Lexus GX470 2003 Audio / LEXUS 2003 GX470 OWNER'S MANUAL (OM60A45U)

FOREWORD
i
Congratulations on your selection of this Lexus. In Lexus vehicles we h\
ave invested all our engineering and design resources; all
the know−
how we have gained in over 60 years of making automobiles; the highest m\
otivation of our most talented employees; and
our tradition of incessant striving toward ever greater quality.
This Owner’s Manual explains the features of your new Lexus. Please read it and fol\
low the instructions carefully so that you can
enjoy many years of safe motoring.
When it comes to service, remember that your Lexus dealer knows your vehicle bes\
t and is interested in your complete satisfaction.
Your Lexus dealer will provide quality maintenance and any other assistan\
ce you may require.
If there is not a Lexus dealer near you, or you need emergency assistanc\
e for any reason, please call the following number:
U.S. OWNERS
 When traveling in the U.S. mainland or Canada:
Lexus Roadside Assistance 180025LEXUS (TollFree)
(18002553987)
 HAWAII:
Lexus Customer Service Assistance 180025LEXUS (TollFree)
(18002553987)
Please leave this Owner’s Manual in this vehicle at the time of resale. The next owner will nee\
d this information also.
All information and specifications in this manual are current at the time o\
f printing. However, because of the Lexus policy
of continual product improvement, we reserve the right to make changes a\
t any time without notice.
Please note that this manual applies to all models and explains all equipment, \
including options. Therefore, you may find
some explanations for equipment not installed on your vehicle.

INTRODUCTION
ii
New vehicle warranty
Your new vehicle is covered by the following Lexus limited
warranties:
New vehicle warranty
 Emission control systems warranty
 Others
For further information, please refer to the “Owner’s Guide”,
“Owner’s Manual Supplement” or “Warranty Booklet”.
Your responsibility for maintenance
It is the owner’s responsibility to make sure the specified
maintenance is performed. Section 5 of this Owner’s Manual
gives details of these maintenance requirements. Included in
Section 6 is general maintenance. For scheduled
maintenance information, please refer to the “Owner’s Manual
Supplement / Scheduled Maintenance”.
Accessories, spare parts and modification of
your Lexus
A wide variety of non −genuine spare parts and accessories for
Lexus vehicles are currently available in the market. You
should know that Toyota does not warrant these products and
is not responsible for their performance, repair, or
replacement, or for any damage they may cause to, or adverse
effect they may have on, your Lexus vehicle. This vehicle should not be modified with non
−genuine Lexus
products. Modification with non −genuine Lexus products
could af fect its performance, safety or durability, and may even
violate governmental regulations. In addition, damage or
performance problems resulting from the modification may not
be covered under warranty.
If you install any Genuine Accessories such as a bull −bar,
winch, etc., consult your Lexus dealer.
Installation of a mobile twoway radio system
As the installation of a mobile two −way radio system in your
vehicle could affect electronic systems such as the multiport
fuel injection system/sequential multiport fuel injection system,
cruise control system, anti −lock brake system, SRS airbag
system and seat belt pretensioner system, be sure to check
with your Lexus dealer for precautionary measures or special
instructions regarding installation.
Scrapping of your Lexus
The SRS airbag and seat belt pretensioner devices in your
Lexus contain explosive chemicals. If the vehicle is scrapped
with the airbags and seat belt pretensioners left as they are,
this may cause an accident such as a fire. Be sure to have the
systems of the SRS airbag and seat belt pretensioner removed
and disposed of by a qualified service shop or by your Lexus
dealer before you scrap your vehicle.

INTRODUCTION
iii
Onpavement and offroad driving tips
This vehicle belongs to the utility vehicle class. Utility vehicles
have a significantly higher rollover rate than other types of
vehicles. This vehicle will handle and maneuver differently
from an ordinary passenger car because it is designed for
off−road use also. In addition, this vehicle has a higher ground
clearance and center of gravity than that of an ordinary
passenger car. This vehicle design feature causes this type of
vehicle to be more likely to rollover. Failure to operate this
vehicle correctly may result in loss of control, accidents or
vehicle rollover causing death or serious injury. Be sure to read
“Off −road vehicle precautions” on page 339 and “Off −road
driving precautions” on page 342.

HOW TO USE THIS MANUAL
iv
HOW TO USE THIS MANUAL
The contents of this manual are explained briefly on this
page to help you make the best use of the manual. Please
read this page and the rest of the Owner’s Manual
carefully to make sure you fully understand the operation
of your vehicle.
This will help you enjoy safe and comfortable driving.
TABLE OF CONTENTS
The table of contents and the pictorial index provide easy
reference to the appropriate pages.
BASIC OPERATION QUICK REFERENCE
Operation of basic equipment is briefly explained in an easily
understandable way for quick reference.
SECTION 1 INSTRUMENTS AND CONTROLS
The vehicle’s equipment is divided into the 7 groups listed
below. Use of the equipment is explained, including any points
you should pay particular attention to.
1. Keys and doors
2. Switches
3. Gauges, meters and service reminder indicators
4. Interior equipment
5. Exterior equipment
6. Comfort adjustment
7. Theft deterrent
SECTION 2 AIR CONDITIONING AND AUDIO
The features of the vehicle’s air conditioning and audio are
explained in detail. Be sure to read this section so that you can
make full use of them.
SECTION 3 STARTING AND DRIVING
Starting the engine, driving, stopping, operation of features
affecting vehicle handling, hints on vehicle safety and safe
driving techniques are all explained. Please read everything
in this section, and remember − drive safely!
SECTION 4 IN CASE OF AN EMERGENCY
This section explains what to do in the event of an urgent
situation such as the engine not starting or getting a flat tire,
etc. If such a problem occu rs, check the contents of this
Owner’s Manual and follow the instructions given.
SECTION 5 MAINTENANCE
This section explains the importance of regular maintenance.
Regular and periodic inspection and maintenance of your
Lexus will help to keep your vehicle in its best condition.
SECTION 6 SERVICE PROCEDURES AND
SPECIFICATIONS
Simple maintenance procedure and service data are provided
here for your reference should you wish to perform inspection
and maintenance yourself.
INDEX
The page number is listed for each item in the Owner ’s Manual
so that you can rapidly find the item and page you are
searching for.

HOW TO USE THIS MANUAL
v
GAS STATION INFORMATION
The information you need to know for appropriate servicing at
the gas station is provided here.
QUICK INDEX
This is designed so that you can quickly find the needed
information when an urgent situation arises.
Safety symbol
In this manual, you will also see a circle with a slash through
it. This means “Do not”, “Do not do this”, or “Do not le\
t this
happen”.
Safety and vehicle damage warnings
In this manual you will see CAUTION and NOTICE warnings.
These are used in the following ways:
CAUTION
This is a warning against anything which may cause
injury to people if the warning is ignored. You are
informed about what you must or must not do in order
to reduce the risk of injury to yourself and others.
NOTICE
This is a warning against anything which may cause
damage to the vehicle or its equipment if the warning is
ignored. You are informed about what you must or must
not do in order to avoid or reduce the risk of damage to
your Lexus and its equipment.
Your Lexus Owner’s Manual provides you with a
considerable amount of information. To use this
information most effectively, please take the time to
familiarize yourself with the contents and use of the
manual.

HOW TO USE THIS MANUAL
vi

PICTORIAL INDEX
vii
INSTRUMENT PANEL

For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
viiiPage
1Driving position memory switches
171
. . . . . . . . . . .
2Power window switches 33
. . . . . . . . . . . . . . . . . . . . . . .
3Power door lock switch 20
. . . . . . . . . . . . . . . . . . . . . . .
4Window lock switch 34
. . . . . . . . . . . . . . . . . . . . . . . . . . .
5Power rear view mirror control switches 116 . . . . . . .
6Side vents 189
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7Headlight, turn signal and fog light switches 24 . . . .
8Wiper and washer switch 27
. . . . . . . . . . . . . . . . . . . . . .
9Center vents 189
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10Emergency flasher switch 36
. . . . . . . . . . . . . . . . . . . . .
11Car audio 195
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12Multiinformation display 53
. . . . . . . . . . . . . . . . . . . . . .
13Automatic air conditioning controls 179
. . . . . . . . . .
14Rear window defogger switch 31
. . . . . . . . . . . . . . . . . .
15Front passenger’s seat belt reminder light 46 . . . . . .
16Glove box 70
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17Ashtray 66
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
18Cigarette lighter 66
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19Seat heater switches 37
. . . . . . . . . . . . . . . . . . . . . . . . . . Page
20Fourwheel drive control lever
309
. . . . . . . . . . . . . . .
21Automatic transmission selector lever 303 . . . . . . . .
22Parking brake lever 301
. . . . . . . . . . . . . . . . . . . . . . . . .
23Center differential lock switch 309
. . . . . . . . . . . . . . .
24Power outlet (12 VDC) 68
. . . . . . . . . . . . . . . . . . . . . . . . .
25Downhill assist control switch 326
. . . . . . . . . . . . . . .
26Electronic modulated suspension
control switch 320 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27Rear height control air suspension
switches 315. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Ignition switch 300
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29“2nd STRT” switch 309
. . . . . . . . . . . . . . . . . . . . . . . . . .
30Cruise control switch 312
. . . . . . . . . . . . . . . . . . . . . . .
31Steering pad switches 214
. . . . . . . . . . . . . . . . . . . . . . .
32Hood lock release lever 83
. . . . . . . . . . . . . . . . . . . . . . .
33Fuel filler door opener 84
. . . . . . . . . . . . . . . . . . . . . . . . .
34Instrument panel light control dial 60
. . . . . . . . . . . . . .
35Outside rear view mirror defogger switch 32 . . . . . . .
36Power outlet (115 VAC) main switch 68
. . . . . . . . . . . .

PICTORIAL INDEX
ix
INSTRUMENT CLUSTER

For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
xPage
1Automatic transmission second start
indicator light 309
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Unengaged “Park” warning light 49
. . . . . . . . . . . . . . .
3Automatic transmission fluid temperature
warning light 49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4Low washer fluid warning light 51
. . . . . . . . . . . . . . . . .
5Automatic transmission indicator lights 303 . . . . . .
6Driver’s seat belt reminder light 45
. . . . . . . . . . . . . . . .
7Turn signal indicator light 25
. . . . . . . . . . . . . . . . . . . . .
8Brake system warning light 44
. . . . . . . . . . . . . . . . . . . .
9Headlight high beam indicator light 25
. . . . . . . . . . . .
10“ABS” warning light 48
. . . . . . . . . . . . . . . . . . . . . . . . . .
11Open door warning light 49
. . . . . . . . . . . . . . . . . . . . . . .
12Tachometer 42
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Headlight indicator light 24
. . . . . . . . . . . . . . . . . . . . . . .
14Cruise control indicator light 312
. . . . . . . . . . . . . . . .
15Engine oil replacement reminder light 51
. . . . . . . . . .
16Engine coolant temperature gauge 41
. . . . . . . . . . . . . Page
17Discharge warning light
50
. . . . . . . . . . . . . . . . . . . . . . .
18Low engine oil pressure warning light 50
. . . . . . . . . .
19Malfunction indicator lamp 47
. . . . . . . . . . . . . . . . . . . .
20Slip indicator light 322, 324, 327, 329
. . . . . . . . . . . . .
21Vehicle skid control system off
indicator light 324 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22Center differential lock indicator light 309
. . . . . . . .
23“VSC TRAC” warning light 50
. . . . . . . . . . . . . . . . . . . . .
24Downhill assist control system
indicator light 326 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
25Rear height control indicator lights 319
. . . . . . . . . . .
26Security indicator light 12, 175
. . . . . . . . . . . . . . . . . . .
27SRS warning light 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Trip meter reset knob 42
. . . . . . . . . . . . . . . . . . . . . . . . .
29Odometer and trip meter 42
. . . . . . . . . . . . . . . . . . . . . .
30Low fuel level warning light 51
. . . . . . . . . . . . . . . . . . . .
31Fuel gauge 40
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
