high speed driving.
Normal mode
Suitable for normal driving.
TRAC/VSC Off Mode
To turn off TRAC: Push the VSC OFF switch
briefly. The message “TRAC OFF” appears on
the multi-information display.
To turn off VSC: Push and hold the VSC OFF
switch for 3 seconds when the vehicle is not mov-
ing. The slip off indicator light should come on
and the message “TRAC OFF” appears on the
multi-information display.
Push the button again to turn the system back on.
: If equipped
AVS controls the suspension and steering wheel operation according to the road and
driving conditions.
1
2
This switch turns off the traction control system or vehicle stability control system.
Use this switch if the wheels get stuck in snow, mud etc.

Quick_GS_G_U
26
Headlights
The side marker, parking, tail, license plate and
instrument panel lights turn on.
The headlights and all lights listed above turn on.
The headlights and parking lights turn on/off
automatically in accordance with ambient light
levels.
To engage the high beams, push the lever forward.
To flash the high beams, pull the lever and hold.
■AFS (Adaptive Front lighting System) (if equipped)
AFS improves visibility on curves by automatically adjusting the horizontal orientation of the
headlights in accordance with vehicle speed and the degree of the tire angle that are con-
trolled by steering input.
The system can be turned on and off using the
“AFS OFF” switch.
1
2
3

27
Quick_GS_G_U
Fog Lights
The fog lights can be used only when the head-
lights (low beam) are on.
Windshield Wipers and Washers
■Intermittent wiper with interval adjuster (if equipped)
Off
Intermittent operation
Low speed
High speed
Single wipe1
2
3
4
5

Quick_GS_G_U
28
Intermittent operation: Wiper interval can be
adjusted by turning the band.
To spray washer fluid, pull the lever. The wipers
will operate automatically.
■Rain-sensing windshield wipers (if equipped)
Off
Automatic operation
Low speed
High speed
Single wipe1
2
3
4
5

29
Quick_GS_G_U
Automatic operation: Sensitivity can be adjusted
by turning the band.
To spray washer fluid, pull the lever. The wipers
will operate automatically.
Headlight Cleaner
The headlight cleaner can be used only when the
“ENGINE START STOP” switch is in IGNITION
ON mode and the headlights are on.
: If equipped

Quick_GS_G_U
30
Rear Window and Outside Rear View
Mirror Defoggers
To defog the rear window and outside mirrors,
press the button.
Press again to cancel.

Instrument Panel Light Control
Brighter
Darker
Maximum brightness
Changes the cluster glass tint
The system turns off automatically after 15 to 60 minutes.
1
2
3
4
