display Lexus GS450h 2007 Hybrid system / LEXUS 2007 GS450H THROUGH JUNE 2006 PROD. QUICK REFERENCE MANUAL

1
When Driving
To p i c 3
Overview
Contents
Entering and Exiting
To p i c 1
Before Driving
To p i c 2
lStartingP.1 7
lTransmissionP.1 8
lPa r k i n g B ra keP.1 8
lMulti-information DisplayP.1 9
lTu r n S i g n a l L e v e rP. 2 0
lEmergency Flasher SwitchP. 2 0
lMode Select SwitchP. 2 0
lIntuitive Parking AssistP. 2 1
lCruise ControlP. 2 2
lKeysP. 7
lSmart Access System with
Push-button StartP. 8
lAnti-theft SystemP.9
The Quick Guide is not intended as a substitute for your Owner’s
Manual. We strongly encourage you to review the Owner’s
Manual and supplementary manuals so you will have a better
understanding of your vehicle’s capabilities and limitations.
lDynamic Radar Cruise
ControlP. 2 3
lAVS (Adaptive Variable
Suspension)P. 2 4
lTRAC OFF SwitchP. 2 4
lSeatsP.1 1
lDriving and Seat Position Memory
SystemP.1 2
lHead RestraintsP.1 3
lSeatbeltsP.1 3
lOutside Rear View MirrorsP.1 4
lInside Rear View MirrorP.1 4
lSteering WheelP.1 5
lOdometer/Trip Meter and
Trip Meter Reset ButtonsP.1 5

3
OverviewInstrument Panel
Windshield wipers and
washer switch
P.28Headlight switch
Turn signal lever
Fog light switch P.27
P.20
P.28
See P.5
Inside door lock button P.45
Door lock switch P.45
Power window switches P.46
Window lock switch P.46
Tilt and telescopic
steering control switch
P.15
Parking brake pedal P.18
Telephone switch P.36
Cruise control switch P.22, 23
Multi-information
display
P.19
Driving and seat position
memory switches
∗ P.12
Distance switch∗ P.23
“DISP” switch P.19

Topic 2
Before Driving
15
Steering Wheel
Up
Down
Away from the driver
Toward the driver
Odometer/Trip Meter and Trip Meter Reset
Buttons
Changes the display.
Resets the trip meter driving range to 0.
1
2
3
4
The steering wheel retracts automatically when the power switch is turned OFF to allow for
easy exit and entry. The steering wheel returns automatically to its previously set position
when the power switch is switched to ACC or IG-ON mode.
1
2

When DrivingTo p i c 3
Starting ..................................................................... 17
Transmission............................................................ 18
Parking Brake ......................................................... 18
Multi-information Display................................... 19
Turn Signal Lever.................................................. 20
Emergency Flasher Switch ................................ 20
Mode Select Switch............................................. 20
Intuitive Parking Assist ........................................ 21
Cruise Control ...................................................... 22
Dynamic Radar Cruise Control ....................... 23
AVS (Adaptive Variable Suspension) ............ 24
TRAC OFF Switch ............................................... 24

Topic 3
When Driving
18
Entering and Exiting
Before DrivingBefore Driving
When DrivingWhen Driving
Rain and
Night Driving
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Transmission
nShift positions
PPa r k *
RReverse
NNeutral (drive not engaged)
DDrive
SS mode
*: The hybrid system can only be started in P.
The vehicle can only be shifted out of P when
the power switch is in IG-ON mode and the
brake pedal is depressed.
nS mode
S mode allows the driver to select the shift range manually based on driving conditions.
Shift the shift lever to S.
To u p s h i f t : shift the shift lever toward "+".
To d o w n s h i f t : shift the shift lever toward "-".
The selected shift range is displayed on the
instrument cluster.
Par ki n g B rake
To s e t: firmly depress the parking brake pedal.
To r e l e a s e: depress the parking brake pedal
again.

Topic 3
When Driving
19
Multi-information Display
nDisplay information
lEnergy monitor
lTrip information
•Driving range
•Average fuel consumption after refueling
•Current fuel consumption
•Average vehicle speed
lIntuitive parking assist information
(if equipped)
lDynamic radar cruise control settings
(if equipped)
lWa r n i n g m e s s a g e s
nChanging the display
Trip information items can be switched by press-
ing the DISP switch.
The multi-information display shows information about your vehicle, including the items
shown below.
nWhen using the intuitive parking assist or dynamic radar cruise control, the appropriate
display is shown on the screen.
nIf a problem is detected in any of the vehicle's systems, a warning message is shown on the
multi-information display.

Topic 3
When Driving
21
Intuitive Parking Assist (If Equipped)
nTurning the system on and off
The system can be turned on and off using the
intuitive parking assist switch.
nScreen display
Multi-information display
Sensors are used to detect obstacles near the
vehicle. The distance to a detected obstacle is
shown by the number of indicator bars.
Indicates obstacles detected by the dual sen-
sors
Indicates the steering maneuvers required to
avoid an obstacle.
Indicates obstacles detected by the rear cor-
ner sensors
Indicates obstacles detected by the back sen-
sors Touch screen
The system uses a screen display and buzzer to inform the driver of obstacles near the
vehicle when parking or driving at low speed.
1
2
3
4

Topic 3
When Driving
23
Dynamic Radar Cruise Control (If Equipped)
nCruise control display
Cruise control settings are shown on the multi-
information display.
Vehicle ahead indicator
Vehicle-to-vehicle distance
Preset speed
nVehicle-to-vehicle distance control mode
Press the ON-OFF button.
Accelerate or decelerate to the desired
speed, and then push the lever down.
Following distance can be adjusted using the
vehicle-to-vehicle distance control switch.
nConventional (constant speed) cruise control mode
Press the ON-OFF button.
Push the lever forward and hold for at least
one second.
Accelerate or decelerate to the desired
speed, and then push the lever down.
nAdjusting the speed setting
To increase speed: push the lever up.
To decrease speed: push the lever down.
Release the lever when the desired speed is
reached
nCanceling
To temporarily cancel the dynamic radar cruise
control, pull the lever.
To turn the system off, press the ON-OFF button.
Dynamic radar cruise control supplements conventional cruise control with a vehicle-to-
vehicle distance control mode.
1
2
3
The vehicle-to-vehicle distance control mode maintains the preset cruising speed as long
as no vehicle is detected ahead.

Topic 5
Driving Comfort
31
Touch Screen
By touching the screen with your finger, you can control the audio system, air-conditioning
and adjust the screen display, etc. For details, see the Owner’s Manual.
*: See Navigation System Owner’s Manual
When you press this button...This display appears.
CLIMATEAir conditioning operation screen
AUDIOAudio control screen
INFOInformation screen
DISPDisplay screen
Trip informationTrip information screen
MaintenanceMaintenance screen*
Te l e p h o n eTelephone screen
Adjust ClockAdjust clock screen
CalenderCalender screen*
LEXUS Park AssistLEXUS Park Assist setting screen
LanguageSelect language screen
Screen SettingScreen setting screen
1
2
3
4
5
6
7
8
9
10
11
12

Topic 5
Driving Comfort
32
Entering and Exiting
When Driving
Rain and
Night Driving
Driving ComfortDriving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Before Driving
Air Conditioning System
Press to display the air conditioning operation screen. For details, refer to the Owner’s
Manual
Vehicles with navigation system
Vehicles without navigation system
Air conditioning operation screen display button
Driver’s side temperature control
Automatic mode
Dual operation switch
Passenger’s side temperature control
1
2
3
4
5
