Lexus GS350 2013 Opening, closing and locking the doors and trunk / LEXUS 2013 GS350 QUICK GUIDE (OM30C68U) User Guide
Page 11 of 94
■Exiting the vehicle
Touch the lock sensor (the indentation on
the upper part of the door handle) to lock
all the doors.
■Opening the trunk
Press the button.
If the vehicle is equipped with power
trunk opener and closer, the trunk lid
automatically opens fully.
For details on what to do when the electronic key does not operate properly, see page 91.
Page 12 of 94
Theft Deterrent System
■Engine immobilizer system
The indicator light flashes after the engine
switch has been turned off to indicate that
the system is operating.
The indicator light stops flashing after the
engine switch has been turned to ACCES-
SORY or IGNITION ON mode to indicate
that the system has been canceled.
The alarm uses light and sound to give an alert when an intrusion is detected.
To set the alarm:
Close the doors, trunk and hood, and lock all th e doors. The system will be set automatically
after 30 seconds. The indicator light changes from being on to flashing when the system is set.
To deactivate or stop the alarm:
● Unlock the doors or open the trunk.
● Turn the engine switch to ACCESSORY or IGNITION ON mode, or start the engine.
(The alarm will be deactivated or stopped after a few seconds.)
Page 13 of 94
Ty p e A
Ty p e B Ty p e C
Seat position adjustment switch
Seatback angle adjustment switch
Seat cushion (front) angle adjustment
Vertical height adjustment switch
Seatback upper angle adjustment
switch (if equipped) Lumbar support adjustment switch
Pelvic support adjustment switch (if
Seat cushion length adjustment switch
Seatback side support adjustment
switch (if equipped)
Page 14 of 94
Driving Position Memory
■Entering a position to memory
Adjust the driver’s seat, steering wheel, and outside rear view mirrors to the desired
positions. (When memorizing the front pass enger’s seat, adjust the front passenger’s
seat to the desired positions.)
While pressing the “SET” button, or
within 3 seconds after the “SET” button
is pressed, press button “1”, “2” or “3”
until the signal beeps.
If the selected button has already been
preset, the previously recorded posi-
tion will be overwritten.
■Recalling the memorized position
Press button “1”, “2” or “3” to recall the
■Linking driving position memory with door unlock operation (driver’s side
While pressing the button to recall the posi-
tion, press the driver’s door lock switch
(either lock or unlock) until the signal
The driving position is recalled when the
driver’s door is unlocked using the entry
function or wireless remote control and the
driver’s door is opened.
Your preferred driving position (the position of the driver’s seat, steering wheel and out-
side rear view mirrors) can be memorized and recalled by pressing a button.
The same buttons are found on the front passenger’s side, allowing the position of the
front passenger’s seat to be memorized (if equipped).
Page 15 of 94
Engine (Ignition) Switch
■Starting the engine
Check that the parking brake is set.
Check that the shift lever is set in P.
Firmly depress the brake pedal.
will be displayed on the multi-
information display. If it is not displayed,
the engine cannot be started.
Press the engine switch.
The engine will crank until it starts or
for up to 30 seconds, whichever is less.
Continue depressing the brake pedal
until the engine is completely started.
The engine can be started from any
engine switch mode.
Performing the following operations when ca rrying the electronic key on your person
starts the engine or changes engine switch modes.
Page 16 of 94
■Stopping the engine
Stop the vehicle.
Shift the shift lever to P.
Set the parking brake.
Press the engine switch.
Release the brake pedal and check that “P OWER ON” on the multi-information dis-
play is off.
■ Changing engine switch modes
Modes can be changed by pressing the engine switch with the brake pedal released. (The
mode changes each time the switch is pressed.)
The emergency flashers can be used.
The multi-information display will not be
ACCESSORY mode Some electrical components such as the
audio system can be used.
“POWER ON” will be displayed on the
IGNITION ON mode All electrical components can be used.
“POWER ON” will be displayed on the
*: If the shift lever is in a position other than
P when turning off the engine, the
engine switch will be turned to ACCES-
SORY mode, not to off.
Page 17 of 94
■If your vehicle has to be stopped in an emergency
Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way,
stop the vehicle using the following procedure:
Steadily step on the brake pedal with both feet and firmly depress it.
Do not pump the brake pedal repeatedly as this will increase the effort required to slow
Shift the shift lever to N.
If the shift lever is shifted to N
After slowing down, stop the vehicl e in a safe place by the road.
Stop the engine.
If the shift lever cannot be shifted to N
Keep depressing the brake pedal with both feet to reduce vehicle speed as much as
possible. To stop the engine, press and hold the
engine switch for 2 consecutive seconds or
more, or press it briefly 3 times or more in
Stop the vehicle in a safe place by the road.
Press and hold for 2 seconds or more
or press briefly 3 times or more
Page 18 of 94
■Shifting the shift lever
While the engine switch is in IGNITION ON mode, move the shift lever with the
brake pedal depressed.
When shifting the shift lever between P and D, make sure that the vehicle is com-
Page 19 of 94
■Shift position purpose
*1: To improve fuel efficiency and reduce noises, set the shift lever in the D position for nor-
*2: Any gear range can be fixed when driving in M mode.
■ Selecting shift ranges in the D position
To drive using temporary shift range selection, operate the “-” paddle shift switch. The shift
range can then be selected by operating the “-” and “+” paddle shift switches.
The selected shift range, from 1 to 6,
will be displayed in the meter.
To return to normal D position driving,
the “+” paddle shift switch must be held
down for a period of time.
Shift positionObjective or function
PParking the vehicle/starting the engine
MM mode driving*2
Page 20 of 94
■Selecting gears in the M position
To enter M mode, shift the shift lever to M. Gears can then be selected by operating the shift
lever or paddle shift switch es, allowing you to drive in the gear of your choosing.
The gear changes once every time the
shift lever or paddle shift switch is
The selected gear, from 1 to 6, will be
displayed in the meter.
When in the M position, the gear will not change unless the shift lever or paddle shift
switches are operated. However, even when in the M position, the gears will be automati-
cally changed in the following situation: When vehicle speed drops (downshift only).
When the automatic transmission fluid or engine coolant temperature is low.
When automatic transmission fluid temperature is high.
When the needle of the tachometer is in the red zone (the range which exceeds the
allowable revs of the engine).
In the following situations, the gear will not shift even if the shift lever or paddle shift switches
are operated. “1st Gear not available due to slippery road surface” is displayed on the multi informa-
The vehicle speed is low (upshift only).
