check transmission fluid Lexus GX460 2018 Owner's Manual / LEXUS 2018 GX460 OWNER'S MANUAL (OM60Q09U)

164
GX460_OM_OM60Q09U_(U)4-1. Before driving
NOTICE
■When driving the vehicle
●Do not depress the accelerator and brake pedals at the same time during driving, as
this may restrain
the engine output.
●Do not use the accelerator pedal or depre ss the accelerator and brake pedals at the
same time to hold the vehicle on a hill.
■When parking the vehicle
Always set the parking brake, and shift the sh ift lever to P. Failure to do so may cause
the vehicle to move or the vehicle may acce lerate suddenly if the accelerator pedal is
accidentally depressed.
■Avoiding damage to vehicle parts
●Do not turn the steering wheel fully in either direction and hold it there for an
extended period of time.
Doing so may damage the power steering pump.
●When driving over bumps in the road, drive as slowly as possible to avoid damaging
the wheels, underside of the vehicle, etc.
■If you get a flat tire while driving
A flat or damaged tire may cause the following situations . Hold the steering wheel
firmly and gradually depress the brake pedal to slow down the vehicle.
●It may be difficult to control your vehicle.
●The vehicle will make abnormal sounds or vibrations.
●The vehicle will lean abnormally.
Information on what to do in case of a flat tire. ( →P. 542)
■When encountering flooded roads
Do not drive on a road that has flooded af ter heavy rain etc. Doing so may cause the
following serious damage to the vehicle:
●Engine stalling
●Short in electrical components
●Engine damage caused by water immersion
In the event that you drive on a flooded road and the vehicle is flooded, be sure to have
your Lexus dealer check the following:
●Brake function
●Changes in quantity and quality of oil and fluid used for the engine, transmission,
transfer, differentials, etc.
●Lubricant condition for the propeller shaft, bearings and suspension joints (where
possible), and the function of all joints, bearings, etc.

GX460_OM_OM60Q09U_(U)
4716-3. Do-it-yourself maintenance
6
Maintenance and care
■Fluid level
The fluid level should be within the appropriate range.Full (when cold)
Add fluid (when cold)
Full (when hot)
Add fluid (when hot)
Hot: The vehicles has been driven around 50 mph (80 km/h) for 20 min- utes, or slightly longer in frigid temperatures.
(Fluid temperature, 140 °F - 175 °F [60° C - 80 °C]).
Cold: The engine has not been run for about 5 hours. (Room temperature, 50 °F - 85 °F [10 °C - 30 °C]).
■Checking the fluid level
Make sure to check the fluid type and prepare the necessary items.
Clean all dirt off the reservoir.
Remove the cap by turnin g it counterclockwise.
Wipe the dipstick clean.
Reinstall the cap and remove it again.
Check the fluid level.
Power steering fluid
1
2
3
4
Fluid typeAutomatic transmission fluid DEXRON® II or III
ItemsRag or paper, clean funnel (only for adding fluid)
1
2
3
4
5

5337-2. Steps to take in an emergency
GX460_OM_OM60Q09U_(U)
7
When trouble arises
Indicates that the automatic transmission fluid tempera-
ture is too high A buzzer also sounds.
→ Immediately stop the vehicle in a safe place, shift the
shift lever to P and wait until the warning message
and light go off. If the warning message and light go
off, you may start the vehicle again.
If the warning message and light do not go off, con-
tact your Lexus dealer.
Indicates a malfunction in the automatic transmission
system A buzzer also sounds.
→ Have the vehicle inspected by your Lexus dealer.
Indicates that the moon roof is not fully closed (with the
engine switch off, and the driver’s door open)
A buzzer also sounds.
→ Close the moon roof.
Indicates that engine oil level is low
A buzzer also sounds.
→ Check the level of engine oil, and add if necessary.
Indicates a malfunction in:
• The LED headlight system;
• The automatic headlight leveling system; or
• The Automatic High Beam system (if equipped)
A buzzer also sounds.
→ Have the vehicle inspected by your Lexus dealer.
Indicates that the washer fluid level is low
→Add washer fluid.
Warning messageDetails/Actions
(Flashes)

629Alphabetical index
GX460_OM_OM60Q09U_(U)
Emergency flashers .............................. 510
EngineAccessory mode................................. 190
Compartment......................................463
Hood ........................................................462
How to start the engine ................... 189
Identification number ....................... 572
If the engine will not start............... 556
Ignition switch (engine switch)..... 189
Overheating ........................................ 564
Engine compartment cover ............. 464
Engine coolant....................................... 467 Capacity .................................................574
Checking................................................ 467
Preparing and checking before winter .................................... 377
Engine immobilizer system ..................72
Engine oil ................................................. 465 Capacity ................................................. 572
Checking............................................... 465
Preparing and checking before winter .................................... 377
Engine switch .......................................... 189
Engine switch light ............................... 402
Event data recorder (EDR) ...................10 Flat tire .......................................................542
Floor mats....................................................26
Fluid
Automatic transmission .................. 576
Brake........................................................ 577
Steering .................................................. 578
Washer ................................................... 475
Fog lights......................................................211 Switch .....................................................211
Four-wheel drive system....................342
Front passenger occupant classification system ........................... 48
Front passenger’s seat belt reminder light ......................................522
Front seats ................................................. 122 Adjustment.............................................. 122
Cleaning................................................. 449
Correct driving posture .................... 28
Driving position memory.................135
Head restraints .....................................140
Seat heaters ......................................... 400
Seat position memory .......................135
Front turn signal lights ........................ 200 Replacing light bulbs .......................502
Turn signal lever .................................200
Wattage ................................................. 579F
