Lexus GX460 2020 Owner's Manual / LEXUS 2020 GX460 OWNER'S MANUAL (OM60R27U)

GX460_OM_OM60R27U_(U)
3915-1. Using the air conditioning system and defogger
5
Interior features
Heats the seat
The indicator light comes on.
The higher the number of dots, the
warmer the airflow becomes.
Blows air from the seat
The indicator light comes on.
The higher the number of dots, the
stronger the airflow becomes.
The seat heaters and ventilators can be used when the engine switch is in IGNITION
ON mode.
Seat heaters and ventilators (if equipped)
1
2

392
GX460_OM_OM60R27U_(U)5-2. Using the interior lights
Interior lights list
Personal/interior lights (
P. 393)
Inside door handle lights
Shift lever lights
Engine switch light Scuff lights (if equipped)
Footwell lights
Door courtesy lights
Running board lights1
2
3
4
5
6
7
8

GX460_OM_OM60R27U_(U)
3935-2. Using the interior lights
5
Interior features
Turns the lights off
Turns the door position on
Turns the lights on
Personal/interior lights main switch
Personal/interior lights
1
2
3
FrontRear
Turns the lights on/off Turns the lights on/off

394
GX460_OM_OM60R27U_(U)5-2. Using the interior lights
■Illuminated entry system
The lights automatically turn on/off according
to engine switch mode, the presence of the
electronic key, whether the doors are locked/unlocked, and whether the doors are
open/closed.
■To prevent battery discharge
If the following lights remain on when the engine switch is turned off the lights will go off
automatically after 20 minutes:
●Personal/interior light
●Inside door handle lights
●Footwell lights
●Running board lights
■Customization
Settings (e.g. adjust the time elapsed before th e interior lights automatically turn off) can
be changed. (Customizable features:  P. 576)
NOTICE
To prevent battery discharge, do not leave th e lights on longer than necessary when the
engine is not running.

395
GX460_OM_OM60R27U_(U)5-3. Using the storage features
5
Interior features
List of storage features
Cup holders (
P. 398)
Auxiliary boxes ( P. 400)
Bottle holders/door pockets (P. 399)
Glove box ( P. 396)Console box (if equipped)
(P. 396)
Cool box (if equipped) ( P. 409)
Coin holder (if equipped) (P. 398)
WARNING
●Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause
the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracke d if they come into contact with other
stored items.
• Lighters or spray cans may explode. If they come into contact with other stored
items, the lighter may catch fire or the spray can may release gas, causing a fire
hazard.
●When driving or when the storage compartments are not in use, keep the lids closed.
In the event of sudden braking or sudden swerving, an accident may occur due to an
occupant being struck by an open lid or the items stored inside.
1
2
3
4
5
6

396
GX460_OM_OM60R27U_(U)5-3. Using the storage features
Unlock with the mechanical key
Lock with the mechanical key
Open (push the button)
The glove box light turns on when the tail lights are on.
Your vehicle is equipped with either a console box or cool box.
For vehicles with the cool box, refer to P. 409.
Lift the lid while pulling up the lower
lever to release the lock.
Glove box
1
2
3
Console box (if equipped)

GX460_OM_OM60R27U_(U)
3975-3. Using the storage features
5
Interior features
●The console box light turns on when the tail lights are on.
●When using the console box lid as an armrest,
slide the console box lid forward or backward
as needed. Slide the lid while pulling up the
upper lever to release the lock.
●The tray slides forward/backward and can be
removed.
NOTICE
Do not insert items exceeding the height of the tray. Doing so may prevent opening and
closing of the lid.

398
GX460_OM_OM60R27U_(U)5-3. Using the storage features
The coin holder is located in the console box.
■Cup holders
Coin holder (if equipped)
Cup holders/bottle holders/door pockets
Front seatsSecond seats (7
-passenger mod-
els)
Press down and release the cup
holder lid. Pull the armrest down, and then press
in and release the button.
Second seats (6-passenger mod-
els)Third seats (if equipped)
Pull the cup holder up.

GX460_OM_OM60R27U_(U)
3995-3. Using the storage features
5
Interior features
■Bottle holders/door pockets
■Cup holder lights (front seats)
●The cup holder lights turn on when the tail lights are on.
●The brightness of the cup holder lights chan ge in conjunction with the instrument clus-
ter light. ( P. 89)
■When using the holder as a bottle holder
●Close the cap.
●The bottle may not be stored depending on its size or shape.
■Removing the cup holders (secon d seats for 6-passenger models)
FrontRear
The cup holders can be removed.
WARNING
■Items unsuitable for the cup holders/bottle holders
●Do not place anything other than cups or beverage cans in the cup holders. Even
when the lid is closed, items must not be stored in the cup holders.
Other items may be thrown out of the holder s in the event of sudden braking, sudden
swerving or an accident, cause injury. If possible, cover hot drinks to prevent burns.
●Do not place anything other than bottles in the bottle holders.
In the event of an accident or sudden brak ing, other items may be thrown out of the
holders and cause injury.
■When not in use
Keep the cup holders closed.
Injuries may result in the event of sudden braking, sudden swerving or an accident.

400
GX460_OM_OM60R27U_(U)5-3. Using the storage features
NOTICE
●To prevent damage, stow the rear cup holders before stowing the armrest. (second
seats for 7-passenger models)
●To prevent damage, do not fold down the second seatbacks when using a cup holder
on the second seats.
(6-passenger models)
●To prevent damage, do not rest your hands on the cup holders or kick them.
●Do not place open bottles or glass and paper cups containing liquid in the bottle hold-
ers. The contents may sp ill and glasses may break.
Auxiliary boxes
Type AType B
Press in the button and then pull down
the lid.
The overhead console is useful for tem-
porarily storing sung lasses and similar
small items.
Push the lid.
Type C (if equipped)
