Lexus GX460 2010 Scheduled Maintenance Guide /

31
GX460_QG_U (OM60E77U)
Headlights
U.S.A.
Turn off the daytime running
light system.
The headlights, parking lights
and so on turn on and off auto-
matically (when the “ENGINE
START STOP” switch is in
IGNITION ON mode).
The side marker, parking, tail,
license plate and instrument
panel lights turn on.
The headlights and all the lights
listed above turn on.
Canada
OFF
The side marker, parking, tail,
license plate and instrument
panel lights turn on.
The headlights and all lights
listed above turn on.
The headlights, parking lights
and so on turn on and off auto-
matically (when the “ENGINE
START STOP” switch is in
IGNITION ON mode).

32
GX460_QG_U (OM60E77U)
■Turning on the high beam headlights
With the headlights on, push the lever
away from you to turn on the high
beams.
When the light switch is in “AUTO” posi-
tion, the Automatic High Beam system
will be activated.
Pull the lever toward you to the center
position to turn the high beams off.
Pull the lever toward you and release it
to flash the high beams once.
You can flash the high beams with the
headlights on or off.
■AFS (Adaptive Front-lighting System) (if equipped)
AFS (Adaptive Front-lighting System) secures excellent visibility at intersections and on
curves by automatically adjusting the direction of the light axis of the headlights according
to vehicle speed and the degree of the tire’s angle as controlled by steering input.
AFS operates at speeds of 6 mph (10 km/h) or higher.
■Deactivating AFS
Press the menu switch.
The multi-information display will
change modes to electronic features
control mode.
Press the “ENTER” switch upwards or
downwards until “AFS” appears.
Press the “ENTER” switch to change to
“OFF”.
The “AFS OFF” indicator will be dis-
played.
Each pressing of the switch turns “AFS”
on and off.
Press the menu switch to change to the nor-
mal display.

33
GX460_QG_U (OM60E77U)
Automatic High Beam (If Equipped)
■Activating the Automatic High Beam system
Turn the headlight switch to “AUTO”
position.
Push the lever away from you.
The Automatic High Beam indicator will
come on when the headlights are turned
on automatically to indicate that the sys-
tem is active.
The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of
streetlights, the lights of oncoming and preceding vehicles, etc., and automatically turns
high beam on or off as necessary.
When all of the following conditions are fulfilled, high beam will be automatically turned on
(after approximately 1 second):
• Vehicle speed is above approximately 20 mph (32 km/h).
• The area ahead of the vehicle is dark.
• There are no oncoming or preceding vehicles with headlights or tail lights turned on.

34
GX460_QG_U (OM60E77U)
Windshield Wipers and Washers
Off
Rain-sensing wiper operation
Low speed wiper operation
High speed wiper operation
Te m p o r a r y o p e r a t i o n
Increases the sensitivity
Decreases the sensitivity
Washer/wiper dual operation
The wipers operate automatically. (After
operating several times, the wipers
operate one more time after a short
delay to prevent dripping.)
Vehicles with the headlight cleaners: If
the headlights are on, the headlight
cleaners will operate once.

35
GX460_QG_U (OM60E77U)
Rear Window Wiper and Washer
Off
Intermittent window wiper
operation
Normal window wiper opera-
tion
Washer/wiper dual operation
Washer/wiper dual operation

36
GX460_QG_U (OM60E77U)
Navigation System (If Equipped)
■Register home
Push the “SETUP” button.
Touch “Navi.”.
To u c h “ H o m e ” .
Touch “Set Home”.
To u c h “A d d r e s s ” .
To u c h “ C i t y ” .
Input a city name and touch “OK”.
Touch the button of the desired city
name from the displayed list.
Input the street name and touch “OK”.
When the desired street name is found,
touch the corresponding button.
Input a house number and touch “OK”.
Touch “Enter”.
To u c h “ O K ” .STEP2
STEP3
STEP5
STEP6

37
GX460_QG_U (OM60E77U)
■Destination input  Search by address
Select by city name
Push the “DEST” button
To u c h “A d d r e s s ” .
To u c h “ C i t y ” .
Input a city name and touch “OK”.
Touch the button of the desired city
name from the displayed list.
Input the street name and touch “OK”.
When the desired street name is found,
touch the corresponding button.
Input a house number and touch “OK”.
To u c h “ G o t o ” .
To u c h “ O K ” .
STEP2
STEP3
STEP4
STEP6

38
GX460_QG_U (OM60E77U)
■Destination input  Search by address
Select by street address
Push the “DEST” button.
To u c h “A d d r e s s ” .
Touch “Street Address”.
Input a house number and touch “OK”.
Input the street name and touch “OK”.
When the desired street name is found,
touch the corresponding button.
Input a city name and touch “OK”.
Touch the button of the desired city
name from the displayed list.
To u c h “ G o t o ” .
To u c h “ O K ” .
-
STEP2
STEP3
STEP4
STEP5

39
GX460_QG_U (OM60E77U)
■Destination input  Search points of interest by name
Push the “DEST” button.
Touch “Point of Interest”.
To u c h “ N a m e ” .
Input the name of the point of interest
and touch “OK”.
Touch the button of the desired destina-
tion.
To u c h “ G o t o ” .
To u c h “ O K ” .STEP2
STEP3
STEP4
STEP5

40
GX460_QG_U (OM60E77U)
■Destination input Search points of interest by category
Push the “DEST” button.
Touch “Point of Interest”.
Touch “Category”.
Touch “Near a Destination”.
Touch the button of the desired destina-
tion and set the search point.
Touch the desired point of interest cate-
gory.
Touch the desired point of interest cate-
gory from the list.
To u c h “ G o t o ” .
To u c h “ O K ” .STEP2
STEP3
STEP4
STEP6
