F02388
Matchmarks
F02389
± SUSPENSION AND AXLEREAR LOWER SUSPENSION ARM
SA±99
2099 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
(d) Place matchmarks on the adjusting cam and No.2 lower
suspension arm.
(e) Remove the nut, adjusting cam No.2 and adjusting cam
No.1.
Torque: 110 N´m (1,120 kgf´cm, 81 ft´lbf)
HINT:
At the time of installation, after stabilizing the suspension,
torque the nut.
(f) Remove the bolt, nut, washer and No.2 lower suspension
arm.
Torque: 110 N´m (1,120 kgf´cm, 81 ft´lbf)
HINT:
At the time of installation, after stabilizing the suspension,
torque the nut.
