41
GS350_QG_U (OM30C68U)
■Indication on the multi-information display
When the LKA system is on, the lane line display and steering wheel display are shown.
Lane keeping assist function operation
indication
Steering wheel displayed: 
Indicates that the function is currently
operating.
Steering wheel not displayed: 
Indicates that the function is not cur-
rently operating.
Dynamic radar cruise control display
Lane departure warning function indi-
cation (when the inside of the white line
is white):
The function has recognized lane
markers.
Lane departure warning function indi-
cation (when the inside of the white line
is black):
A lane marker is not recognized by the
system, or the LKA system functions
are temporarily canceled.
1
2
3
4

42
GS350_QG_U (OM30C68U)
Driving Mode Select Switch
■Vehicles without AVS
Normal mode
For normal driving.
Press the switch to change the driving mode to normal mode when selected to Eco
mode or sport mode.
Eco drive mode
Use Eco mode to help achieve low fuel cons umption during trips that involve frequent
accelerating.
When the driving mode select switch is tu rned left, the “ECO MODE” indicator comes
on in the multi-information display.
Sport mode
An acceleration response suitable for sports driving is provided by controlling steering
response and transmission. Suitable for when precise handling is desirable, for example
when driving on mountain roads.
When the driving mode select switch is turned right, the “SPORT” indicator comes on
in the instrument cluster.
The driving modes can be select ed to suit driving condition.
1
2
3

43
GS350_QG_U (OM30C68U)
■Ve h i c l e s w i t h AV S
Normal mode
For normal driving.
Press the switch to change the driving mode to normal mode when selected to Eco
mode or sport mode.
Eco drive mode
Use Eco mode to help achieve low fuel cons umption during trips that involve frequent
accelerating.
When the driving mode select switch is turned left, the “ECO MODE” indicator comes
on in the multi-information display.
Sport mode
•SPORT S mode Improves acceleration response by contro lling the transmission. Suitable for when
precise handling is desirable, for example when driving on mountain roads.
When the driving mode select switch is turned right while a made other than SPORT
S mode is selected, the “SPORT S” indicator comes on in the instrument cluster.
•SPORT S+ mode Improves steering performance and driving st ability by simultaneously controlling the
steering and suspension in addition to th e transmission. Suitable for sporty driving.
When the driving mode select switch is turned right while SPORT S mode is selected,
the “SPORT S+” indicator comes on in the instrument cluster.1
2
3

44
GS350_QG_U (OM30C68U)
Lexus Night View (if equipped)
■Displaying the Lexus night view
Turn the engine switch to IGNITION ON mode.
The headlights turn on
Press the Lexus night view switch
The Lexus night view is displayed on the
Remote Touch screen.
To return the screen to its previous state,
press the switch again.
When the light sensor determines that it is
currently night time from the brightness of
the surrounding area, the Lexus night view
can be operated by pressing the Lexus
night view switch while the headlights are
on.
Lexus night view is a system which assists with nighttime driving. Near-infrared rays are
irradiated forward and an image converted from the irradiated light is shown on the
Remote Touch screen. The image shows pede strians, obstacles, and road conditions
ahead of the vehicle, which are difficult to see at nighttime with the naked eye.
1
2
3

45
GS350_QG_U (OM30C68U)
■The Lexus night view display
● When displaying on the “Main Display”
Lexus night view screen
“Side Display” switching button
Brightness adjustment button
● When displaying on the “Side Display”
When another screen is displayed on the
“Main Display” while the Lexus night view is
being shown on the “Main Display”, the
Lexus night view screen will be displayed on
the “Side Display”.
Lexus night view screen
“Main Display” switching button
1
2
3
1
2

46
GS350_QG_U (OM30C68U)
Tire Pressure Warning System
■The tire inflation pressure display function (if equipped)
The tire pressure detected by the tire pres-
sure warning system can be displayed on
the multi-information display.
■Initializing the tire pressure warning system
Press and hold the tire pressure warning
reset switch until the tire pressure warning
light blinks slowly 3 times.
Your vehicle is equipped with a tire pressure warning system that uses tire pressure warn-
ing valves and transmitters to detect low tire inflation pressure before serious problems
arise.

47
GS350_QG_U (OM30C68U)
Remote Touch
■Basic operation
“•” button
Press this button to change ma p scale and scroll through lists.
Compass (“MAP/VOICE”) button
Press this button to display the compass mode screen (vehicle’s current position).
Remote Touch knob
Use this knob to move the cursor and select items on the screen.
Feedback force, pointer sound volume, on or off of selection sounds etc. can be
changed. Refer to the “Owner’s Manual” and “Navigation System Owner’s Manual”.
“MENU” button
Press this button to display the “Menu” screen.
The Remote Touch can be used to operate the Remote Touch screens.
1
2
3
4

48
GS350_QG_U (OM30C68U)
■Menu
Vehicles without a navigation system
Press the “MENU” button on the Remote
Touch to display the “Menu” screen.
“Destination” ( P. 5 1 )
“Info/Apps” or “Info”
“Setup”
“Radio” ( P. 6 5 )
“Media” ( P. 6 4 )
“Climate” ( P. 6 8 )
“Phone” ( P. 5 7 )
“Display” ( P. 4 9 )
Vehicles with a navigation system
1
2
3
4
5
6
7
8

49
GS350_QG_U (OM30C68U)
■Side Display (vehicles with a navigation system)
The following functions can be displayed
and operated on the “Side Display”.
Audio ( P. 6 4 )
Air conditioning ( P. 6 8 )
Vehicle information
■ Display
Press the “MENU” button on the Remote
Touch and select “Display” on the “Menu”
screen.
Displays the screen in “Day Mode”
with the headlight switch on
Turns the screen off
Change function
Adjust contrast/brightness
1
2
3
1
2
3
4

50
GS350_QG_U (OM30C68U)
■Screen scroll operation
To scroll over the map, place the pointer in a
position near the desired destination and
then press and hold the Remote Touch
knob.
Indicates the street name, city name,
etc. for the selected point
Displays various information for the
selected point
Indicates the distance from the current
position to the pointer
Switches the screens
Zooms in on the map
Zooms out on the map
■Setting a route
While route guidance is operating, you can change the route using the following method.
Select “Route”.
The following settings can be accessed
Detour setting
Route preferences
Route overview
Pause and resume route guidance

1
2
3
4
5
6
1
2
3
4
Some functions are unavailable while the vehicl e is in motion. Refer to the “Navigation Sys-
tem Owner’s Manual”.
