Page 133 of 628
GX460_OM_OM60T19U_(U)
1333-3. Adjusting the seats
3
Operation of each component
■Power easy access system
The driver’s seat and steering wheel move in accordance with engine switch mode and
the driver’s seat belt condition. ( P. 145)
■Active head restraints
Even small forces applied to the seatback may cause the head restraint to move. Pushing
up a locked head restraint fo rcibly may appear the head re straint inner structure. These
do not indicate problems.
WARNING
■When adjusting the seat position
●Take care when adjusting the seat position to ensure that other passengers are not
injured by the moving seat.
●Do not put your hands under the seat or near the moving parts to avoid injury.
Fingers or hands may become jammed in the seat mechanism.
■Seat adjustment
To reduce the risk of sliding under the lap be lt during a collision, do not recline the seat
more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces
directly to the abdomen, or your neck may contact the shou lder belt, increasing the risk
of death or serious injury in the event of an accident.
Adjustments should not be made while drivin g as the seat may unexpectedly move and
cause the driver to lose control of the vehicle.
Inner
structure During rear-end collision
Page 147 of 628
GX460_OM_OM60T19U_(U)
1473-3. Adjusting the seats
3
Operation of each component
■To stop the position recall operation part-way through
Perform any of the following:
●Press the “SET” button.
●Press button “1” or “2”.
●Operate any of the seat adjustment switches (only cancels seat position recall).
●Operate the tilt and telescopic steering control switch (only cancels steering wheel
position recall).
■Seat positions that can be memorized ( P. 132)
The adjusted positions other than the position adjusted by lumbar support switch can be
recorded.
■Operating the driving position memory after turning the engine switch off
Recorded seat positions can be activated up to 180 seconds after the driver’s door is
opened and another 60 seconds after it is closed again.
■In order to correctly use the driving position memory function
If a seat position is already in the furthest po ssible position and the seat is operated in the
same direction, the recorded position may be slightly different when it is recalled.
Each electronic key can be registered to recall your preferred driving position.
■Registering procedure
Record your driving position to button “1” or “2” before performing the follow-
ing:
Carry only the key you want to regist er, and then close the driver’s door.
If 2 or more keys are in the vehicle, the driving position cannot be recorded
properly.
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Recall the driving position that you want to record.
Memory recall function
1
2
3
Page 149 of 628
GX460_OM_OM60T19U_(U)
1493-3. Adjusting the seats
3
Operation of each component
■Recalling the driving position using the memory recall function
●Different driving positions can be registered for each electronic key. Therefore, the
driving position that is recalled may be di fferent depending on the key being carried.
●If a door other than the driver’s door is unlocked with the smart access system with
push-button start, the driving position cannot be recalled. In this case, press the driving
position button which has been set.
■Customization
The unlock door settings of the memo ry recall function can be customized.
(Customizable features: P. 584)
WARNING
■Seat adjustment caution
Take care during seat adjustment so that the seat does not strike the rear passenger or
squeeze your body against the steering wheel.
Page 153 of 628
1533-4. Adjusting the steering wheel and mirrors
3
Operation of each component
GX460_OM_OM60T19U_(U)
Steering wheel
Up
Down
Toward the driver
Away from the driver
To sound the horn, press on or close to
the mark.
Adjustment procedure
1
2
3
4
Horn
Page 154 of 628
1543-4. Adjusting the steering wheel and mirrors
GX460_OM_OM60T19U_(U)
■The steering wheel can be adjusted when
The engine switch is in ACCESSORY or IGNITION ON mode
*.
*: If the driver’s seat belt is fastened, the steering wheel can be adjusted regardless of engine switch mode.
■Automatic adjustment of the steering position
A desired steering position ca n be entered to memory and recalled automatically by the
driving position memory system. ( P. 146)
■Power easy access system
The steering wheel and driver’s seat move in accordance with engine switch mode and
the driver’s seat belt condition. ( P. 145)
WARNING
Do not adjust the steeri ng wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an accident, result-
ing in death or serious injury.
Page 157 of 628
1573-4. Adjusting the steering wheel and mirrors
3
Operation of each component
GX460_OM_OM60T19U_(U)
Outside rear view mirrors
To select a mirror to adjust, press the
switch.Left
Right
To adjust the mirror, press the switch. Up
Right
Down
Left
Manual type
Push the mirror back in the direction of
the vehicle’s rear.
Adjustment procedure
1
1
2
2
1
2
3
4
Folding and extending the mirrors
Page 158 of 628
1583-4. Adjusting the steering wheel and mirrors
GX460_OM_OM60T19U_(U)
Power type
Extends the mirrors
Folds the mirrors
When the mirror select switch is in the L or R position, the outside rear view mir-
rors will automatically angle downwards wh en the vehicle is reversing in order to
give a better view of the ground.
To disable this function, move the mirror select switch to the neutral position
(between L and R).
■Mirror angle can be adjusted when
The engine switch is in ACCESSORY or IGNITION ON mode.
■When the mirrors are fogged up
The outside rear view mirrors can be cleare d using the mirror defoggers. Turn on the
rear window defogger to turn on the outside rear view mirror defoggers. ( P. 389)
■Automatic adjustment of the mirror angle
A desired mirror face angle can be entered to memory and recalled automatically by the
driving position memory. ( P. 145)
■Auto anti-glare function (driver’s side only)
When the anti-glare inside re ar view mirror is set to automatic mode, the outside rear
view mirrors will activate in conjunction with the anti-glare inside rear view mirror to
reduce reflected light. ( P. 155)
1
2
Linked mirror function when reversing
Page 617 of 628
617Alphabetical index
GX460_OM_OM60T19U_(U)
Emergency flashers .............................508
EngineAccessory mode................................. 201
Brake Override System .................. 169
Compartment..................................... 459
Drive-Start Control............................ 170
Hood ....................................................... 458
How to start the engine ................. 200
Identification number .......................562
If the engine will not start............... 545
Ignition switch (engine switch)... 200
Overheating ........................................ 553
Engine compartment cover ............. 460
Engine coolant....................................... 463 Capacity ................................................ 564
Checking................................................463
Preparing and checking before winter .................................... 374
Engine immobilizer system .................. 77
Engine oil ...................................................461 Capacity .................................................562
Checking................................................. 461
Preparing and checking before winter .................................... 374
Warning message .............................529
Engine oil maintenance data ........... 462
Engine switch .........................................200
Engine switch light ...............................400
Event data recorder (EDR) ...................10 Flat tire ........................................................ 531
Floor mats....................................................26
Fluid
Automatic transmission ..................566
Brake........................................................ 567
Steering ................................................. 568
Washer ..................................................... 471
Fog lights.................................................... 221 Replacing light bulbs ...................... 505
Switch ........................................................ 221
Four-wheel drive system....................344
Front passenger occupant classification system ............................ 47
Front passenger’s seat belt reminder light ..................................... 520
Front seats ................................................. 132 Adjustment.............................................. 132
Cleaning................................................. 445
Correct driving posture .................... 28
Driving position memory.................145
Head restraints .................................... 150
Seat heaters ..........................................398
Seat position memory .......................145
Front turn signal lights ............................211 Replacing light bulbs ........................ 501
Turn signal lever .....................................211
Wattage .................................................569F
Page 622 of 628
622Alphabetical index
GX460_OM_OM60T19U_(U)
Seat heaters ............................................ 398
Seat ventilators ...................................... 399
Seat position memory...........................145
Seats...................................................132, 134Adjustment ................................... 132, 134
Adjustment precautions ........ 133, 144
Child seats/child restraint system installation............................. 58
Cleaning .................................................445
Driving position memory ................ 145
Head restraint ....................................... 150
Properly sitting in the seat ................ 28
Seat position memory....................... 145
Ventilators ............................................ 399
Sensor Automatic headlight system ...........214
Automatic High Beam system ..... 216
Inside rear view mirror ..................... 156
Intuitive parking assist-sensor .....270
LDA (Lane Departure Alert) ...... 250
Radar sensor ........................................ 234
Rain-sensing windshield wipers ................................................... 224
Service reminder indicators ............... 84
Shift lever Automatic transmission ................. 206
If the shift lever cannot be shifted from P .................................. 209
Shift lock system....................................208
Side airbags ............................................... 36
Side mirrors .............................................. 157 Adjusting and folding........................ 157
Blind Spot Monitor............................. 361 Side turn signal lights ..............................211
Replacing light bulbs ...................... 505
Turn signal lever .....................................211
Smart access system with push-button start................................. 125 Antenna location.................................. 125
Starting the engine ............................200
Snow tires .................................................376
Spare tire ................................................... 531 Inflation pressure............................... 568
Storage location ................................. 532
Spark plug ............................................... 564
Specifications......................................... 560
Speedometer ............................................ 90
Steering lock Column lock release ....................... 203
Steering wheel ........................................ 153 Adjustment..............................................153
Audio switches
*
Heated steering wheel ................... 397
Steering wheel position memory.................................................145
Stop/tail lights Replacing light bulbs ...................... 505
Storage feature ..................................... 403
Stuck If the vehicle becomes stuck........556
Sunshade Roof ............................................................164
Sun visors................................................... 419
Switch Automatic High Beam switch ....... 216
AVS switch ........................................... 343
BSM (Blind Spot Monitor) switch ................................................... 362
Center differential lock/ unlock switch.................................... 345
