± AIR CONDITIONINGAIR CONDITIONING AMPLIFIER (Electrical Multi Vision)
AC±91
2776 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INSTALLATION
Installation is in the reverse order of removal (See page AC±89).

AC0XX±01
I05028
AC±92
± AIR CONDITIONINGENGINE COOLANT TEMPERATURE (ECT) SWITCH
2777 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
ENGINE COOLANT
TEMPERATURE (ECT) SWITCH
REMOVAL
1. REMOVE ENGINE UNDER COVER
2. DRAIN ENGINE COOLANT FROM RADIATOR
HINT:
It is not necessary to drain out all coolant
3. REMOVE ECT SWITCH
(a) Disconnect the connector.
(b) Remove the ECT switch.
Torque: 7.4 N´m (75 kgf´cm, 65 in.´lbf)
(c) Remove the O±ring from ECT switch.
HINT:
At the time of installation, please refer to the following item.
Lubricate a new O±ring with soapy water and install the switch.

AC0XY±01
P01924
Ohmmeter
± AIR CONDITIONINGENGINE COOLANT TEMPERATURE (ECT) SWITCH
AC±93
2778 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INSPECTION
INSPECT ECT SWITCH
(a) Using an ohmmeter, check that no continuity exists be-
tween the terminals when the coolant temperature is
above 100 °C (212 °F).
If continuity exists, replace the switch.
(b) Using an ohmmeter, check that continuity exists between
the terminals when the coolant temperature is below
91 °C (196 °F).
If there no continuity exists, replace the switch.

AC0XZ±01
AC±94
± AIR CONDITIONINGENGINE COOLANT TEMPERATURE (ECT) SWITCH
2779 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INSTALLATION
Installation is in the reverse order of removal (See page AC±92).

AC0Y0±01
I03748
± AIR CONDITIONINGAIR REFINER FILTER
AC±95
2780 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
AIR REFINER FILTER
REMOVAL
1. REMOVE GLOVE COMPARTMENT DOOR
(See page BO±91)
2. REMOVE AIR REFINER FILTER
(a) Remove the cover.
(b) Pull out the air refiner filter.

AC0Y1±01
AC±96
± AIR CONDITIONINGAIR REFINER FILTER
2781 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INSTALLATION
Installation is in the reverse order of removal (See page AC±95).

AT05V±01
± AUTOMATIC TRANSMISSIONAUTOMATIC TRANSMISSION SYSTEM
AT±1
1949 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
AUTOMATIC TRANSMISSION SYSTEM
PRECAUTION
If the vehicle is equipped with a mobile communication system, refer to the precautions in the IN sec-
tion.

AT060±01
D01091
Shift Lock Control ECU Shift Lock Override ButtonKey Interlock Solenoid
Stop Light Switch
± AUTOMATIC TRANSMISSIONSHIFT LOCK SYSTEM
AT±11
1959 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
SHIFT LOCK SYSTEM
LOCATION

AT061±01
D01925
ACC
EP1KLS+
SLS+
Z16909
4 (+)
3 (±)
Z16910
4 (+)
3 (±)
AT±12
± AUTOMATIC TRANSMISSIONSHIFT LOCK SYSTEM
1960 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INSPECTION
1. INSPECT SHIFT LOCK CONTROL ECU
Using a voltmeter, measure the voltage at each terminal.
HINT:
Do not disconnect the ECU connector.
TerminalMeasuring ConditionSpecified Condition
(1) IG SW ACC and shift lever P position0 V
1 ± 10 (KLS ± E)(2) IG SW ACC and shift lever except P position7.5 ± 11V (about I second)
after 6 ± 9 V
4 10 (ACC E)(1) IG SW ON10 ± 14 V4 ± 10 (ACC ± E)(2) IG SW ACC10 ± 14 V
7 10 (P1 E)(1) Shift lever P position0 V7 ± 10 (P1 ± E)(2) Shift lever except P position10 ± 14 V
(1) IG SW ON and shift lever P position0 V
8 10 (SLSE)(2) IG SW ON and depress brake pedal or shift lever N position3 ± 6 V8 ± 10 (SLS ± E)(3) IG SW ON and release brake pedal or shift lever except P position0 V
(4) IG SW ACC and shift lever except P position3 ± 6 V
10 ± Ground (E ± Ground)ConstantContinuity
2. INSPECT KEY INTERLOCK SOLENOID
(a) Disconnect the solenoid connector.
(b) Using an ohmmeter, measure the resistance between ter-
minals 3 and 4.
Standard resistance: 12 ± 17 W
If the resistance value is not as specified, replace the solenoid.
(c) Touch the solenoid with your finger and check that the so-
lenoid operation can be felt when battery voltage is ap-
plied intermittently to terminals 3 and 4.
If the operation is not as specified, replace the solenoid.

AT062±01
D01037
No.1 Safety PadEnd Pad
Finish PlateGlove Compartment Panel Assembly
No.2 Under Cover Box Plate
Ash Receptacle
No.1 Under Cover
Cluster Finish Panel
Shift Lever Assembly
Rear Console Armrest
Console Box
No.3 Console Box Mounting Bracket
No.1 Console Box DuctLower Rear Console Box
8.3 (85, 74 in.´lbf)
N´m (kgf´cm, ft´lbf) : Specified torque
± AUTOMATIC TRANSMISSIONFLOOR SHIFT ASSEMBLY
AT±13
1961 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
FLOOR SHIFT ASSEMBLY
COMPONENTS
