park assist Lexus GS350 2015 RADIO OPERATION / LEXUS 2015 GS350 OWNERS MANUAL QUICK GUIDE (OM30E50U)

2
GS350_QG_OM30E50U_(U)
Garage Door Opener....................................................................................................................... 81
Hands-free System For Cellular Phone
Bluetooth
® phone pairing ......................................................................................................... 57
Contacts transfer .............................................................................................................. ............ 58
Registering the contacts in the favorites list........................................................................59
Calling by name (vehicles with navigation sy stem) .........................................................60
Calling by favorites list ...................................................................................................... ...........60
Calling using e-mail/SMS/MMS message ......................................................................... 61
Receiving a call ............................................................................................................... ................. 61
Steering switches .............................................................................................................. .............. 61
Headlights ............................................................................................................................... ...............25
Head-up Display ............................................................................................................................... ...23
Intuitive Parking Assist .....................................................................................................................36
Lexus Enform ............................................................................................................................... ........ 85
Lexus Enform Safety Connect ..................................................................................................... 83
Lexus Night View ............................................................................................................................... .42
LKA (Lane-Keeping Assist) .......................................................................................................... 38
Multi-information Display ............................................................................................................... 21
Navigation System Register home .................................................................................................................. ................ 51
Destination input - Search by address .................................................................................. 52
Destination input - Search points of interest by name....................................................54
Destination input - Search points of interest by category.............................................55
Destination input - Search points of intere st by telephone number .........................56
Pa r k in g B ra ke ............................................................................................................................... ........20
Portable Audio Device Ports .......................................................................................................... 81
Rear Air Conditioning System Front controller ............................................................................................................................... 73
Remote Touch ....................................................................................................................................... 45

9
GS350_QG_OM30E50U_(U)
OverviewInstrument Panel
Intuitive parking assist switch P.36
Rear sunshade switch*
Remote Touch P.45
Seat ventilator switches P.74
Shift lever*
Driving mode select switch P.40
Snow mode switch*
Seat heater switch P.74
Seat heater switch P.74

21
GS350_QG_OM30E50U_(U)
Multi-information Display
■Display contents
● Trip information
• Eco Driving Indicator
•Outside temperature
• Current fuel consumption
• Average fuel consumption after refuel-
ing
• Average fuel consumption
• Average vehicle speed
•Driving range
• Tire inflation pressure (if equipped) ( P. 4 4 )
● Drive monitor
•Outside temperature
• Average fuel consumption after refuel-
ing
•Driving range
● Intuitive parking assist display
* (if
equipped)
● Dynamic radar cruise control display
* (if
equipped)
● Dynamic radar cruise control with full-
speed range
* (if equipped)
● LKA (Lane-Keeping Assist) display
* (if
equipped)
● Wa r n i n g m e s s a g e s
*: Automatically displayed when the sys-
tem is used. Display can be switched by
pressing the “DISP” button.
The multi-information display presents the dr iver with a variety of driving-related data
including the current outside air temperature.

36
GS350_QG_OM30E50U_(U)
Intuitive Parking Assist (if equipped)
■Turning the system on and off
Turns the intuitive parking assist on/off
When on, the indicator light comes on to
inform the driver that the system is oper-
ational.
The distance from your vehicle to nearby ob stacles when parallel parking or maneuver-
ing into a garage is measured by the sens ors and communicated via the multi-informa-
tion display, Remote touch screen and a buzzer. Always check the surrounding area
when using this system.

50
GS350_QG_OM30E50U_(U)
■Selecting the operation screen
When selecting the side display, move the Remote Touch knob to the right until is dis-
played at the boundary between the main displa y and the side display, and then move it fur-
ther to the right. When selecting the main di splay, move the Remote Touch knob to the left
until is displayed at the boundary between the main display and the side display, and
then move it further to the left.
■ Display the side display
Basic screens
The following functions can be displaye d and operated on the side display.
Audio (P. 6 2 )
Air conditioning system ( P. 6 8 )
Vehicle information
Interruption screens
Each of the following screens is displayed au tomatically in accordance with conditions.
● Intuitive parking assist (if equipped) ( P. 3 6 )
● Phone ( P. 5 7 )
● Destination Assist
● Driving mode ( P. 4 0 )
● Lexus night view (if equipped) ( P. 4 2 )
■To display on the main display
Detailed information that is not shown on the si de display can be set to display on the main
display.
Select , or .
1
2
3

90
What to do if...
GS350_QG_OM30E50U_(U)
*1: It also comes on due to natural causes such as natural air leaks and tire inflation pressurechanges caused by temperature. Adjust the tire inflation pressure to the specified level.
The light will turn off after a few minutes. In case the light does not turn off even if the tire
inflation pressure is adjusted, have the system checked by your Lexus dealer.
*2: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
Follow the correction procedures.
Open door warning lightMaster warning light
Low fuel level warning light
(Illuminates without
blinking)
Tire pressure warning light*1
Seat belt reminder light
See the OWNER’S MANUAL
Tu r n s i g n a l i n d i c a t o rIntuitive parking assist
indicator (if equipped)
*2
Headlight indicator (U.S.A.)“AFS OFF” indicator
(if equipped)
Tail light indicator (Canada)
(Flashes)
Slip indicator
Headlight high beam indicatorVSC OFF indicator
Front fog light indicator
(if equipped)
(Flashes
faster)
“PCS” warning light
(if equipped)
Cruise control indicatorParking brake indicator
(U.S.A.)
Radar cruise control
indicator (if equipped)Parking brake indicator
(Canada)
Cruise control “SET” indicator
BSM (Blind Spot Monitor)
outside rear view mirror
indicators (if equipped)
LKA (Lane-Keeping assist)
indicator (if equipped) “A I R B A G O N /
OFF” indicator
For further information, re fer to the OWNER’S MANUAL.
