3-7. Other interior features
GX460_OM_OM60J63U_(U)
Armrest
NOTICE
■To prevent damage to the armrest
Do not apply too much load on the armrest.
Fold down the armrest for use.
GX460_OM_OM60J63U_(U).book Page 560 Thursday, March 29, 2012 9:10 AM

561
3-7. Other interior features
3
Interior features
GX460_OM_OM60J63U_(U)
Coat hooks
CAUTION
■Items that cannot be hung on the coat hook
Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS
curtain shield airbags deploy, these items may become projectiles, causing death or
serious injury.
GX460_OM_OM60J63U_(U).book Page 561 Thursday, March 29, 2012 9:10 AM

562
3-7. Other interior features
GX460_OM_OM60J63U_(U)
Assist grips
CAUTION
■Assist grip (Type A)
Do not use the assist grip (Type A) when getting in or out of the vehicle or rising
from your seat.
NOTICE
■To prevent damage of the assist grip
Do not hang any heavy object or put a heavy load on the assist grip.
An assist grip (Type A) can be used to support your body while sitting on the
seat.
An assist grip (Type B) can be used when getting in or out of the vehicle and
others.
Assist grip (Type A)
Assist grip (Type B)
GX460_OM_OM60J63U_(U).book Page 562 Thursday, March 29, 2012 9:10 AM

563
3-7. Other interior features
3
Interior features
GX460_OM_OM60J63U_(U)
Floor mat
CAUTION
Observe the following precautions.
Failure to do so may cause the driver’s floor mat to slip, possibly interfering with the
pedals while driving. An unexpectedly high speed may result or it may become diffi-
cult to stop the vehicle, leading to a serious accident.
■When installing the driver’s floor mat
●Do not use floor mats designed for other models or different model year vehicles,
even if they are Lexus Genuine floor mats.
●Only use floor mats designed for the driver’s seat.
●Always install the floor mat securely using the retaining hooks (clips) provided.
●Do not use two or more floor mats on top of each other.
●Do not place the floor mat bottom-side up or upside-down.
Use only floor mats designed specifically for vehicles of the same model
and model year as your vehicle. Fix th em securely in place onto the carpet.
Fix the floor mat in place using
the retaining hooks (clips) pro-
vided.
The shape of the retaining hooks
(clips) and the fixing procedure
of the floor mat for your vehicle
may differ from those shown in
the illustration. For details, refer
to the floor mat retention clip
installation instructions supplied
with the clips.
GX460_OM_OM60J63U_(U).book Page 563 Thursday, March 29, 2012 9:10 AM

564
3-7. Other interior features
GX460_OM_OM60J63U_(U)
CAUTION
■Before driving
●Check that the floor mat is securely fixed in
the correct place with all the provided
retaining hooks (clips). Be especially care-
ful to perform this check after cleaning the
floor.
●With the engine stopped and the shift lever
in P, fully depress each pedal to the floor to
make sure it does not interfere with the
floor mat.
GX460_OM_OM60J63U_(U).book Page 564 Thursday, March 29, 2012 9:10 AM

565
3-7. Other interior features
3
Interior features
GX460_OM_OM60J63U_(U)
Luggage compartment features
■Cargo hooks
Vehicles without third seats Raise the hook to use.
The cargo hooks are provided
for securing loose items.
Vehicles with third seats
Raise the hook to use.
The cargo hooks are provided
for securing loose items.
When using the deck hooks, the
third seat must be fold down.
(→ P. 76 )
■Warning reflector holder
Turn the knob clockwise.
Open the lid.
STEP1
GX460_OM_OM60J63U_(U).book Page 565 Thursday, March 29, 2012 9:10 AM

566
3-7. Other interior features
GX460_OM_OM60J63U_(U)
Secure the warning reflector.
The warning reflector itself is not
included as an original equip-
ment.
■Cargo net hooks
Vehicles without third seats
Vehicles with third seats
To hang the cargo net, use the
cargo net hooks.
The cargo net itself is not
included as an original equip-
ment.
STEP2
GX460_OM_OM60J63U_(U).book Page 566 Thursday, March 29, 2012 9:10 AM

567
3-7. Other interior features
3
Interior features
GX460_OM_OM60J63U_(U)
■Auxiliary box (if equipped)
Remove the cover.
■ Luggage cover (if equipped)
Vehicles without third seats Attach the hooks to the head
restraints.
Vehicles with third seats Attach the hooks to the head
restraints.
When using the luggage cover,
the third seats must be fold
down. (→P. 76 )
STEP1
STEP1
GX460_OM_OM60J63U_(U).book Page 567 Thursday, March 29, 2012 9:10 AM

568
3-7. Other interior features
GX460_OM_OM60J63U_(U)
Removing the luggage coverThe luggage cover can be removed by following the procedure below. Retract the cover and release both
ends, then lift it out.
Vehicles without third seats: After
removing the luggage cover, place
it somewhere other than the pas-
senger compartment.
Stowing the luggage cover (vehicle with third seat)
Push the case while pressing the
lock release button.
Vehicles without a rear automatic
air conditioning system: Shorten
one side only.
Vehicles with a rear automatic air
conditioning system: Shorten both
sides.
Pull out the luggage cover and
hook it on the anchors.STEP2
STEP1
Lock release button
GX460_OM_OM60J63U_(U).book Page 568 Thursday, March 29, 2012 9:10 AM

569
3-7. Other interior features
3
Interior features
GX460_OM_OM60J63U_(U)Push the case until it locks.
Check that the lock release button
can be seen.
Vehicles without a rear automatic
air conditioning system: Shorten
one side only.
Vehicles with a rear automatic air
conditioning system: Shorten both
sides.
Secure the luggage cover with lug-
gage cover restraining bands.
Check that luggage cover and lug-
gage cover restraining bands are
secured.
Fold over the cover and the sub
cover.
STEP2
Lock release button
STEP3
STEP4
