Lexus GX460 2015 Owner's Manual

500
GX 460 _O M_ OM6 0L 72U _( U)6-3. Do-it-yourself maintenance
GX460_OM_OM60L72U_(U).book Page 500 Friday, May 16, 2014 3:03 PM

501
GX 460 _O M_ OM6 0L 72U _( U)
7When trouble arises
7-1. Essential informationEmergency flashers ..................502
If your vehicle has to be stopped in
an emergency...........................503
7-2. Steps to take in an emergency If your vehicle needs to be towed ................................504
If you think something is wrong ...........................................509
Fuel pump shut off system ....... 510
If a warning light turns on or a warning buzzer
sounds............................................. 511
If a warning message is displayed...................................... 519
If you have a flat tire................... 533
If the engine will not start ........ 546
If the shift lever cannot be shifted from P............................548
If the electronic key does not operate properly ............. 549
If the vehicle battery is discharged ................................. 552
If your vehicle overheats ......... 555
If the vehicle becomes stuck .............................................558
GX460_OM_OM60L72U_(U).book Page 501 Friday, May 16, 2014 3:03 PM

502
GX 460 _O M_ OM6 0L 72U _( U)7-1. Essential information
Emergency flashers
Press the switch.
All the turn signals will flash.
To turn them off, press the switch once
again.
■Emergency flashers
If the emergency flashers are used for a long time while the engine is not operating, the
battery may discharge.
The emergency flashers are used to warn other drivers when the vehicle has
to be stopped in the road due to a breakdown, etc.
GX460_OM_OM60L72U_(U).book Page 502 Friday, May 16, 2014 3:03 PM

503
GX 460 _O M_ OM6 0L 72U _( U)
7
When trouble arises
7-1. Essential information
If your vehicle has to be stopped in an emergency
Steadily step on the brake pedal with both feet and firmly depress it.
Do not pump the brake pedal repeatedly as this will increase the effort required to
slow the vehicle.
Shift the shift lever to N.
XIf the shift lever is shifted to N
After slowing down, stop the vehicle in a safe place by the road.
Stop the engine.
XIf the shift lever cannot be shifted to N
Keep depressing the brake pedal with both feet to reduce vehicle speed as
much as possible.
To stop the engine, press and hold
the engine switch for 2 consecutive
seconds or more, or press it briefly 3
times or more in succession.
Stop the vehicle in a safe place by the road.
Only in an emergency, such as if it becomes impossible to stop the vehicle in
the normal way, stop the vehicle using the following procedure:
1
2
3
4
3
Press and hold for 2 seconds or more,
or press briefly 3 times or more
4
CAUTION
■If the engine has to be turned off while driving
Power assist for the brakes and steering wheel will be lo st, making the brake pedal
harder to depress and the steering wheel heavier to turn. Decelerate as much as possi-
ble before turning off the engine.
5
GX460_OM_OM60L72U_(U).book Page 503 Friday, May 16, 2014 3:03 PM

504
GX 460 _O M_ OM6 0L 72U _( U)7-2. Steps to take in an emergency
If your vehicle needs to be towed
The following may indicate a problem with your transmission. Contact your
Lexus dealer or commercial towing service before towing.
●The engine is running but the vehicle will not move.
●The vehicle makes an abnormal sound.
If towing is necessary, we recommend having your vehicle towed by your
Lexus dealer or commercial towing servic
e, using a lift-type truck or flatbed
truck.
Use a safety chain system for all towing , and abide by all state/provincial and
local laws.
Situations needs to contact dealers before towing
GX460_OM_OM60L72U_(U).book Page 504 Friday, May 16, 2014 3:03 PM

5057-2. Steps to take in an emergency
GX 460 _O M_ OM6 0L 72U _( U)
7
When trouble arises
Do not tow with a sling-type truck to
prevent body damage.
Towing with a sling-type truck
Towing with a wheel-lift type truck
XFrom the frontXFrom the rear
Use a towing dolly under the rear
wheels. Use a towing dolly under the front
wheels.
GX460_OM_OM60L72U_(U).book Page 505 Friday, May 16, 2014 3:03 PM

5067-2. Steps to take in an emergency
GX 460 _O M_ OM6 0L 72U _( U)
If your Lexus is transported by a flatbed
truck, it should be tied down at the
locations shown in the illustration.
If you use cables or chains to tie down
your vehicle, the angles shaded in black
must be 45°.
Do not overly tighten the tie downs or
the vehicle may be damaged.
If a tow truck is not available in an emergency, your vehicle may be temporarily
towed using cables or chains secured to the emergency towing hooks. This
should only be attempted on hard surfaced roads for 50 miles (80 km) at low
speeds.
A driver must be in the vehicle to steer and operate the brakes. The vehicle’s
wheels, drive train, axles, steering and brakes must be in good condition.
Using a flatbed truck
Emergency towing
GX460_OM_OM60L72U_(U).book Page 506 Friday, May 16, 2014 3:03 PM

5077-2. Steps to take in an emergency
GX 460 _O M_ OM6 0L 72U _( U)
7
When trouble arises
Securely attach cables or chains to
the towing hooks.
Take care not to damage the vehicle
body.
Enter the vehicle being towed and start the engine.
If the engine does not start, turn the engine switch to IGNITION ON mode.
Set the four-wheel drive control switch in H4 and push the center differential
lock/unlock switch to unlock the center differential. ( →P. 336)
For models with the rear height control air suspension: Change the vehicle
height to N (normal) mode and press the height control OFF button to end
the vehicle height control operation. ( →P. 3 3 1 )
Shift the shift lever to N and release the parking brake.
When the shift lever cannot be shifted: →P. 5 4 8
■While towing
If the engine is not running, the power assist for the brakes and steering will not function,
making steering and braking more difficult.
■Wheel nut wrench
Wheel nut wrench is installed in the tool box. ( →P. 5 3 4 )
Emergency towing procedure
1
2
3
4
5
GX460_OM_OM60L72U_(U).book Page 507 Friday, May 16, 2014 3:03 PM

5087-2. Steps to take in an emergency
GX 460 _O M_ OM6 0L 72U _( U)
CAUTION
Observe the following precautions.
Failure to do so may result in death or serious injury.
■When towing the vehicle
■While towing
●When towing using cables or chains, avoid sudden starts, etc. which place excessive
stress on the towing hooks, cables or chains . The towing hooks, cables or chains may
become damaged, broken debris may hit people and cause serious damage.
●Do not turn the engine switch off.
There is a possibility that the steering wh eel is locked and cannot be operated.
NOTICE
■To avoid serious damage to your vehicle
■To prevent body damage when towing with a sling-type truck
Do not tow with a sling-type truck, either from the front or rear.
Be sure to transport the vehicle with all four
wheels raised off the ground. If the vehicle is
towed with the tires contacting the ground, the
drivetrain or related parts may be damaged,
the vehicle may fly off the truck.
Do not use the rear emergency towing hook.
GX460_OM_OM60L72U_(U).book Page 508 Friday, May 16, 2014 3:03 PM

509
GX 460 _O M_ OM6 0L 72U _( U)
7
When trouble arises
7-2. Steps to take in an emergency
If you think something is wrong
●Fluid leaks under the vehicle
(Water dripping from the air conditioning after use is normal.)
●Flat-looking tires or uneven tire wear
●Engine coolant temperature gauge needle continually points higher than nor-
mal
●Changes in exhaust sound
●Excessive tire squeal when cornering
●Strange noises related to the suspension system
●Pinging or other noises related to the engine
●Engine missing, stumbling or running roughly
●Appreciable loss of power
●Vehicle pulls heavily to one side when braking
●Vehicle pulls heavily to one side when driving on a level road
●Loss of brake effectiveness, spongy feeling, pedal almost touches the floor
If you notice any of the following symptoms, your vehicle probably needs
adjustment or repair. Contact your Lexus dealer as soon as possible.
Visible symptoms
Audible symptoms
Operational symptoms
