± ENGINE MECHANICAL (2JZ±GE)VALVE CLEARANCE
1360 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
5. REMOVE NO.3 TIMING BELT COVER
Using a 5 mm hexagon wrench, remove the 4 bolts, oil filler cap,
timing belt cover and gasket.
6. REMOVE IGNITION COILS AND HIGH±TENSION
CORD SET ASSEMBLY (See page IG±7)
7. REMOVE SPARK PLUGS
8. DISCONNECT ENGINE WIRE FROM CYLINDER HEAD
COVERS
9. REMOVE CYLINDER HEAD COVERS
(See page EM±33)
10. SET NO.1 CYLINDER TO TDC/COMPRESSION
(a) Turn the crankshaft pulley and align its groove with the
timing mark º0º of the No.1 timing belt cover.
NOTICE:
Always turn the crankshaft clockwise.
(b) Check that the timing marks of the camshaft timing pul-
leys are aligned with the timing marks of the No.4 timing
belt cover.
If not, turn the crankshaft 1 revolution (360°).
11. INSPECT VALVE CLEARANCE
(a) Check only those valves indicated in the illustration.

Using a feeler gauge, measure the clearance be-
tween the valve lifter and camshaft.

Record the valve clearance measurements of those
that are out of specification. They will be used later
to determine the required replacement adjusting
shim.
Valve clearance (Cold):
Intake0.15 ± 0.25 mm(0.006 ± 0.010 in.)
Exhaust0.25 ± 0.35 mm (0.010 ± 0.014 in.)
(b) Turn the crankshaft pulley 1 revolution (360°), and align
the groove with the timing mark º0º of the No.1 timing belt
cover.

MA004±04
B01384
± MAINTENANCEENGINE
MA±5
48 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
ENGINE
INSPECTION
HINT:
Inspect these items when the engine is cold.
1. REPLACE TIMING BELT
(2JZ±GE ENGINE: See page EM±16)
(1UZ±FE ENGINE: See page EM±14)
2. INSPECT DRIVE BELT
(2JZ±GE ENGINE: See page CH±1)
(1UZ±FE ENGINE: See page CH±1)
3. REPLACE SPARK PLUGS
(2JZ±GE ENGINE: See page IG±1)
(1UZ±FE ENGINE: See page IG±1)
4. INSPECT AIR FILTER
(a) Remove the air filter.
(b) Visually check that the air filter is not excessively dam-
aged or oily.
If necessary, replace the air filter.
(c) Clean the filter with compressed air.
First blow from the inside thoroughly, then blow the out-
side of the filter.
(d) Reinstall the air filter.
5. REPLACE AIR FILTER
Replace the air filter with a new one.
6. REPLACE ENGINE OIL AND OIL FILTER
(2JZ±GE ENGINE: See page LU±2)
(1UZ±FE ENGINE: See page LU±3)
7. REPLACE ENGINE COOLANT
(2JZ±GE ENGINE: See page CO±2)
(1UZ±FE ENGINE: See page CO±2)
8. REPLACE GASKET IN FUEL TANK CAP
(2JZ±GE ENGINE: See page EC±7)
(1UZ±FE ENGINE: See page EC±7)
9. INSPECT FUEL LINES AND CONNECTIONS
Visually check the fuel lines for cracks, leakage, loose connec-
tions, deformation or tank band looseness.
10. INSPECT EXHAUST PIPES AND MOUNTINGS
Visually check the pipes, hangers and connections for severe
corrosion, leaks or damage.
11. ADJUST VALVE CLEARANCE
(2JZ±GE ENGINE: See page EM±5)
(1UZ±FE ENGINE: See page EM±4)
