DRIVING TIPS
345
Check the electronic ignition system for loose
connections or obvious damage.
Keep the door locks from freezing.
Squirt
lock de− icer or glycerine into the locks to keep them from
freezing.
Use a washer fluid containing an antifreeze solution.
This product is available at your Lexus dealer and most auto
parts stores. Follow the manufacturer’s directions for how
much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute
because it may damage your vehicle’s paint.
Do not use your parking brake when there is a possibility
it could freeze.
When parking, put the transmission into “P” and block the front
wheels. Do not use the parking brake, or snow or water
accumulated in and around the parking brake mechanism may
freeze the parking brake, making it hard to release.
Keep ice and snow from accumulating under the fenders.
Ice and snow built up under your fenders can make steering
difficult. During bad winter driving, stop and check under the
fenders occasionally. Depending on where you are driving, we recommend you
carry some emergency equipment.
Some of the things you might put in the vehicle are tire chains,
window scraper, bag of sand or salt, flares, small shovel,
jumper cables, etc.

IN CASE OF AN EMERGENCY
364B: If no steam is coming from your engine:
Leave the engine running and turn off the air conditioning.
Check the following.

Is the cooling fan operating?
 Is the coolant in the acceptable range?
 Is the engine drive belt O.K.?
CAUTION
When the engine is running, keep hands and clothing
away from the moving fan and engine drive belt.
 Do not attempt to remove the radiator cap when the
engine and radiator are hot. Serious injury could
result from scalding hot fluid and steam blown out
under pressure.
If the cooling fan is not operating or the coolant is not in the
acceptable range, turn off the engine and call your Lexus
dealer.
If both conditions are O.K., after the engine coolant
temperature has cooled to normal, continue driving your
vehicle.
If the engine coolant temperature does not cool down, or your
vehicle overheats again, have it checked as soon as possible
by your Lexus dealer.
IF YOU HAVE A FLAT TIRE
1. Reduce your speed gradually, keeping a straight line. Move
cautiously off the road to a safe place − well away from the
traffic. A void stopping on the center divider of a highway. Park
on a level spot with firm ground.
2. Stop the engine and turn on your emergency flashers.
3. Firmly set the parking brake and put the transmission in “P”.
4. Have everyone get out of the vehicle on the side away from
traffic.
5. Read the following instructions thoroughly.
CAUTION
When jacking, be sure to observe the following to
reduce the possibility of personal injury:
 Turn off the active height control suspension by
pushing the active height control switch.
 Follow jacking instructions.
 Do not put any part of your body under a vehicle
supported by a jack. Personal injury may occur.
 Do not start or run the engine while your vehicle is
supported by the jack.
 Stop the vehicle on a level firm ground, firmly set the
parking brake and put the transmission in “P”. Block
the wheel diagonally opposite to the one being
changed if necessary.

MAINTENANCE
398Parking brake
Check that the lever has the proper travel and that, on a safe
incline,
your vehicle is held securely with only the parking brake
applied.
Automatic transmission “Park” mechanism
Check the lock release button of the selector lever for proper
and smooth operation. On a safe incline, check that your
vehicle is held securely with the selector lever in “P” position
and all brakes released.
Engine compartment
Items listed below should be checked from time to time,
e.g. each time when refueling.
Washer fluid
Make sure there is sufficient fluid in the tank. See page 454 for
additional information.
Engine coolant level
Make sure the coolant level is between the “F” and “L” lines on
the see− through reservoir when the engine is cold. See page
422 for additional information.
Radiator, condenser and hoses
Check that the front of the radiator and condenser are clean
and not blocked with leaves, dirt, or insects. See page 423 for
additional information.
Battery
Check the battery condition by the indicator color. See page
447 for additional information.

INTRODUCTION
407
NOTICE
Remember that battery and ignition cables carry high
currents or voltages. Be careful of accidentally
causing a short circuit.
 Before closing the engine hood, check to see that you
have not forgotten any tools, rags, etc.
 Do not drive with the air cleaner removed, or
excessive engine wear could result. Also backfiring
could cause a fire in the engine compartment.
 Do not overfill automatic transmission fluid and
power steering fluid, or the transmission and power
steering could be damaged.
 Be careful not to scratch the glass surface with the
wiper frame.
PARTS AND TOOLS
Here is a list of parts and tools you will need to perform
do−it−yourself maintenance. Remember all Lexus parts are
designed in metric sizes, so your tools must be metric.
Checking the engine oil level
Parts (if level is low):
“Toyota Genuine Motor Oil” or equivalent
See page 420 for details about engine oil selection.
Tools:
 Rag or paper towel
 Funnel (only for adding oil)
Checking the engine coolant level
Parts (if level is low):
“Toyota Genuine Long Life Coolant” or equivalent
See “Checking the engine coolant level” on page 422 for
instructions.
 Demineralized or distilled water
Tools:
 Funnel (only for adding coolant)

INTRODUCTION
408
Checking brake fluid
Parts (if level is low):
FMVSS No. 116 DOT 3 or SAE J1703 brake fluid
Tools:
 Rag or paper towel
 Funnel (only for adding fluid)
Checking power steering fluid
Parts (if level is low):
Automatic transmission fluid DEXRON
II or III
Tools:
 Rag or paper towel
 Funnel (only for adding fluid)
Checking battery condition
Tools:
Warm water
 Baking soda
 Grease
 Conventional wrench (for terminal clamp bolts)
Checking and replacing the blade type fuses
Parts (if replacement is necessary):
Fuse with same amperage rating as original
Checking the cartridge type fuses
Parts (if replacement is necessary):
Genuine Lexus fuse or equivalent with same amperage
rating as original
Adding washer fluid
Parts:
Water
 Washer fluid containing antifreeze (for winter use)
Tools:
 Funnel

CHASSIS
429
CHASSIS LUBRICATION
Propeller shafts Spiders and slide yoke
Lithium base wheel bearing grease, NLGI No.2
STEERING
Free play
Less than 30 mm (1.2 in.)
Power steering fluidAutomatic transmission fluid DEXRONII or III
TIRES AND WHEELS
Tire size
P265/65R17 110S
Tire inflation pressure Recommended cold tire inflation pressure220 kPa (2.2 kgf/cm2 or bar, 32 psi)
Wheel size17 x 7 1/2 JJ
Wheel nut torque112 N·m (11.5 kgf·m, 83 ft·lbf)
NOTE:
For complete information on tires (e.g. replacing tires or replacing wheel\
s), see “Checking tire pressure” through “Aluminum wh eel
precautions” on pages 432 through 440.

CHASSIS
431
CHECKING POWER STEERINGFLUID
The power steering fluid reservoir is located under the
right side engine compartment cover. Before checking
the power steering fluid, remove the cover. (For details,
see “Removing the engine compart covers” on page 405.)
Check the fluid level, simply look at the seethrough
reservoir. If necessary, add automatic transmission fluid
DEXRON
II or III .
If the vehicle has been driven around 80 km/h (50 mph) for 20
minutes (a little more in frigid temperatures), the fluid is hot
(60 C − 80C or 140F − 175F). You may also check the level
when the fluid is cold (about room temperature, 10 C − 30C
or 50F − 85F) if the engine has not been run for about five
hours.
 1 If cold O.K.2 If cold add3 If hot O.K.
4 If hot add
Clean all dirt off the reservoir and look at the fluid level. If the
fluid is cold, the level should be in the “COLD” range. Similarly,
if it is hot, the fluid level should be in the “HOT” range. If th\
e
level is at the low side of the appropriate range, add automatic
transmission fluid DEXRON
II or III to bring the level within
the range.
To remove the reservoir cap, turn it counterclockwise and lift
up. To reinstall it, turn it clockwise. After replacing the reservoir
cap, visually check the steering box case, vane pump and hose
connections for leaks or damage.

GAS STATION INFORMATION
Fuel selection:
Select Octane Rating 87 (Research Octane Number 91) or
higher. For improved vehicle performance, the use of
premium unleaded gasoline with an Octane Rating of 91
(Research Octane Number 96) or higher is recommended.
 Fuel tank capacity:
87 L (2 3 gal., 19.1 lmp.gal.)
 Engine oil:
“Toyota Genuine Motor Oil” or equivalent
Oil grade: API grade SL “Energy −Conserving” or ILSAC
multigrade engine oil.
Recommended oil viscosity: SAE 5W −30
Oil capacity:
Drain and refill with filter 6.2 L (6.5 qt., 5.5 lmp.qt .)
without filter 5.7 L (6.0 qt., 5.0 lmp.qt .)
See page 419 for detailed information.
Engine coolant:
Capacity: 12.9 L (13.6 qt., 11.4 lmp.qt .)
Coolant type − ”Toyota Genuine Long Life Coolant” or
equivalent
With ethylene −glycol type coolant for a proper corrosion
protection of aluminum components
Do not use alcohol type antifreeze or plain water alone.
For checking the engine coolant, see page 422.
 Automatic transmission:
Fluid type − “Toyota Genuine ATF Type T −IV”
See page 428 for detailed information.
 Tire information:
See pages 432 through 440 for detailed information.
 Tire pressure:
Tire size: P265/65R17 110S
Tire pressure: 220kPa (2.2 kgf/cm
2 or bar, 32 psi)
