STARTING AND DRIVING
432
ELECTRIC POWER STEERINGSYSTEM
The electric power steering system, using an electric
motor, assists the turning of the steering wheel.
In the following cases, you may feel the steering becomes
heavy. However, the electric power steering system
warning light does not come on. (Because it is not a
malfunction.)
When maneuvering or turning frequently over a long time, the
power steering effect will be reduced to prevent the system
from overheating. A void turning the steering wheel, or stop the
vehicle and select the engine switch in “ACC” or “OFF” mode.
The system will become cool in about 10 minutes.
NOTICE
Frequent maneuvering and turning over a long time may
cause damage to the system in which the mechanism
prevents overheating of the electric power steering
system.
When the battery is discharged, check the battery’s condition.
If necessary, recharge or replace the battery. For details, see
“Checking battery condition” on page 571.
G31040
 Electric power steering system warning light
The light comes on when the engine switch is selected in
“IG−ON” mode. If the electric power steering system works
properly, the light turns off after a few seconds. If the system
has malfunctions, the light comes on again.
If the following conditions occur, this indicates a
malfunction somewhere in the components monitored by
the warning light system. Contact your Lexus dealer as
soon as possible to service the vehicle.
 The light does not come on when the engine switch is
selected in “IG −ON” mode or remains on.
 The light stays on while you are driving.

STARTING AND DRIVING
441
To initialize the system, perform the following:
1. Park
the vehicle at a safe place and apply the parking brake.
Stop the engine.
2. Adjust the pressure of all the installed tires to the specified
level. (See “Tires and wheels” on pages 534 and 537.)
3. Start the engine.
4. Push and hold the reset switch until the low tire pressure
warning light blinks three times, and the message
“PRESSURE INITIAL” appears on the multi− information
display.
Do not turn the engine off for about 20 minutes until
initialization is complete.
G31007
When initializing the system, make sure the low tire pressure
warning light blinks three times and the message “PRESSURE
INITIAL” appears on the multi− information display. If the
warning light does not blink three times and the message does
not appear on the multi−information display, initialization failed
and the tire pressure warning system will not function properly.
In this case, initialize the system again.
Do not push the reset switch without adjusting the tire inflation
pressure to the specified level. Otherwise, the low tire
pressure warning light may not come on even if the tire inflation
pressure is low, or it may come on when the tire inflation
pressure is actually normal.
If you push the reset switch while the vehicle is moving,
initialization is not performed.
If the low tire pressure warning light does not blink and the
message does not appear on the multi−information display
when you push and hold the reset switch, have the tire
pressure warning system checked at your Lexus dealer.

STARTING AND DRIVING
446
Adaptive variable suspension control (GS430
only)
When the precollision sensor detects an object or
vehicle with which your vehicle may collide, and
determines that a collision may be unavoidable, the
adaptive variable suspension adjusts the damping effect
on the shock absorbers and regulates the vehicle not to
pitch forward so much.
The adaptive variable suspension will operate in the following
conditions:
When the vehicle speed is about 5 km/h (3 mph) or over.
 When the approaching speed in regard to the object or the
vehicle exceeds about 30 km/h (18 mph).
Precollision system failure warning
G31079
Precollision system warning light
The light warns that there is a problem somewhere in the
precollision system.
The light comes on when the engine switch is selected in
“IG−ON” mode. If the system works properly, the light goes off
after a few seconds.
If the light does not come on when the engine switch is selected
in “IG−ON” mode, have your vehicle checked by your Lexus
dealer.
If the system has a problem, the pre− collision system warning
light comes on or blinks. At this time, the master warning light
comes on, a warning tone sounds, and either of the following
messages appears on the multi−information display.
 PCS DISABLED NOW
 CHECK PCS

DRIVING TIPS
450
BREAKIN PERIOD
Drive gently and avoid high speeds.
You need not follow a break−in schedule with your new Lexus.
But following a few simple tips for the first 1600 km (1000 miles)
can add to the future economy and long life of your vehicle:
 Avoid full throttle acceleration when starting and driving.
 Avoid racing the engine.
 Try to avoid hard stops during the first 300 km (200 miles).
 Do not drive for a long time at any single speed, either fast
or slow.
OPERATION IN FOREIGN
COUNTRIES
If you plan to drive your Lexus in another country ...
First, comply with the vehicle registration laws.
Second, confirm the availability of the correct fuel (unleaded
and minimum octane rating).
TIPS FOR DRIVING IN VARIOUS CONDITIONS
Always slow down in gusty crosswinds. This will allow you
much better control.
 Drive slowly onto curbs and, if possible, at a right angle.
Avoid driving onto high, sharp −edged objects and other
road hazards. Failure to do so can lead to severe tire
damage such as a tire burst.
Drive slowly when passing over bumps or travelling on a
bumpy road. Otherwise, the impact could cause severe
damage to the tires and/or wheels.
 When parking on a hill, turn the front wheels until they touch
the curb so that the vehicle will not roll. Apply the parking
brake, and place the transmission in ”P”. If necessary, block
the wheels.
 Washing your vehicle or driving through deep water may get
the brakes wet. To see whether they are wet, check that
there is no traffic near you and then press the pedal lightly.
If you do not feel a normal braking force, the brakes are
probably wet. To dry them, drive the vehicle cautiously while
lightly pressing the brake pedal with the parking brake
applied. If they still do not work safel y, pull to the side of the
road and call a Lexus dealer for assistance.

IN CASE OF AN EMERGENCY
462
IF YOUR ENGINE STALLS WHILEDRIVING
If your engine stalls while driving . . .
1. Reduce your speed gradually, keeping a straight line. Move
cautiously off the road to a safe place.
2. Turn on your emergency flashers.
3. Turn the engine switch off, and try starting the engine again.
If the engine will not start, see ”If your vehicle will not start”\
.
CAUTION
If the engine is not running, the power assist for the
brakes and steering will not work, so steering and
braking will be much harder than usual.
IF YOUR VEHICLE WILL NOT START
(a) Simple checks
Before making these checks, make sure you have followed the
correct starting procedure instructions in ”Operating the
engine switch” on page 342 and that you have sufficient fuel.
Since your vehicle is equipped with the engine immobilizer,
also check whether the other keys will start the engine. If they
work, your electronic key may be broken. Have the key
checked at your Lexus dealer. If none of your keys work, there
may be a malfunction in the engine immobilizer. Call your
Lexus dealer. See ”Keys” on page 8.
If the engine is not turning over or is turning over too
slowly
1. Check that the battery terminals are tight and clean.
2. If the battery terminals are O.K., switch on the interior light.
3. If the light is out, dim or goes out when the starter is cranked,
the battery is discharged. You may try jump starting. See ”(c)
Jump starting” for further instruction.
If the light is O.K., but the engine still will not start, it needs
adjustment or repair. Call a Lexus dealer, Roadside
Assistance or Customer Service Assistance. (See
”Foreword”.)

IN CASE OF AN EMERGENCY
466
CAUTION
When making the connections, to avoid serious injury,
do not lean over the battery or accidentally let the
jumper cables or clamps touch anything except the
correct battery terminals or the ground.
5. Charge the discharged battery with the jumper cables
connected for approximately 5 minutes. At this time, run the
engine in the vehicle with the booster battery at about 2000
rpm with the accelerator pedal lightly depressed.
6. Start your engine in the normal way. After starting, run it at
about 2000 rpm for several minutes with the accelerator pedal
lightly depressed.
7. Carefully disconnect the cables in the exact reverse order:
the negative cable and then the positive cable.
8. Carefully dispose of the battery cover cloths which may now
contain sulfuric acid.
9. If removed, replace all the battery vent plugs.
If the cause of your battery discharging is not apparent (for
example, lights left on), you should have it checked at your
Lexus dealer.
If the first start attempt is not successful...
Check that the clamp on the jumper cables are tight. Recharge
the discharged battery with the jumper cables connected for
several minutes and restart your engine in the normal way.
If another attempt is not successful, the battery may be
depleted. Have it checked at your Lexus dealer.
IF YOU CANNOT INCREASE ENGINE SPEED
If engine speed does not increase when the accelerator
pedal is depressed, there may be a problem somewhere
in the electronic throttle control system. Move the vehicle
to a safe place by means of creeping and call a Lexus
dealer for assistance:
1. Depress the brake pedal and shift to the “D” position.
2. Gradually release the brake pedal, and the vehicle starts to
move by creeping. After arriving at a safe place, stop the
vehicle and call a Lexus dealer for assistance.
CAUTION
 The above method of moving the vehicle is for
emergency. Use it only for moving minimum
distances to a safe place.
 Be especially careful to prevent erroneous pedal
operation.

MAINTENANCE
494Battery
Your Lexus has a maintenance free battery. You do not have
to add distilled water. For longer life of the battery, however,
see page 571 for additional information.
Brake fluid level
Make sure the brake fluid level is correct. See page 538 for
additional information.
Engine oil level
Check the level on the dipstick with the engine turned off and
the vehicle parked on a level spot.
See page 522 for additional
information.
Exhaust system
If you notice any change in the sound of the exhaust or smell
exhaust fumes, have the cause located and corrected
immediately. (See “Engine exhaust caution” on page 341.)
Vehicle interior
Items listed below should be checked regularly, e.g. while
performing periodic services, cleaning the vehicle, etc.
Lights
Make sure the headlight, stop lights, tail lights, turn signal
lights, and other lights are working. Check headlight aim.
Service reminder indicators and warning buzzers
Check that all service reminder indicators and warning
buzzers function properly.
Steering wheel
Check that it ha s the specified free play. Be alert for changes
in steering condition, such as hard steering, excessive free
play or strange noise.
Seats
Check that all front seat controls such as seat adjusters,
seatback recliner, etc. operate smoothly. Check that the head
restraints move up and down smoothly and that the locks hold
securely in any latched position.
Seat belts
Check that the seat belt system such as buckles, retractors
and anchors operate properly and smoothly. Make sure the
belt webbing is not cut, frayed, worn or damaged.

ENGINE
514– COOLING SYSTEM
Capacity
10.1 L (10.7 qt., 8.9 lmp.qt.)
Coolant type”Toyota Super Long Life Coolant” or similar high quality ethylene glyco\
l
based non −silicate, non− amine, non−nitrite, and non −borate coolant
with long −life hybrid organic acid technology (Coolant with long −life
hybrid organic acid technology is a combination of low phosphates and
organic acids.)
Do not use plain water alone.
NOTE:
“Toyota Super Long Life Coolant” is used in your Lexus vehicle at factory fil\
l. In order to avoid technical problems, only use ”Toyota
Super Long Life Coolant” or similar high quality ethylene glycol based non −silicate, non −amine, non −nitrite, and non −borate coolant
with long−life hybrid organic acid technology. (Coolant with long −life hybrid organic acid technology is a combination of low
phosphates and organic acids.) Do not use plain water alone. Please contact you\
r Lexus dealer for further details.
– IGNITION SYSTEM
Spark plug – Make DENSO NGK
– Gap
SK20R11
IFR6A11
1.1 mm (0.043 in.)
– ELECTRICAL SYSTEM
Battery – Open voltage at 20 C (68F):
– Charging rates
12.7V Fully charged
12.3V Half charged
11.9V Discharged
[Voltage that is checked 20 minutes after the engine switch is off with all
the lights turned off]
5A max.

ENGINE
517
– COOLING SYSTEM
Capacity
9.1 L (9.6 qt., 8.0 lmp.qt.)
Coolant type”Toyota Super Long Life Coolant” or similar high quality ethylene glyco\
l
based non −silicate, non− amine, non−nitrite, and non −borate coolant
with long −life hybrid organic acid technology (Coolant with long −life
hybrid organic acid technology is a combination of low phosphates and
organic acids.)
Do not use plain water alone.
NOTE:
“Toyota Super Long Life Coolant” is used in your Lexus vehicle at factory fil\
l. In order to avoid technical problems, only use ”Toyota
Super Long Life Coolant” or similar high quality ethylene glycol based non −silicate, non −amine, non −nitrite, and non −borate coolant
with long−life hybrid organic acid technology. (Coolant with long −life hybrid organic acid technology is a combination of low
phosphates and organic acids.) Do not use plain water alone. Please contact you\
r Lexus dealer for further details.
– IGNITION SYSTEM
Spark plug – Make DENSO NGK
– Gap
FK20HBR11
ILFR6D11T
1.1 mm (0.043 in.)
– ELECTRICAL SYSTEM
Battery – Open voltage at 20 C (68F):
– Charging rates
12.7V Fully charged
12.3V Half charged
11.9V Discharged
[Voltage that is checked 20 minutes after the engine switch is off with all
the lights turned off]
5A max.

ENGINE
524
G62006
GS300 (fourwheel drive models)
1
Add oil 2O.K. 3Too full
4. Pull the dipstick out and look at the oil level while holding a
rag under the end. If it is between the full level mark (
5 ) and
the low level mark ( 4 ), it is O.K.
NOTICE
Be careful not to drop engine oil on the vehicle
components.
G62003
GS430 GS300
If the oil level is below or only slightly above the low level
mark, add engine oil of the same type as already in the
engine.
Remove the oil filler cap and add engine oil a little at a time,
checking the dipstick. We recommend that you use a funnel
when adding oil. The approximate quantity of oil needed to
raise the level between low and full on the dipstick is indicated
as follows:
1.5 L (1.6 qt., 1.3 lmp. qt.)
For the engine oil capacity, see “Specifications” on pages 512
and 515.
When the level reaches within the correct range, return the
filler cap and turn the cap clockwise until you hear a click.
