Page 6 of 186
TABLE OF CONTENTS
6
GX460_MM_OM60T29U_(U)20.03.27 13:49
1. BASIC FUNCTION......................................... 10
BUTTONS OVERVIEW ..................................... 10
“Apps” SCREEN...................................................... 12
HOME SCREEN .................................................... 14
2. QUICK REFERENCE ................................... 18
“Setup” SCREEN..................................................... 18
1. BASIC INFORMATION BEFORE OPERATION ............................................... 22
INITIAL SCREEN .................................................. 22
TOUCH SCREEN GESTURES ..................... 23
TOUCH SCREEN OPERATION ................. 24
“Apps” SCREEN OPERATION ..................... 25
HOME SCREEN OPERATION .................... 26
ENTERING LETTERS AND NUMBERS/LIST SCREEN OPERATION ....................... 27
SCREEN ADJUSTMENT .................................. 29
2. Bluetooth® SETTINGS.................................. 31
REGISTERING/CONNECTING Bluetooth® DEVICE .......................................... 31
SETTING Bluetooth® DETAILS ..................... 36
3. OTHER SETTINGS ....................................... 44
GENERAL SETTINGS ....................................... 44
VOICE SETTINGS ............................................... 49
1. BASIC OPERATION..................................... 52
QUICK REFERENCE......................................... 52
SOME BASICS ...................................................... 54
2. RADIO OPERATION.................................. 60
AM/FM RADIO..................................................... 60
XM Satellite Radio................................................. 68
3. MEDIA OPERATION...................................76
CD .................................................................................76
USB MEMORY.......................................................79
iPod .............................................................................. 83
Bluetooth
® AUDIO ............................................. 89
AUX ..................................................................................95
VTR................................................................................97
4. AUDIO/VISUAL REMOTE CONTROLS ................................................. 99
STEERING SWITCHES ..................................... 99
5. SETUP .............................................................. 102
AUDIO SETTINGS ............................................ 102
6. TIPS FOR OPERATING THE AUDIO/VISUAL SYSTEM ................... 105
OPERATING INFORMATION .................. 105
1QUICK GUIDE
2BASIC FUNCTION
3AUDIO/VISUAL SYSTEM
Page 31 of 186
31
GX460_MM_OM60T29U_(U)20.03.27 13:49
2
BASIC FUNCTION
2. Bluetooth® SETTINGS
1. REGISTERING/CONNECTING Bluetooth® DEVICE
1Turn the Bluetooth® connection setting
of your cellular phone on.
This function is not available when
Bluetooth® connection setting of your cel-
lular phone is set to off.
2Press the button.
Operations up to this point can also be per-
formed by pressing the switch on the
steering wheel.
3Select “Yes” to register a phone.
4When this screen is displayed, search
for the device name displayed on this
screen on the screen of your
Bluetooth
® device.
For details about operating the Bluetooth®
device, see the manual that comes with it.
To cancel the regi stration, select “Cancel” .
5Register the Bluetooth® device using
your Bluetooth
® device.
A PIN-code is not required for SSP
(Secure Simple Pairing) compatible
Bluetooth
® devices. Depending on the
type of Bluetooth® device being con-
nected, a message confirming registration
may be displayed on the Bluetooth
®
device’s screen. Respond and operate the
Bluetooth® device according to the confir-
mation message.
REGISTERING A Bluetooth®
PHONE FOR THE FIRST TIME
To use the hands-free system, it is neces-
sary to register a Bluetooth
® phone with
the system.
Once the phone has been registered, it
is possible to use the hands-free system.
This operation cannot be performed
while driving.
For details about registering a
Bluetooth
® device: P.37
Page 51 of 186
3
51
1
2
3
4
5
6
GX460_MM_OM60T29U_(U)20.03.27 13:49
7
1. CD.................................................................... 76
OVERVIEW.................................................................. 76
PLAYING AN AUDIO CD .................................. 78
PLAYING AN MP3/WMA/AAC DISC ....... 78
2. USB MEMORY........................................... 79
OVERVIEW.................................................................. 79
PLAYING A USB AUDIO ................................... 82
3. iPod .................................................................. 83
OVERVIEW................................................................. 83
iPod AUDIO ................................................................ 88
iPod VIDEO ................................................................. 88
4. Bluetooth® AUDIO ................................... 89
OVERVIEW................................................................. 89
CONNECTING A Bluetooth® DEVICE ....... 94
LISTENING TO Bluetooth® AUDIO ............... 94
5.AUX ..................................................................... 95
OVERVIEW................................................................. 95
6. VTR .................................................................. 97
OVERVIEW.................................................................. 97
1. STEERING SWITCHES ........................... 99
1. AUDIO SETTINGS .................................. 102
AUDIO SETTINGS SCREEN ............................ 102
1. OPERATING INFORMATION.......... 105
RADIO.......................................................................... 105
CD PLAYER AND DISC...................................... 106
iPod................................................................................. 108
FILE INFORMATION ............................................ 109
TERMS ............................................................................ 112
ERROR MESSAGES ............................................... 113
3MEDIA OPERATION4AUDIO/VISUAL REMOTE
CONTROLS
5SETUP
6TIPS FOR OPERATING THE
AUDIO/VISUAL SYSTEM
AUDIO/VISUAL SYSTEM
Page 53 of 186
53
1. BASIC OPERATION
3
AUDIO/VISUAL SYSTEM
GX460_MM_OM60T29U_(U)20.03.27 13:49
FunctionPage
Using the radio60
Playing an audio CD or MP3/WMA/AAC disc76
Playing a USB memory79
Playing an iPod83
Playing a Bluetooth® device89
Using the AUX port95
Playing the VTR97
Using the steering wheel audio switches99
Audio system settings102
INFORMATION
●The display and button positions will differ depending on the type of the system.
Page 99 of 186
99
GX460_MM_OM60T29U_(U)20.03.27 13:49
3
AUDIO/VISUAL SYSTEM
4. AUDIO/VISUAL REMOTE CONTROLS
1. STEERING SWITCHES
Volume control switch
Some parts of the audio/visual system can be adjusted using the switches on the steer-
ing wheel.
No.Switch
Volume control switch
“” switch
“MODE” switch
ModeOperationFunction
All
PressVolume up/down
Press and hold
(0.8 sec. or more)Volume up/down continuously
Page 116 of 186
116
GX460_MM_OM60T29U_(U)20.03.27 13:49
1. VOICE COMMAND SYSTEM OPERATION
1. VOICE COMMAND SYSTEM
Talk switch
Press the talk switch to start the voice com-
mand system.
To cancel voice recognition, press and hold
the talk switch.
It is unnecessary to speak directly into the
microphone when giving a command.
The voice command system enables the
audio/visual and hands-free and to be
operated using voice commands.
Refer to the command list for samples of
voice commands. ( P.122)
USING THE VOICE
COMMAND SYSTEM
STEERING SWITCH
MICROPHONE
INFORMATION
●Wait for the confirmation beep before
speaking a command.
●Voice commands may not be recognized
if:
• Spoken too quickly.
• Spoken at a low or high volume.
• The roof or windows are open.
• Passengers are talking while voice com-
mands are spoken.
• The air conditioning speed is set high.
• The air conditioning vents are turned towards the microphone.
●In the following conditions, the system
may not recognize the command prop-
erly and using voice commands may not
be possible:
• The command is incorrect or unclear.Note that certain words, accents or
speech patterns may be difficult for the
system to recognize.
• There is excessive background noise, such as wind noise.
Page 120 of 186
120
1. VOICE COMMAND SYSTEM OPERATION
GX460_MM_OM60T29U_(U)20.03.27 13:49
1Press the talk switch.
2Say the phone number.
In the same manner as it is displayed on the
screen, “Dial
a number” say the phone number.
Say the phone number one digit at a time.
For example, if the phone number is
2345678:
Say “two three four five six seven eight”
Calling to the following phone number
• 3 digit numbers (911, 411, 611)
• 7 digit numbers (Local phone numbers)
• 10 digit numbers (Area code + Local
phone number)
• 11 digit phone numbers (1 + Area code + Local phone number)
3When the confirmation screen appears,
say “Yes” or select “Yes” or press the
switch on the steering wheel.
As the system cannot recognize additional
numbers, say the complete number without
stopping.
Calling to other phone number
3Say “Call” or push the switch on the
steering wheel.
INFORMATION
●In the same manner as it is displayed on
the screen, “Call
the name, or the name and type of phone,
of a contact.
For example: “Call a contact” , “John
Smith” or “Call a contact” , “Mary Davis” ,
“Mobile”
●There are 4 types of phones: Home,
Mobile, Office and Other.
●Short or abbreviated names in the con-
tacts list may not be recognized. Change
names in the contacts list to full names.
●Sometimes a voice recognition result
confirmation screen will be displayed.
After confirming the result, say “Yes” or
“No” .
●When the system recognizes multiple
names from the contacts list, a name can-
didate list will be displayed on the screen.
If the desired name is not displayed on the
top of the screen, say or select the num-
ber of the name from the candidate list to
select a name from the candidate list.
●When a contact has multiple phone num-
bers registered in the contacts list, a can-
didate list will be displayed. If the desired
phone number is not displayed on the top
of the screen, say or select the number of
the desired phone number from the can-
didate list to select a phone number from
the candidate list.
VOICE COMMAND
EXAMPLE: DIAL NUMBER
When the system recognizes multiple
phone numbers, a phone number candi-
date list will be disp layed on the screen.
Pressing the
switch on the steering
wheel makes a call to the top entry on the
list. If the desired phone number is not
displayed on the top of the screen, say
the number of the desired phone number
from the candidate list to select a phone
number from the candidate list.
Page 124 of 186
124
GX460_MM_OM60T29U_(U)20.03.27 13:49
2. MOBILE ASSISTANT OPERATION
1. MOBILE ASSISTANT
1Press and hold this switch until you hear
the beeps.
2The Mobile Assistant can be used only
when the “Mobile Assistant” screen is
displayed.
To cancel the Mobile Assistant, select
“Cancel”, or press and hold the on the
steering wheel.
To restart the Mobile Assistant for addi-
tional commands, press the on the
steering wheel.
• Mobile Assistant can only be restarted
after the system responds to a voice com-
mand. • After some phone and music commands,
the Mobile Assistant feature will automat-
ically end to complete the requested
action.
The Mobile Assistant feature will
activate Apple’s Siri
® Eyes Free mode
via the steering wheel switches. To
operate the Mobile Assistant, a
compatible cellular phone must be
registered and connected to this system
via Bluetooth
®. ( P.31)
The volume of the Mo bile Assistant can
be adjusted using the “PWR/VOL” knob
or steering wheel volume control
switches. The Mob ile Assistant and
phone call volumes are synchronized.
INFORMATION
●The available features and functions may
vary based on the iOS version installed
on the connected device.
●Some Siri features are limited in Eyes
Free mode. If you attempt to use an
unavailable function, Siri will inform you
that the function is not available.
●If Siri is not enabled on the cellular phone
connected via Bluetooth®, an error mes-
sage will be displayed on the screen.
●While a phone call is active, the Mobile
Assistant cannot be used.
●If using the navigation feature of the cellu-
lar phone, ensure the active audio source
is Bluetooth
® audio or iPod in order to
hear turn by turn direction prompts.
Page 132 of 186
132
GX460_MM_OM60T29U_(U)20.03.27 13:49
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES)
1. QUICK REFERENCE
The phone top screen can be used to make a phone call. To display the hands-free op-
eration screen, press the button or the switch on the steering wheel.
Several functions are available to operate on each screen that is displayed by selecting
the 4 tabs.
FunctionPage
Phone operation
Registering/conne cting Bluetooth® phone31
Calling on the Bluetooth® phone136
Receiving on the Bluetooth® phone142
Talking on the Bluetooth® phone143
Message functionUsing the Bluetooth® phone message function146
Setting up a phonePhone settings152
Bluetooth® settings36
Page 133 of 186
133
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES)
GX460_MM_OM60T29U_(U)20.03.27 13:49
6
PHONE
2. SOME BASICS
The hands-free system enables calls to
be made and received without having to
take your hands off the steering wheel.
This system supports Bluetooth
®.
Bluetooth
® is a wireless data system
that enables cellular phones to be used
without being connected by a cable or
placed in a cradle.
The operating procedure of the phone is
explained here.
WARNING
●While driving, do not use a cellular phone
or connect the Bluetooth® phone.
●Your audio unit is fitted with Bluetooth®
antennas. People with implantable car-
diac pacemakers, cardiac resynchroniza-
tion therapy-pacemakers or implantable
cardioverter defibrill ators should main-
tain a reasonable distance between
themselves and the Bluetooth
® antennas.
The radio waves may affect the operation
of such devices.
●Before using Bluetooth® devices, users
of any electrical medical device other
than implantable cardiac pacemakers,
cardiac resynchronization therapy-pace-
makers or implantable cardioverter
defibrillators should consult the manufac-
turer of the device for information about
its operation under th e influence of radio
waves. Radio waves could have unex-
pected effects on the operation of such
medical devices.
NOTICE
●Do not leave your cellular phone in the
vehicle. The temperature inside may rise
to a level that coul d damage the phone.
INFORMATION
●This system is not guaranteed to operate
with all Bluetooth® devices.
●If your cellular phone does not support
Bluetooth®, this system cannot function.
●In the following conditions, the system
may not function:
• The cellular phone is turned off.
• The current position is outside the com-
munication area.
• The cellular phone is not connected.
• The cellular phone has a low battery.
●When using Bluetooth® audio and
hands-free system at the same time, the
following problems may occur:
• The Bluetooth
® connection may be cut.
• Noise may be heard on the Bluetooth
®
audio playback.
REGISTERING/
CONNECTING A Bluetooth®
PHONE
To use the hands-free system for cellular
phones, it is necessary to register a cel-
lular phone with the system. ( P.31)
Bluetooth® PHONE
CONDITION DISPLAY
The condition of the Bluetooth
® phone
appears on the upper right side of the
screen. ( P.16)
