Lexus GX460 2013 Specifications /

401
3-1. Using the air conditioning system and defogger
3
Interior features
GX460_OM_OM60J63U_(U)
Using the automatic air conditioning system
Vehicles without a rear automatic air conditioning system Press the “AUTO” button.
The air conditioning system begins to operate. Air outlets and fan
speed are automatically adjusted according to the temperature
setting.
Press “ ” on the temperature control button on the driver’s side
to increase the temperature and “ ” to decrease the tempera-
ture.
When the “DUAL” button is pressed (the indicator on the “DUAL” but-
ton is on) or the passenger’s side temperature control button is pressed,
the temperature for the driver and passenger seats can be adjusted
separately.
Vehicles with a rear automatic air conditioning system
Press the “AUTO” button.
The air conditioning system begins to operate. Air outlets and fan
speed are automatically adjusted according to the temperature
setting.
Press to switch to automatic air intake mode.
The air conditioning system automa tically switches between out-
side air and recirculated air modes.
Press “ ” on the temperature control button on the driver’s side
to increase the temperature and “ ” to decrease the tempera-
ture.
When the “3ZONE” button is pressed (the indicator on the “3ZONE”
button is on), the front passenger’s side temperature control button is
pressed or “REAR/TEMP” button is pressed, the temperature for the
driver’s, front passenger’s and rear seats ( P. 413) can be adjusted
separately.
STEP1
STEP2
STEP1
STEP2
STEP3

402
3-1. Using the air conditioning system and defogger
GX460_OM_OM60J63U_(U)
Adjusting the settings manually
■ Basic setting
Vehicles without a rear automatic air conditioning system To turn on the air conditioning system and adjust the fan speed,
press “ ” on to increase the fan speed and “” to
decrease the fan speed.
Press to turn the fan off.
To adjust the temperature setting, press “ ” on the temperature
control button on the driver’s si de to increase the temperature
and “ ” to decrease the temperature.
The air conditioning system switch es between individual and simulta-
neous modes each time the “DUAL” button is pressed.
When the “DUAL” button is pressed (the indicator on the “DUAL” but-
ton is on) or the passenger’s side temperature control button is pressed,
the temperature for the driver and passenger seats can be adjusted
separately.
To change the air outlets, press “ ” or “ ” on .
The air outlets used are switched each time either side of the button is
pressed. The air flow shown on the display indicates the following:
STEP1
STEP2
STEP3

403
3-1. Using the air conditioning system and defogger
3
Interior features
GX460_OM_OM60J63U_(U)Vehicles with a rear automatic air conditioning system
To turn on the air conditioning system and adjust the fan speed,
press “ ” on to increase the fan speed and “” to
decrease the fan speed.
Press to turn the fan off.
To adjust the temperature setting, press “ ” on the temperature
control button on the driver’s si de to increase the temperature
and “ ” to decrease the temperature.
The air conditioning system switch es between individual and simulta-
neous modes each time the “3ZONE” button is pressed.
When the “3ZONE” button is pressed (the indicator on the “3ZONE”
button is on), the front passenger’s side temperature control button is
pressed or the “REAR/TEMP” button is pressed, the temperature for
the driver’s, front passenger’s and rear seats ( P. 413) can be adjusted
separately.
To change the air outlets, press “ ” or “ ” on .
The air outlets used are switched each time either side of the button is
pressed. The air flow shown on the display indicates the following:
STEP1
STEP2
STEP3

404
3-1. Using the air conditioning system and defogger
GX460_OM_OM60J63U_(U) Air flows to the upper body.
*1: Only the in automatic mode (Air may not always flow.)
*2: Vehicles without a rear automatic air conditioning system
Air flows to the upper body and
feet.
*: Vehicles without a rear automatic air conditioning system

405
3-1. Using the air conditioning system and defogger
3
Interior features
GX460_OM_OM60J63U_(U) Air flows to the feet.
*: Vehicles without a rear automatic air conditioning system
Air flows to the feet and the wind-
shield defogger operates.
The air intake is automatically
switched to (outside air)
mode.
The air conditioning system oper-
ates automatically.
*: Vehicles without a rear automatic air conditioning system

406
3-1. Using the air conditioning system and defogger
GX460_OM_OM60J63U_(U)■
Switching between outside air and recirculated air modes
Vehicles without a rear automatic air conditioning system
Press .
The mode switches between (recirculated air mode) and (out-
side air mode) modes each time the button is pressed.
Vehicles with a rear automatic air conditioning systemPress .
The mode switches among (recirculated air mode), automatic and (outside air mode) modes each time the button is pressed.
When the system is switched to automatic mode, the air conditioning sys-
tem operates automatically.
Changing the rear seat settings (veh icles with a rear automatic air con-
ditioning system)
■ Adjusting the temperature setting
Press “ ” on the “REAR/TEMP” button to increase the temperature
and “ ” to decrease the temperature.
The air conditioning system switch es between individual and simulta-
neous modes each time the “3ZONE” button is pressed.

407
3-1. Using the air conditioning system and defogger
3
Interior features
GX460_OM_OM60J63U_(U)
Defogging the windshield
Defogging
The air intake is automatically
switched to (outside air)
mode. It is not possible to recircu-
lated air mode when the switch is
on.
The air conditioning system oper-
ates automatically.
Micro dust and pollen filter mode buttonOperates micro dust and pollen fil-
ter on/off.
Outside air mode switches to (recirculated air) mode. Pol-
len is removed from the air and the
air flows to the upper part of the
body.
Usually the system will turn off
automatically after approximately
3 minutes.

408
3-1. Using the air conditioning system and defogger
GX460_OM_OM60J63U_(U)
Adjusting the sensitivity of the ai r intake control in automatic mode
(vehicles with a rear automatic air conditioning system)
Press for 2 or more
seconds.
Press “” (increase) or “ ”
(decrease) on the temperature
control button on the driver’s side.
From - 3 (low) to 3 (high) can be
set.
STEP1
STEP2

409
3-1. Using the air conditioning system and defogger
3
Interior features
GX460_OM_OM60J63U_(U)
Adjusting the position of and opening and closing the air outlets
Front center outlets Direct air flow to the left or right,
up or down
Turn the knob to open or close
the vent
Front side outlets Direct air flow to the left or right,
up or down
Turn the knob to open or close
the vent

410
3-1. Using the air conditioning system and defogger
GX460_OM_OM60J63U_(U)Rear outlets (vehicles without a rear automatic air conditioning sys-
tem)
Direct air flow to the left or right,
up or down.
Turn the knob to open or close
the vent.
■Air conditioning system settings
When the “ENGINE START STOP” switch is turned on, the air conditioning system
settings will be set to those that were in use the last time the “ENGINE START
STOP” switch was turned off.
Air conditioning system settings are memori zed individually on each electronic key,
so the settings reproduced will be specific to the key that is used.
■Using automatic mode
Fan speed is adjusted automatically accord ing to the temperature setting and ambi-
ent conditions. As a result, the following may occur.
●Immediately after the switch is pressed, the fan may stop for a while until warm
or cool air is ready to flow.
●Cool air may flow to the area around the upper body when the heater is on.
