GX460_U.S.A. (OM60E69U)
3-6. Using the storage featuresList of storage fe atures................ 515
• Glove box ..................................... 516
• Console box ................................. 517
• Coin holder................................... 519
• Bottle holders/ 
door pockets .............................. 520
• Cup holders................................. 522
• Auxiliary boxes........................... 525
3-7. Other interior features Cool box ......................................... 528
Sun visors.......................................... 531
Vanity mirror .................................. 532
Clock ................................................ 533
Conversation mirror ................... 534
Power outlet (12 V DC) .................................... 535
Power outlet  (120 V AC [type A]) ................ 537
Power outlet  (120 V AC [type B]) ................ 542
Heated steering wheel............... 549
Seat heaters and 
ventilators ...................................... 551
Armrest ............................................ 554
Coat hooks .................................... 555
Floor mats........................................ 556
Luggage compartment 
features.......................................... 557
Garage door opener.................. 567
Compass.......................................... 575
Safety Connect ............................ 580 4-1. Maintenance and care
Cleaning and protecting 
the vehicle exterior.................. 588
Cleaning and protecting 
the vehicle interior .................... 592
4-2. Maintenance Maintenance requirements.............................. 595
General maintenance ................ 597
Emission inspection and 
maintenance (I/M) 
programs ....................................... 601
4-3. Do-it-yourself maintenance Do-it-yourself service 
precautions .................................. 602
Hood ................................................. 607
Engine compartment................. 608
Tires ................................................... 627
Tire inflation pressure................. 634
Wheels ............................................ 638
Air conditioning filter.................. 640
Electronic key battery ................ 642
Checking and replacing 
fuses ................................................ 645
Headlight aim (vehicles with low 
beam halogen bulbs) ............. 658
Light bulbs ....................................... 660
4Maintenance and care

Maintenance and care4
587
GX460_U.S.A. (OM60E69U)
4-1. Maintenance and careCleaning and protecting 
the vehicle exterior............ 588
Cleaning and protecting 
the vehicle interior .............. 592 4-2. Maintenance
Maintenance 
requirements........................ 595
General maintenance ........... 597
Emission inspection and 
maintenance (I/M) 
programs ................................ 601
4-3. Do-it-yourself maintenance Do-it-yourself service 
precautions ........................... 602
Hood .......................................... 607
Engine compartment ........... 608
Tires............................................. 627
Tire inflation pressure........... 634
Wheels ...................................... 638
Air conditioning filter ........... 640
Electronic key battery.......... 642
Checking and replacing 
fuses ........................................ 645
Headlight aim (vehicles with low 
beam halogen bulbs) ......... 658
Light bulbs ................................ 660

604
4-3. Do-it-yourself maintenance
GX460_U.S.A. (OM60E69U)
ItemsPa r t s a n d t o o l s
Fuses( P. 6 4 5 )• Fuse with same amperage rating as
original
Headlight aim ( P. 6 5 8 )• Phillips-head screwdriver
Light bulbs( P. 6 6 0 )
• Bulb with same number and watt-
age rating as original
• Phillips-head screwdriver
•Flathead screwdriver
•Wrench
Power steering fluid level 
( P. 6 2 0 )
• Automatic transmission fluid
DEXRON® II or III
•Rag or paper towel
• Clean funnel
Radiator and condenser ( P. 6 1 7 )
Tire inflation pressure ( P. 6 3 4 )• Tire pressure gauge
• Compressed air source
Wa s h e r f l u i d ( P. 6 2 6 )
• Water washer fluid containing anti-
freeze (for winter use)
• Funnel (used only for adding water or washer fluid)

658
4-3. Do-it-yourself maintenance
GX460_U.S.A. (OM60E69U)
Headlight aim (vehicles with low beam halogen bulbs)
: If equipped
■ Vertical movement adjustment bolts
Adjustment bolt A
Adjustment bolt B
■ Before checking the headlight aim
Make sure the vehicle has a full ta nk of gas and the area around
the headlight is not deformed.
Park the vehicle on level ground.
Sit in the driver’s seat.
Bounce the vehicle several times.
STEP1
STEP2
STEP3
STEP4

660
4-3. Do-it-yourself maintenance
GX460_U.S.A. (OM60E69U)
Light bulbs
You may replace the following bulbs by yourself. The difficulty level of
replacement varies depending on the bulb. If necessary bulb replacement
seems difficult to perform, contact your Lexus dealer. 
For more information about replacing other light bulbs, contact your Lexus
dealer.
■ Prepare a replacement light bulb
Check the wattage and color of the light bulb being replaced. 
( P. 76 1 )
■ Remove the engine compartment cover
 P. 6 0 9
■ Front bulb locations
Headlight low beam 
(halogen bulb)
Headlight high beam Parking/front side marker light
Front turn signal light
Fog light

661
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_U.S.A. (OM60E69U)
Replacing light bulbs■ Headlight low beams (vehicles with halogen bulbs)
Turn the cover counterclockwise
and remove it.
■Rear bulb locations
Rear turn signal light
Back-up light
Rear side marker light
STEP1

663
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_U.S.A. (OM60E69U)■
Headlight high beams
Turn the bulb base counterclock-
wise.
Unplug the connector while push-
ing the lock release.
STEP1
STEP2

670
4-3. Do-it-yourself maintenance
GX460_U.S.A. (OM60E69U)Remove the light bulb.
■ Lights other than the above
If any of the lights listed below ha s burnt out, have it replaced by your
Lexus dealer.
● Headlight low beams (high-intensity discharge bulbs)
● Side turn signal lights
● High mounted stoplight
● Stop/tail lights
● License plate light
● Outer foot light
STEP3

671
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_U.S.A. (OM60E69U)
■High-intensity discharge (HID) headlights
If voltage to the high-intensity discharge bulbs is insufficient, the light may not come
on, or may go out temporarily. The high-i ntensity discharge bulbs will come on
when normal power is restored.
■LED light bulbs
The side turn signal lights, tail/stop lights, license plate light and high mounted stop-
light consist of a number of LEDs. If any LEDs burn out, take your vehicle to your
Lexus dealer to have the light replaced.
If two or more LEDs in a stoplight burn out, your vehicle may not conform to local
laws (SAE).
■Condensation build-up on the inside of the lens
Contact your Lexus dealer for more inform ation in the following situations. Tempo-
rary condensation build-up on the inside of the headlight lens does not indicate a
malfunction.
●Large drops of water are built up on the inside of the lens.
●Water has built up in side the headlight.

672
4-3. Do-it-yourself maintenance
GX460_U.S.A. (OM60E69U)
CAUTION
■Replacing light bulbs
●Turn off the headlights. Do not attempt to replace the bulb immediately after turn-
ing off the headlights. 
The bulbs become very hot and may cause burns.
●Do not touch the glass portion of the light bulb with bare hands. Hold the bulb by
the plastic or metal portion. 
If the bulb is scratched or dropped it may blow out or crack.
●Fully install light bulbs and any parts used to secure them. Failing to do so may
result in heat damage, fire, or water ente ring the headlight unit. This may damage
the headlights or cause condensation to build up on the lens.
■High-intensity discharge (HID) headlights
●Contact your Lexus dealer before replac ing high-intensity discharge headlights
(including light bulbs).
●Do not touch the high-intensity discharge headlight’s high voltage socket when
the headlights are turned on. 
An extremely high voltage of 20000 V will be discharged and could result in
death or serious injury by electric shock.
●Do not attempt to repair or disassemble lig ht bulbs, connectors, electric circuits
or component parts. 
Doing so may result in serious injury due to electric shock.
■To prevent damage or fire
●Make sure bulbs are fully seated and locked.
●Check the wattage of the bulb before installing to prevent heat damage.
