901-2. Theft deterrent system
GS350/250_EE (OM30C36E)
Canceling and automatic re-enabling of the intrusion sensor and tilt sensor
The alarm will still be set even when the intrusion sensor and tilt sensor are
canceled.
After the intrusion sensor and tilt sensor are canceled, pressing the engine
switch or unlocking the doors using the entry function, wireless remote con-
trol or mechanical key will re-enable the intrusion sensor and tilt sensor.
The intrusion sensor and tilt sensor will automatically be re-enabled when
the alarm system is deactivated.
Intrusion sensor detection considerations
The sensor may trigger the alarm in the following situations:
Places with extreme vibrations or noises, or situations in which the vehicle
is subject to repeated impacts or vibrations:
• When parked in a parking garage
• When the vehicle is transported by a ferry, trailer, train, etc.
• When ice adhering to the vehicle is removed
• When the vehicle is in an automatic or high-pressure car wash
• When in a hail or lightning storm
A window or the moon roof is open.
In this case, the sensor may detect the
following:
• Wind or the movement of objects
such as leaves and insects inside the
vehicle
• Ultrasonic waves emitted from
devices such as the intrusion sensors
of other vehicles
• The movement of people outside the
vehicle
Unstable items, such as dangling acces-
sories or clothes hanging on the coat
hooks, are in the vehicle.

911-2. Theft deterrent system
1
GS350/250_EE (OM30C36E)
For safety and security
Tilt sensor detection considerations (if equipped)
The sensor may trigger the alarm in the following situations:
The vehicle is transported by a ferry, trailer, train, etc.
The vehicle is parked in a parking garage.
The vehicle is inside a car wash that moves the vehicle.
Any of the tires loses air pressure.
The vehicle is jacked up.
An earthquake occurs or the road caves in.
NOTICE
To ensure the intrusion sensor function correctly
Installing accessories other than genuine Lexus parts or leaving objects
between the driver’s seat and front passenger’s seat may reduce the detec-
tion performance.
To ensure that the sensors operate prop-
erly, do not touch or cover them.
Do not spray air fresheners or other
products directly into the sensor holes.

921-2. Theft deterrent system
GS350/250_EE (OM30C36E)

93
2Instrument cluster
GS350/250_EE (OM30C36E)
2. Instrument cluster
Warning lights
and indicators.................... 94
Gauges and meters .............. 98
Multi-information display. 101
Head-up display ................ 109

942. Instrument cluster
GS350/250_EE (OM30C36E)
Warning lights and indicators
Instrument cluster
The units used on the speedometer and some indicators may differ
depending on the target region.
Center panel
The warning lights and indicators on the instrument cluster and
center panel inform the driver of the status of the vehicle’s various
systems.
For the purpose of explanation, the following illustration displays
all warning lights and indicators illuminated.

952. Instrument cluster
2
Instrument cluster
GS350/250_EE (OM30C36E)Warning lights inform the driver of malfunctions in the indicated
vehicle’s systems.
*1: These lights turn on when the engine switch is turned to IGNITION ON
mode to indicate that a system check is being performed. They will turn
off after the engine is on, or after a few seconds. There may be a malfunc-
tion in a system if the lights do not come on, or turn off. Have the vehicle
Warning lights
*1Brake system warning
light
(P. 749)*1, 2
(if
equipped)
“AFS OFF” indicator
(P. 751)
*1Charging system warn-
ing
light (P. 7 5 0 )*2Parking brake indicator
(P. 751)
*1Malfunction indicator
lamp (P. 750)*1Brake system warning
light (P. 7 5 1 )
*1SRS warning light
(P. 750)Open door warning light
(P. 752)
*1ABS warning light
(P. 750)Low fuel level warning
light (P. 7 5 2 )
*1Electric power steering
system warning light
(P. 751)Seat belt reminder light
(P. 752)
*1, 2
(if
equipped)
“PCS” warning light
(P. 751)
*1
Master warning light
(P. 752)
*1Slip indicator
(P. 751)*1Tire pressure warning
light
(P. 753)

962. Instrument cluster
GS350/250_EE (OM30C36E)
inspected by any authorized Lexus dealer or repairer, or another duly qual-
ified and equipped professional.
*2: The light flashes to indicate a malfunction.
The indicators inform the driver of the operating state of the vehi-
cle’s various systems.
Indicators
Turn signal indicator
(P. 222)Cruise control “SET”
indicator (P. 254)
Tail light indicator
(P. 228)
(if
equipped)
LKA (Lane-Keeping
Assist) indicator
(P. 276)
Headlight high beam
indicator (P. 228)

(if
equipped)
Lexus parking assist-
sensor indicator (P.
285)
(if
equipped)
Automatic High Beam
indicator (P. 233)
*1
(if
equipped)
“AFS OFF” indicator
(P. 230)
(if
equipped)
Front fog light indicator
(P. 239)*1, 2 Slip indicator
(P. 333, 339)
Rear fog light indicator
(P. 239)
*1VSC OFF indicator
(P. 334)
Cruise control indicator
(P. 254)
*1, 3
(if
equipped)
“PCS” warning light
(P. 342)
(if
equipped)
Radar cruise control
indicator (P. 258)Parking brake indicator
(P. 224)

972. Instrument cluster
2
Instrument cluster
GS350/250_EE (OM30C36E)
*1
“PASSENGER AIR BAG” indica-
tor
(P. 56)

982. Instrument cluster
GS350/250_EE (OM30C36E)
*1: These lights turn on when the engine switch is turned to IGNITION ON
mode to indicate that a system check is being performed. They will turn
off after the engine is on, or after a few seconds. There may be a malfunc-
tion in a system if the lights do not come on, or turn off. Have the vehicle
inspected by any authorized Lexus dealer or repairer, or another duly qual-
ified and equipped professional.
*2: The light flashes to indicate that the system is operating.
*3: The light comes on when the system is turned off. The light flashes faster
than usual to indicate that the system is operating.
CAUTION
If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning light not
come on when you start the engine, this could mean that these systems are
not available to help protect you in an accident, which could result in death
or serious injury. Have the vehicle inspected by any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional
immediately if this occurs.

992. Instrument cluster
2
Instrument cluster
GS350/250_EE (OM30C36E)
Gauges and meters
The units used on the speedometer may differ depending on the target
region.
Engine coolant temperature gauge
Displays the engine coolant temperature
Tachometer
Displays the engine speed in revolutions per minute
ECO lamp and SPORT lamp
Changes colors according to driving mode
Multi-information display
Presents the driver with a variety of driving-related data (P. 102)
Speedometer
Displays the vehicle speed
Fuel gauge
Displays the quantity of fuel remaining in the tank
Shift position and shift range
Displays the selected shift position or selected shift range (P. 214)
1
2
3
4
5
6
7
