engine Lexus GX460 2013 Specifications /

635
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)
Washer fluidIf any washer does not work or the
warning message appears on the
multi-information display, the
washer tank may be empty. Add
washer fluid.
CAUTION
■When refilling the washer fluid
Do not refill the washer fluid when the engine is hot or running, as the washer fluid
contains alcohol and may catch fire if spilled on the engine etc.
NOTICE
■Do not use any fluid other than washer fluid
Do not use soapy water or engine antifreeze instead of washer fluid.
Doing so may cause streaking on the vehicle’s painted surfaces.
■Diluting washer fluid
Dilute washer fluid with water as necessary.
Refer to the freezing temperatures listed on the label of the washer fluid bottle.

650
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
Air conditioning filter
The air conditioning filter must be changed regularly to maintain air condi-
tioning efficiency.
■Removal method
Turn the “ENGINE START STOP” switch off.
Open the glove box and
remove the glove box cover.
Remove the filter cover.
Replace the filter with a new
one.
The “UP” marks shown on the
filter should be pointing up.
STEP1
STEP2
STEP3
STEP4

655
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)
Checking and replacing fuses
If any of the electrical components do not operate, a fuse may have blown.
If this happens, check and replace the fuses as necessary.
Turn the “ENGINE START STOP” switch off.
Open the fuse box cover.
Engine compartment Push the tab in and lift the lid off.
Driver’s side instrument panel Remove the lid.
After a system failure, see “Fuse layout and amperage ratings”
( P. 658) for details about which fuse to check.
Remove the fuse with the pull-out tool.STEP1
STEP2
STEP3
STEP4

658
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
Fuse layout and amperage ratingsEngine compartment
FuseAmpereCircuit
1A/C RR40 ARear air conditioning system
2AIR SUS50 AAir suspension system, AIR SUS
NO.2
3INV15 AInverter
4DEF30 ARear window defogger
5DEICER20 AWindshield wiper deicer

670
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
Light bulbs
You may replace the following bulbs by yourself. The difficulty level of
replacement varies depending on the bulb. If necessary bulb replacement
seems difficult to perform, contact your Lexus dealer.
For more information about replacing other light bulbs, contact your Lexus
dealer.
■ Prepare a replacement light bulb
Check the wattage and color of the light bulb being replaced.
( P. 76 9 )
■ Remove the engine compartment cover
 P. 6 1 9
■ Front bulb locations
Headlight low beam
(halogen bulb)
Headlight high beam
and daytime running lights
Parking/front side marker light
Front turn signal light
Fog light

When trouble arises5
683
GX460_OM_OM60J63U_(U)
5-1. Essential informationEmergency flashers............... 684
If your vehicle needs to be towed ............................ 685
If you think something is wrong ....................................... 691
Fuel pump shut off system.... 692 5-2. Steps to take in an
emergency
If a warning light turns on or a warning buzzer
sounds..................................... 693
If a warning message is displayed................................ 705
If you have a flat tire................ 726
If the engine will not start ..... 740
If the shift lever cannot be shifted from P ........................ 742
If you lose your keys ............... 743
If the electronic key does not operate properly........... 744
If the vehicle battery is discharged ............................. 746
If your vehicle overheats ...... 749
If the vehicle becomes stuck........................................ 752
If your vehicle has to be stopped in an
emergency ............................ 754

684
GX460_OM_OM60J63U_(U)
5-1. Essential information
Emergency flashers
NOTICE
■To prevent battery discharge
Do not leave the emergency flashers on longer than necessary when the engine is
not running.
Use the emergency flashers if the vehicle malfunctions or is involved in an
accident.
Press the switch to flash all the
turn signal lights. To turn them
off, push the switch once again.

5
When trouble arises
685
5-1. Essential information
GX460_OM_OM60J63U_(U)
If your vehicle needs to be towed
Before towingThe following may indicate a problem with your transmission. Contact
your Lexus dealer before towing.
● The engine is running but the vehicle will not move.
● The vehicle makes an abnormal sound.
If towing is necessary, we recommend having your vehicle towed by your
Lexus dealer or a commercial towing se rvice, using a lift-type truck or a flat
bed truck.
Use a safety chain system for all towi ng, and abide by all state/provincial
and local laws.
The wheels and axle on the ground must be in good condition.
If they are damaged, use a to wing dolly or flat bed truck.

5
When trouble arises
689
5-1. Essential information
GX460_OM_OM60J63U_(U)
■Before emergency towingThe “ENGINE START STOP” switch must be in the ACCESSORY mode
(engine off) or IGNITION ON mode (engine running).
Put the four-wheel drive control switch in H4. (The center differential is
unlocked.)
Put the vehicle height in the N mode and press height control switch to
turn off the rear height control air suspension.
Shift the shift lever in N.
Release the parking brake.
CAUTION
■Caution while towing
●Use extreme caution when towing the vehicle.
Avoid sudden starts or erratic driving maneuvers which place excessive stress on
the emergency towing eyelets and the cables or chains. Always be cautious of the
surroundings and other vehicles while towing.
●Do not turn the “ENGINE START STOP” switch off.
Doing so will lock the steering wheel and prevent operation, possibly causing an
accident and result ing in death or serious injury.
●If the engine is not running, the power assi st for the brakes and steering will not
function, making steering and braking more difficult.
STEP1
STEP2
STEP3
STEP4
STEP5

5
When trouble arises
691
5-1. Essential information
GX460_OM_OM60J63U_(U)
If you think something is wrong
If you notice any of the following symptoms, your vehicle probably needs
adjustment or repair. Contact your Lexus dealer as soon as possible.
■Visible symptoms
●Fluid leaks under the vehicle
(Water dripping from the air conditioning after use is normal.)
● Flat-looking tires or uneven tire wear
● Engine coolant temper ature gauge needle continually points
higher than normal
■ Audible symptoms
●Changes in exhaust sound
● Excessive tire squeal when cornering
● Strange noises related to the suspension system
● Pinging or other noises related to the engine
■ Operational symptoms
●Engine missing, stumbling or running roughly
● Appreciable loss of power
● Vehicle pulls heavily to one side when braking
● Vehicle pulls heavily to one side when driving on a level road
● Loss of brake effectiveness, sp ongy feeling, pedal almost touches
the floor
