steering wheel adjustment Lexus GX460 2018 Owner's Manual / LEXUS 2018 GX460 OWNER'S MANUAL (OM60Q09U)

GX460_OM_OM60Q09U_(U)
1373-3. Adjusting the seats
3
Operation of each component
■To stop the position recall operation part-way through
Perform any of the following:
●Press the “SET” button.
●Press button “1” or “2”.
●Operate any of the seat adjustment switches (only cancels seat position recall).
●Operate the tilt and telescopic steering control switch (only cancels steering wheel
position recall).
■Seat positions that can be memorized ( → P. 122)
The adjusted positions other than the position adjusted by lumbar support switch can be
recorded.
■Operating the driving position memory after turning the engine switch off
Recorded seat positions can be activated up to 180 seconds after the driver’s door is
opened and another 60 seconds after it is closed again.
■In order to correctly use the driving position memory function
If a seat position is already in the furthest po ssible position and the seat is operated in the
same direction, the recorded position may be slightly different when it is recalled.
Each electronic key can be registered to recall your preferred driving position.
■Registering procedure
Record your driving position to button “1” or “2” before performing the follow-
ing:
Carry only the key you want to regist er, and then close the driver’s door.
If 2 or more keys are in the vehicle, the driving position cannot be recorded
properly.
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Recall the driving position that you want to record.
Memory recall function
1
2
3

GX460_OM_OM60Q09U_(U)
1393-3. Adjusting the seats
3
Operation of each component
■Recalling the driving position using the memory recall function
●Different driving positions can be registered for each electronic key. Therefore, the
driving position that is recalled may be di fferent depending on the key being carried.
●If a door other than the driver’s door is unlocked with the smart access system with
push-button start, the driving position cannot be recalled. In this case, press the driving
position button which has been set.
■Customization
The unlock door settings of the memo ry recall function can be customized.
(Customizable features: →P. 594)
CAUTION
■Seat adjustment caution
Take care during seat adjustment so that th e seat does not strike the rear passenger or
squeeze your body against the steering wheel.

1433-4. Adjusting the steering wheel and mirrors
3
Operation of each component
GX460_OM_OM60Q09U_(U)
Steering wheel
Up
Down
Toward the driver
Away from the driver
To sound the horn, press on or close to
the mark.
Adjustment procedure
1
2
3
4
Horn

1443-4. Adjusting the steering wheel and mirrors
GX460_OM_OM60Q09U_(U)
■The steering wheel can be adjusted when
The engine switch is in ACCESSORY or IGNITION ON mode
*.
*: If the driver’s seat belt is fastened, the steering wheel can be adjusted regardless of engine switch mode.
■Automatic adjustment of the steering position
A desired steering position ca n be entered to memory and recalled automatically by the
driving position memory system. (→ P. 135)
CAUTION
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an accident, result-
ing in death or serious injury.

1473-4. Adjusting the steering wheel and mirrors
3
Operation of each component
GX460_OM_OM60Q09U_(U)
Outside rear view mirrors
To select a mirror to adjust, press the
switch.Left
Right
To adjust the mirror, press the switch. Up
Right
Down
Left
Manual type
Push the mirror back in the direction of
the vehicle’s rear.
Adjustment procedure
1
1
2
2
1
2
3
4
Folding and extending the mirrors

1483-4. Adjusting the steering wheel and mirrors
GX460_OM_OM60Q09U_(U)
Power type
Extends the mirrors
Folds the mirrors
When the mirror select switch is in the L or R position, the outside rear view mir-
rors will automatically angle downwards wh en the vehicle is reversing in order to
give a better view of the ground.
To disable this function, move the mirror select switch to the neutral position
(between L and R).
■Mirror angle can be adjusted when
The engine switch is in ACCESSORY or IGNITION ON mode.
■When the mirrors are fogged up
Turn on the mirror defoggers to defog the mirrors. ( →P. 391)
■Automatic adjustment of the mirror angle
A desired mirror face angle can be entered to memory and recalled automatically by the
driving position memory. ( →P. 135)
■Auto anti-glare function
When the anti-glare inside re ar view mirror is set to automatic mode, the outside rear
view mirrors will activate in conjunction with the anti-glare inside rear view mirror to
reduce reflected light. ( →P. 145)
1
2
Linked mirror function when reversing

629Alphabetical index
GX460_OM_OM60Q09U_(U)
Emergency flashers .............................. 510
EngineAccessory mode................................. 190
Compartment......................................463
Hood ........................................................462
How to start the engine ................... 189
Identification number ....................... 572
If the engine will not start............... 556
Ignition switch (engine switch)..... 189
Overheating ........................................ 564
Engine compartment cover ............. 464
Engine coolant....................................... 467 Capacity .................................................574
Checking................................................ 467
Preparing and checking before winter .................................... 377
Engine immobilizer system ..................72
Engine oil ................................................. 465 Capacity ................................................. 572
Checking............................................... 465
Preparing and checking before winter .................................... 377
Engine switch .......................................... 189
Engine switch light ............................... 402
Event data recorder (EDR) ...................10 Flat tire .......................................................542
Floor mats....................................................26
Fluid
Automatic transmission .................. 576
Brake........................................................ 577
Steering .................................................. 578
Washer ................................................... 475
Fog lights......................................................211 Switch .....................................................211
Four-wheel drive system....................342
Front passenger occupant classification system ........................... 48
Front passenger’s seat belt reminder light ......................................522
Front seats ................................................. 122 Adjustment.............................................. 122
Cleaning................................................. 449
Correct driving posture .................... 28
Driving position memory.................135
Head restraints .....................................140
Seat heaters ......................................... 400
Seat position memory .......................135
Front turn signal lights ........................ 200 Replacing light bulbs .......................502
Turn signal lever .................................200
Wattage ................................................. 579F

634Alphabetical index
GX460_OM_OM60Q09U_(U)
Seat heaters ............................................400
Seat ventilators ....................................... 401
Seat position memory.......................... 135
Seats................................................... 122, 124Adjustment ....................................122, 124
Adjustment precautions ........ 123, 134
Child seats/child restraint system installation..............................59
Cleaning .................................................449
Driving position memory ................ 135
Head restraint ....................................... 140
Properly sitting in the seat ................ 28
Seat position memory....................... 135
Ventilators .............................................. 401
Sensor Automatic headlight system .........204
Inside rear view mirror ..................... 146
Intuitive parking assist-sensor .....................................245
Rain-sensing windshield wipers .................................................... 216
Service reminder indicators ............... 78
Shift lever Automatic transmission ................... 194
If the shift lever cannot be shifted from P .................................... 198
Shift lock system...................................... 197
Shopping bag hooks .............................413
Side airbags ............................................... 36
Side mirrors .............................................. 147 Adjusting and folding.........................147
Blind Spot Monitor............................357
Side turn signal lights ..........................200 Replacing light bulbs ....................... 506
Turn signal lever ................................ 200 Smart access system with
push-button start.................................. 115 Antenna location................................... 115
Starting the engine ............................. 189
Snow tires .................................................379
Spare tire ..................................................542 Inflation pressure................................ 578
Storage location ................................. 543
Spark plug ................................................574
Specifications......................................... 570
Speedometer ............................................ 83
Steering lock Column lock release ......................... 192
Steering wheel ........................................ 143 Adjustment.............................................. 143
Audio switches
*
Heated steering wheel ................... 399
Steering wheel position memory.................................................135
Stop/tail lights Replacing light bulbs ...................... 506
Storage feature ..................................... 405
Stuck If the vehicle becomes stuck........ 567
Sun shade Roof ............................................................154
Sun visors................................................... 421
Switch “2nd START” button ..........................195
AVS switch ............................................. 341
BSM (Blind Spot Monitor) switch ................................................... 357
Center differential lock/ unlock switch.................................... 343
Crawl Control switch...................... 346
