fuse Lexus GS450h 2013 Using the audio system / LEXUS 2013 GS450H (OM30D01U) Owner's Manual

GS450h_U (OM30D01U)
6836-3. Do-it-yourself maintenance
6
Maintenance and care
■The upper part of the 12-volt battery*
*
: When one or more of the fuses in this unit are blown, the unit needs to be replaced as a whole.
FuseAmpereCircuit
1EPB30Parking brake
2LUG-J/B BATT40Luggage compartment junction block
3EPS80Electric power steering
4ARS80No circuit
5MAIN220Engine compartment junction block

684
GS450h_U (OM30D01U)
6-3. Do-it-yourself maintenance
■After a fuse is replaced
●If the lights do not turn on even after the fuse has been replaced, a bulb may need
replacement. (P. 6 8 7 )
●If the replaced fuse blows again, have the vehicle inspected by your Lexus dealer.
■If there is an overload in a circuit
The fuses are designed to blow, protecting the wiring harness from damage.
■When replacing light bulbs
Lexus recommends that you use genuine Lexu s products designed for this vehicle.
Because certain bulbs are connected to circuits designed to prevent overload, non-
genuine parts or parts not designed for this vehicle may be unusable.
CAUTION
■To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failure to do so may cause damage, and possibly a fire or injury.
●Never use a fuse of a higher amperage rating than that indicated, or use any
other object in place of a fuse.
●Always use a genuine Lexus fuse or equivalent.
Never replace a fuse with a wire, even as a temporary fix.
This can cause extensive damage or even fire.
●Do not modify the fuses or fuse boxes.
NOTICE
■Before replacing fuses
Have the cause of electrical overload determined and repaired by your Lexus
dealer as soon as possible.

762
GS450h_U (OM30D01U)
7-2. Steps to take in an emergency
If the hybrid system will not start
One of the following may be the cause of the problem:
●The electronic key may not be functioning properly. (P. 76 8 )
●There may not be sufficient fuel in the vehicle’s tank.
Refuel the vehicle.
●There may be a malfunction in the immobilizer system. ( P. 7 9 )
●There may be a malfunction in the steering lock system.
●The hybrid system may be malfunctio ning due to an electrical problem
such as electronic key battery de pletion or a blown fuse. However,
depending on the type of malfuncti on, an interim measure is available
to start the hybrid system. ( P. 763)
One of the following may be the cause of the problem:
●The 12-volt battery may be discharged. ( P. 770)
●The 12-volt battery terminal connecti ons may be loose or corroded.
Reasons for the hybrid system not st arting vary depending on the situa-
tion. Check the following and perf orm the appropriate procedure:
The hybrid system will not start even though the correct starting
procedure is being followed. ( P. 1 8 9 )
The interior lights and headlights are dim, or the horn does not
sound or sounds at a low volume.

846Alphabetical index
GS450h_U (OM30D01U)
Front seats ................................................ 148Adjustment ............................................. 148
Cleaning ................................................ 620
Correct driving posture ....................30
Driving position memory ................ 150
Head restraints ..................................... 155
Power easy access system ............ 153
Seat heaters ......................................... 590
Seat position memory....................... 150
Seat ventilators ..................................... 591
Front side marker lights .......................213 Light switch .............................................213
Replacing light bulbs ........................697
Welcome light illumination control ..................................................... 121
Front turn signal lights ........................ 205 Replacing light bulbs ......................... 691
Turn signal lever ................................ 205
Wattage ....................................................791
Fuel ............................................................. 784 Capacity .................................................784
Fuel gauge ................................................89
Information ............................................ 792
Refueling................................................. 227
Type .............................................. 227, 784
Warning light .........................................714
Warning messages........................... 737
Fuel consumption Average fuel consumption...............96
Average fuel consumption after refueling.......................................95
Current fuel consumption ................95 Fuel filler door......................................... 227
If the fuel filler door cannot be opened ......................... 230
Refueling .................................................227
Fuses...........................................................670
Garage door opener.......................... 600
Gauges........................................................ 89
Glove box ................................................576
Glove box light.......................................576
Hands-free system (for cellular phone)........................... 506
HD Radio
® system ................................ 414
Head restraints........................................ 155
Headlight cleaner .................................226
Headlights ................................................. 213 Adaptive Front-lighting System (AFS) ..................................... 215
Discharge headlights precautions .......................................699
Headlight leveling warning message............................724
Light switch............................................. 213
Replacing light bulbs ....................... 697
Wattage ................................................... 791
Headlights aim ...................................... 685
Head-up display ..................................... 102
G
H

852Alphabetical index
GS450h_U (OM30D01U)
Rear turn signal lights ......................... 205Replacing light bulbs ....................... 695
Turn signal lever ................................ 205
Wattage ....................................................791
Rear view mirror Inside rear view mirror ..................... 159
Outside rear view mirrors ................ 161
Rear view monitor system .................274
Rear window defoggers .................... 384
Refueling ...................................................227 Capacity .................................................784
Fuel types ...............................................784
If the fuel filler door cannot be opened ........................ 230
Opening the fuel tank cap............. 229
Regenerative braking .............................72
Remote Touch ....................................... 328
Remote Touch screen ........................330
Replacing Electronic key battery ..................... 668
Fuses........................................................ 670
Light bulbs ............................................ 687
Tires .......................................................... 749
Reporting safety defects for U.S. owners...................................820
Reset the maintenance data ............ 624
Road accident cautions ......................... 77 Safety Connect ......................................607
Seat belts .....................................................32
Adjusting the seat belt........................ 33
Automatic Locking Retractor ........ 34
Child restraint system installation ............................................. 62
Cleaning and maintaining the seat belt ......................................... 621
Emergency Locking Retractor................................................ 34
How to wear your seat belt..............32
How your child should wear the seat belt .......................................... 35
Pre-collision seat belts ....................... 34
Pregnant women, proper seat belt use ......................................... 36
Reminder light and buzzer ............. 714
Seat belt extender ................................ 35
Seat belt pretensioners ...................... 34
SRS warning light ................................ 712
Seat heaters............................................ 590
Seat position memory ..........................150
Seat ventilators........................................ 591
Seating capacity ..................................... 186S
