Page 3 of 628
3
1
8 7
6
5
4
3
2
GX460_OM_OM60T19U_(U)
9
4-1. Before driving Driving the vehicle ..................... 168
Cargo and luggage .................... 176
Vehicle load limits ...................... 180
Trailer towing (with towing hitch) ..................... 181
Dinghy towing ...............................199
4-2. Driving procedures Engine (ign ition) switch ...........200
Automatic transmission .......... 206
Turn signal lever ............................ 211
Parking brake ................................ 212
4-3. Operating the lights and wipers
Headlight switch ..........................213
Automatic High Beam...............216
Fog light switch .............................221
Windshield wipers and washer ......................................... 222
Rear window wiper and washer ......................................... 226
Headlight cleaner switch........ 228
4-4. Refueling Opening the fuel tank cap ..... 229 4-5. Using the driving support
systems
Lexus Safety System + ............. 233
PCS (Pre-Collision System) ....................................... 239
LDA (Lane Departure Alert) ............................................ 250
Dynamic radar cruise control ......................................... 258
Intuitive parking assist.............. 270
Rear view monitor system...... 278
Multi-terrain Select...................288
Multi-terrain Monitor............... 292
Rear height control air suspension ................................. 339
AVS (Adaptive Variable Suspension System) .............. 343
Four-wheel drive system ........ 344
Crawl Control............................. 348
Downhill assist control system.......................................... 352
Driving assist systems .............. 355
BSM (Blind Spot Monitor).......361 • The Blind Spot Monitor function .................................... 366
• The Rear Cross Traffic Alert function......................... 369
4-6. Driving tips Winter driving tips..................... 374
Off-road precautions................377
4Driving
Page 15 of 628
15Pictorial index
GX460_OM_OM60T19U_(U)
Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 222
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 374
To prevent freezing (windshield wiper de-icer
*) . . . . . . . . . . . . . . . . . . . . . . . P. 389
Precautions against car wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 443
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 229
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 229
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 562
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 472
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 568
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 37 4
Checking/rotation/tire pressure warning system . . . . . . . . . . . . . . . . . . . . . . P. 472
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 531
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 458
Opening. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 458
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 562
Coping with overheat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 553
Warning lights/warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 114, 520
Camera*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 278, 292
Headlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 213
Parking lights/daytime running lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 213
Fog lights
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 221
Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 211
Stop/tail lights
Hill-start assist control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 356
Downhill assist control system*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 352
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 213
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 206
Side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 213
4
5
6
7
8
Light bulbs of the exte rior lights for driving
(Replacing method: P. 499, Watts: P. 569)
*: If equipped
9
10
11
12
13
14
15
16
Page 167 of 628
167
GX460_OM_OM60T19U_(U)
4Driving
4-1. Before drivingDriving the vehicle ...................... 168
Cargo and luggage .................... 176
Vehicle load limits .......................180
Trailer towing (with towing hitch) .................... 181
Dinghy towing .............................. 199
4-2. Driving procedures Engine (ignition) switch .......... 200
Automatic transmission.......... 206
Turn signal lever.............................211
Parking brake ............................... 212
4-3. Operating the lights and wipers
Headlight switch .......................... 213
Automatic High Beam .............. 216
Fog light switch ............................ 221
Windshield wipers and washer.......................................... 222
Rear window wiper and washer.......................................... 226
Headlight cleaner switch ........228
4-4. Refueling Opening the fuel tank cap......229 4-5. Using the driving support
systems
Lexus Safety System + ............. 233
PCS (Pre-Collision System)........................................ 239
LDA (Lane Departure Alert) ............................................250
Dynamic radar cruise control .........................................258
Intuitive parking assist .............. 270
Rear view monitor system ...... 278
Multi-terrain Select .................. 288
Multi-terrain Monitor ............... 292
Rear height control air suspension ................................. 339
AVS (Adaptive Variable Suspension System)............... 343
Four-wheel drive system ........ 344
Crawl Control .............................348
Downhill assist control system .......................................... 352
Driving assist systems ..............355
BSM (Blind Spot Monitor) ...... 361 • The Blind Spot Monitor function .................................... 366
• The Rear Cross Traffic Alert function ......................... 369
4-6. Driving tips Winter driving tips ..................... 374
Off-road precautions ............... 377
Page 214 of 628
214
GX460_OM_OM60T19U_(U)4-3. Operating the lights and wipers
With the headlights on, push the
lever away from you to turn on the
high beams.
Pull the lever toward you to the center
position to turn the high beams off.
Pull the lever toward you and release
it to flash the high beams once.
You can flash the high beams with the
headlights on or off.
■Daytime running light system
●The daytime running lights illuminate using th
e same lights as the parking lights and illu-
minate brighter than the parking lights.
●To make your vehicle more visible to other drivers during daytime driving, the daytime
running lights turn on automatically when a ll of the following conditions are met. (The
daytime running lights are not designed for use at night.)
• The engine is running
• The parking brake is released
• The headlight switch is in the or “AUTO”* position
*: When the surroundings are bright
The daytime running lights remain on after they illuminate, even if the parking brake is
set again.
●For the U.S.A.: Daytime running lights can be turned off by operating the switch.
●Compared to turning on the headlights, the daytime running light system offers greater
durability and consumes less electricity, so it can help improve fuel economy.
■Headlight control sensor
Turning on the high beam headlights
1
2
The sensor may not function properly if an
object is placed on the sensor, or anything that
blocks the sensor is affixed to the windshield.
Doing so interferes with the sensor detecting
the level of ambient light and may cause the
automatic headlight system to malfunction.
Page 219 of 628
GX460_OM_OM60T19U_(U)
2194-3. Operating the lights and wipers
4
Driving
●In the situations shown below, the system may not be able to accurately detect sur-
rounding brightness levels. This may cause the low beams to remain on or the high
beams to cause problems for pedestrians, ve hicles ahead or other parties. In these
cases, manually switch between the high and low beams.
• In bad weather (rain, snow, fog, sandstorms etc.)
• The windshield is obscured by fog, mist, ice, dirt etc.
• The windshield is cracked or damaged.
• The camera sensor is deformed or dirty.
• The camera sensor temperature is extremely high.
• Surrounding brightness levels are equal to th ose of headlights, tail lights or fog lights.
• Vehicles ahead have headlights that are either switched off, dirty, are changing color,
or are not aimed properly.
• When driving through an area of intermittently changing brightness and darkness.
• When frequently and repeated ly driving ascending/descending roads, or roads with
rough, bumpy or uneven surfaces (such as stone-paved roads, gravel tracks etc.).
• When frequently and repeatedly taking curves or driving on a winding road.
• There is a highly reflective object ahead of the vehicle, such as a sign or a mirror.
• The back of a vehicle ahead is highly re flective, such as a container on a truck.
• The vehicle’s headlights are damaged or dirty.
• The vehicle is listing or tilting, due to a flat tire, a trailer being towed etc.
• The high beam and low beam are repeated ly being switched between in an abnor-
mal manner.
• The driver believes that the high beam may be causing problems or distress to other drivers or pedestrians nearby.
Page 222 of 628
222
GX460_OM_OM60T19U_(U)4-3. Operating the lights and wipers
Windshield wipers and washer
Operating the lever operates th
e wipers or washer as follows.
Intermittent windshield wipers with interval adjuster
Off
Intermittent operation
Low speed operation
High speed operation
Temporary operation
Wiper intervals can be adjusted when intermittent operation is selected.
Increases the intermittent windshield
wiper frequency
Decreases the intermittent wind-
shield wiper frequency
Operating the wiper lever
1
2
3
4
5
6
7
Page 223 of 628
GX460_OM_OM60T19U_(U)
2234-3. Operating the lights and wipers
4
Driving
Washer/wiper dual opera-
tion
Pulling the lever operates the wipers
and washer.
The wipers will automatically operate a
couple of times afte r the washer squirts.
Vehicles with headlight cleaners: If the
headlights are on, the headlight cleaners
will operate once.
Rain-sensing windshield wipers
*1 or *2 Off
Rain-sensing operation
*1 or *2
Low speed operation
*1 or *2
High speed operation
*1 or *2
High speed operation
*1: For the U.S.A.
*2:For Canada When “AUTO” is selected, the wipers
will operate automatically when the sen-
sor detects falling rain . The system auto-
matically adjusts wiper timing in
accordance with rain volume and vehi-
cle speed.
8
1
2
3
4
5
Page 224 of 628
224
GX460_OM_OM60T19U_(U)4-3. Operating the lights and wipers
The sensor sensitivity can be adju
sted when “AUTO” is selected.
Increases the sensitivity
Decreases the sensitivity
Washer/wiper dual opera-
tion
Pulling the lever op erates the wipers
and washer.
The wipers operate automatically. (After
operating several times, the wipers
operate one more time after a short
delay to prevent dripping.)
Vehicles with headlight cleaners: If the
headlights are on, the headlight cleaners
will operate once.
■The windshield wiper and washer can be operated when
The engine switch is in IGNITION ON mode.
■Raindrop sensor (vehicles with rain-sensing windshield wipers)
●If the wiper switch is turned to the “AUTO” position while the engine switch is in
IGNITION ON mode, the wipers will operate on ce to show that “AUTO” mode is acti-
vated.
●When the sensor sensitivity ring is turned toward high while in “AUTO” mode, the wip-
ers will operate once to indicate that the sensor sensitivity is enhanced.
●If the temperature of the rain drop sensor is 194 F (90 C) or higher, or 5 F (-15 C) or
lower, the automatic operation may not occur. In this case, operate the wipers in any
mode other than “AUTO”.
6
7
8
●The raindrop sensor judges the amount of
raindrops.
An optical sensor is ad opted. It may not oper-
ate properly when sunlight from the rising or
setting of the sun inte rmittently strikes the
windshield, or if bugs etc. are present on the
windshield.
Page 225 of 628
GX460_OM_OM60T19U_(U)
2254-3. Operating the lights and wipers
4
Driving
■Effects of vehicle speed on wiper operation (vehicles with rain-sensing windshield wip-
ers)
With the settings other than “AUTO” also, the time until drip prevention wiper sweep
occurs is changed depending on vehicle speed.
With the low speed wiper operation selected, wiper operation will be switched from low
speed to intermittent wiper operation only when the vehicle is stationary. (However,
when the sensor sensitivity is adjusted to the highest level, the mode cannot be switched.)
■If no windshield washer fluid sprays
Check that the washer nozzles are not blocked if there is washer fluid in the windshield
washer fluid reservoir.
WARNING
■Caution regarding the use of windshield wipe rs in “AUTO” mode (vehicles with rain-
sensing windshield wipers)
The windshield wipers may operate unexpectedly if the sensor is touched or the wind-
shield is subject to vibration in “AUTO” mo de. Take care that your fingers etc. anything
else does not become caught in the windshield wipers.
■Caution regarding the use of washer fluid
When it is cold, do not use the washer fl uid until the windshield becomes warm. The
fluid may freeze on the windshield and cause lo w visibility. This may lead to an accident,
resulting in death or serious injury.
NOTICE
■When the windshield is dry
Do not use the wipers, as they may damage the windshield.
■When the washer fluid tank is empty
Do not operate the switch continually as the washer fluid pump may overheat.
■When there is no washer fluid spray from the nozzle
Damage to the washer fluid pump may be cau sed if the lever is pulled toward you and
held continually.
■When a nozzle becomes blocked
In this case, contact your Lexus dealer.
Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 226 of 628
226
GX460_OM_OM60T19U_(U)4-3. Operating the lights and wipers
Rear window wiper and washer
Operating the switch
operates the rear wiper as follows.
*1 or *2 Off
*1 or *2
Intermittent operation
*1 or *2
Normal operation
*1: For the U.S.A.
*2:For Canada
Washer/wiper dual opera-
tion
Pushing the lever operates the wiper
and washer.
The wipers will automatically operate a
couple of times afte r the washer squirts.
■The rear window wiper and washer can be operated when
●The engine switch is in IGNITION ON mode.
●The glass hatch is closed.
■If no windshield washer fluid sprays
Check that the washer nozzles are not blocked if there is washer fluid in the windshield
washer fluid reservoir.
1
2
3
4
