INTERIOR EQUIPMENT
78
CAUTION
Make sure the floor mat is properly placed on the floor
carpet. If the floor mat slips and interferes with the
movement of the pedals during driving, it may cause an
accident.
WARNING REFLECTOR HOLDER
 1 To disengage 2 To engage
This belt is designed to hold the warning reflector. To
disengage or engage the belt, do as shown above.
Although the warning reflector itself is not included as original
equipment, this auxiliary box can be used to store the warning
reflector.
Make sure the warning reflector is securely held.

Finish
INTERIOR EQUIPMENT
79
COAT HOOKS
To use the coat hook, push the hook.
CAUTION
Do not hook a hanger, heavy or sharp pointed object on
the coat hook. If the curtain shield airbag inflates, those
items will be hurled away with great force or the curtain
shield airbag may not activate correctly. When you
hang clothes, hang them on the coat hook directly.
LUGGAGE COVER
Using luggage cover
To use the luggage cover, pull out the luggage cover and
hook it on the anchors.
CAUTION
Do not place anything on the luggage cover . Such items
may be thrown about and possibly injury people in the
vehicle during sudden braking or an accident.

Finish
INTERIOR EQUIPMENT
80
Removing luggage cover
To remove the luggage cover, retract and release the both
ends, and lift it out.
After remove the luggage cover, place it somewhere other than
the passenger compartment. This will prevent passengers
from injury in the event of a sudden stop or accident.
When installing the luggage cover, keep the “TOP” mark
of the luggage cover ends upward.
TIEDOWN HOOKS
To secure your luggage, use the tiedown hooks as shown
above.
See “Luggage stowage precautions” on page 81 for
precautions when loading luggage.
NOTICE
Do not use the third seat anchors instead of the
tiedown hooks.

Finish
INTERIOR EQUIPMENT
81
LUGGAGE STOWAGEPRECAUTIONS
When stowing luggage or cargo in or on the vehicle,
observe the following:
Put luggage or cargo in the luggage compartment when at
all possible. Be sure all items are secured in place.
 Be careful to keep the vehicle level. Placing the weight as
far forward as possible helps maintain vehicle balance.
 For better fuel economy, do not carry unnecessary weight.
CAUTION
To prevent luggage or packages from sliding forward
during braking, do not stack anything in the luggage
compartment higher than the seatbacks. Keep
luggage or packages low, as close to the floor as
possible.
 Never allow anyone to ride in the luggage
compartment. It is not designed for passengers.
They should ride in their seats with their seat belts
properly fastened. Otherwise, they are much more
likely to suffer serious bodily injury, in the event of
sudden braking or a collision.
Do not place anything on the luggage cover. Such
items may be thrown about and possibly injury
people in the vehicle during sudden braking or an
accident.
 Do not drive with objects left on top of the instrument
panel. They may interfere with the driver’s field of
view. Or they may move during sharp vehicle
acceleration or turning, and impair the driver’s
control of the vehicle. In an accident they may injure
the vehicle occupants.
NOTICE
Do not load the vehicle beyond the vehicle capacity
weight specified on the tire pressure label.

SECTION 1 – 5
82
INSTRUMENTS AND CONTROLS
Exterior equipment
Hood83
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . .
Fuel tank cap 84
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
Moon roof 86
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
Quarter windows 89
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Roof luggage carrier 90
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Rear step bumper 92
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .

EXTERIOR EQUIPMENT
83
HOOD
1. To open the hood, pull the hood lock release lever under
the instrument panel. The hood will spring up slightly.
2. Insert your fingers under the hood, push up the
auxiliary catch lever and lift the hood.
Before closing the hood, check to see that you have not
forgotten any tools, rags, etc. Then lower the hood and make
sure it locks.
CAUTION
Before driving, be sure that the hood is closed and
securely locked. Otherwise, the hood may open
unexpectedly while driving and an accident may occur.

EXTERIOR EQUIPMENT
84
FUEL TANK CAP
This indicates that the fuel filler door is on the left side of
your vehicle.
1. To open the fuel filler door, pull the lever under the
instrument panel.
When refueling, turn off the engine.
CAUTION
Do not smoke, cause sparks or allow open flames
when refuelling. The fumes are flammable.
 When opening the cap, do not remove the cap
quickly. In hot weather, fuel under pressure could
cause injury by spraying out of the filler neck if the
cap is suddenly removed.

EXTERIOR EQUIPMENT
85
2. To remove the fuel tank cap, turn the cap
counterclockwise by 90 degrees (to the pressure point
1
), and then turn it an additional 30 degrees (to
point 2
). Pause slightly before removing it.
Although a click will be heard as you turn the cap to point
1
,
it does not indicate that the cap can be removed.
It is not unusual to hear a slight swoosh when the cap is
opened.
15PY017
3. The removed cap can be stored on the back side of the
fuel filler door.
Position the cap so that the hooks point to the left and right or
up and down, and set it in the receptacle on the back side of
the door.

EXTERIOR EQUIPMENT
86When installing the cap, turn the cap clockwise until you
hear one click. When you hear the click, the cap is fully
closed.
CAUTION

Make sure the cap is installed securely to prevent fuel
spillage in case of an accident.
 Use only a genuine Lexus fuel tank cap for
replacement. It is designed to regulate fuel tank
pressure.
NOTICE
Observe the following precautions. Otherwise, the cap
could be damaged or become hard to open.
Apply force only in the turning direction to the cap.
Do not pull or pry it.
 Do not tighten the cap further after you hear one click
when installing.
MOON ROOF
 1 Open2 Close
To slide open the moon roof, push the switch on the
“SLIDE OPEN” side for about 1 second. The moon roof
will fully open. To stop partway, push the same side or
“TILT UP” side briefly.
The sunshade can be opened or closed manually. However,
if you open the moon roof, the sunshade will be opened with
the moon roof.
When the moon roof is fully opened, the wind deflector raises
to reduce the entering of the strong wind. The angle of the
deflector is changed according to the vehicle speed.
To close the moon roof, push the switch on the “TILT UP”
side for about 1 second. The moon roof will fully close.
To stop partway, push the same side or “SLIDE OPEN”
side briefly.

EXTERIOR EQUIPMENT
87
To slide open the tiltedup moon roof:
Push the switch on the “SLIDE OPEN” side to tilt down the
moon roof. After releasing the switch, push the switch on the
same side again.

1 Tilt down2 Tilt up
To tilt up the moon roof, push the switch on the “TILT UP”
side for about 1 second. The moon roof will fully tilt up.
To stop partway, push the same side or “SLIDE OPEN”
side briefly.
To tilt down the moon roof, push the switch on the “SLIDE
OPEN” side for about 1 second. The moon roof will fully
tilt down. To stop partway, push the same side or “TILT
UP” side briefly.
To operate the moon roof, the ignition key must be in the “ON”
position. Key off operation:
Even if the ignition key is turned to the
“ACC” or “LOCK” position, the moon roof can be operated until
a front door is opened (or for 43 seconds).
To tilt up the slideopened moon roof:
Push the switch on the “TILT UP” side to close the moon roof
fully. After releasing the switch, push the switch on the same
side again.
Operating the moon roof from outside the
vehicle
The moon roof can be operated using an ignition key.*
NOTE:
*This feature can be deactivate.
Ask your Lexus dealer for details.
 Close  Open
Insert the ignition key into the key hole on the driver’s
door.
