643
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_U.S.A. (OM60E69U)
■Use a CR1632 lithium battery
●Batteries can be purchased at your Lexus dealer, local electrical appliance
shops or camera stores.
●Replace only with the same or equivalent type recommended by the manufac-
turer.
●Dispose of used batteries according to the local laws.
■If the electronic key battery is discharged
The following symptoms may occur.
●The smart access system with push-button start and wireless remote control will
not function properly.
●The operational range is reduced.
Remove the depleted battery.
Insert a new battery with the “+”
terminal facing up.
STEP3

652
4-3. Do-it-yourself maintenance
GX460_U.S.A. (OM60E69U)
51ECU-B10 A
Body ECU, meter, heater, steering
sensor, wireless remote control, seat
position memory, tilt and telescopic
steering, multi display, Smart access
system with push button start, folding
seat, cool box, DSS#2 ECU, steering
switch, D-module switch, overhead
module
52WSH FR NO.27. 5 ADSS#1 ECU
53H-LP RH-LO15 AHeadlight low beam (right), headlight
leveling system
54H-LP LH-LO15 AHeadlight low beam (left), headlight
leveling system
55INJ10 ACoil, injector, ignition, noise filter
56EFI NO.210 A
O2 SSR, AFM, ACIS VSV, AI
COMB, KEY OFF PUMP, EYP VSV,
EGR VALVE, CANISTER VSV, AI
VSV RLY, AI PUMP HTR RLY
57WIP FR NO.27. 5 ADSS#1 ECU
58WSH RR15 ARear window washer
59SPARESpare fuse
60SPARESpare fuse
61SPARESpare fuse
FuseAmpereCircuit

738
5-2. Steps to take in an emergency
GX460_U.S.A. (OM60E69U)
If the electronic key does not operate properly
Locking and unlocking the doors and key linked functions
Use the mechanical key (P. 2 6 )
in order to perform the following
operations (driver’s door only):
Locks all the doors
Closes the windows and moon
roof (turn and hold)
*
Unlocks the door
Turning the key rearward unlocks
the driver’s door. Turning the key
once again unlocks the other
doors.
Opens the windows and moon
roof (turn and hold)
*
*
: This setting must be customized at your Lexus dealer.
If communication between the electron ic key and vehicle is interrupted
(  P. 40) or the electronic key cannot be used because the battery is
depleted, the smart access system with push-button start and wireless
remote control cannot be used. In such cases, the doors can be opened or
the engine can be started by following the procedure below.

786
6-2. Customization
GX460_U.S.A. (OM60E69U)
Smart
access 
system with
push- 
button start
and wire-
less remote
control 
(
P. 2 9 ,
48)
LOCK FEED-
BACK VOL-
UME
(Adjust the vol-
ume of confor-
mation buzzer
sounds when
the vehicle is
locked or
unlocked)
7
Off
O–OO
1 to 6
LO C K /
UNLOCK
ANSWER
BACK
RESPONSE
(Enable/disable
the operation of
the emergency
flashers when
the vehicle is
locked or
unlocked)
OnOffO–OO
ItemFunctionDefault
settingCustomized setting

787
6-2. Customization
6
Vehicle specifications
GX460_U.S.A. (OM60E69U)
Smart
access sys-
tem with
push-but-
ton start
and wire-
less remote
control
(
P. 2 9 ,
48)
AUTO.
RELOCK TIME
ADJUSTMENT
(Adjust the time
elapsed before
the automatic
door lock func-
tion is activated
if a door is not
opened after
being unlocked)
60 seconds
Off
O–OO30 seconds
120 seconds
Open door
reminder
buzzer (When
locking the
vehicle)
OnOff–––O
Glass hatch
opening opera-
tion (When the
electronic key is
used)
Push and
hold (Short)
Push twice
–––O
One short push
Push and
hold (Long)
Off
ItemFunctionDefault settingCustomized setting

792
6-2. Customization
GX460_U.S.A. (OM60E69U)
Illumination
(
P. 511)
Operation after
the “ENGINE
START STOP”
switch is turned
to OFF
*4
OnOff–––O
Operation
when the doors
are unlocked
with the smart
access system
with push-but-
ton start or the
wireless remote
control func-
tion
*4
OnOff–––O
Operation
when you
approach the
vehicle with the
electronic key
on your per-
son
*4
OnOff–––O
ItemFunctionDefault settingCustomized setting

814
Alphabetical index
GX460_U.S.A. (OM60E69U)
Garage door opener .......................... 567
Gas station information......................824
Gauges ...................................................... 195
Glove box ................................................. 516
Glove box light ....................................... 516
Hands-free system for cellular 
phones.................................................... 477
Hazard lights Switch ...................................................... 674
Head restraints Adjustment............................................... 83
Headlights cleaner ................................ 241
Headlights Adaptive front lighting 
system .................................................. 223
Discharge headlights 
precautions ....................................... 672
Replacing light bulbs..........................661
Switch ...................................................... 220
Wattage.................................................... 761
Heaters Seat heaters ........................................... 551
Side mirror ............................................404
Heated steering..................................549
Height control Rear height control air 
suspension.......................................... 310
Hill-start assist control ......................... 331
Hood .......................................................... 607
Hooks Cargo ...................................................... 557
Cargo hooks .......................................559
Coat ........................................................ 555
Horn ............................................................ 194 I/M test ...................................................... 601
Identification
Engine ....................................................... 751
Vehicle...................................................... 751
Ignition switch .......................................... 179
Ignition switch light Ignition switch light ...............................511
Illuminated entry system ......................514
Indicator lights ........................................ 198
Initialization Items to initialize...................................801
Inside door handle light ........................ 511
Inside rear view mirror .......................... 96
Instrument cluster light control.........196
Interior lights Interior lights ............................................ 511
Switch ........................................................ 513
Wattage ................................................... 761
Intuitive parking assist......................... 259
Jack Vehicle-equipped jack....................720
Jack handle ............................................. 720
Keyless entry ................................................. 48
Keys Electronic key ......................................... 26
Engine switch .......................................... 29
If you lose your keys ......................... 737
If the electronic key does not 
operate properly............................ 738
Key number plate.................................. 26
Keyless entry........................................... 48
Keys.............................................................. 26
Mechanical key ...................................... 26
Wireless remote control key.......... 48G
H
I
J
K

819
Alphabetical index
GX460_U.S.A. (OM60E69U)
Warning buzzersBrake system ....................................... 705
Open door .............................. 690, 703
Open glass hatch reminder......... 704
Seat belt reminder ............................690
Warning lights Anti-lock brake system 
(ABS) .................................................. 688
Brake system .......................................686
Charging system ............................... 687
Kinetic dynamic suspension 
system..................................................689
Low fuel level.......................................690
Malfunction indicator lamp .......... 687
Master warning light ..........................691
Open door ...........................................690
PCS ......................................................... 688
Seat belt reminder light ..................690
Slip indicator light ............................. 688
SRS airbags ......................................... 688
Tire pressure warning light.............691
Warning messages Automatic transmission fluid 
temperature ...................................... 700
Automatic transmission  system.................................................. 700
Brake system ....................................... 705
Dynamic radar cruise control 
system...................................... 702, 707
Engine oil maintenance.................. 705
Engine oil pressure........................... 699
Intuitive parking assist ....................... 701
Low washer level............................... 705
Open door ........................................... 703
Open glass hatch .............................. 704 Open moon roof ...............................704
Pre-collision system............... 701, 706
Rear height control air suspension

system ................................................... 701
Smart access system with push 
button start ........................................ 709
Steering lock system ....................... 700
Warning reflector holder ................. 558
Washer Checking ...............................................626
Preparing and checking 
before winter ..................................... 361
Switch.......................................................235
Washing and waxing .......................... 588
Weight Cargo capacity .................................. 353
Load limits ............................................ 359
Weight.................................................... 750
Wheels ......................................................638
Wide view front & side monitor...... 279
Window glasses ......................................101
Window lock switch ...............................101
Windows Power windows ..................................... 101
Rear window defogger.................. 404
Washer ...................................................235
Windshield wiper de-icer..................405
Windshield wipers................................ 235
Winter driving tips ................................. 361
Wireless remote control key Locking/Unlocking .............................48
Replacing the battery.......................642
Wireless remote control key ..........48
WMA disc ............................................... 424W
*: Refer to the “Navigatio n System Owner’s Manual”.
