INTRODUCTION
ii
New vehicle warranty
Your new vehicle is covered by the following Lexus limited
warranties:
New vehicle warranty
 Emission control systems warranty
 Others
For further information, please refer to the “Owner’s Guide”,
“Owner’s Manual Supplement” or “Warranty Booklet”.
Your responsibility for maintenance
It is the owner’s responsibility to make sure the specified
maintenance is performed. Section 5 of this Owner’s Manual
gives details of these maintenance requirements. Included in
Section 6 is general maintenance. For scheduled
maintenance information, please refer to the “Owner’s Manual
Supplement / Scheduled Maintenance”.
Accessories, spare parts and modification of
your Lexus
A wide variety of non −genuine spare parts and accessories for
Lexus vehicles are currently available in the market. You
should know that Toyota does not warrant these products and
is not responsible for their performance, repair, or
replacement, or for any damage they may cause to, or adverse
effect they may have on, your Lexus vehicle. This vehicle should not be modified with non
−genuine Lexus
products. Modification with non −genuine Lexus products
could af fect its performance, safety or durability, and may even
violate governmental regulations. In addition, damage or
performance problems resulting from the modification may not
be covered under warranty.
If you install any Genuine Accessories such as a bull −bar,
winch, etc., consult your Lexus dealer.
Installation of a mobile twoway radio system
As the installation of a mobile two −way radio system in your
vehicle could affect electronic systems such as the multiport
fuel injection system/sequential multiport fuel injection system,
cruise control system, anti −lock brake system, SRS airbag
system and seat belt pretensioner system, be sure to check
with your Lexus dealer for precautionary measures or special
instructions regarding installation.
Scrapping of your Lexus
The SRS airbag and seat belt pretensioner devices in your
Lexus contain explosive chemicals. If the vehicle is scrapped
with the airbags and seat belt pretensioners left as they are,
this may cause an accident such as a fire. Be sure to have the
systems of the SRS airbag and seat belt pretensioner removed
and disposed of by a qualified service shop or by your Lexus
dealer before you scrap your vehicle.

AIR CONDITIONING
190
(e) Checking and replacing the airconditioning filter
The air conditioning filter is behind the glove box.
The air conditioning filter may clog after long use. The filter
may need to be replaced if the air flow of the air conditioner and
heater experiences extreme reductions in operating ef ficiency,
or if the windows begin to fog up easily.
To maintain the air conditioning efficiency, inspect and replace
the air conditioning filter according to the maintenance
schedule. (For scheduled maintenance information, please
refer to the “Owner’s Manual Supplement / Scheduled
Maintenance”.)
1. Open the glove box and unhook the cip as shown
above.
2. Push each side of the glove box to disconnect the
claws.

STARTING AND DRIVING
298
To ensure that the threeway catalytic converter and
the entire emission control system operate properly,
your vehicle must receive the periodic inspections
required by the Lexus Maintenance Schedule. For
scheduled maintenance information, refer to the
“Owner’s Manual Supplement / Scheduled
Maintenance”.
ENGINE EXHAUST CAUTION
CAUTION
Avoid inhaling the engine exhaust. It contains
carbon monoxide, which is a colorless and odorless
gas. It can cause unconsciousness or even death.
 Make sure the exhaust system has no holes or loose
connections. The system should be checked from
time to time. If you hit something, or notice a change
in the sound of the exhaust, have the system checked
immediately.
 Do not run the engine in a garage or enclosed area
except for the time needed to drive the vehicle in or
out. The exhaust gases cannot escape, making this
a particularly dangerous situation.
 Do not remain for a long time in a parked vehicle with
the engine running. If it is unavoidable, however, do
so only in an unconfined area and adjust the heating
or cooling system to force outside air into the vehicle.
 Keep the back door closed while driving. An open or
unsealed back door may cause exhaust gases to be
drawn into the vehicle.

DRIVING TIPS
344
Always perform a maintenance inspection after each
day of offroad driving that has taken you through
rough terrain, sand, mud, or water. For scheduled
maintenance information, refer to the “Owner’s
Manual Supplement / Scheduled Maintenance”.
WINTER DRIVING TIPS
Make sure your coolant is properly protected against
freezing.
Your coolant must contain ethylene −glycol type coolant for a
proper corrosion protection of aluminum components. Use
“Toyota Genuine Long Life Coolant” or equivalent. See
“Checking the engine coolant level” on page 422 for
instructions.
NOTICE
Do not use alcohol type antifreeze or plain water alone.
When it is extremely cold, we recommend to use 60% solution
for your Lexus, to provide protection down to about −50C
(−58 F). Do not use more than 70% solution for better coolant
performance.
Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so it
must be in top shape to provide enough power for winter
starting. Page 447 tells you how to visually inspect the battery.
Your Lexus dealer and most service stations will be pleased to
check the battery charge level.
Make sure the engine oil viscosity is suitable for the cold
weather.
See page 420 for recommended viscosity. Leaving a heavy
summer oil in your vehicle during winter months may cause
harder starting. If you are not sure about which oil to use, call
your Lexus dealer − they will be pleased to help.

DRIVING TIPS
353
Trailer lights
 Socket for trailer lights
Your vehicle is equipped with a wire harness stored in the rear
end underbody. Models with weight carrying hitch receiver are
fitted with a socket for trailer lights under the rear bumper. Use
either of them to connect and operate the trailer lights.
However, the trailer lights must comply with federal,
state/provincial and local regulations. See your local
recreational vehicle dealer or rental agency for the correct type
of wiring and relays for your trailer. Check for correct operation
of the turn signals and stop lights each time you hitch up. Direct
splicing may damage your vehicle’s electrical system and
cause a malfunction of your lights.
Breakin schedule
Lexus recommends that you do not tow a trailer with a new
vehicle or a vehicle with any new power train component
(engine, transmission, differential, wheel bearing, etc.) for the
first 800 km (500 miles) of driving.
Maintenance
 If you tow a trailer, your vehicle will require more frequent
maintenance due to the additional load. For this
information, please refer to the scheduled maintenance
information in the “Owner’s Manual Supplement /
Scheduled Maintenance”.
 Retighten all fixing bolts of the towing ball and bracket after
approximately 1000 km (600 miles) of trailer driving.
Connecting a trailer
Stop your vehicle and a trailer in line and perform the following:
1. Put the rear height control air suspension in the “LO” (low)
mode. Turn the ignition switch off or push the “HEIGHT
CONTROL OFF” switch to turn off the rear height control air
suspension.
2. Connect a trailer.
3. Turn the ignition switch on or push the “HEIGHT CONTROL
OFF” switch to turn on the rear height control air suspension.
Select the “N” (normal) mode with the height select switch.
Disconnecting a trailer
Stop your vehicle and a trailer in line and perform the following:
1. Put the rear height control air suspension in the “LO” (low)
mode. (Make sure the vehicle height is in the “LO” (low) mode
by pushing the height select switch on the “
” side.)
2. Turn the ignition switch off or push the “HEIGHT CONTROL
OFF” switch to turn off the rear height control air suspension.

DRIVING TIPS
357

Avoid continuous speeding up and slowing down.
Stop−and−go driving wastes fuel.
 Avoid unnecessary stopping and braking. Maintain a
steady pace. Try to time the traf fic signals so you only need
to stop as little as possible or take advantage of through
streets to avoid traffic lights. Keep a proper distance from
other vehicles to avoid sudden braking. This will also
reduce wear on your brakes.
 Avoid heavy traffic or traffic jams whenever possible.
 Do not rest your foot on the brake pedal. This causes
premature wear, overheating and poor fuel economy.
 Maintain a moderate speed on highways. The faster you
drive, the greater the fuel consumption. By reducing your
speed, you will cut down on fuel consumption.
 Keep the front wheels in proper alignment. Avoid hitting
the curb and slow down on rough roads. Improper
alignment not only causes faster tire wear but also puts an
extra load on the engine, which, in turn, wastes fuel.
 Keep the bottom of your vehicle free from mud, etc. This
not only lessens weight but also helps prevent corrosion.
Keep your vehicle tunedup and in top shape. A dirty air
cleaner, improper valve clearance, dirty plugs, dirty oil and
grease, brakes not adjusted, etc. all lower engine
performance and contribute to poor fuel economy. For
longer life of all parts and lower operating costs, keep all
maintenance work on schedule, and if you often drive under
severe conditions, see that your vehicle receives more
frequent maintenance. (For scheduled maintenance
information, please refer to the “Owner’s Manual
Supplement / Scheduled Maintenance”.)
CAUTION
Never turn off the engine to coast down hills. Your
power steering and brake booster will not function
without the engine running. Also, the emission control
system operates properly only when the engine is
running.

SECTION 5
394
MAINTENANCE
Maintenance
Maintenance requirements395
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General maintenance 396
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Does your vehicle need repairing? 399
. . . . . . . . . . . . . . . . . . . . . . . . .
Emissions inspection and maintenance (I/M) programs 400
. . . . . . . .
For scheduled maintenance information, please
refer to the “Owner’s Manual Supplement /
Scheduled Maintenance”.

MAINTENANCE
395
MAINTENANCE REQUIREMENTS
Your Lexus vehicle has been designed to have fewer
maintenance requirements with longer service intervals to
save both your time and money. However, each regular
maintenance as well as day−to−day care is more important
than ever before to ensure smooth, trouble −free, safe, and
economical driving.
It is the owner’s responsibility to make sure the specified
maintenance, including general maintenance services, is
performed. Note that both the new vehicle and emission
control system warranties specify that proper maintenance
and care must be performed. See the “Owner’s Guide”,
“Owner’s Manual Supplement” or “Warranty Booklet” for
complete warranty information.
General maintenance
General maintenance items are those day −to−day care
practices that are important to your vehicle for proper
operation. It is the owner’s responsibility to ensure that the
general maintenance items are performed regularly.
These checks or inspections can be done either by yourself or
your Lexus dealer.
Scheduled maintenance
The scheduled maintenance items listed in the “Owner’s
Manual Supplement / Scheduled Maintenance” are those
required to be serviced at regular intervals. For details of your maintenance schedule, read the “Owner’s
Manual Supplement / Scheduled Maintenance”.
It is recommended that only genuine Lexus parts be used
for maintenance or for the repair of the emission control
system.
The owner may elect to use nonLexus supplied parts for
replacement purposes without invalidating the emission
control system warranty. However, use of replacement
parts which are not of equivalent quality may impair the
effectiveness of the emission control systems.
You may also elect to have maintenance, replacement, or
repair of the emission control devices and system
performed by any automotive repair establishment or
individual without invalidating this warranty. See
“Owner’s Guide”, “Owner’s Manual Supplement” or
“Warranty Booklet” for complete warranty information.
Where to go for service?
Lexus
technicians are well −trained specialists and are kept up
to date with the latest service information through technical
bulletins, service tips, and in −dealership training programs.
They are well informed about the operation of all the systems
on your vehicle.
You can be confident that your Lexus dealer’s service
department performs the best job to meet the maintenance
requirements of your vehicle − reliably and economically.

MAINTENANCE
397
Tire rotation
Rotate the
tires according to the maintenance schedule. (For
scheduled maintenance information, please refer to the
“Owner’s Manual Supplement / Scheduled Maintenance”.)
See page 434 for additional information.
Fluid leaks
Check underneath for leaking fuel, oil, water or other fluid after
the vehicle has been parked for a while. If you smell fuel fumes
or notice any leak, have the cause found and corrected
immediately.
Doors and engine hood
Check that all side doors and back door, operate smoothly and
all latches lock securely. Make sure the engine hood
secondary latch secures the hood when the primary latch is
released.
Vehicle interior
Items listed below should be checked regularly, e.g. while
performing periodic services, cleaning the vehicle, etc.
Lights
Make sure the headlights, stop lights, tail lights, turn signal
lights, and other lights are working. Check headlight aim.
Service reminder indicators and warning buzzers
Check that all service reminder indicators and warning buzzers
function properly. Steering wheel
Check that it has the
specified free play. Be alert for changes
in steering condition, such as hard steering, excessive free
play or strange noise.
Seats
Check that all front seat controls such as seat adjusters,
seatback recliner, etc. operate smoothly. Check that the head
restraints move up and down smoothly and that the locks hold
securely in any latched position. For folding −up second and
third seats, and detachable third seat, check that the latches
lock securely.
Seat belts
Check that the seat belt system such as buckles, retractors
and anchors operate properly and smoothly. Make sure the
belt webbing is not cut, frayed, worn or damaged.
Accelerator pedal
Check the pedal for smooth operation and uneven pedal ef fort
or catching.
Brake pedal
Check the pedal for smooth operation and the proper
clearance and free play. Check the brake booster function.
Brakes
At a safe place, check that the brakes do not pull to one side
when applied.

CHASSIS
428 AUTOMATIC TRANSMISSION
Fluid capacity Drain and refill
Up to 3.0 L (3.2 qt., 2.6 lmp.qt.)
Fluid typeToyota Genuine ATF Type TIV*
*Change automatic transmission fluid only as necessary.
Generally, it is necessary to change automatic transmission
fluid only if your vehicle is driven under one of the Special
Operating Conditions listed in your “Owner’s Manual
Supplement / Scheduled Maintenance”. When changing the
automatic transmission fluid, use only “Toyota Genuine ATF
Type T−IV” (ATF JWS3309 or NWS6500) to aid in assuring
optimum transmission performance.NOTICE
Using automatic transmission fluid other than “Toyota
Genuine ATF Type TIV” may cause deterioration in
shift quality, locking up of your transmission
accompanied by vibration, and ultimately damage the
automatic transmission of your vehicle.
Please contact your Lexus dealer for further details.
BRAKES
Pedal clearance
55 mm (2.2 in.) Min. *1
Pedal free play1 − 6 mm (0.04 − 0.24 in.)
Brake pad wear limit1.0 mm (0.04 in.)
Parking brake lining wear limit1.0 mm (0.04 in.)
Parking brake adjustment5 − 7 clicks *2
Fluid typeSAE J1703 or FMVSS No. 116 DOT 3
*1: Minimum pedal clearance when depressed with the force of 490 N (50 kgf,\
110 lbf) with the engine running
*
2: Parking brake adjustment when pulled with the force of 196 N (20 kgf, 4\
4 lbf)
