4115-3. Using the storage features
5
Interior features
●The console box light turns on when the tail lights are on.
●When using the console box lid as an armrest,
slide the console box lid forward or backward
as needed. Slide the lid while pulling up the
upper lever to release the lock.
●The tray in the console box slides forward/
backward.
●To remove the tray, lift up.
NOTICE
Do not insert items exceeding the height of the tray. Doing so may prevent opening and
closing of the lid.

412
GX460_OM_OM60Q84U_(U)5-3. Using the storage features
The coin holder is located in the console box.
■Cup holders
Coin holder (if equipped)
Cup holders/bottle holders/door pockets
Front seatsSecond seats (7
-passenger mod-
els)
Press down and release the cup
holder lid. Pull the armrest down, and then press
in and release the button.
Second seats (6-passenger mod-
els)Third seats (if equipped)
Pull the cup holder up.

GX460_OM_OM60Q84U_(U)
4135-3. Using the storage features
5
Interior features
■Bottle holders/door pockets
■Cup holder lights (front seats)
●The cup holder lights turn on when the tail lights are on.
●The brightness of the cup holder lights chan ge in conjunction with the instrument clus-
ter light. ( P. 88)
■When using the holder as a bottle holder
●Close the cap.
●The bottle may not be stored depending on its size or shape.
■Removing the cup holders (secon d seats for 6-passenger models)
FrontRear
The cup holders can be removed.
CAUTION
■Items unsuitable for the cup holders/bottle holders
●Do not place anything other than cups or beverage cans in the cup holders. Even
when the lid is closed, items must not be stored in the cup holders.
Other items may be thrown out of the holder s in the event of sudden braking, sudden
swerving or an accident, cause injury. If possible, cover hot drinks to prevent burns.
●Do not place anything other than bottles in the bottle holders.
In the event of an accident or sudden brak ing, other items may be thrown out of the
holders and cause injury.
■When not in use
Keep the cup holders closed.
Injuries may result in the event of sudden braking, sudden swerving or an accident.

414
GX460_OM_OM60Q84U_(U)5-3. Using the storage features
NOTICE
●To prevent damage, stow the rear cup holders before stowing the armrest. (second
seats for 7-passenger models)
●To prevent damage, do not fold down the second seatbacks when using a cup holder
on the second seats.
(6-passenger models)
●To prevent damage, do not rest your hands on the cup holders or kick them.
●Do not place open bottles or glass and paper cups containing liquid in the bottle hold-
ers. The contents may sp ill and glasses may break.
Auxiliary boxes
Type AType B
Press in the button and then pull down
the lid.
The overhead console is useful for tem-
porarily storing sung lasses and similar
small items.
Push the lid.
Type C (if equipped)

GX460_OM_OM60Q84U_(U)
4155-3. Using the storage features
5
Interior features
■Auxiliary box light (type B)
●The auxiliary box light turns on when the tail lights are on.
●The brightness of the auxiliary box light changes in conjunction with the instrument
cluster light. ( P. 88)
■Closing the auxiliary box lid
Slide the auxiliary box lid forward.
CAUTION
■Caution while driving
Do not place cups, beverage cans or bottles in the box. They may be thrown out of the
box in the event of sudden bra king, sudden swerving or an accident, resulting in injury.
(type B and C)
■Items unsuitable for storing (type A)
●Do not store items heavier than 0.4 lb. (0.2 kg).
Doing so may cause the auxiliary box to open and the items inside may fall out, result-
ing in an accident.
●Do not put large items in the overhead console.
The overhead console may not be able to be shut from the conversation mirror state.

416
GX460_OM_OM60Q84U_(U)5-3. Using the storage features
Luggage compartment features
Raise the hook to use.
The cargo hooks are provided for
securing loose items.
When using the deck hooks, the third
seat must be fold down. (
P. 134)
Open the cover.
Turn the knob clockwise.
Open the cover.
Secure the warning reflector.
The warning reflector itself is not
included as an original equipment.
Cargo hooks
Warning reflector holder
1
1
2
2

GX460_OM_OM60Q84U_(U)
4175-3. Using the storage features
5
Interior features
To hang the cargo net, use the cargo net hooks.
The cargo net itself is not included as an original equipment.
Remove the cover.
Cargo net hooks
Auxiliary box (if equipped)

418
GX460_OM_OM60Q84U_(U)5-3. Using the storage features
■Installing the luggage cover
Attach the hooks to the head
restraints.
When using the lu ggage cover, the
third seats must be folded down.
(  P. 134)
6-passenger models only: Secure
the middle part of the luggage
cover as shown.
Pull out the luggage cover and
hook it on the anchors.
■Removing the luggage cover
Retract the cover and release both
ends, then lift it out.
Luggage cover (if equipped)
1
2

GX460_OM_OM60Q84U_(U)
4195-3. Using the storage features
5
Interior features
■Stowing the luggage cover
Push the case while pressing the
lock release button.
Vehicles without a rear automatic air
conditioning system: Shorten one
side only.
Vehicles with a rear automatic air
conditioning system: Shorten both
sides.
Push the case until it locks.
Check that the lock release button
can be seen.
Vehicles without a rear automatic air
conditioning system: Shorten one
side only.
Vehicles with a rear automatic air
conditioning system: Shorten both
sides.
Secure the luggage cover with
luggage cover restraining bands.
Check that luggage cover and lug-
gage cover restraining bands are
secured.
Fold over the cover and the sub
cover.
Lock release button
1
Lock releasebutton
2
3
4

420
GX460_OM_OM60Q84U_(U)5-3. Using the storage features
Stow the hooks.
Fold over the sub cover.
■Extending the case
Push the lock release button.
Pull the case until it locks.
Check that the lock release button
can be seen.
5
6
Lock release button
1
Lock release button
2
