4015-3. Using the storage features
5
Interior features
■Auxiliary box light (type B)
●The auxiliary box light turns on when the tail lights are on.
●The brightness of the auxiliary box light changes in conjunction with the instrument
cluster light. ( P. 89)
■Closing the auxiliary box lid
Slide the auxiliary box lid forward.
WARNING
■Caution while driving
Do not place cups, beverage cans or bottles in the box. They may be thrown out of the
box in the event of sudden bra king, sudden swerving or an accident, resulting in injury.
(type B and C)
■Items unsuitable for storing (type A)
●Do not store items heavier than 0.4 lb. (0.2 kg).
Doing so may cause the auxiliary box to open and the items inside may fall out, result-
ing in an accident.
●Do not put large items in the overhead console.
The overhead console may not be able to be shut from the conversation mirror state.

402
GX460_OM_OM60R27U_(U)5-3. Using the storage features
Luggage compartment features
Raise the hook to use.
The cargo hooks are provided for
securing loose items.
When using the cargo hooks, the third
seat must be fold down. (
P. 134, 136)
Open the cover.
Turn the knob clockwise.
Open the cover.
Secure the warning reflector.
The warning reflector itself is not
included as an original equipment.
Cargo hooks
Warning reflector holder
1
1
2
2

GX460_OM_OM60R27U_(U)
4035-3. Using the storage features
5
Interior features
To hang the cargo net, use the cargo net hooks.
The cargo net itself is not included as an original equipment.
Remove the cover.
Cargo net hooks
Auxiliary box (if equipped)

404
GX460_OM_OM60R27U_(U)5-3. Using the storage features
■Installing the luggage cover
Attach the hooks to the head
restraints.
When using the lu ggage cover, the
third seats must be folded down.
(  P. 134, 136)
6-passenger models only: Secure
the middle part of the luggage
cover as shown.
Pull out the luggage cover and
hook it on the anchors.
■Removing the luggage cover
Retract the cover and release both
ends, then lift it out.
Luggage cover (if equipped)
1
2

GX460_OM_OM60R27U_(U)
4055-3. Using the storage features
5
Interior features
■Stowing the luggage cover
Push the case while pressing the
lock release button.
Vehicles without rear automatic air
conditioning system: Shorten one
side only.
Vehicles with rear automatic air con-
ditioning system: Shorten both sides.
Push the case until it locks.
Check that the lock release button
can be seen.
Vehicles without a rear automatic air
conditioning system: Shorten one
side only.
Vehicles with a rear automatic air
conditioning system: Shorten both
sides.
Secure the luggage cover with
luggage cover restraining bands.
Check that luggage cover and lug-
gage cover restraining bands are
secured.
Fold over the cover and the sub
cover.
Lock release button
1
Lock releasebutton
2
3
4

406
GX460_OM_OM60R27U_(U)5-3. Using the storage features
Stow the hooks.
Fold over the sub cover.
■Extending the case
Push the lock release button.
Pull the case until it locks.
Check that the lock release button
can be seen.
5
6
Lock release button
1
Lock release button
2

GX460_OM_OM60R27U_(U)
4075-3. Using the storage features
5
Interior features
■Adjusting the sub cover
Fasten the button when the second seats are in the rear-most position.
Unfasten the buttons before sliding the second seats forward.
WARNING
●To avoid injury, always return the cargo hooks to their stowed positions when not in
use.
●Keep the auxiliary box closed. In the event of sudden braking or sudden swerving, an
accident may occur due to an occupant bein g struck by an open auxiliary box or the
items stored inside.
●Keep the both sides of the luggage cover case locked. Otherwise, the luggage cover
may fly out in case of the su dden braking, sudden swerving or an accident, resulting in
death or serious injury.
●When stowing the luggage cover in the luggage compartment, use the luggage
cover restraining bands to secure the left and right sides of the luggage cover. Other-
wise, the luggage cover may fly out in case of the sudden braking, sudden swerving or
an accident, resulting in death or serious injury.
●Do not allow children to climb on the lugg age cover. Climbing on the luggage cover
could result in damage to the luggage cove r, possibly causing death or serious injury
to the child.

408
GX460_OM_OM60R27U_(U)5-3. Using the storage features
NOTICE
■To prevent damage to
the luggage cover
When stowing the luggage cover, do not put luggage on the luggage cover.
●Do not use the luggage cover restraining ba nds for anything other than securing the
luggage cover.
●Do not insert coins etc. into the area shown in
the illustration.

409
GX460_OM_OM60R27U_(U)5-4. Using the other interior features
5
Interior features
Other interior features
Lift the lid while pulling up the lower
lever to release the lock.
Turns the cool box on/off
When on, the indicator light comes on.
■The cool box can be operated when
The engine switch is in IGNITION ON mode.
■If the front air conditioning system is not in use when the cool box is turned on
The front air conditioning system is automatically turned on.
Cool box (if equipped)
1
2

410
GX460_OM_OM60R27U_(U)5-4. Using the other interior features
■While the cool box is on
The front air conditioning sy
stem cannot be turned off.
■Items unsuitable for the cool box
●Drinks in unsealed containers
●Fragile items, perishables or anything with strong odor
●Owner’s manual, electronic devices, CDs, etc.
■When the indicator light flashes
The cool box is not operated when an y of the following conditions occurs.
●When the air conditioning system is off
Turn the air conditioning system on also turns on the cool box.
●When outside air temperature is about 32 F (0 C) or below.
If the indicator light continues to flash, ther e may be a malfunction in the system. Turn the
air conditioning system off and have it inspected by your Lexus dealer.
■When using the cool box lid as an armrest
Slide the cool box lid forward or backward as
needed. Slide the lid while pulling up the upper
lever to release the lock.
WARNING
Keep the cool box closed. In the event of su dden braking or sudden swerving, an acci-
dent may occur due to an occupant being struck by the open cool box or the items
stored inside.
NOTICE
To prevent battery discharge, do not leave the cool box on longer than necessary when
the engine is not running.
