coolant temperature Lexus GX470 2003 Basic Functions / LEXUS 2003 GX470 OWNER'S MANUAL (OM60979U)

For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
xPage
1Automatic transmission second start
indicator light 309
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Unengaged “Park” warning light 49
. . . . . . . . . . . . . . .
3Automatic transmission fluid temperature
warning light 49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4Low washer fluid warning light 51
. . . . . . . . . . . . . . . . .
5Automatic transmission indicator lights 303 . . . . . .
6Driver’s seat belt reminder light 45
. . . . . . . . . . . . . . . .
7Turn signal indicator light 25
. . . . . . . . . . . . . . . . . . . . .
8Brake system warning light 44
. . . . . . . . . . . . . . . . . . . .
9Headlight high beam indicator light 25
. . . . . . . . . . . .
10“ABS” warning light 48
. . . . . . . . . . . . . . . . . . . . . . . . . .
11Open door warning light 49
. . . . . . . . . . . . . . . . . . . . . . .
12Tachometer 42
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Headlight indicator light 24
. . . . . . . . . . . . . . . . . . . . . . .
14Cruise control indicator light 312
. . . . . . . . . . . . . . . .
15Engine oil replacement reminder light 51
. . . . . . . . . .
16Engine coolant temperature gauge 41
. . . . . . . . . . . . . Page
17Discharge warning light
50
. . . . . . . . . . . . . . . . . . . . . . .
18Low engine oil pressure warning light 50
. . . . . . . . . .
19Malfunction indicator lamp 47
. . . . . . . . . . . . . . . . . . . .
20Slip indicator light 322, 324, 327, 329
. . . . . . . . . . . . .
21Vehicle skid control system off
indicator light 324 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22Center differential lock indicator light 309
. . . . . . . .
23“VSC TRAC” warning light 50
. . . . . . . . . . . . . . . . . . . . .
24Downhill assist control system
indicator light 326 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
25Rear height control indicator lights 319
. . . . . . . . . . .
26Security indicator light 12, 175
. . . . . . . . . . . . . . . . . . .
27SRS warning light 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Trip meter reset knob 42
. . . . . . . . . . . . . . . . . . . . . . . . .
29Odometer and trip meter 42
. . . . . . . . . . . . . . . . . . . . . .
30Low fuel level warning light 51
. . . . . . . . . . . . . . . . . . . .
31Fuel gauge 40
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Finish
SECTION 1 – 3
39
INSTRUMENTS AND CONTROLS
Gauges, meters and service reminder indicators
Fuel gauge40
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . .
Engine coolant temperature gauge 41
. . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 42
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Odometer and trip meter 42
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service reminder indicators and warning buzzers 43
. . . . . . . . . . . . . .
Multi−information display 53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument panel light control 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
41
ENGINE COOLANT
TEMPERATURE GAUGE
 Normal range
The gauge indicates the engine coolant temperature when
the ignition switch is on. The engine operating
temperature will vary with changes in weather and engine
load.
If the needle points to the red zone or higher, stop your vehicle
and allow the engine to cool.
Your vehicle may overheat during severe operating conditions,
such as:
 Driving up a long hill on a hot day.
 Reducing speed or stopping after high speed driving.
 Idling for a long period with the air conditioning on in
stop−and−go traffic.
 Towing a trailer. It is not a malfunction even if the needle of the engine coolant
temperature gauge returns to “C” when the ignition switch is
turned to the “START”.
NOTICE

Do not remove the thermostat in the engine cooling
system as this may cause the engine to overheat. The
thermostat is designed to control the flow of coolant
to keep the temperature of the engine within the
specified operating range.
 Do not continue driving with an overheated engine.
See “If your vehicle overheats” on page 364.

STARTING AND DRIVING
300
IGNITION SWITCH WITH STEERINGLOCK
“START” Starter motor on. The key will return to the
“ON” position when released.
For starting tips, see page 302.
It is not a malfunction even if the needle of the tachometer, fuel
gauge or engine coolant temperature gauge returns to the
bottom position when the ignition switch is turned to the
“START” position.
“ON” Engine on and all accessories on.
This is the normal driving position.
It is not malfunction even if the needle on the speedometer may
move when the ignition switch is turned to the “ON” position.
NOTICE
Do not leave the key in the “ON” position if the engine
is not running. The battery will discharge and the
electronic ignition system could be damaged.
“ACC” Accessories such as the radio operate, but the
engine is off.
If you leave the key in the “ACC” or “LOCK” position and open
the driver’s door, a buzzer will remind you to remove the key.

STARTING AND DRIVING
305
 1 Brake pedal 2 “D” (Drive) position
2. With your foot holding down the brake pedal, shift the
selector lever to “D”.
Always use the “D” position to improve fuel economy and quiet
driving. Only in this position, shifting into the overdrive gear is
possible. However, while the engine coolant temperature is
low, the transmission will not shift into the overdrive gear even
in the “D” position. (See “(b) Using engine braking” and\
“(f)
Good driving practice” for exceptions.)
CAUTION
Never put your foot on the accelerator pedal while
shifting.
3. Release the parking brake and brake pedal. Depress
the accelerator pedal slowly for smooth starting.
In normal cruising, the vehicle will start in first gear and
automatically shift up to the most suitable gear. On inclines,
declines or winding roads, etc., the vehicle shifts up and down
automatically according to the running conditions to obtain the
suitable driving power and engine braking.
When the lever is in the “4” position, the automatic
transmission system will select the most suitable gear for the
running conditions such as hill climbing, hard towing, etc.
If you need to accelerate rapidly while driving, depress the
accelerator pedal to the full throttle position. This provides
more acceleration by automatically downshifting the
transmission to the next lower gear or beyond, depending on
the vehicle speed.
If engine braking is needed, such as in descending a long hill,
see “(b) Using engine braking”.

DRIVING TIPS
345
WINTER DRIVING TIPS
Make sure you have a proper freeze protection of engine
coolant.
Your coolant must contain ethylene−glycol type coolant for a
proper corrosion protection of aluminum components. Use
“Toyota Genuine Long Life Coolant” or equivalent. See
“Checking the engine coolant level” on page 422 for
instructions.
NOTICE
Do not use alcohol type antifreeze or plain water alone.
When it is extremely cold, we recommend to use 60% solution
for your Lexus, to provide protection down to about −50C
(−58 F). Do not use more than 70% solution for better coolant
performance.
Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so it
must be in top shape to provide enough power for winter
starting. Page 447 tells you how to visually inspect the battery.
Your Lexus dealer and most service stations will be pleased to
check the battery charge level.
Make sure the engine oil viscosity is suitable for the cold
weather.
See page 420 for recommended viscosity. Leaving a heavy
summer oil in your vehicle during winter months may cause
harder starting. If you are not sure about which oil to use, call
your Lexus dealer − they will be pleased to help. Check the electronic ignition system for loose
connections or obvious damage.
Keep the door locks from freezing.
Squirt
lock de− icer or glycerine into the locks to keep them from
freezing.
Use a washer fluid containing an antifreeze solution.
This product is available at your Lexus dealer and most auto
parts stores. Follow the manufacturer’s directions for how
much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute
because it may damage your vehicle’s paint.
Do not use your parking brake when there is a possibility
it could freeze.
When parking, put the transmission into “P” and block the front
wheels. Do not use the parking brake, or snow or water
accumulated in and around the parking brake mechanism may
freeze the parking brake, making it hard to release.
Keep ice and snow from accumulating under the fenders.
Ice and snow built up under your fenders can make steering
difficult. During bad winter driving, stop and check under the
fenders occasionally.

DRIVING TIPS
355

Crosswinds and rough roads will adversely affect handling
of your vehicle and trailer, causing sway. Pay attention to
the rear from time to time to prepare yourself for being
passed by large trucks or buses, which may cause your
vehicle and trailer to sway. If swaying happens, firmly grip
the steering wheel and reduce speed immediately but
gradually. Never increase speed. If it is necessary to
reduce speed, brake slowly. Steer straight ahead. If you
make no extreme correction with the steering or brakes,
your vehicle and trailer will stabilize.
 Be careful when passing other vehicles. Passing requires
considerable distance. After passing a vehicle, do not forget
the length of your trailer and be sure you have plenty of room
before changing lanes.
 In order to maintain efficient engine braking and electrical
charging performance, do not use overdrive. Transmission
must be “4” position.
 Because of the added load of the trailer, your vehicle’s
engine may overheat on hot days (at temperatures over
30C [85 F]) when going up a long or steep grade with a
trailer. If the engine coolant temperature gauge indicates
overheating, immediately turn off the air conditioning (if in
use), pull your vehicle off the road and stop in a safe spot.
See “If your vehicle overheats” on page 363.
Always pl ace wheel blocks under both the vehicle and trailer
wheels when parking. Apply the parking brake firmly. Put
the transmission in “P”. Avoid parking on a slope with a
trailer, but if it cannot be avoided, do so only after performing
the following:
1. Apply the brakes and keep them applied.
2. Have someone place wheel blocks under both the vehicle
and trailer wheels.
3. When the wheel blocks are in place, release your brakes
slowly until the blocks absorb the load.
4. Apply the parking brake firmly.
5. Shift into “P” and turn off the engine.

IN CASE OF AN EMERGENCY
363
IF YOU CANNOT INCREASE THEENGINE SPEED
If the engine speed does not increase with the accelerator
pedal depressed down, there may be a problem somewhere
in your electronic throttle control system.
At this time, vibration may occur. However, if you depress the
accelerator pedal more firmly and slowly, you can drive your
vehicle at low speeds. Have your vehicle checked by your
Lexus dealer as soon as possible.
Even if the abnormality of the electronic throttle control system
is corrected during low speed driving, the system may not be
recovered until the engine is stopped and the ignition key is
turned to “ACC” or “LOCK” position.
CAUTION
Be especially careful to prevent erroneous pedal
operation.
IF YOUR VEHICLE OVERHEATS
If your engine coolant temperature gauge indicates
overheating, if you experience a loss of power, or if you
hear a loud knocking or pinging noise, the engine has
probably overheated.
When the engine overheats
Pull safely off the road, stop the vehicle and turn on your
emergency flashers. Put the transmission in “P” and apply the
parking brake.
A: If steam is coming from your engine:
Turn off the engine. Leave the hood closed until there is no sign
of steam or coolant. Your engine could have been seriously
damaged already. Call your Lexus dealer for assistance.
CAUTION
To help avoid personal injury, keep the hood closed until
there is no steam. Escaping steam or coolant is sign of
very high pressure.

IN CASE OF AN EMERGENCY
364B: If no steam is coming from your engine:
Leave the engine running and turn off the air conditioning.
Check the following.

Is the cooling fan operating?
 Is the coolant in the acceptable range?
 Is the engine drive belt O.K.?
CAUTION
When the engine is running, keep hands and clothing
away from the moving fan and engine drive belt.
 Do not attempt to remove the radiator cap when the
engine and radiator are hot. Serious injury could
result from scalding hot fluid and steam blown out
under pressure.
If the cooling fan is not operating or the coolant is not in the
acceptable range, turn off the engine and call your Lexus
dealer.
If both conditions are O.K., after the engine coolant
temperature has cooled to normal, continue driving your
vehicle.
If the engine coolant temperature does not cool down, or your
vehicle overheats again, have it checked as soon as possible
by your Lexus dealer.
IF YOU HAVE A FLAT TIRE
1. Reduce your speed gradually, keeping a straight line. Move
cautiously off the road to a safe place − well away from the
traffic. A void stopping on the center divider of a highway. Park
on a level spot with firm ground.
2. Stop the engine and turn on your emergency flashers.
3. Firmly set the parking brake and put the transmission in “P”.
4. Have everyone get out of the vehicle on the side away from
traffic.
5. Read the following instructions thoroughly.
CAUTION
When jacking, be sure to observe the following to
reduce the possibility of personal injury:
 Turn off the active height control suspension by
pushing the active height control switch.
 Follow jacking instructions.
 Do not put any part of your body under a vehicle
supported by a jack. Personal injury may occur.
 Do not start or run the engine while your vehicle is
supported by the jack.
 Stop the vehicle on a level firm ground, firmly set the
parking brake and put the transmission in “P”. Block
the wheel diagonally opposite to the one being
changed if necessary.

MAINTENANCE
399
Brake fluid level
Make sure the brake fluid level is correct. See page 430 for
additional information.
Engine oil level
Check the level on the dipstick with the engine turned off and
the vehicle parked on a level spot. See page 419 for
additional
information.
Power steering fluid level
Check the level through the reservoir. The level should be in
the “HOT” or “COLD” range depending on the fluid
temperature. See page 431 for additional information.
Exhaust system
If you notice any change in the sound of the exhaust or smell
exhaust fumes, have the cause located and corrected
immediately. (See “Engine exhaust caution” on page 298.)
DOES YOUR VEHICLE NEED REPAIRING?
Be on the alert for changes in performance and sounds, and
visual tip −offs that indicate service is needed. Some important
clues are:
 Engine missing, stumbling, or pinging
 Appreciable loss of power
 Strange engine noises
 A fluid leak under the vehicle (However, water dripping from
the air conditioning after use is normal.)
 Change in exhaust sound (This may indicate a dangerous
carbon monoxide leak. Drive with the windows open and
have the exhaust system checked immediately.)
 Flat−looking tires, excessive tire squeal when cornering,
uneven tire wear
 Vehicle pulls to one side when driving straight on a level
road
 Strange noises related to suspension movement
 Loss of brake effectiveness, spongy feeling brake pedal,
pedal almost touches floors, vehicle pulls to one side when
braking
 Engine coolant temperature continually higher than normal
