GAUGES, METERS AND SERVICE REMINDER INDICATORS
44IF THIS INDICATOR OR
BUZZER COMES ON ...
DO THIS.
(k)Stop and check.
(l)Stop and check.
(m)Replace engine oil.
(n)Fill up tank.
(o)Add washer fluid.
(p)Key reminder buzzerRemove key.
(a) Brake System Warning Light and Buzzer
This light comes on in the following cases when the ignition key
is in the “ON” position.
 When the parking brake is applied ...
This light comes on for a few seconds when the ignition key is
in the “ON” position even after the parking brake is released.
 When the brake fluid level is low ...
CAUTION
It is dangerous to continue driving normally when the
brake fluid level is low.
When the hydraulic brake booster fails ...
If the hydraulic booster causes a problem resulting in poor
braking performance, the warning light comes on and buzzer
sounds continuously.
Have your vehicle checked at your Lexus dealer in the
following cases:
 The light does not come on even if the parking brake is
applied when the ignition key is in the “ON” position.
 The light does not come on even if the ignition key is turned
on with the parking brake released.
A warning light turning on briefly during operation does not
indicate a problem.

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
50
(j) “VSC TRAC” Warning Light
The light warns that there is a problem somewhere in the
following.
Vehicle skid control system
 Active traction control system
 Downhill assist control system
 Hill− start assist control system
The light will come on when the ignition key turned to “ON”, and
will go off after a few seconds.
It is not a malfunction that the warning light may stay on for 60
seconds after the ignition key is turned to the “ON” position.
Depressing the brake pedal repeatedly may turn on the lights.
It is normal if they go out after a few seconds.
There is no problem when the “VSC TRAC” warning light
comes on when the brake actuator temperature becomes high.
If the light comes on while driving, the above mentioned
systems do not work. However, as conventional braking
operates when applied, there is no problem to continue your
driving.
In the following cases, contact your Lexus dealer:
 The warning light does not come on after the ignition key is
turned to “ON”.
 The warning light remains on after the ignition key is turned
to “ON”.
 The warning light comes on while driving.
(k) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn off the
engine, and check for the cause. Look first at the engine drive
belt.
 If it is loose or broken, the generator will not charge the
battery properly.
 If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however, until the
battery is discharged. Turn off the air conditioning, blower,
radio, etc., and drive directly to the nearest Lexus dealer or
repair shop.
NOTICE
Do not continue driving if the engine drive belt is broken
or loose.
(l) Low Engine Oil Pressure Warning Light
This light warns that the engine oil pressure is too low.
If it flickers or stays on while you are driving, pull off the road
to a safe place and stop the engine immediately. Call a Lexus
dealer or qualified repair shop for assistance.

Finish
GAUGES, METERS AND SERVICE REMINDER INDICATORS
51
The light may occasionally flicker when the engine is idling or
it may come on briefly after a hard stop. There is no cause for
concern if it then goes out when the engine is accelerated
slightly.
The light may come on when the oil level is extremely low. It
is not designed to indicate low oil level, and the oil level must
be checked using the oil level dipstick.
NOTICE
Do not drive the vehicle with the warning light on even
for one block. It may ruin the engine.
(m) Engine Oil Replacement Reminder Light
This light reminds you when to replace the engine oil.
This light will come on when the ignition key is turned to “ON”
and will go off after about a few seconds.
When you drive for about 8000 km (5000 miles) after the
engine oil replacement, this light illuminates for about 3
seconds and then flashes for about 12 seconds with the
ignition key turned to “ON” position. If you continue driving
without the engine oil replacement, and if the driving range
exceeds
12000 km (7500 miles), the light will come on after the
ignition key is turned to “ON” position. The light will remain on
thereafter.
If the light is flashing, we recommend that you replace the
engine oil at an early opportunity depending on the driving and
road condition. If the light comes on, replace it as soon as
possible. You need to reset the light after the engine oil replacement.
Reset the light by following the procedure below:
1. Turn the ignition key to the “OFF” position with the odometer
reading
shown. (For details, see “Odometer and trip meter” on
page 42.)
2. Turn the ignition key to the “ON” position while holding down
the trip meter reset knob.
Hold down the knob until the light goes off. Before the light
goes off, it illuminates for 3 seconds, flashes for 2 seconds and
illuminates for 1 second.
If the system fails to reset, the light will remain flashing. In this
case, return to step 1 and try again.
(n) Low Fuel Level Warning Light
This light comes on when the fuel level in the tank becomes
very low. Fill the tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the low fuel level warning light may come on earlier than usual.
(o) Low Washer Fluid Warning Light
This light comes on when the fluid level in the tank becomes
very low. Fill the tank as soon as possible.
(p) Key Reminder Buzzer
This buzzer reminds you to remove the key when you open the
driver’s door with the ignition key in the “ACC” or “LOCK”
position.

AUDIO
231
1. Pull the case out while pushing the lock release button to
the side.
2. Remove the discharged battery.
3. Put in a new battery with the positive (+) side up.Put in the case securely.
NOTICE
Make sure that the positive side of the controller
battery is facing correctly.
 Do not replace the battery with wet hands. Water may
cause rust.
 Do not touch or move any components inside of the
controller, or it may interfere with proper operation.
 Be careful not to bend the electrode of the controller
battery insertion and that dust or oil does not adhere
to the transmitter case.
 Close the battery case securely.
After replacing the battery, check that the controller operates
properly. If the controller still does not operate properly , contact
your Lexus dealer.

AUDIO
247
1. Pull the case out while pushing the lock release button to
the side.
2. Remove the discharged battery.
3. Put in a new battery with the positive (+) side up.Put it in the case securely.
NOTICE
Be sure that the positive side of the controller battery
is facing correctly.
 Do not replace the battery with wet hands. Water may
cause rust.
 Do not touch or move any components inside of the
controller, or it may interfere with proper operation.
 Be careful not to bend the electrode of the controller
battery insertion and that dust or oil does not adhere
to the transmitter case.
 Close the battery case securely.
After replacing the battery, check that the controller operates
properly. If the controller still does not operate properly , contact
your Lexus dealer.

AUDIO
249
4. Insert a disc with the label side backward and close the
lid.
The player is intended for the use with 12 cm (4.7 in.) discs only.
If the label faces down, the disc cannot be played. In this case,
“DISC CHECK” appears on the screen.
If a disc which is not playable is inserted, “DISC CHECK” will
also appear on the screen. For appropriate discs for this
player, see “Car audio/video system operating hints” on page
289.The indicator light turns on while the disc is loaded.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop, always keep the console box closed
while driving.
NOTICE
Never try to disassemble or oil any part of the DVD
player. Do not insert anything other than a disc into the
slot.
5. Close the cover and console box.

DRIVING TIPS
343
CAUTION
Always observe the following precautions to minimize
the risk of serious personal injury or damage to your
vehicle:
Drive carefully when off the road. Do not take
unnecessary risks by driving in dangerous places.
 Do not grip the steering wheel spokes when driving
offroad. A bad bump could jerk the wheel and injure
your hands. Keep both hands and especially your
thumbs on the outside of the rim.
 Always check your brakes for effectiveness
immediately after driving in sand, mud, water or
snow.
 After driving through tall grass, mud, rock, sand,
rivers, etc., check that there is no grass, bush, paper,
rags, stone, sand, etc. adhering or trapped on the
underbody. Clear off any such matter from the
underbody. If the vehicle is used with these materials
trapped or adhering to the underbody, a breakdown
or fire could occur.
 In a rollover crash, an unbelted person is
significantly more likely to die than a person wearing
a seat belt. Therefore, the driver and all passengers
should fasten their seat belts whenever the vehicle is
moving.
 When driving offroad or in rugged terrain, do not
drive at excessive speeds, jump, make sharp turns,
strike objects, etc. This may cause loss of control or
vehicle rollover causing death or serious injury. You
are also risking expensive damage to your vehicle’s
suspension and chassis.
NOTICE
 If driving through water, such as when crossing
shallow streams, first check the depth of the water
and the bottom of the river bed for firmness. Drive
slowly and avoid deep water.
 Take all necessary safety measures to ensure that
water damage to the engine or other components
does not occur.
Water entering the engine air intake will cause severe
engine damage.
Water can wash the grease from wheel bearings,
causing rusting and premature failure, and may also
enter the differentials, transmission and transfer
case, reducing the gear oil’s lubricating qualities.
 Sand and mud that has accumulated in brake drums
and around brake discs may affect braking ef ficiency
and may damage brake system components.

DRIVING TIPS
344
Always perform a maintenance inspection after each
day of offroad driving that has taken you through
rough terrain, sand, mud, or water. For scheduled
maintenance information, refer to the “Owner’s
Manual Supplement / Scheduled Maintenance”.
WINTER DRIVING TIPS
Make sure your coolant is properly protected against
freezing.
Your coolant must contain ethylene −glycol type coolant for a
proper corrosion protection of aluminum components. Use
“Toyota Genuine Long Life Coolant” or equivalent. See
“Checking the engine coolant level” on page 422 for
instructions.
NOTICE
Do not use alcohol type antifreeze or plain water alone.
When it is extremely cold, we recommend to use 60% solution
for your Lexus, to provide protection down to about −50C
(−58 F). Do not use more than 70% solution for better coolant
performance.
Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so it
must be in top shape to provide enough power for winter
starting. Page 447 tells you how to visually inspect the battery.
Your Lexus dealer and most service stations will be pleased to
check the battery charge level.
Make sure the engine oil viscosity is suitable for the cold
weather.
See page 420 for recommended viscosity. Leaving a heavy
summer oil in your vehicle during winter months may cause
harder starting. If you are not sure about which oil to use, call
your Lexus dealer − they will be pleased to help.

IN CASE OF AN EMERGENCY
381
Emergency towing hook precautions:

Before emergency towing, check that the eyelet is not
broken or damaged and that the installation bolts are not
loose.
 Fasten the towing cable or chain securely to the hook.
 Do not jerk the eyelet. Apply steady and even force.
 To avoid damaging the eyelet, do not pull from the side or at
a vertical angle. Always pull straight ahead.
CAUTION
If the emergency towing eyelet is used to get out when
your vehicle becomes stuck in the mud, sand or other
condition from which the vehicle cannot be driven out
under its own power, make sure to observe the
precautions mentioned below. Otherwise, excessive
stress will be put on the eyelet and the towing cable or
chain may break, causing serious injury or damage.
If the towing vehicle can hardly move, do not forcibly
continue the towing. Contact your Lexus dealer or a
commercial tow truck service for assistance.
 Tow the vehicle as straight ahead as possible.
 Keep away from the vehicle during towing.
Tips for towing a stuck vehicle:
The following methods are effective to use when your
vehicle is stuck in the mud, sand or other condition from
which the vehicle cannot be driven out under its own
power. Use extreme caution when towing the vehicle. In
addition, keep away from the vehicles and towing cable or
chain when towing.
 Remove the sand and soil in the front and the back of the
tires.
 Place stones or wood under the tires.

MAINTENANCE
397
Tire rotation
Rotate the
tires according to the maintenance schedule. (For
scheduled maintenance information, please refer to the
“Owner’s Manual Supplement / Scheduled Maintenance”.)
See page 434 for additional information.
Fluid leaks
Check underneath for leaking fuel, oil, water or other fluid after
the vehicle has been parked for a while. If you smell fuel fumes
or notice any leak, have the cause found and corrected
immediately.
Doors and engine hood
Check that all side doors and back door, operate smoothly and
all latches lock securely. Make sure the engine hood
secondary latch secures the hood when the primary latch is
released.
Vehicle interior
Items listed below should be checked regularly, e.g. while
performing periodic services, cleaning the vehicle, etc.
Lights
Make sure the headlights, stop lights, tail lights, turn signal
lights, and other lights are working. Check headlight aim.
Service reminder indicators and warning buzzers
Check that all service reminder indicators and warning buzzers
function properly. Steering wheel
Check that it has the
specified free play. Be alert for changes
in steering condition, such as hard steering, excessive free
play or strange noise.
Seats
Check that all front seat controls such as seat adjusters,
seatback recliner, etc. operate smoothly. Check that the head
restraints move up and down smoothly and that the locks hold
securely in any latched position. For folding −up second and
third seats, and detachable third seat, check that the latches
lock securely.
Seat belts
Check that the seat belt system such as buckles, retractors
and anchors operate properly and smoothly. Make sure the
belt webbing is not cut, frayed, worn or damaged.
Accelerator pedal
Check the pedal for smooth operation and uneven pedal ef fort
or catching.
Brake pedal
Check the pedal for smooth operation and the proper
clearance and free play. Check the brake booster function.
Brakes
At a safe place, check that the brakes do not pull to one side
when applied.
