STARTING AND DRIVING
447
G13030
The precollision system warning light blinks, and the
above message appears in the following conditions:
The millimeter wave radar sensor or the grille cover is
dirty.
Clean the grille or sensor with a soft cloth to remove the dirt.
 The precollision seat belts are activated repeatedly for
a short time.
The system turns of f temporarily for overheating protection.
The above conditions do not indicate a malfunction. If the
problem is removed, the warning lights and message go out
and the system returns to normal.
G13031
If the pre−collision system warning light remains on, and the above message appears, the pre −collision system may not
operate. Contact your Lexus dealer as soon as possible to
service the vehicle.
Precaution for precollision system
It should be noted that the pre −collision sensor may detect the
following as the objects with which your vehicle might collide,
and the pre −collision system may operate, even though there
is no possibility of collision.
 When traveling through a curve, there is an object on the
edge of the road.
 When traveling through a curve, another vehicle is passing
from the opposite direction.
 When traveling across a narrow iron bridge.
 When there is a metallic object on the road.
 When there is a steel plate on the road at a construction site.
 When there is a bump on the road.
 When waiting to turn to the left in an intersection, and
another vehicle is passing from the opposite direction.
 If your vehicle approaches another vehicle ahead very
quickly.

DRIVING TIPS
455

Avoid continuous speeding up and slowing down.
Stop−and−go driving wastes fuel.
 Avoid unnecessary stopping and braking. Maintain a
steady pace. Try to time the traf fic signals so you only need
to stop as little as possible or take advantage of through
streets to avoid traffic lights. Keep a proper distance from
other vehicles to avoid sudden braking. This will also
reduce wear on your brakes.
 Avoid heavy traffic or traffic jams whenever possible.
 Do not rest your foot on the brake pedal. This causes
premature wear, overheating and poor fuel economy.
 Maintain a moderate speed on highways. The faster you
drive, the greater the fuel consumption. By reducing your
speed, you will cut down on fuel consumption.
 Keep the front wheels in proper alignment. Avoid hitting
the curb and slow down on rough roads. Improper
alignment not only causes faster tire wear but also puts an
extra load on the engine, which, in turn, wastes fuel.
 Keep the bottom of your vehicle free from mud, etc.
This not only lessens weight but also helps prevent
corrosion.
Keep your vehicle tunedup and in top shape. A dirty air
cleaner, improper valve clearance, dirty plugs, dirty oil and
grease, brakes not adjusted, etc. all lower engine
performance and contribute to poor fuel economy. For
longer life of all parts and lower operating costs, keep all
maintenance work on schedule, and if you often drive under
severe conditions, see that your vehicle receives more
frequent maintenance (For scheduled maintenance
information, please refer to the “Owner’s Manual
Supplement / Scheduled Maintenance”.)
CAUTION
Never turn off the engine to coast down hills. Your
power steering and brake booster will not function
without the engine running. Also, the emission control
system operates properly only when the engine is
running.

IN CASE OF AN EMERGENCY
465
G40027
GS300 5
Discharged battery 6Booster battery
GS300 only—Before carrying out the following procedure,
remove the engine compartment cover. (See page 504.)
JUMP STARTING PROCEDURE
1. If the booster battery is installed in another vehicle, make
sure the vehicles are not touching. Turn off all unnecessary
lights and accessories. When boosting, use the battery of matching or higher quality.
Any other battery may be difficult to jump start with.
If jump starting is difficult, charge the battery for several
minutes.
2. If required, remove all the vent plugs from the booster
battery. Lay a cloth over
the open vents on the booster battery.
(This helps reduce the explosion hazard, personal injuries and
burns.)
If the booster battery is an extended maintenance interval
battery, it is not necessary to remove the vent plugs.
3. If the engine in the vehicle with the booster battery is not
running, start it and let it run for about 5 minutes. During jump
starting, run the engine at about 2000 rpm with the accelerator
pedal lightly depressed.
4. Locate positive (+) and negative ( −) terminals of each
battery. Connect the jumper cables in the exact order (
1 2
3 4) shown in the illustration.
1 Connect a positive (red) jumper cable clamp to the
positive (+) terminal of the discharged battery.
2Connect the clamp at the other end of the positive (red)
cable to the positive (+) terminal of the booster battery.
3Connect a negative (black) cable clamp to the negative
(−) terminal of the booster battery.
4Connect the clamp at the other end of the negative (black)
cable to a solid, stationary, unpainted metallic point (such
as shown in the illustration) away from the battery. Do not
connect it to or near any part that moves when the engine
is cranked.

IN CASE OF AN EMERGENCY
466
CAUTION
When making the connections, to avoid serious injury,
do not lean over the battery or accidentally let the
jumper cables or clamps touch anything except the
correct battery terminals or the ground.
5. Charge the discharged battery with the jumper cables
connected for approximately 5 minutes. At this time, run the
engine in the vehicle with the booster battery at about 2000
rpm with the accelerator pedal lightly depressed.
6. Start your engine in the normal way. After starting, run it at
about 2000 rpm for several minutes with the accelerator pedal
lightly depressed.
7. Carefully disconnect the cables in the exact reverse order:
the negative cable and then the positive cable.
8. Carefully dispose of the battery cover cloths which may now
contain sulfuric acid.
9. If removed, replace all the battery vent plugs.
If the cause of your battery discharging is not apparent (for
example, lights left on), you should have it checked at your
Lexus dealer.
If the first start attempt is not successful...
Check that the clamp on the jumper cables are tight. Recharge
the discharged battery with the jumper cables connected for
several minutes and restart your engine in the normal way.
If another attempt is not successful, the battery may be
depleted. Have it checked at your Lexus dealer.
IF YOU CANNOT INCREASE ENGINE SPEED
If engine speed does not increase when the accelerator
pedal is depressed, there may be a problem somewhere
in the electronic throttle control system. Move the vehicle
to a safe place by means of creeping and call a Lexus
dealer for assistance:
1. Depress the brake pedal and shift to the “D” position.
2. Gradually release the brake pedal, and the vehicle starts to
move by creeping. After arriving at a safe place, stop the
vehicle and call a Lexus dealer for assistance.
CAUTION
 The above method of moving the vehicle is for
emergency. Use it only for moving minimum
distances to a safe place.
 Be especially careful to prevent erroneous pedal
operation.

MAINTENANCE
494Battery
Your Lexus has a maintenance free battery. You do not have
to add distilled water. For longer life of the battery, however,
see page 571 for additional information.
Brake fluid level
Make sure the brake fluid level is correct. See page 538 for
additional information.
Engine oil level
Check the level on the dipstick with the engine turned off and
the vehicle parked on a level spot.
See page 522 for additional
information.
Exhaust system
If you notice any change in the sound of the exhaust or smell
exhaust fumes, have the cause located and corrected
immediately. (See “Engine exhaust caution” on page 341.)
Vehicle interior
Items listed below should be checked regularly, e.g. while
performing periodic services, cleaning the vehicle, etc.
Lights
Make sure the headlight, stop lights, tail lights, turn signal
lights, and other lights are working. Check headlight aim.
Service reminder indicators and warning buzzers
Check that all service reminder indicators and warning
buzzers function properly.
Steering wheel
Check that it ha s the specified free play. Be alert for changes
in steering condition, such as hard steering, excessive free
play or strange noise.
Seats
Check that all front seat controls such as seat adjusters,
seatback recliner, etc. operate smoothly. Check that the head
restraints move up and down smoothly and that the locks hold
securely in any latched position.
Seat belts
Check that the seat belt system such as buckles, retractors
and anchors operate properly and smoothly. Make sure the
belt webbing is not cut, frayed, worn or damaged.

ENGINE
514– COOLING SYSTEM
Capacity
10.1 L (10.7 qt., 8.9 lmp.qt.)
Coolant type”Toyota Super Long Life Coolant” or similar high quality ethylene glyco\
l
based non −silicate, non− amine, non−nitrite, and non −borate coolant
with long −life hybrid organic acid technology (Coolant with long −life
hybrid organic acid technology is a combination of low phosphates and
organic acids.)
Do not use plain water alone.
NOTE:
“Toyota Super Long Life Coolant” is used in your Lexus vehicle at factory fil\
l. In order to avoid technical problems, only use ”Toyota
Super Long Life Coolant” or similar high quality ethylene glycol based non −silicate, non −amine, non −nitrite, and non −borate coolant
with long−life hybrid organic acid technology. (Coolant with long −life hybrid organic acid technology is a combination of low
phosphates and organic acids.) Do not use plain water alone. Please contact you\
r Lexus dealer for further details.
– IGNITION SYSTEM
Spark plug – Make DENSO NGK
– Gap
SK20R11
IFR6A11
1.1 mm (0.043 in.)
– ELECTRICAL SYSTEM
Battery – Open voltage at 20 C (68F):
– Charging rates
12.7V Fully charged
12.3V Half charged
11.9V Discharged
[Voltage that is checked 20 minutes after the engine switch is off with all
the lights turned off]
5A max.

ENGINE
517
– COOLING SYSTEM
Capacity
9.1 L (9.6 qt., 8.0 lmp.qt.)
Coolant type”Toyota Super Long Life Coolant” or similar high quality ethylene glyco\
l
based non −silicate, non− amine, non−nitrite, and non −borate coolant
with long −life hybrid organic acid technology (Coolant with long −life
hybrid organic acid technology is a combination of low phosphates and
organic acids.)
Do not use plain water alone.
NOTE:
“Toyota Super Long Life Coolant” is used in your Lexus vehicle at factory fil\
l. In order to avoid technical problems, only use ”Toyota
Super Long Life Coolant” or similar high quality ethylene glycol based non −silicate, non −amine, non −nitrite, and non −borate coolant
with long−life hybrid organic acid technology. (Coolant with long −life hybrid organic acid technology is a combination of low
phosphates and organic acids.) Do not use plain water alone. Please contact you\
r Lexus dealer for further details.
– IGNITION SYSTEM
Spark plug – Make DENSO NGK
– Gap
FK20HBR11
ILFR6D11T
1.1 mm (0.043 in.)
– ELECTRICAL SYSTEM
Battery – Open voltage at 20 C (68F):
– Charging rates
12.7V Fully charged
12.3V Half charged
11.9V Discharged
[Voltage that is checked 20 minutes after the engine switch is off with all
the lights turned off]
5A max.

ELECTRICAL COMPONENTS
566
No.FUSEAMPERECIRCUIT
1 STR LOCK25Steering lock system
2 SECURITY7.5Smart access system with
push−button start
3 TI &TE20Power tilt and telescopic
steering wheel, Multiplex
communication system
4 AM17.5Starting system
5 STOP SW7.5
Stop/tail lights, Multi− port fuel
injection system/sequential
multiport fuel injection system,
Starting system, Electronic
control brake system, Vehicle
stability control system, Shift
lock system
6 OBD7.5On− board diagnosis system
7 FR P/SEAT
RH30Power seat system
8 AIR SUS20Electronic modulated
suspension
9 PWR
OUTLET15Power outlet
10 CIG15Cigarette lighter
11 ACC7.5
Multiplex communication
system, Smart access system
with push− button start, Rear
view monitor system, Audio
system, Air conditioning system
No.FUSEAMPERECIRCUIT
12 IGN10
Multi− port fuel injection
system/sequential multiport fuel
injection system, SRS airbag
system, Stop/tail lights,
Steering lock system, Electronic
control brake system
13 GAUGE7.5Gauges and meters
14 ECUIG
RH10
Power tilt and telescopic
steering wheel, Multiplex
communication system, Smart
access system with
push −button start, Audio
system, Air conditioning
system, Shift lock system, Tire
pressure warning system,
Combination switch
15 FR S/HTR
RH15Seat heater, Heated and
ventilated seats
16 RHIG7.5
Seat heater switches, Front
right door control system, Rear
right door control system,
Capacitor, Combination switch,
Seat belt pretensioners,
Intuitive parking assist
17 AM215Starting system

ELECTRICAL COMPONENTS
568
No.FUSEAMPERECIRCUIT
28 ECUIG LH10
Vehicle stability control system,
Electronic control brake system,
Yaw rate and G sensor,
Steering sensor, Cruise control
system, Dynamic radar cruise
control system, Electronic
power steering system, Variable
gear ratio steering system,
Rear view monitor system,
Four−wheel drive system, Front
controller, Moon roof, Rain
sensor
29 FR S/HTR
LH15Seat heater, Heated and
ventilated seats
30 FR P/SEAT LH30Power seat system
31 A/C7.5Air conditioning system
32 TV7.5Audio system, Air conditioning
system, Rear view monitor
system
33 TRK OPN10Trunk lid opener
34 LHB10Theft deterrent system
35 S/ROOF25Moon roof
36 ECUB10
Variable gear ratio steering
system, Electronic power
steering system, Driver’s seat
switch module
37 ABS
MAIN310Electronic control brake system
No.FUSEAMPERECIRCUIT
38 TURNHAZ15Turn signal lights, Emergency
flashers
39 IG2 MAIN20“IG2”, “GAUGE” and “IGN”
40 RAD NO.230Audio system
41 D/C CUT20“DOME “ and “MPX− B”
42 RAD NO.130Audio system
43 MPXB10
Multiplex communication
system, Front controller, Door
control system (Power door
lock system, Door courtesy
lights, Power windows, Power
rear view mirror control system,
Outside rear view mirror
heaters), Power seat system,
Steering sensors, Electronic
control brake system, Power tilt
and telescopic steering system,
Gauges and meters,
Combination switch
44 DOME10
Foot lights, Vanity lights,
Gauges and meters, Steering
spot light, Steering switch
illumination, Rear personal
lights, Automatic transmission
selector lever spot light, Front
personal lights
45 ABS
MAIN210Electronic control brake system
46 ABS
MOTOR30Anti− lock brake system

ELECTRICAL COMPONENTS
570
No.FUSEAMPERECIRCUIT
70 A/F15Multi−port fuel injection
system/sequential multiport fuel
injection system
71 ETCS10Multi−port fuel injection
system/sequential multiport fuel
injection system
72 ALTS7.5Charging system
73 EM VLV10No circuit
74 HLP CLN30Headlight cleaner system
75 A/C COMP7.5Air conditioning system
76 DEICER25No circuit
77 FR
CTRLAM30“FR TAIL”, “FR FOG” and
“WASHER”
78 IG210Starting system
79 EFI NO.210
Multi− port fuel injection
system/sequential multiport fuel
injection system, Evaporative
system
80 HLP R
LW R15Right− hand headlight (low
beam)
81 HLP L
LW R15Left− hand headlight (low beam)
82 F/PMP25Fuel pump
No.FUSEAMPERECIRCUIT
83 EFI
GS430:
25
GS300: 25Multi− port fuel injection
system/sequential multiport fuel
injection system
84 INJ20Multi− port fuel injection
system/sequential multiport fuel
injection system
85 HLP UPR15Headlights (high beam)
86 HORN10Horn
87 WASHER20Windshield wipers and washer
88 FR TAIL10Parking lights, Side marker
lights
89 FR FOG15Front fog lights
90 RR
S/SHADE7.5Rear electric sunshade
91 PSB30Pre− collision system
92 RRIG210No circuit
93 RRIG110Pre− collision system, Rear
electric sunshade, Seat belt
pretensioners
94 RRB10Luggage compartment light,
Noise filter
95 RR FOG7.5Rear fog lights
96 STOP LP L10Stoplights, Back up lights
